Page 1
ITEM #: QTY:
MODEL #:
PROJECT NAME:
021218
3601 S. Banker St. Effingham, IL 62401 • P.O. BOX 609 • Ph: (888) 431-2667 • Fax: (800) 433-2667
"RN-LB" LE BLOC
FEATURES:
• CHERRY END GRAIN TOP
• FACE AND SIDES STANDARD BOOS BLOCK CREAM
FINISH WITH BEESWAX
• L-4 LEGS (PENCIL) STANDARD
• SHIPPED IN 1 CARTON: RN-LB1818, RN-LB2418,
RN-LB2424
• SHIPPED IN 2 CARTONS: RN-LB3024, RN-LB3030
• RN-LB1818 UPSABLE
• OPTIONS: 3" BLACK LOCKING CASTER: CAS-RN
CAS-RN
LE BLO C
MODEL # QTY
RN-LB1818
RN - LB 2418
RN- LB2424
RN- LB30 24
RN-LB3030
RN - LB 2418
184
Page 2
DETAILED SPECIFICATIONS
LE BLO C
MODEL # SIZE HEIGHT WEIGHT (LBS)
RN-LB1818 18" X 18" X 10" 34" 78
RN - LB 2418 24" X 18" X 10" 34" 104
RN- LB2424 24" X 24" X 10" 34" 138
RN- LB30 24 30" X 24" X 10" 34" 173
RN-LB3030 30" X 30" X 10" 34" 216
SOME UNITS SHIP UN ASSEMBLED FOR REDUCED SHIPPING COST. ALL DIMENSIONS ARE T YPICAL . TOLERA NCE +/- .50 0"
John Boos & Co. is constantly engaged in a program of improving products and therefore reserves the right to change specications without prior notice.
3601 S. Banker St. • Effingham, IL 62401 • PO BOX 609 • [email protected]
www.johnboos.com
021218
185
