JOEMEEK VC7

The VC7 embodies the best of transformer mic pre amplifier

design, along with a unique and useful impedance matching feature

JOEMEEK

The VC7

The JOEMEEK VC7 offers two high performance,
transformer coupled mic pre amplifiers in a
single unit, with additional features not found
on other units. As well as phase reverse, input
and output gain, and a switchable Sallen and Key
high pass filter, the VC7 offers a unique
microphone impedance matching facility that
allows the engineer to 'tune' a microphone to
maximise performance or suit a situation.

The VC7 principle

It's JOEMEEK Company theory that 'big' sounds
are only possible if the recording process keeps
the response and phase of the lower frequencies
flat and under control. The JOEMEEK VC7
achieves this by maintaining an extended
frequency range down below 8Hz (when the
filter is selected to 'flat'). This ensures that there
are no sudden phase shifts in the low end. The
proof of the theory is that the sound from the
VC7 is characteristically full bodied and
rounded in character. Such extreme LF
response can often bring its own problems so a
precision high pass filter with a suitable range of
frequencies is fitted per channel.

Dual transformer coupled

'Superbal'

Robust 48V phantom power

Additional balanced M&S encoded outputs

Unique mic impedance matching

Sallen and key high pass filter

Phase reverse switch

mic pre amplifiers for

supreme sound quality and depth

balanced XLR line outputs

on appropriate

impedance settings

for

monitoring M&S recordings, or decoding/encoding

feature per

channel, allows the user to optimise the sound from

any microphone

Selectable at

25,50,75,100Hz, , indicator, and

overload indicator per channel

- dual channel impedance matching mic pre amplifier

Special Features

The feature that really sets the VC7 apart from
other custom pre amplifiers is the mic
impedance matching facility that can be used as
a precision trim, or an artistic effect. The VC7
offers the following options:

source impedances from 250

ohms up to 600 ohms.

The VC7 also comes equipped with M&S
outputs that may be used to convert a Left/Right
signal into middle and side, or, when using an
M&S microphone, the VC7 will enable you to
monitor in L/R while recording in M&S.

VC7 History

The JOEMEEK VC7 is a development of historic
tried and tested circuits and designs from the
1960's to the present day, combined in a dual
channel outboard rack unit. It gives accurate
matching of microphone to amplifier that is not
possible with other microphone amplifiers.
This is in addition to its most important feature,
a characteristically warm yet open sound, that
can be tuned to match any microphone. In
short the VC7 represents the best design
features of any mic pre amplifier, as well as some
extended useful features that are unique to this
model.

· '50ohm'

· '200 ohm'

· 'LOW Ph'

· ’200Ph'

· '600Ph'

Classic microphones with 50

ohm impedance;

Use this position for all
conventional 200 ohm microphones
which do not require phantom power.

This setting is designed
specifically for modern capacitor
microphones with solid state head
amplifiers.

Setting for most phantom

powered capacitor microphones.

Is for other capacitor microphones

which have

"Anyone not able to try this unit would be at a

loss, there are no gimmicks here, just quality

and flexibility at a good price.

Paul White, Sound on Sound
