Overview

Features

XLR Mic Input

Mic Mute switch

3.5 Mm Stereo Line Input and Output

¼" Stereo Headphone Jack

3-Conductor 2.5mm Headset Interface
(Most Legacy Phones)

RemoteMix One Field Interview Tool Overview

iv

4-Conductor 3.5mm Headset Interface
(iPhone, most Android Phones &
Notebooks)

>20 Hours on one 9 Volt Alkaline Battery

Introducing the RemoteMix One

JK Audio combines professional audio electronics with a exible communications

interface in a rugged new belt pack design. RemoteMix One™ offers a

professional look and feel to eld reporters and live remote talent.

RemoteMix One™ performs live man-on-the-street interviews through your
cell phone and can provide two-way IFB connections through a cell phone or

notebook for truly exible remote monitoring.

Connect to cell phones and notebooks through the wired headset jack. This

professional microphone preamp and powerful headphone amplier provide

a vast improvement in sound quality. A 3.5 mm stereo line input jack allows
recordings to be mixed into the broadcast. The 3.5 mm stereo line output jack
provides your full bandwidth microphone signal on the left channel and the return
audio on the right channel.

The stereo headphone output gives you a mix of the XLR microphone input,

3.5 mm input, and return audio. This powerful ½ watt stereo headphone amplier

will cut through any crowd noise.

Use as a headset replacement for normal voice calls, or transmit full bandwidth
audio using third party CODEC apps. Replaceable interface cables connect to
most phones and notebooks.

1

Controls & Indicators Controls & Indicators

1 2 3 4 5

3) Aux Send Control

Adjusts the level of audio from the

3.5 mm Aux Send input jack.

4) Headphones Control

Sets the level of audio sent to the
headphone output jack.

5) Power Indicator

Indicates when the power is turned on.

76

1) Mic Control

Controls the level of your microphone
input.

RemoteMix One Field Interview Tool Controls & Indicators

2

2) Peak Indicator

The peak LED indicates clipping on
the input channel if the level is set
too high. The microphone and Aux
Send are a combined input. If you

see this red LED ashing, you should

decrease the Mic and/or Aux Send
input levels.

6) Mic Mute Button

Mutes the Mic input.

7) Power Button

Press to activate the unit. Press again
to turn the unit off.

Signal Level Pots

To Phone From Phone

There are two signal level pots on
the left side of the RemoteMix One

that can be adjusted with a small at

blade screwdriver. The left pot is to
adjust signal level to the phone. The
right pot is signal level from phone.
These allow a user to compensate for
differences between phones so that
the numbers on the thumb wheels
have a true meaning.

3

Getting Connected Getting Connected

3

4 5

1 2

1) Headset Interface

Connect the Headset Interface to the
headset jack on your wireless phone
using the supplied cable.

RemoteMix One Field Interview Tool Getting Connected

4

2) Headphones

Connect your headphones to this 1/4”
jack. The 1 watt stereo headphone
output gives you a mix of the XLR mic
input, 3.5 mm Aux Send input and the
Headset Interface audio.

3) Stereo Line Level Output

The unbalanced 3.5 mm stereo xed

line level output jack provides your full
bandwidth microphone signal on the
left channel and the Headset Interface
audio on the right channel.

This stereo output jack allows you to
make a full bandwidth recording using
your favorite recorder for transfer back
at the station or over the web.

4) Stereo Line Level Aux In

Connect the output of your other audio
equipment to this unbalanced stereo

3.5mm Aux In jack. This enables you
to add background music or sound
clips to your remote broadcast.
This audio is not present at the
Stereo Output but will be sent to the
Headphone jack.

5) Mic Input

Connect your dynamic microphone
to the XLR jack. This device will
not provide phantom power for a
condenser type microphone.

You can use both the balanced
XLR and unbalanced 3.5 mm inputs
simultaneously. The line level Aux In
jack allows recordings to be mixed into
the broadcast with your microphone
to be sent out through the Headset
Interface.

5

FAQs FAQs

How long will the battery last?

Based on our tests using a standard
alkaline battery, the battery should
last for >20 hours under normal use.

Lithium batteries can signicantly

increase the battery life, but at a
higher cost. As an indicator of low
battery, the red power LED will grow
dim and then extinguish a short
while before the battery is completely
exhausted and the unit shuts down.

RemoteMix One Field Interview Tool FAQs

6

If I have an audio source
connected to the Aux In jack, will
that audio also be present at the
Output mini jack?

No, the stereo mini jack output only
contains audio from the Mic input
and the Headset Interface. This
input would be a good place to add
background music or sound clips
during a live interview that is being
sent to your broadcast studio via the
Headset Interface.

Can I send and receive audio at
the same time?

Yes you can! You can have full duplex
conversations with your microphone
sent to the Left channel of the stereo
line output and the Headset Interface
audio sent to the Right channel.

Why is the peak LED still red
after I turned down the mic
volume level?

The microphone and Aux Send are
a combined input. If you see this red

LED ashing, you should decrease

the Mic and/or Aux Send input levels
until the combined input is no longer
clipping.

7

Technical Information

Specications

Input Impedence / Level

Female XLR Mics 2k ohms / -35 dBu nom

1/8” (3.5mm) Stereo Line 20k ohms / -10 dBm nom

Block Diagram

3.5 mm

Line output

Output

1/8” (3.5mm) Stereo 100 ohms / -10 dBu nom

Headphone 1/4” Stereo 8 ohms / ½ watt per channel

Power 9 VDC Battery

Size 4.7” x 3.75” x 1.65” (12 x 9.5 x 4.2 cm)

Weight 10 ounces (275 grams)

RemoteMix One Field Interview Tool Block Diagram

8

Mic

Input

3.5 mm line input

Headset
Interface

Headset Jack

Headphone

9
