JJPlus JA736101 User Manual
W23-JA736101 Mini PCI User’s Manual
1. Product Overview
The W23-JA736101 series PCI adapter cards contain an Atheros AR9220
chip for IEEE 802.11b/g/n Wireless LAN applications. The mini PCI adapter
cards support key security features like Wi-Fi Protected Access (WPA),
WPA2, WEP and 802.1x.
2. Packaging Contents
The mini PCI card package contains the following item(s):
1 x Wireless Mini PCI Adapter
3. Installation guide
Shut down the power of the platform
Align the PCI adapter with the Mini PCI socket on the platform
Adjust and push down the PCI adapter gently until the metal locking
levers on the Mini PCI socket is latched. (Please take note that the PCI
adapter can only fit in one direction due to the keyed notch. Wrong
orientation will cause improper installation and may damage the Mini
PCI socket)
Connect the antenna(s) on the mini PCI module
Reboot on the platform
Install drivers if necessary
4. Frequency
802.11b/g/n: 2412 ~ 2472 MHz
5. FCC Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
JJPlusCorp.
11F., No.788, Zhongzheng Rd., Zhonghe Dist., New Taipei City 235, Taiwan
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
6. FCC Caution
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
For product available in the USA/Canada market, only channel 1~11 can be
operated. Selection of other channels is not possible.
This device and its antenna(s) must not be co-located or operation in
conjunction with any other antenna or transmitter.
7. FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
8. Important Notes
This module is intended for OEM integrator. The OEM integrator is still
responsible for the FCC compliance requirement of the end product, which
integrates this module.
20cm minimum distance has to be able to be maintained between the
antenna and the users for the host this module is integrated into. Under such
configuration, the FCC radiation exposure limits set forth for a
population/uncontrolled environment can be satisfied.
Any changes or modifications not expressly approved by the manufacturer
could void the user's authority to operate this equipment.
