JJC WR-100 User Manual

JJC WR-100 WIRELESS CONTROLLER

Thank you for purchasing JJC WR-100 series wireless controller. For the best performance, please
read this instruction carefully before using.

Remove the remote control socket cap of the camera.
Take out the JJC WR-100 wireless controller receiver and plug it into the remote control socket of the
camera.

Slide the function button in the W Mode. The receiver is active. Under this condition, the receiver can
receive the signal from the transmitter; the receiver consumes the power of the battery. User can uses
the Shutter button of the transmitter and Focus button to control the Camera’s shutter and Focus.
Press the transmitter’s Shutter button to take a photo. Press the transmitter’s Focus button to focus.

Slide the function button in the O Mode. The receiver is turnoff. Under this condition, the transmitter
can not active the receiver to control the camera. The receiver will not consume any power of the
battery. User can use the shutter button of the receiver to take photos. Press the shutter button
halfway to focus. Press it fully to take a photo.

Slide the function button in the L Mode and turn on the camera to BULB mode. Under this condition,
the transmitter opens the lens; Slid the function button in the O Mode, the transmitter closes the lens.

1

When the camera is under no-Bulb mode and taking the photo, the transmitter will lock the shutter
button, and the camera will implement continues shooting. Under L mode, the transmitter can not
control the receiver.

Operating range

Maximum operating range 100m. (The operating range may be obstructions or interference with other
electronic equipment to reduce the distance)

Charging

The WR-100 inbuilt High Capacity Li-ion battery. Take out the power adapter, plug it into the power
socket of the transmitter and then plug the power adapter to the power outlet. When the transmitter is
under charging, the light of transmitter is on. There are 5 lights, each light represent 20% of battery
power. When all of the lights are on, which mean the battery is full, please take off the power
adapter.

WR-100A compatible with Canon

EOS 5D EOS 1D EOS 1D Mark II EOS 1Ds EOS 1Ds Mark II

EOS 1Ds Marks III EOS 20D EOS 10D EOS D60 EOS D30

EOS 30D EOS 5D EOS 1V EOS 3 EOS D2000

EOS 50D EOS 5D Mark II EOS 7D EOS 1D Mark IV

WR-100B compatible with Nikon/ Kodak/ Fuji

D2H D1x D1h D1

D2x *D100 D200 F5

Nikon

Kodak DCS-14n

Fuji Finepix S5pro Finepix S3pro

*D100 via Vertical Battery Pack

WR-100C compatible with Canon/ Pentax/ Contax/ Samsung

PENTAX

CONTAX

Samsung GX-1L, GX-1S GX-10 GX-20

CANON

D2Xs D700 D3x D300s

D3s

F6 F100 F90 F90x

K100D K110D K20D K200D

*ist D *ist Ds *ist K7
MZ-6 ZX-L MZ-L

N/645 645 N1 NX

N Digital

EOS 30 EOS 33 EOS 50E EOS 300

EOS 300V EOS 300D EOS 350D

EOS 3000

2
