Operating Instructions and Parts Manual
Dust Collector
Model: DC-650A/C/ARC/CRC
DC-650ARC shown DC-650C shown
WMH TOOL GROUP
2420 Vantage Drive
Elgin, Illinois 60123 Part No. M-708640
Ph.: 800-274-6848 Revision G1 12/04
www.wmhtoolgroup.com Copyright © WMH Tool Group
This manual has been prepared for the owner and operators of the JET DC-650 Series Dust Collectors. Its
purpose, aside from machine operation, is to promote safety using accepted operating and maintenance
procedures. To obtain maximum life and efficiency from your dust collector and to aid in using it safely, please
read this manual thoroughly and follow the instructions carefully.
Warranty and Service
WMH Tool Group warrants every product it sells. If one of our tools needs service or repair, one of our
Authorized Repair Stations located throughout the United States can provide quick service or information.
In most cases, a WMH Tool Group Repair Station can assist in authorizing repair work, obtaining parts, or
perform routine or major maintenance repair on your JET product.
For the name of an Authorized Repair Station in your area, please call 1-800-274-6848, or visit our web site at
www.wmhtoolgroup.com.
More Information
WMH Tool Group is consistently adding new products to the line. For complete, up-to-date product
information, check with your local WMH Tool Group distributor, or visit our web site at www.wmhtoolgroup.com
WMH Tool Group Warranty
WMH Tool Group makes every effort to assure that its products meet high quality and durability standards and
warrants to the original retail consumer/purchaser of our products that each product be free from defects in
materials and workmanship as follows: 1 YEAR LIMITED WARRANTY ON ALL PRODUCTS UNLESS
SPECIFIED OTHERWISE. This Warranty does not apply to defects due directly or indirectly to misuse, abuse,
negligence or accidents, normal wear-and-tear, repair or alterations outside our facilities, or to a lack of
maintenance.
WMH TOOL GROUP LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD SPECIFIED ABOVE,
BEGINNING FROM THE DATE THE PRODUCT WAS PURCHASED AT RETAIL. EXCEPT AS STATED
HEREIN, ANY IMPLIED WARRANTIES OR MERCHANTABILITY AND FITNESS ARE EXCLUDED. SOME
STATES DO NOT ALLOW LIMITATIONS ON HOW LONG THE IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATION MAY NOT APPLY TO YOU. IN NO EVENT SHALL WMH TOOL GROUP BE LIABLE
FOR DEATH, INJURIES TO PERSONS OR PROPERTY, OR FOR INCIDENTAL, CONTINGENT, SPECIAL,
OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR PRODUCTS. SOME STATES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
To take advantage of this warranty, the product or part must be returned for examination, postage prepaid, to
an Authorized Repair Station designated by our office. Proof of purchase date and an explanation of the
complaint must accompany the merchandise. If our inspection discloses a defect, we will either repair or
replace the product at our discretion, or refund the purchase price if we cannot readily and quickly provide a
repair or replacement. We will return the repaired product or replacement at WMH Tool Group’s expense, but
if it is determined there is no defect, or that the defect resulted from causes not within the scope of WMH Tool
Group’s warranty, then the user must bear the cost of storing and returning the product. This warranty gives
you specific legal rights; you may also have other rights, which vary from state to state.
WMH Tool Group sells through distributors only. Members of the WMH Tool Group reserve the right to effect at
any time, without prior notice, alterations to parts, fittings and accessory equipment, which they may deem
necessary for any reason whatsoever.
2
Table of Contents
Warranty and Service ...........................................................................................................................................2
Table of Contents.................................................................................................................................................. 3
Warnings ............................................................................................................................................................... 4
Introduction ...........................................................................................................................................................6
Specifications........................................................................................................................................................ 6
DC-650 Series Dust Collector ........................................................................................................................... 6
Unpacking ............................................................................................................................................................. 7
Contents of the Shipping Carton ....................................................................................................................... 7
Assembly...............................................................................................................................................................8
Motor Housing and Support Canister................................................................................................................8
Base Assembly.................................................................................................................................................. 8
Mounting the Support Canister to Base ............................................................................................................8
Filter Bag Installation – DC-650A/ARC ............................................................................................................. 9
Collector Bag Installation – DC-650A/ARC ....................................................................................................... 9
Canister Installation – DC-650C/CRC.............................................................................................................10
Collector Bag Installation – DC-650C/CRC.....................................................................................................10
Electrical Connections ........................................................................................................................................11
Turning the Machine On & Off ............................................................................................................................11
DC-650A and DC-650C...................................................................................................................................11
DC-650ARC and DC-650CRC ........................................................................................................................11
Setting the Timer ............................................................................................................................................. 11
Maintenance........................................................................................................................................................12
Cleaning the Filter Bag – DC-650A/ARC ........................................................................................................12
Removing the Collector Bag – DC-650A/ARC................................................................................................12
Cleaning the Filter – DC-650C/CRC ............................................................................................................... 12
Removing the Collector Bag – DC-650C/CRC ...............................................................................................12
Motor ............................................................................................................................................................... 12
Connecting the Dust Collector to a Machine...................................................................................................12
Grounding the Dust Collection System ........................................................................................................... 12
Parts....................................................................................................................................................................13
Replacement Parts..........................................................................................................................................13
Parts List .........................................................................................................................................................13
Parts Breakdown ............................................................................................................................................. 15
Remote Control Breakdown for DC-650ARC/CRC.........................................................................................16
Wiring Diagrams .................................................................................................................................................17
DC-650A/C Models .........................................................................................................................................17
DC-650ARC/CRC Models...............................................................................................................................18
3
Warnings
1. Read and understand the entire owners manual before attempting assembly or operation.
2. Read and understand the warnings posted on the machine and in this manual. Failure to comply with all of
these warnings may cause serious injury.
3. Replace the warning labels if they become obscured or removed.
4. This dust collector is designed and intended for use by properly trained and experienced personnel only. If
you are not familiar with the proper and safe operation of a dust collector, do not use until proper training
and knowledge have been obtained.
5. Do not use this dust collector for other than its intended use. If used for other purposes, WMH Tool Group
disclaims any real or implied warranty and holds itself harmless from any injury that may result from that
use.
6. Always wear approved safety glasses/face shields while using this dust collector. Everyday eyeglasses
only have impact resistant lenses; they are not safety glasses.
7. Before operating this dust collector, remove tie, rings, watches and other jewelry, and roll sleeves up past
the elbows. Remove all loose clothing and confine long hair. Non-slip footwear or anti-skid floor strips are
recommended. Do not wear gloves.
8. Wear ear protectors (plugs or muffs) during extended periods of operation.
9. Some dust created by power sanding, sawing, grinding, drilling and other construction activities contain
chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these
chemicals are:
• Lead from lead based paint.
• Crystalline silica from bricks, cement and other masonry products.
• Arsenic and chromium from chemically treated lumber.
Your risk of exposure varies, depending on how often you do this type of work. To reduce your exposure
to these chemicals, work in a well-ventilated area and work with approved safety equipment, such as face
or dust masks that are specifically designed to filter out microscopic particles.
10. Do not operate this machine while tired or under the influence of drugs, alcohol or any medication.
11. Make certain the switch is in the OFF position before connecting the machine to the power supply.
12. Make certain the machine is properly grounded.
13. Make all machine adjustments or maintenance with the machine unplugged from the power source.
14. Remove adjusting keys and wrenches. Form a habit of checking to see that keys and adjusting wrenches
are removed from the machine before turning it on.
15. Keep safety guards in place at all times when the machine is in use. If removed for maintenance purposes,
use extreme caution and replace the guards immediately.
16. Check damaged parts. Before further use of the machine, a guard or other part that is damaged should be
carefully checked to determine that it will operate properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts, breakage of parts, mounting and any other conditions
that may affect its operation. A guard or other part that is damaged should be properly repaired or
replaced.
17. Provide for adequate space surrounding work area and non-glare, overhead lighting.
18. Keep the floor around the machine clean and free of scrap material, oil and grease.
19. Keep visitors a safe distance from the work area. Keep children away.
4
blahblahblah
20. Make your workshop child proof with padlocks, master switches or by removing starter keys.
21. Give your work undivided attention. Looking around, carrying on a conversation and “horse-play” are
careless acts that can result in serious injury.
22. Do not use the dust collector for anything except wood dust. Materials such as liquids, metal shavings,
metal dust, screws, glass, plastic or rock can cause sparks and/or damage when coming into contact with
any part of the dust collector.
23. Use recommended accessories; improper accessories may be hazardous.
24. Maintain tools with care. Follow instructions for lubricating and changing accessories.
25. Turn off the machine before cleaning. Use a brush or compressed air to remove chips or debris — do not
use your hands.
26. Do not stand on the machine. Serious injury could occur if the machine tips over.
27. Never leave the machine running unattended. Turn the power off and do not leave the machine until it
comes to a complete stop.
28. Remove loose items and unnecessary work pieces from the area before starting the machine.
Familiarize yourself with the following safety notices used in this manual:
This means that if precautions are not heeded, it may result in minor injury and/or possible
machine damage.
This means that if precautions are not heeded, it may result in serious injury or possibly even
death.
- - SAVE THESE INSTRUCTIONS - -
5
Introduction
This manual is provided by JET covering the safe operation and maintenance procedures for models
DC-650 Series Dust Collectors. This manual contains instructions on installation, safety precautions, general
operating procedures, maintenance instructions and parts breakdown. This machine has been designed and
constructed to provide years of trouble free operation if used in accordance to instructions set forth in this
manual. If there are any questions or comments, please contact either your local supplier or WMH Tool Group.
Specifications
DC-650 Series Dust Collector
Model ...................................................................................DC-650A/ARC........................................ DC-650C/CRC
Stock Number ...............................................................708640/708640RC............................... 708640C/708641RC
Blower Wheel Diameter ........................................................................ 9.5” .......................................................... 9.5"
Sound Rating at 3 feet ................................................................. 65-70 dB ..................................................65-70 dB
Hose Diameter .........................................................................................4"............................................................. 4"
Bag Diameter .........................................................................................14”........................................................... 14"
Filter and Collector Bag Length .................................................31.5”/21.6”........................................................ 33.5”
Collector Bag Capacity (cu ft): ............................................................... 2.1 ........................................................... 2.1
Air Flow @ 4” (CFM):............................................................................ 650 .......................................................... 650
Max. Static Pressure (inch of water): ..................................................... 6.5 ........................................................... 6.5
Velocity @ 4” (FPM):.......................................................................... 6,300....................................................... 6,300
Overall Dimensions:...........................................................26.4”x14”x56.7”.............................26-1/2” x 14” x 61-1/2”
Motor (TEFC): ............................... 1 HP, 1Ph, 115V/230V, Prewired 115V......1 HP, 1Ph 115/230V, Prewired 115V
Net Weight (lbs): .....................................................................................69............................................................ 84
Gross weight (lbs): .................................................................................. 74............................................................ 87
The above specifications were current at the time this manual was published, but because of our policy of
continuous improvement, WMH Tool Group reserves the right to change specifications at any time and without
prior notice, without incurring obligations.
