JETKART PHANTOM
-MANUAL-
1
TABLE OF CONTENTS
A. Introduction 3
B. Included in the Box 4
C. Features and Specs 5
D. Assembly 5
E. Charging the Battery 7
F. Operating the Phantom 8
G. Care and Maintenance 10
H. Safety Warnings 12
I. Warranty 14
J. Product Registration 15
2
INTRODUCTION
Congratulations on your new Jetson JetKart Phantom! The Phantom
is an innovative and fun Jetkart, ready to take on everyday use. Before
your rst ride, check whether the wheels are damaged, or parts are
loose. If there are any abnormalities, please contact Customer Support
at 1-(888) 976-9904 or email us at customerservice@jetsonbike.com.
This product manual can help you understand, use, and maintain your
Phantom. In order to avoid danger caused by collisions, falls, and
loss of control, please use caution and learn how to ride the Phantom
safely. Jetson and authorized dealers cannot be held liable for injury or
damage caused from riding the Phantom. Users ride at their own risk.
The rider is responsible for consequences caused by violating warnings
or improper operations.
If you want to return this product for any reason, be sure to rst call or
email us before taking it back to the store so we can assist you.
3
INCLUDED IN THE BOX
1
1. Foot Rest
2. Foot Rest Tube
3. Frame Tube
4. Seat
2
3
7
8
6
5. Front Lights
6. Power Button
7. Knob
8. Front Wheel
3
2 4
5
4
1
5
1. Charging Port
2. Left Handlebar
4. Right Handlebar
5. Back Lights
3. Back Rest
4
FEATURES AND SPECS
MODEL: PHANTOM
WHEEL SIZE: 6.5”(REAR)
MAX SPEED: 9 MPH
MAX RANGE: 8 MILES
BATTERY TYPE: LITHIUM ION
BATTERY CAPACITY: 36V, 4.4Ah
MOTOR TYPE: HUB
CLIMBING ANGLE: 20°
MOTOR: 500w
CHARGER: 110-220V
CHARGE TIME: 2-3 HOURS
PRODUCT WEIGHT: 29 LBS
WEIGHT LIMIT: 220 LBS
RECOMMENDED AGE: 13+
ASSEMBLY
1. Slide the Frame Tube into the slot at the bottom of the Seat and
tighten the screws under the Seat using the provided Allen Key.
2. Slide the Foot Rest Tube into the Frame Tube and tighten the
Knob. Make sure the screws in the Foot Rest Tube are tight and
secure. Set the length to a comfortable distance, where your legs
are slightly bent.
Tighten
Screws
Tighten
Screws
Tighten
Knob
3. Insert the Back Rest into the slot at the back of the Seat. Tighten
two screws into the back of the Back Rest and two screws under
the Seat using the provided Allen Key.
5
