BLUETOOTH® CD PLAYER
WITH DIGITAL FM RADIO
Model: BWA17AA003
TM
PRODUCT GUIDE
Features and Controls
Features
• Bluetooth Wireless
• Wireless range: 60 ft.
• CD player: CD, CD-R/RW
• Programmable tracks
• AM/FM radio (DLL)
• Top-load disc player
• Analog volume control
• Built-in stereo speakers
• Negative LCD display with white backlight
• 3.5mm audio input
• AC power: built-in AC power cable
• DC battery power: requires 6 C batteries (not
included)
• Battery life: ~8 hours of audio
Repeat
Press to repeat the current
track. Press twice to repeat
the entire album.
CD/Line In/OFF/FM/Bluetooth
Switch between CD/Line In, OFF, FM radio and Bluetooth.
LCD Display
3.5mm Audio Line Input
CD Door (top)
Skip/Search
Press to skip between
tracks on a loaded CD.
Press and hold to search
through the current track.
Volume
Turn to adjust the volume.
POWER
PAIR
Stop
Press to stop a
CD during play.
Program
Press to program the
loaded CD to play tracks in
a specied order.
Power & Battery
Plug the power cord into a standard AC power outlet to power the unit. This unit requires 6 C-size, batteries (not included) for battery power.
Tuning
In radio mode, turn
to adjust the AM or
FM radio station.
Pair/Play/Pause
Press & Hold to begin
pairing a Bluetooth device.
Press to play or pause the
current track.
3.5 mm Audio inputRadioBluetooth Wireless
Pairing a Bluetooth Device
for the First Time
1. Press the Source button to switch to
Bluetooth Mode. The letters “bt”will ash on
the display.
2. When pairing, remain within 3 feet of the unit.
3. If the unit does not automatically begin to pair,
press and hold the Pair button.
4. Using the native controls on your Bluetooth
device, select the BWA17AA003 in your
Bluetooth settings to pair.
5. If your device requests a password, enter the
default password 0 0 0 0 .
6. Refer to the user’s manual for your specic
device for instructions on pairing and
connecting Bluetooth devices. When
successfully paired, the display will stop
ashing.
7. After initial pairing, the unit will stay paired
unless unpaired manually by the user or erased
due to a reset of the device.
8. If your device should become unpaired, follow
the above steps again.
9. If any pairing issues should occur, unpair the
unit on your Bluetooth device and follow the
above steps again.
Playing Audio Wirelessly
1. To select, play, pause or skip a track, use the
native controls on the connected Bluetooth
Device, or press the Pair/Play/Pause or Tun/
Skip/Search buttons.
2. Audio played through the connected
Bluetooth device will now be heard through
the speakers.
Radio Reception
An AM and FM antenna is built into the radio.
To improve radio reception, adjust the position
of the boombox.
Playing the Radio
1. Slide the Source Switch switch to AM or FM
radio mode.
2. Adjust the Tuning dial to tune the radio.
CD
Loading and Playing a CD
Note: This unit is not compatible with MP3 CDs.
1. Open the CD door and place a CD in the
boombox, label side facing up.
2. Close the CD door.
3. Adjust the Source Switch to CD mode.
4. Press the Play/Pause button to begin playing
the loaded disc.
Programming a CD
1. Press the Stop button to stop a loaded CD.
2. Press the Program button.
“01” will blink on the display.
3. Press the Skip/Search buttons to select a track.
4. Press the Program button to add the selected
track to the program.
5. Repeat steps 4 and 5 to program up to 20
tracks to play in a specied order.
6. Press the Stop button to cancel a program.
Using the Line In
3.5 mm audio input cable not included.
1. Plug one end of a 3.5 mm audio input cable
into the Line In input on the back of the unit,
and plug the other end of the cable into the
audio output/headphone jack on an MP3
Player or other audio source.
2. Turn ON the speaker using the Power button.
3. Turn ON the connected audio device using it’s
Power button.
4. Slide the Source Switch to Line In.
5. Select and begin playing audio on the
connected audio device. Audio played through
the connected device should now be heard
through the speakers.
Important Safety Instructions
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding - type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. When the provided plug does not t into
your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories specied by the manufacturer.
• Unplug this apparatus during lightning storms or when unused
for long periods of time.
• Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such as powersupply cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
• Minimum distances 5cm around the apparatus for sufcient ventilation;
The ventilation should not be impeded by covering the ventilation openings
with items, such as newspapers, table-cloths, curtains, etc.; No naked ame
sources, such as lighted candles, should be placed on the apparatus; The use of
apparatus in moderate climates.
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT, FULLY INSERT.
• Mains plug is used as disconnect device and it should remain readily operable
during intended use. In order to disconnect the apparatus from the mains
completely, the mains plug should be disconnected from the mains socket
outlet completely.
• WARNING: Shock hazard - Do Not Open.
• WARNING: To reduce the risk of re or electric shock, do not expose this
apparatus to rain, moisture, dripping, or splashing.
• Objects lled with liquids, such as vases, shall not be placed on the apparatus.
• CAUTION: Use of controls or adjustments or performance of procedures
other than those specied may result in hazardous radiation exposure.
• WARNING: Changes or modications to this unit not expressly approved by
the party responsible for compliance could void the user’s authority to operate
the equipment.
• WARNING: Do not place this unit directly onto furniture surfaces with any
type of soft, porous, or sensitive nish. As with any rubber compound made
with oils, the feet could cause marks or staining where the feet reside. We
recommend using a protective barrier such as a cloth or a piece of glass
between the unit and the surface to reduce the risk of damage and/or staining.
• CAUTION: Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.
• WARNING: There is a danger of explosion if you attempt to charge standard
Alkaline batteries in the unit. Only use rechargeable NiMH batteries.
• Battery shall not be exposed to excessive heat such as sunshine, re or the
like.
• Caution marking is located at the rear or bottom of the apparatus.
• The marking information is located at the rear or bottom of the apparatus.
• Keep new and used batteries away from children. If the battery compartment
does not close securely, stop using the product and keep it away from children.
• If you think batteries might have been swallowed or placed inside any part of
the body, seek immediate medical attention.
• Do not mix old and new batteries.
• Completely replace all old batteries with new ones.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh,
etc) batteries.
• Batteries should be recycled or disposed of per state and local guidelines.
• WARNING: This product may contain chemicals known to the State of
California to cause birth defects, or other reproductive harm (California Prop
65). Wash hands after handling.
• This product meets and complies with all Federal regulations.
FCC Notice:
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
WARNING: DO NOT INGEST BATTERY,
CHEMICAL BURN HAZARD.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
Warning: To reduce the risk of electric shock, do not remove
cover (or back). No user-serviceable parts inside. Refer
servicing to qualied service personnel.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
The lightning ash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufcient magnitude to
constitute a risk of electric shock to persons.
This symbol indicates that this product incorporates double
insulation between hazardous mains voltage and user
accessible parts.
This product utilizes a Class 1 laser to read Compact Discs.
This laser Compact Disc Player is equipped with safety
switches to avoid exposure when the CD door is open and
the safety interlocks are defeated. Invisible laser radiation is
present when the CD Player’s lid is open and the system’s
interlock has failed or been defeated. It is very important
that you avoid direct exposure to the laser beam at all times.
Please do not attempt to defeat or bypass the safety switches.
--- Reorient or relocate the receiving antenna.
--- Increase the separation between the equipment and receiver.
--- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
--- Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This equipment complied with FCC radiation exposure limits set forth for an uncontrolled environment.
The ETL logo & Laser making are placed inside battery compartment of the unit.
