Jetlun RD75613 Users Manual
User%Guide%
rev%1.0%
Jetlun%Appliance%Module%%
88%PARKGROVE%DRIVE%|%SO%SAN%FRANCISCO%|%CA%|%94080%|%USA%
T:%+1%866%498%2703%|%F:%+1%650%360%1977%
Jetlun Corporation
Jetlun Appliance Module User Guide rev 1.0 DRAFT
2
!
!
© 2009-10 Jetlun Corporation. All rights reserved.
Notice: No part of this publication may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying and recording, or stored in a database
or retrieval system for any purpose without the express written permission of Jetlun Corporation.
Jetlun Corporation reserves the right to make changes to this userʼs guide at any time without
notice and assumes no responsibility for its use. Jetlun products and services can only be
ordered under the terms and conditions of Jetlun Corporation's applicable agreements. All of the
features described in this userʼs guide may not be currently available. Refer to the most recent
product announcement for information about feature and product availability.
This userʼs guide contains the most current information available at the time of publication.
When new and/ or revised information becomes available, this entire userʼs guide is updated
and distributed to all registered users.
Trademarks, Product Names, and Service Names
Jetlun, the stylized J logo, and the Jetlun logo are either trademarks or registered trademarks of
Jetlun Corporation. All other product or service names are property of their respective owners.
http://www.jetlun.com
Jetlun Corporation
Jetlun Appliance Module User Guide rev 1.0 DRAFT
3
!
!
Table of Contents
1.0! ABOUT THIS GUIDE........................................................................................................... 5!
1.1! BECOMING FAMILIAR WITH THIS USER GUIDE....................................................................... 5!
1.1.1! Quick Reference ........................................................................................................ 5!
1.1.2! Icon Descriptions .......................................................................................................5!
1.2! GETTING ADDITIONAL HELP ................................................................................................5!
1.3! SENDING FEEDBACK REGARDING THIS DOCUMENTATION .....................................................5!
2.0 ! PRODUCT OVERVIEW...................................................................................................... 6!
2.1! PACKAGE CONTENTS .........................................................................................................6!
2.2! FRONT PANEL ....................................................................................................................6!
2.3 BOTTOM PANEL..................................................................................................................... 7!
3.0! INSTALLING THE JETLUN APPLIANCE MODULE.......................................................... 9!
3.1 ! CONNECTING THE JETLUN APPLIANCE MODULE TO YOUR ROUTER...................................... 9!
3.2! JOINING A ZIGBEE NETWORK ..............................................................................................9!
3.3 ! LEAVING A ZIGBEE NETWORK ............................................................................................ 9!
5.0! LEGAL AND REGULATORY NOTICES ........................................................................... 10!
5.1! IMPORTANT NOTE OF MODIFICATIONS............................................................................... 10!
5.2! NATIONAL AND REGIONAL REGULATORY NOTICES............................................................. 10!
5.2.1! U.S. Federal Communications Commission (FCC) Notifications............................. 10!
5.2.2 ! Declarations of Conformity .....................................................................................11!
5.3! USER INFORMATION FOR CONSUMER PRODUCTS COVERED BY EU DIRECTIVE 2002/96/EC
ON WASTE ELECTRIC AND ELECTRONIC EQUIPMENT (WEEE).....................................................13!
5.4! LEGAL NOTICES ...............................................................................................................19!
5.4.1! Software License Terms and Conditions ................................................................. 19!
5.4.2! Hardware Warranty in U.S....................................................................................... 22!
5.4.3! Limit of Liability ........................................................................................................ 22!
6.0 ! TECHNICAL SPECIFICATIONS ...................................................................................... 24!
List of Figures
Figure 1: Front Panel of the Appliance Module............................................................................. 6!
Figure 2: Bottom Panel of the Gateway ........................................................................................7!
List of Tables
Table 1: Where to find information in this User Guide .................................................................. 5!
Table 2: Icon descriptions............................................................................................................. 5!
Table 3: Front Panel LED Description .......................................................................................... 7!
Table 4: Back Panel of the Gateway Description.......................................................................... 8!
Jetlun Corporation
Jetlun Appliance Module User Guide rev 1.0 DRAFT
4
!
!
Jetlun Corporation
Jetlun Appliance Module User Guide rev 1.0 DRAFT
5
!
!
1.0 ABOUT THIS GUIDE
1.1 Becoming familiar with this User Guide
1.1.1 Quick Reference
The Jetlun Gateway (RD75613) User Guide describes the following:
Table 1: Where to find information in this User Guide
Planning and Installing the Jetlun Appliance Module
Chapter 2 and 3
Configuring and maintaining the Jetlun Appliance Module
Chapter 4 and 5
1.1.2 Icon Descriptions
While reading through the User Guide, you may see various icons that call attention to
specific items. Below is a description of these icons:
Table 2: Icon descriptions
NOTE: This mark indicates that there is a note of interest and is
something that you should pay attention to while using the
product.
IMPORTANT: This mark identifies an indication that you should
watch for, or reiterates something that you should always keep
in mind.
WARNING: This exclamation point indicates that there is a
caution or warning and may be something that could damage
your property or project.
1.2 Getting Additional Help
To get information or assistance for problems that you encounter, please contact Jetlun
Technical Support by emailing support@jetlun.com.
Please always include with all inquiries the following information:
• Product name, model number, part number (if applicable) and serial number
• A description of the system configuration
• The circumstances surrounding the error or failure
• A detailed description of the problem and what has been done to try to resolve it
1.3 Sending Feedback regarding this Documentation
We welcome your feedback on Jetlun Gateway documentation. This includes feedback on the
structure, content, accuracy, or completeness of our documents, and any other comments you
may have. Please send your comments to docs@jetlun.com.
Jetlun Corporation
Jetlun Appliance Module User Guide rev 1.0 DRAFT
6
!
!
2.0 PRODUCT OVERVIEW
Thank you for choosing the Jetlun Appliance Module (RD75613). The Appliance Module
is a 3-prong, ZigBee® and HomePlug® enabled electrical wall module that can be
plugged into a standard wall outlet to monitor the energy efficiency of any electrical
appliance or device and can be remotely controlled. When used in conjunction with the
Jetlun Gateway (RD75606), multiple outlets in the same home can be tracked
individually or as a group over the Internet giving you unprecedented insight into and
control over your household energy footprint.
With the Jetlun Appliance Module, you can:
• Measure and control the energy consumption of standard home electrical appliances
or devices
• Gain insight into and control over your household energy footprint, improving your
overall energy efficiency
2.1 Package Contents
When you first open the box, please check and confirm that the following items are all
included:
• 1x Appliance Module RD75613
• 1x Quick Installation Guide
If any of the parts are incorrect, missing or damaged, contact the retailer where you
made your purchase. Keep the carton, including the original packaging materials in case
you need to return the unit for repair.
2.2 Front Panel
Figure 1: Front Panel of the Appliance Module
Jetlun Corporation
Jetlun Appliance Module User Guide rev 1.0 DRAFT
7
!
!
Table 3: Front Panel LED Description
The Power LED lights up GREEN and will stay on while the
Appliance Module is powered on. When the Appliance Module
goes through its self-diagnostic mode during every boot-up, this
LED will flash GREEN. When the diagnostic cycle is complete,
the LED will be GREEN and solidly lit. When the Appliance
Module is operating on battery, the LED will flash RED. When the
Appliance Module is recharging the battery, the LED will flash
GREEN.
The Zigbee LED continuously lights up GREEN when the
Appliance Module is successfully connected to another Zigbee
device on the network. If the LED is flashing, the Appliance
Module is actively sending or receiving data over the network. If
the LED is flashing RED, the Appliance Module is experiencing
collisions on the network.
The HomePlug LED continuously lights up GREEN when the
Appliance Module is successfully connected to another
HomePlug device on the network. If the LED is flashing, the
Appliance Module is actively sending or receiving data over the
network. If the LED is flashing RED, the Appliance Module is
experiencing collisions on the network.
The Zigbee Security LED is lit GREEN when it is connected to a
Zigbee device on the network. If the LED is OFF, then the
Appliance Module is not connected to a Zigbee network.
2.3 Bottom Panel
Figure 2: Bottom Panel of the Gateway
Jetlun Corporation
Jetlun Appliance Module User Guide rev 1.0 DRAFT
8
!
!
Table 4: Bottom Panel of the Gateway Description
The Battery switch is where you turn on/off the backup battery in
the Appliance Module. By default, the Appliance Module battery
is turned OFF. It is recommended that you turn the battery to the
ON position during installation.
The Zigbee security button allows you to join/ leave a Zigbee
network. Press the Zigbee security button for 4 seconds (until the
Zigbee security LED is lit on the front panel) means you have
successfully join the network. Press the Zigbee security button
for 7 seconds or longer (until the Zigbee security LED is off on
the front panel) means you have successful left the Zigbee
network.
Jetlun Corporation
Jetlun Appliance Module User Guide rev 1.0 DRAFT
9
!
!
3.0 INSTALLING THE JETLUN APPLIANCE MODULE
Follow these quick steps to install your Jetlun Appliance Module.
3.1 Connecting the Jetlun Appliance Module to your Router
STEP 1: Turn ON the battery switch located on the bottom panel of the Appliance
Module.
STEP 2: Plug the Appliance Module directly into a wall socket.
IMPORTANT: Do not plug the Appliance Module into a UPS, power
strip, or other similar device with surge protection. The Appliance
Module has its own power filter for protection against surges.
STEP 4: Refer to the Jetlun Gateway RD75606 User Guide on how to monitor and
control the Appliance Module through the Jetlun Gateway User Interface.
3.2 Joining a Zigbee Network
STEP 1: With the Appliance Module plugged into the wall socket, press and hold
the Zigbee security button located on the bottom panel of the Appliance
Module for four (4) seconds or until the Zigbee security LED is lit on the
front panel of the Appliance Module.
3.3 Leaving a Zigbee Network
STEP 1: With the Appliance Module plugged into the wall socket, press and hold
the Zigbee security button located on the bottom panel of the Appliance
Module for seven (7) seconds or until the Zigbee security LED is OFF on
the front panel of the Appliance Module.
