Operating Instructions and Parts Manual
SR-1650M Slip Roll
JET
427 New Sanford Road
LaVergne, Tennessee 37086 Part No. M-756050
Ph.: 800-274-6848 Revision B 12/2015
www.jettools.com Copyright © 2015 JET
Warranty and Service
JET warr ants ev ery p rodu ct it sells agai nst manuf acturers’ defects. If o ne of our tools need s ser vice or rep air, please
contact Technical Service by calling 1-800-274-6846, 8AM to 5PM CST, Monday through Friday.
Warranty Period
The general warranty lasts for the time period specified in the literature included with your product or on the official
JET branded website.
• JET products carry a limited warranty which varies in duration based upon the product. (See chart below)
• Accessories carry a limited warranty of one year from the date of receipt.
• Consumable items are defined as expendable parts or accessories expected to become inoperable within a
reasonable amount of use and are covered by a 90 day limited warranty against manufacturer’s defects.
Who is Covered
This warranty covers only the initial purchaser of the product from the date of delivery.
What is Co vered
This warranty covers any defects in workmanship or m aterials subj ect to the limit ati ons st ated b elow . This warranty
does not cover failures due directly or indirectly to misuse, abuse, negligence or accidents, normal wear-and-tear,
improper repair, alterations or lack of maintenance. JET woodworking machinery is designed to be used with Wood.
Use of these machines in the processing of metal, plastics, or other materials may void the warranty. The exceptions
are acrylics and other natural items that are made specifically for wood turning.
Warranty Limitations
Woodworking products with a Five Year Warranty that are used for commercial or industrial purposes default to a
Two Year Warranty. Please contact Technical Service at 1-800-274-6846 for further clarification.
How to Get Technical Support
Please contact Technical Service by calling 1-800-274-6846. Please note that you will be asked to provi d e pr o of
of initial purchase when calling. If a product requires furt h er in s p ection, the Technical Servi c e representative will
explain and assist with any additional action needed. JET has Authorized Service Centers located throughout the
United States. For the name of an Authorized Service Center in your area call 1-800-274-6846 or use the Service
Center Locator on the JET website.
More Information
JET is constantly adding new products. For complete, up-to-date product information, check with your local distributor
or visit the JET website.
How State Law Appli es
This warranty gives you specific legal rights, subject to applicable state law.
Limitations on This Warranty
JET LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD OF THE LIMITED WARRANTY FOR EACH PRODUCT.
EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTI ES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
JET SHALL IN NO EVENT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY, OR FOR
INCIDENTAL, CONTINGENT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR
PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
JET sells through distributors only. The specifications listed in JET printed materials and on official JET website are
given as general information and are not binding. JET reserves the right to effect at any time, without prior notice,
those alterations to parts, fittings, and accessory equipment which they may deem necessary for any reason
whatsoever. JET
Product Listing with Warranty Period
90 Days – Parts; Consumable items
1 Year – Motors; Machine Accessories
2 Year – Metalworking Machinery; Electric Hoists, Electric Hoist Accessories; Woodworking Machinery used
for industrial or commercial purposes
5 Year – Woodworking Machinery
Limited Lifetime – JET Parallel clamps; VOLT Series Electric Hoists; Manual Hoists; Manual Hoist
Accessories; Shop Tools; Warehouse & Dock products; Hand Tools; Air Tools
NOTE: JET is a division of JPW Industries, Inc. References in this document to JET also apply to JPW Industries,
Inc., or any of its successors in interest to the JET brand.
®
branded products are not sold in Canada by JPW Industries, Inc.
2
For your own safety, read the owner’s manual before operating the slip roll.
This slip roll is designed and intended for use by properly trained and experienced personnel
only. If you are not familiar with the proper and safe operation of a slip roll, do not use until
proper training and knowledge has been obtained.
1. KEEP GUARDS IN PLACE and in working order.
2. KEEP ALL BODY PARTS AWAY FROM MOVING PARTS. Avoid placing any part of your body
near belts, cutt er s, gear s, etc.
3. DO NOT EXCEED 16 GAUGE RATED CAPACITY on this slip roll.
4. KEEP THE WORK AREA CLEAN. Cluttered areas and work benche s invite accidents.
5. KEEP CHILDREN AWAY. All visitors should be kept a safe distanc e from the work area.
6. MAKE THE WORKSHOP KID PROOF with padlocks, m aster switc hes, or by removing starter keys.
7. DON’T FORCE THE MACHINE. It will do the job better and safer at the rate for which it was
designed.
8. USE THE RIGHT MACHINE. Don’t force a machine or attachment to do a job for which it was not
designed.
9. WEAR PROPER APPAREL. Do not wear loose clothing, gloves, neck ties, rings, bracelets, or other
jewelry which may get caught in moving parts. Non-slip footwear is recommended. Wear protective
hair covering to contain long hair.
10. ALWAYS USE SAFETY GLASSES. Also use face or dust masks if the cutt ing operation is dusty.
Everyday eyeglasses only have impact resistant lenses; they are not safet y gl asses.
11. DON’T OVERREACH. Keep proper f ooting and balance at all times.
12. MAINTAIN TOOLS WITH CARE. Keep tools sharp and cl ean for the best and safest performance.
Follow instructions for lubricati ng and c hanging accessories.
13. NEVER STAND ON A MACHINE. Serious injury c ould occur if t he m ac hine tipped.
14. CHECK DAMAGED PARTS. Before furt her use of the mac hine, a guard or other part that is
damaged should be carefully checked to determine that it will operate properly and perform its
intended function - check for alignment of moving parts, binding of moving parts, breakage of parts,
mounting, and any ot her c onditions that may affect its operation. A guard or other part that is
damaged should be properly repaired or replaced.
15. SHEET METAL STOCK HAS SHARP EDGES. To prevent cuts, use caution when handling.
16. KEEP HANDS AND FINGERS clear of the area in front and rear of the rolls.
17. DO NOT USE THE MACHINE for any purpose other t han for whic h it was designed
18. FAILUR E TO C OM PLY with all of these warnings may cause serious i njury.
19. SOME DUST CREATED BY power sanding, sawing, gr inding, drilling and other construction
activities contains chemicals known to cause cancer, bir th defects or other reproduc tive harm. Some
examples of these chemicals are:
• Lead from lead based paint
• Crystalli ne sil ic a from bricks and cement and other masonry produc ts, and
• Arsenic and chromium from chemically-tr eated lumber.
YOUR RISK FROM THOSE EXPOSURES varies, depending on how often you do this type of work.
To reduce your exposure t o these chemicals: work in a well ventilated area, and work with approved
safety equipment, such as those dust masks that are specifically designed to fil ter out microscopic
particles
20. DO NOT OPERATE TOOL while under the influence of drugs, alcohol or any m edic ation.
3
Specifications
Stock Number................................................................................................................................ 756050
Model Number .......................................................................................................................... SR-1 650M
Capacity (mild steel) .............................................................................................................................. 16
Maximum Formi ng Length .................................................................................................................... 50 ”
Number and Diamet er of Rolls ...................................................................................................... 3 and 3”
Minimu m Forming Rad ius ....................................................................................................................... 2”
Wire Grooves .................................................................................................................... 1/4", 5/16”, 3/8”
Overall Dimensions (LxWxH) ............................................................................................... 68” x 22” x 24”
Net Weigh t ......................................................................................................................................565 lb
Note: The following photos show the slip roll
mounted to the optional stand (stock no.
#754051). To order this item, contact your
dealer or JET cus tomer service using t he phone
number on the cover.
Uncrating and Clean-Up
1. Remove the crate from around the m ac hine.
2. Carefully clean all rust protected surfaces
with a mild solvent or kerosene and a soft
rag. Do not use lacquer thinner, paint
thinner, or gasoline. These will damage
painted surfaces.
3. Coat all machi ned surfaces with a li ght coat
of oil to inhibit rust.
4. Remove the bolts holdi ng the machine to the
skid.
5. Caref ull y move t he machine t o a well li ghted
area on a solid, level work bench, and
secure to the bench with lag screws or bolts.
6. Machine location must allow access to all
sides, and enough room to load/unload
sheet metal.
Front Rolls
1. The two front rolls (A, Figure 1) carry the
material t hrough as the crank handle (B) i s
turned in a clockwise dir ec tion.
2. The lower roll adjustment knobs (C) are
used to mov e t he l ower roll up and d own f or
different gauge material.
3. The gap between the two f ront rolls should
be equal at both ends.
Rear Roll
1. The rear roll (D, Figure 2) can be adjusted to
control the radius by turning adjustment
knobs (E).
2. The gap between the rear roll and the two
front rolls should be equal at both ends of
the roll to assure an equal radius at both
ends of the material.
Figure 1
Figure 2
4
Releasing the Material
1. Once material has been rolled, release it
from roll by lifting clamp handle (Figure 3).
2. Lift upper roll and piv ot away from machine,
so that material can be r em ov ed.
Figure 3
Ratios
The SR-1650M has two rati os:
1:1 – place handle on upper r od,
5:1 – place handle on lower rod.
To disengage, lift stop (F ) and pull rod (G) to t he
left.
Figure 4
Rolling Wires
There are three wire grooves in the upper and
rear rolls that will accommodate a 1/4", 5/16”
and a 3/8” wire.
Lubrication
(Numbers in parentheses refer to parts
breakdown.)
The machine must be lubricated every day of
service wit h a few drops of oil. An oil pinhole is
located at both ends of the lower rol l (4), rear roll
(5), and rod (25). The upper roll (3) has one oil
pinhole on the left side. The right side can be
lubed by opening the clamp handle (31), and
lightly oiling the end of the upper roll shaft.
Every thi rty days of operation, remove the gear
cover (37) and grease the gears.
Lightly oil the rolls when not in use to prevent
rust.
5
Breakdown for the SR-1650M Slip Roll
6
Parts List for the SR-1650M Slip Roll
Index No. Part No. Description Size Quantity
1 ................ SR1650N-1G............. Base Assembly ........................................................ ...................................... 1
2 ................ SR1650N-2 ............... Hex Cap Screw ........................................................ M16x25 ......................... 4
3 ................ SR1650N-3 ............... Upper Roll ................................................................ ...................................... 1
4 ................ SR1650N-4 ............... Lower Roll ................................................................ ...................................... 1
5 ................ SR1650N-5 ............... Rear Roll .................................................................. ...................................... 1
6 ................ SR1650N-6G............. Left Support ............................................................. ........ .............................. 1
7 ................ SR1650N-7 ............... Left Upper Roll Seat ................................................ ...................................... 1
8 ................ SR1650N-8 ............... Set Rod Assembly ................................................... ...................................... 1
10 .............. SR1650N-10 ............. Bushing .................................................................... ...................................... 2
11 .............. SR1650N-11 ............. Bushing .................................................................... ...................................... 2
12 .............. SR1650N-12 ............. Set Rod .................................................................... ...................................... 3
14 .............. SR1650N-14 ............. Pin............................................................................ ...................................... 2
15 .............. SR1650N-15G........... Right Support ........................................................... ...................................... 1
16 .............. SR1650N-16 ............. Knob ........................................................................ ...................................... 2
17 .............. SR1650N-17 ............. Knob ........................................................................ ...................................... 2
18 .............. SR1650N-18 ............. Spring Pin ................................................................ 5x40 .............................. 5
20 .............. SR1650N-20 ............. Key........................................................................... 8x8x30 .......................... 2
21 .............. SR1650N-21 ............. C-Ring...................................................................... 28 .................................. 2
22 .............. SR1650N-22 ............. Gear ......................................................................... ...................................... 1
23 .............. SR1650N-23 ............. Gear ......................................................................... ...................................... 2
24 .............. SR1650N-24 ............. Gear ......................................................................... ...................................... 1
25 .............. SR1650N-25 ............. Rod .......................................................................... ...................................... 1
26 .............. SR1650N-26 ............. Bushing .................................................................... ...................................... 1
27 .............. SR1650N-27G........... Stop ......................................................................... ...................................... 1
28 .............. SR1650N-28 ............. Shaft Assembly ........................................................ ...................................... 1
31 .............. SR1650N-31G........... Clamp Handle .......................................................... ...................................... 1
32 .............. SR1650N-32 ............. Bushing .................................................................... ...................................... 1
33 .............. SR1650N-33G........... Arm .......................................................................... ...................................... 1
34 .............. SR1650N-34 ............. Handle ..................................................................... ...................................... 1
36 .............. SR1650N-36 ............. Hex Cap Screw ........................................................ M8x20 ........................... 2
37 .............. SR1650N-37G........... Gear Cover Assembly.............................................. ...................................... 1
38 .............. SR1650N-38 ............. Hex Socket Bolt ....................................................... M12x130 ....................... 1
39 .............. SR1650N-39 ............. Flat Head Screw ...................................................... M4x5 ............................. 4
40 .............. SR1650N-40 ............. Hex Nut .................................................................... M16 ............................. 12
41 .............. SR1650N-41 ............. Washer .................................................................... M16 ............................... 6
42 .............. SR1650N-42 ............. Key........................................................................... 8x8x60 .......................... 1
43 .............. SR1650N-43 ............. Set Screw ................................................................ M8x 10 ........................... 1
44 .............. SR1650N-44 ............. Tapping Screw ......................................................... ST4.3x9......................... 8
45 .............. SR1650N-45 ............. Hex Nut .................................................................... M20 ............................... 1
46 .............. SR1650N-46 ............. Cotter Pin ................................................................. 3.2x30 ........................... 1
47 .............. SR1650N-47G........... Plate......................................................................... ...................................... 2
.................. SR1650M-ID ............. ID Label (not shown)................................................ ...................................... 1
.................. SR1650N-W .............. Warning Label (not shown) ...................................... ...................................... 1
.................. JET-113..................... JET Logo with adhesive........................................... 113 x 47mm .................. 1
7
427 New Sanford Road
LaVergne, Tennessee 37086
Phone: 800-274-6848
www.jettools.com
8
Loading...
