JAT-750
Pneumatic Mini Belt Sander
#505750, JAT-750
#505751, JAT-751
#505752, JAT-752
JAT-752
JAT-751
Operation & Parts Manual
M-505750
Edition 2
06/2015
JET
427 New Sanford Road
LaVergne, T N 37086
Ph.: 800- 274- 6848
www.jettools.com
Copyright © 2015 JET
Warranty and Service
–
JET warrants every product it sells against manufacturers’ defects. If one of our tools needs service or repair, please contact
Technical Service by calling 1-800-274-6846, 8AM to 5PM CST, Monday through Friday.
Warranty Period
The general warranty lasts for the time period specified in the literature included with your product or on the official JET branded
website.
• JET products carry a limited warranty which varies in duration based upon the product. (See chart below)
• Accessories carry a limited warranty of one year from the date of receipt.
• Consumable items are defined as expendable parts or accessories expected to become inoperable within a
reasonable amount of use and are covered by a 90 day limited warranty against manufacturer’s defects.
Who is Covered
This warranty covers only the initial purchaser of the product from the date of delivery.
What is Covered
This warranty covers any defects in workmanship or materials subject to the limitations stated below. This warranty does not cover
failures due directly or indirectly to misuse, abuse, negligence or accidents, normal wear-and-tear, improper repair, alterations or
lack of maintenance. JET woodworking machinery is designed to be used with Wood. Use of these machines in the processing of
metal, plastics, or other materials outside recommended guidelines, may void the warranty. The exceptions are acrylics and other
natural items that are made specifically for wood turning.
Warrant y Limitations
Woodworking products with a Five Year Warranty that are used for commercial or industrial purposes default to a Two Year
Warranty. Please contact Technical Service at 1-800-274-6846 for further clarification.
How to Get Technical Support
Please contact Technical Service by calling 1-800-274-6846. Please note that you will be asked to provide proof of initial
purchase when calling. If a product requires further inspection, the Technical Service representative will explain and assist with
any additional action needed. JET has Authorized Service Centers located throughout the United States. For the name of an
Authorized Service Center in your area call 1-800-274-6846 or use the Service Center Locator on the JET website.
More Information
JET is constantly adding new products. For complete, up-to-date product information, check with your local distributor or visit the
JET website.
How State Law Applies
This warranty gives you specific legal rights, subject to applicable state law.
Limitations on This War ra nt y
JET LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD OF THE LIMITED WARRANTY FOR EACH PRODUCT. EXCEPT AS
STATED HEREIN, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATION MAY NOT APPLY TO YOU.
JET SHALL IN NO EVENT BE LI A B L E FOR DEA TH, INJURI E S TO PERSONS OR PROPERTY , OR F OR INCIDE NTA L ,
CONTINGENT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR PRODUCTS. SOME STATES
DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
JET sells through distributors only. The specifications listed in JET printed materials and on official JET website are given as
general information and are not binding. JET reserves the right to effect at any time, without prior notice, those alterations to parts,
fittings, and accessory equipment which they may deem necessary for any reason whatsoever. JET
sold in Canada by JPW I ndustries, Inc.
Product Listing with Warranty Period
90 Days
1 Year – Motors; Machi n e Accesso r i e s
2 Year – Metalworking Machinery; Electric Hoists, Electric Hoist Accessories; Woodworking Machinery used for industrial
or commercial purposes
5 Year – Woodworking Machinery
Limited Lifetime – JET Parallel clamps; VOLT Series Electric Hoists; Manual Hoists; Manual Hoist
Accessories; Shop Tools; Warehouse & Dock products; Hand Tools; Air Tools
NOTE: JET is a division of JPW Industries, Inc. References in this document to JET also apply to JPW Industries, Inc., or any of
its successors in interest to the JET brand.
Parts; Consumable items
®
branded products are not
2 JAT -750/751/ 75 2 Mi ni Belt Sand ers
Safety warnings
General air tool warnings
1. Read and understand this entire manual
bef ore attempti ng assembl y or op erat i on .
2. Read and un derstan d all warn ings post ed on
the tool and in this m anual . Fai lure t o c ompl y
with all of th ese warni ngs may caus e seri ous
injury.
3. Replace warning labels if they become
obscured or remo ved.
4. Do not use this tool for other than its intended
use. If used for other purposes, JET disclaims
any real or implied warranty and holds itself
harmless from any injury that may result from
that use.
5. Al ways wear app roved saf ety gl ass es or fac e
shield while using this tool. (Everyday
eyeglasses only have impact resistant lenses;
they ar e not safet y glas ses.)
6. Wear ear protectors (plugs or muffs) if the
noise exceeds safe levels.
7. Wear gloves and protective clothing if
oper ation pr oduces sparks or fl ying p articles.
Gloves should be tight-fitting, withou t frayed
fing ers or hanging threads . Keep han ds and
body aw ay from the work ing area of to ol.
8. Some dust created by power sanding, sawing,
grinding, drilling and other construction
acti viti es c ontai ns c hem ic als know n t o c aus e
cancer, birth defects or other reproductive
harm. Some examples of these chemicals
are:
• Lead from lead based paint.
• Crystalline silica from bricks, cement and
other m as onry prod uc ts .
• Arsenic and chromium from chemically
treated lumber.
Your risk of exposure varies, depending on
how often you do this t yp e of w ork. To reduc e
your e xposure to t hese chemic als, wor k in a
well-ventilated area and work with approved
safety equipmen t, such as face or dust masks
that are specifically designed to filter out
microscopic particles.
9. Do not operate an air tool continually at full
throttle withou t a w ork l oad on the tool .
10. The air tool must be properly lubricated before
oper atin g.
11. Never start a percussion type air tool (chipper,
breaker, buster, etc.) without securing the
tooling in the retainer and placing the tip
against the work surface.
12. Do not operate air tool without its guards in
place. Do not modify the tool.
13. Do not operate this tool whi le tired or und er
the influence of drugs, alcohol, or any
medication.
14. Adopt a comfortable posture with proper
balance, and maintain secure footing at all
times. Non-slip footwear or anti-skid floor
strips ar e recommend ed.
15. Do not wear loose clothing or jewelry. Confine
long hair.
16. Excessive air pressure and too much free
rotati on may decr eas e lif e of th e tool an d may
caus e a haz ar d ous sit u at i on.
17. Check air hoses for wear, and keep them
away f rom heat and s harp ed ges. R epair or
replace damaged air hose immediately. Do
not carry tool by the air hose.
18. Air hose may cause tripping hazards; keep
hose away from traffic areas.
19. D o not us e this tool n ear flammabl e objects,
or in potentially explosive environments. Do
not use near live electrical wires.
JET 3
20. Do not use power tools in damp or wet
locat ion, or expose t hem t o rain. Keep w ork
area well lighted.
21. Do not leave a connected tool unattended.
When not in use, disconnect tool from air
source.
22. Shut off air supply and discharge any residual
pressure from tool before removing hose,
making adjustments, changing accessories,
or storing tool.
23. Make sure tool is switched off, and your finger
off the trigger, before connecting to air supply.
24. Remo ve adj ustin g keys and wr ench es bef or e
turnin g on t ool.
25. Keep visitors a safe distance from the work
area. Keep children away.
26. Give your work undivided attention. Looking
around, carrying on a conversation and
“horse-play” are careless acts that can result
in serious injury.
27. D o not forc e a tool or att achm ent to do a job
for which it was not designed. The righ t tool
will do the job better and more safely.
30. Use only recommended accessories;
impr op er access ories may be haz ar d ous .
31. Maint ain t ools with care. Keep air t ool clean
and oiled for best and safest performance.
32. Do not use combustible gases, carbon
dioxide, oxygen or any bottled gas as an air
source f or the tool. Th es e can present r isk of
explosion and serious injury.
33. Do not lubricate the tool with combustible
liquids, such as kerosene, diesel or jet fuel.
34. Do not dispose of this tool with normal
household waste. Never dispose of the air tool
into fire.
Specific warnings for Belt Sanders
35. If you are not familiar with the proper and safe
oper ation of a pneumatic belt sander , do not
use unt il pr oper trai ning and kn owl edg e have
been obtained .
36. Secur e workp iec e with cl amps or vise; d o not
hold wor kpiece by h and.
37. Only use accessories that are intended for use
with a pneum atic b elt s an d er.
28. Repetitive motions and/or exposure to
constant vibration can be harmful to hands
and arms. Take frequent breaks and relax
hands during extended operation. Change
posture to avoid dis comf ort or f at ig u e.
29. Compressed air can be harmful if directed
toward s ensiti ve ar eas of the bod y, and may
propel small particles caught in the air stream.
Exerc ise proper c auti on.
Familiarize yourself with the following safety notices used in this manual:
Th is means t hat if preca utions are not he eded, it may resu lt in serio us, or ev en
fatal, injury.
This means that if precautions are not heeded, it may result in minor injury and/or
possible tool damage.
38. Use both hands to operate sander.
39. Inspect abrasive belt before operating. Do not
use a damaged belt.
40. Do not operate sander without the silencer
(muffler) installed.
4 JAT -750/751/ 75 2 Mi ni Belt Sand ers
About this manual
This manual is provided by JET, covering the safe operation and maintenance procedures for a JET Model
JAT -750, JA T-7 51 and J AT- 752 Pn eum atic M ini B elt S an der. T his manu al c ontai ns ins tr ucti ons on s afety
prec autions , gener al operatin g proc edures, m ainten ance pr ocedur es and parts breakd own. Your t ool has
been d esig n ed and c onstr uct ed to pr o vid e c onsist ent, lon g-t erm op eration if us ed i n ac c ordanc e w ith t h e
instructions set forth in this document.
The instructions and warnings in this manual may not encompass all possible workplace environments. The
operator is expected to take appropriate precautions and exercise common sense. As with any tool
oper ati on, safet y of op erator and b yst an d ers sh ou ld be fir s t priority.
If th ere are ques ti ons or comments, pl eas e contact you r local su pp lier or J E T . J E T can also be reac h ed at
our web site: www.jettools.com.
Record the serial number and purchase information of your tool on the cover of this manual for quick access.
Retain this manual for future reference. If the tool transfers ownership, the manual should accompany it.
JET 5
Tool speci fications
Model number JAT-750 JAT-751 JAT-752
Stock number 505750 505751 505752
Belt size 3/8 x 13 in.
Horsepower 0.5
Head rotation 360 deg.
Free speed 20,000 RPM
Average air consumption 4.2 CFM
Air inle t 1/4 in. NPT
Air hose inside diameter 3/8 in.
Required air pres s ure 90 psi (62 1 kP a)
Vibration value 1.3 m/s2 3.1 m/s2 1.3 m/s2
Nois e lev el 1 93 dB(A)
Power setting Variable speed throttle
Grip inline inline inline
Overall length, folded 8-1/8 in. (206.38 mm)
Ove rall length, maximum 13 in. (330.2 mm)
Housing material
Net weight 1. 9 4 lb. (0 .8 8 kg) 2. 9 8 lb. (1 .3 5 kg) 2 .14 lb. (0.97 kg)
Shipping weight 2. 2 7 lb. (1 .0 3 kg) 3.37 lb. (1 .5 3 kg) 2.51 lb. (1.14 kg)
Aluminum with rubber
grip
3/4 x 20-1/2 in. 1/2 x 24 in.
0.6 0.5
360 deg. 360 deg.
18,000 20,000
4.2 CFM 4.2 CFM
1/4 in. NPT 1/4 in. NPT
3/8 in. 3/8 in.
90 psi (62 1 kP a) 90 psi (62 1 kP a)
96 dB(A) 93 dB(A)
Variable speed throttle Variable speed throttle
10 in. (254 mm) 12-1/4 in. (311.15 mm)
15-3/4 in. (400 mm) 18-1/2 in. (470 mm)
Aluminum with rubber
grip
Aluminum with rubber
grip
1
The specif ied val ues ar e emiss ion l evels an d ar e not nec ess aril y to be seen as s afe oper atin g levels . As
workpl ac e condit i ons var y, this informat ion is int end ed to al low the us er to mak e a better esti mati on of th e
hazards and risks invo lved only.
Specifications were current at time of publication, but because of our policy of continuous improvement, JET
reserves the right to change specifications at any time and without prior notice, without incurring obligations.
6 JAT -750/751/ 75 2 Mi ni Belt Sand ers
Setup an d A ss em bly
Any missing parts or damage should be reported
immediately to your JET
damaged tool. Read this instruction manual
thorou g hl y for oper at i on , m ai ntenance and s afety
instructions.
Box contents :
1 Mini belt sander
2 Sanding be lts (one is pre-installed)
1 Hex wr enc h 4mm
1 Operat i on and p ar ts m anu al
1 Warranty card
®
distr ibutor. Do not use a
Operation
The belt sander must be
properly lubricated before operation. See
“Lubricati on” se ctio n.
Disconnect sander from air
hose before making any repair or adjustment.
2. Remove protective cap from air inlet. If an inline oiler is n ot b ei ng used, add 4 or 5 dr ops
of air tool oi l ( n ot inc lu ded) into th e air inl et.
3. Blow out air line to remove any dirt or
moisture, then connect air supply hose to
tool. Set air pressure to 90 psi.
IMPORTANT: Connecting a quick-change
coupling directly to the tool is not
recommended, as vibration may cause the
connection to fail. Instead, add a leader hose
and install any quick-change couplings
farther down the line.
4. Grip s ander secur ely an d pus h saf ety l ever
backward to release throttle lever. Gently
press throttle lever.
5. P lace sandi ng belt on w orkpi ece and mov e
tool back and forth with light pressure. Do not
apply excessive pressure, as it may damage
workpi ece and hast en w e ar on s an di ng b elt.
Adjustments
Trackin g adjustment
Figure 1
1. Adj ust ar m t o desir ed angl e and tig ht en he x
socket cap screw (Figur e 1), with supplied
hex wrench. Make sure arm assembly is
fitted closely to housing shoulder.
Always tighten hex
socket cap screw firmly after adjustment,
or the he ad could r otate , cau sing lo ss of
control.
Tracking adjustment requires
sander to be connected to the hose and
running. Use caution when hands and tools
are close to a running belt.
Belt is tracking properly on all models when
centered on the idl e pulley.
JAT-750/752:
1. Disconnect sander from air source.
2. Loosen set screw with 1.5mm hex wrench
(not provided). See Figure 2.
3. With belt running, turn adjusting screw
clockwise or counterclockwise until belt is
centered on idl e pull e y.
4. Tighten set screw.
JET 7
JAT-751:
Figure 2
Figure 4: JAT-750
Insert hex wrench into hex socket cap screw and
turn clockwise or counterclockwise until belt is
centered on idl e pull e y. S ee Fi gu re 4.
Figure 3
Belt replacement
JAT-750:
1. Disconnect sander from air source.
2. Loosen hex c ap sc rew (S ee F igur e 1), t urn
arm 90-degrees to the handle, and tighten
screw to lock.
JAT-751:
1. Disconnect sander from air source.
2. L oosen h ex cap s crew (s ee Figur e 1), tur n
head 90- degr ees t o the hand le, and ti ght en
screw to lock.
3. S t ead y sander with one hand, while pus h ing
down on idle pulley assembly and removing
belt.
4. I ns t all n ew belt over pul l eys .
5. Release pressure on idle pulley to tension
belt.
3. Stead y sander wit h one hand whil e pushin g
down on the idl e wh eel w it h oth er h and , until
assem bl y loc ks in pl ace. See Fig ur e 4.
4. Remove old belt. Install new belt, centering it
on the pul l eys .
5. Pr ess t ensi on le ver ( A, Fi gure 4) to eng ag e
tension.
8 JAT -750/751/ 75 2 Mi ni Belt Sand ers
Figure 5: JAT-751
JAT-752:
1. Disconnect sander from air source.
2. L oosen h ex cap s crew (s ee Figur e 1), tur n
head 90- degr ees t o the hand le, and ti ght en
screw to lock.
3. Steady sander with one hand. Push down on
idle pulley assembly and turn 1/8 of a full turn
clockwise to lock in place. See Figure 6.
4. Remove ol d b elt. Ins t all new b elt .
5. Rotate idle pulley assembly counterclock wise to eng ag e tens i on.
Figure 6: JAT-752
Shoe repl acement
The sh oe or sanding platen should be replaced
when, due to wear, it no longer sits flat but is
convex in shape.
Figure 7
Idle pulley replacement
Disconnect sander from air
hose before making any repair or adjustment.
Follow Figure 8 for your sander model when
repl aci ng the idle pulley.
JAT-750/752:
1. Disconnect sander from air source.
2. Remove belt (see Belt replacement).
3. Remove screw(s) and remove old shoe
(Figure 7).
4. Install new shoe and fasten with screw(s).
Make su re tab on s h oe end en gages sl ot on
sander ar m.
JAT-751:
1. Disconnect sander from air source.
2. Remove belt (see Belt replacement).
3. Loosen hex socket cap screw (Figure 7).
4. Remove old shoe. Replace with new shoe.
5. Tighten screw and install belt.
Figure 8
JET 9
Tension b ar repl acement
JAT-750/752:
1. Disconnect sander from air source.
2. Remove belt.
3. Pul l out t ensi on b ar f rom hous ing, F igur e 9 .
Be careful not to lose spri ng.
4. Insert new t ensi on bar b y lin ing up pin wit h
pin groove. See Figure 9.
4. W hen finis hed oper atin g tool, disc onn ect air
hose. Wipe off housing with a dry cloth.
Plac e 4 or 5 dr ops of air tool oil into air inl et;
re-connect air and run tool for a few seconds
to distri bu te the oil. Disconnec t air .
Storage
Avoid s torin g the s ander i n ver y humi d loc ations
which promotes rusting of internal mechanisms.
Always oil the tool and disconnect air hose before
storage.
Air system requi rements
1. Use proper air hose size (refer to tool
specifications). The hose should be just long
enough to serve the working area. Excessive
hose len gt h wil l c ause pressur e drop.
2. Make sure air compressor supplies clean,
dry air at correct CFM for the tool.
Figure 9
Speed adjust ment
All m odels h ave a brass screw on the un ders ide
of the handle, used for belt speed adjustment.
This has been set by the manufacturer; it is highly
rec ommen ded t hat t he en d us er not att empt any
adjustment t o the sp eed c ontrol.
Maintenance
Lubrication
The san d er sh ould b e lubr ic ated daily (or before
each use) with air tool oil through the air inlet.
During continual operation, it should be re-oiled
every 1 to 2 hours. This can be done with an inline oiler , or manuall y. If done manu ally, pr oceed
as follows:
1. D is c onn ec t air h os e f r om tool.
2. P l ac e 4 or 5 dr ops of air tool oil into air inlet.
NOTE: Air tool oil not provided; it is available
at most major hardware and tool stores. SAE
#10 oil or s ewing mach ine oil may b e us ed
as a substitute. Do not use detergent oil.
3. Set air pressure to 90 psi.
Excess air pressure
and/or un clean air will sh orten the tool’ s
life and may create a hazardous situation.
4. Drain water f rom air com press or tan k dail y,
as well as any condens ation from air lin es .
W ater in the air lin e may enter the t ool and
cause damage.
5. C h ang e f ilt ers on th e air syst em on a reg ul ar
basis.
6. Air-line pressure may be increased
accor di n gly to compensate f or extra- l ong air
hoses (usually over 25 feet). Inside diameter
of hos e sh oul d b e mini m um 3/8-inc h .
General Air Tool
Information
If the air tool is not performing according to
specif ications , th e foll owing are am ong t he most
common causes. (See also “Troubleshooting”
section.)
• C ontamin ated air suc h as a dirty air system
or water in the system.
3. Re-connect air. Run tool at low throttle
withou t load for a f ew secon ds to distr ibute
the oil th roughout tool.
10 JAT-750/ 75 1/ 752 Mini B elt S an d ers
• Using wrong size tool for the job.
• P oor main tenanc e pr actic es, suc h as usin g
excess i ve air press ure or air volume.
• Improper or no lubrication.
Rule of Th um b
If it takes more than 8 seconds to tighten or loosen
a bolt or nut with an air impact wrench at
maxim um settin g, the air wrenc h is t oo smal l or
the air compressor CFM is not powerful enough
for the job. Continued use in either capacity will
cause damage to the tool.
Tool Pressure
JET Air Tools oper ate on 70-t o-100 psi ( pounds
per square inch) air pressure measured at the tool
when the tool is operating. Set tool to 90 psi
unless indicated otherwise. Pressure in excess of
100 psi will shorten the life of the tool.
Use anti-whip devices across hose couplings to
prevent hose from whipping in the event of a hose
failur e or c oup li ng dis connec t.
Always us e m oist ure tr aps at th e c ompr ess or f or
the main distr ib ut ion line. Use mois ture traps an d
in-lin e oilers on eac h down line th at is to be used
for air tools. ( See Fig ur e 1 0) . Place oiler as close
to air tool as pos s ib l e f or best lubric ati on.
Lubrication
Use a lig ht oil contai ning rust in hibitors, such as
SAE #10. Many JET air tools have integral oil
reservoirs, which should be kept filled when in-line
oilers ar e not used.
Air System Recommendations
Equip the air compressor intake with a
replaceable air filter that can be easily cleaned.
Use safety shut-off valves so air flow can be
stopped quickly in case of a line break.
W hen using multip le hos es, air hoses shou ld be
larger than leader hose. Join multiple hoses
directly, rather than with quick connect fittings
which m ay caus e pressure dr ops and tool power
reduction.
If greasing is required, use a grease that is highly
water resis tant for f ront c ase c ompon ents on air
impact w renches, gr in d ers and sander s .
Recycling
Protect the environment. Your tool contains
materials which can be recovered or recycled.
W hen its us eful life has expired, please leave tool
at a specialized facility.
Recommended arrangement of air piping and air line system
Figure 10
JET 11
Troubl es h oo tin g J AT -7 50/ 75 1/7 52 B e lt Sa nd ers
Any dis ass embly of the tool sh ould be don e by qualif ied servic e personnel. F or problems not ad dressed
below, contact JET technical service at 800-274-6846.
Problem Possible cause Remedy
Tool will not st art . Air valv e cl os ed or obstruc ted. Open val v e; cl ear an y obstruct i ons .
Starts im m ed i ately when
air is connected wit h out
throttle l ever bei ng
pressed.
Exc essive or abn orm al
vibration.
Loss of power; erratic
action.
Exc essive heat d ev el ops
in tool.
Sever e air l eak ag e.
(Note: M inim a l escape of
air is oft en n or m al f or air
tools.)
Dirt or gu m d eposits on
components.
Rotor van es or ot h er c om ponents
are wor n.
Thr ottl e l ever i n op erable. Clean throttl e lev er m ech an is m to
Bearin g( s ) w orn. Dis assemble and i ns p ect bearing.
Thr ottl e l ever m alf u nc ti on. Clean throttl e lev er mechanis m to
Bearin gs w orn. Disassemble and ins p ect bearin g.
Low air pressure. Verify compressor has proper CFM
Moisture or obstr uction in air
hose.
Impr op er size of air tr ans m is s i on
lines, h oses, fitti ngs , or
couplings.
Dirt or gu m d eposits on
components.
Rotor van es are worn. Repl ac e van es (entir e set ).
Insuf f ic i ent lubric ation . Lubricate with air to ol oi l.
Worn components. Replace components as needed.
Air valv e obs truct ed or dam aged. Clean or rep l ac e.
Housi ng loose or damag ed. Tighten or repl ac e as needed.
Flush tool wit h gu m s olvent.
If problem persists, disassemble,
clean and lubricate internal parts.
Repl ac e w orn c om p onents.
(Replace vanes as complete set.)
ensure free movement. Replace
mechanism if needed.
Greas e or r eplace as need ed .
ensure free movement. Replace
mechanism if needed.
Greas e or r eplace as need ed .
rating for tool.
Che ck compressor regu lator
setting; set air pressure to 90 psi.
Set regulator dial on tool to
maximum setting.
Check for loose connections.
Air supply must be clean and dry.
Clean ou t air h os e(s ) and r em ov e
any ki nks or b ends .
Use appr opriat e-si z ed air lines/
hoses. Verify proper fittings or
couplings.
Flush tool wit h gu m s olvent.
Check and cl ean air filt er on
compress or.
Clean e xt er n al areas of tool . If
problem persists, disassemble,
clean and lubricate internal parts.
12 JAT-750/ 75 1/ 752 Mini B elt S an d ers
Replac em e nt par t s
Repl acem ent p arts are lis ted on th e foll owi ng p ages. To ord er par ts or r eac h our s ervic e dep art men t, c all
1-800- 274- 6848 Mon day thr ough Fri day, 8:00 a. m. to 5:00 p. m. CST . Please ha ve the stoc k number and
seri al nu mb er of you r t ool a vai lable wh en you c a ll, s o that we m ay s erve you quic k l y and acc uratel y.
JET 13
#505750, JAT-750, Mini Belt Sander – exploded view
59
58
28
50
46
5
21
13
15 17
14
18
12
19
20
56
57
4
48
47
49
54
55
54
55
1
27
51
60
52
61
3
53
34
33
38
41
16
33
30
40
32
39
31
36
45
37
24
35
42
25
2
43
44
29
26
22
7
8
6
9
10
62
11
23
14 JAT-750/ 75 1/ 752 Mini B elt S an d ers
#505750, JAT-750, Mini Belt Sander – parts list
Index Part No. Description Qty
1 JA T7 50-01 Housi n g (incl . #4 6 gr i p) 1
2 JAT750-02 Guard 1
JAT750-02A Guard subassembly (w/#26) 1
3 JSM6100-03 Air inlet 1
4 JSM6100-04 Throttle lever 1
JSM6100-04A
5 JSM6100-05 Valve stem 1
6 JSM6100-06 Valve 1
7 SM-30107 O-Ring 3.9x1.9 1
8 JSM6100-08 Spring 1
9 JSM6100-09 O-Ring 14.5x1.5 1
10 JSM6100-10 Spacer 1
11 JSM6100-11 Retaining ring RTW-18 1
12 61012 Spacer 1
13 BB-607ZZ Ball bearing 607ZZ 1
14 61014 Rear end plate 1
15 61015 Rotor 1
16 61016 Rotor vane 4
17 61017 Key 3x3x10 1
18 61018 Cylinder 1
19 61019 Front end plate 1
20 BB-628ZZ Ball bearing 628ZZ 1
21 61021 Cap 1
22 61222 Drive pulley 1
23 TS-1541021 Nylon lock hex nut M6 1
24 61024 Shoe 1
25 40343 Screw M5x16L 1
26 61026 Dust shield 1
27 JSM6100-27 Pan head screw M4x25 1
28 JSM6100-28 Exhaust shaft 1
JSM6100-28A
29 TS-2284082 Pan head screw M4x8 1
Thr ottle lev er assembl y
(incl. #4,47,48,49)
Exhaust assembly
(incl. #28,58-61)
1
1
Index Part No. Description Qty
30 61035
31 61036
32 61037 Pan hd. sc rew M2x5 1
33 BB-684ZZ Ball bearing 684ZZ 2
34 61039 Idle pulley sha ft 1
35 61040 Spring 1
36 61041 Tension bar 1
37 61042 Bushing 1
38 61043 Idle pulley 1
39 61044 Spring 1
40 61045 Bracket 1
41 61046 Set sc rew M3 x6 1
42 61 048 Spri n g pi n 2.5x8 1
43 61049 Spring 1
44 61050 Tension lever 1
45 JSM6100-45 Lock pin 3x11.8 1
46 JAT750-46 Rubber Grip 1
47 JSM6100-47 Safety lever 1
48 JSM6100-48 Spring 1
49 40337 Spring pin 3x18L 1
50 JSM6100-51 Screw 1
51 SM-40130 O-Ring 8.8x1.7 1
52 JSM6100-52 Pin 2x13.8 1
53 TS-152705 He x w rench 4mm 1
54 TS-2284082 Pan head screw M4x8 2
55 TS-2361041 Spring washer M4 2
56 TS-2331041 Lock nut M4 1
57 JSM6100-57 Lever support 1
58 JSM5130-35 O-Ring 14x1 1
59 JSM6100-59 O-Ring 5.8x1.9 1
60 JSM6100-60 Muffler 1
61 JSM6100-61 Exhaust sleeve 1
62 J A T750-6 2 S an di n g b el t 12 0G 1
Flat head screw M3x8
Spri n g pi n 3x10
1
1
RPK-6100, Repair Kit, contains #7,9,11,16(4),26
RBK-6100, Rebuild Kit, contains #30-34,38-41
JET 15
#505751, JAT-751, Mini Belt Sander – exploded view
53
52
51
45
40
36
46
4
15
17
42
49
43
48
25
41
38
33
23
43
44
36
35
22
37
47
34
24
39
26
16
30
31
28
2
25
32
29
5
7
8
6
20
1
9
10
11
19
18
12
57
50
54
55
56
21
13
14
58
27
3
16 JAT-750/ 75 1/ 752 Mini B elt S an d ers
#505751, JAT-751, Mini Belt Sander – parts list
Index Part No. Description Qty
1 JA T7 51-01 Hous i n g (incl. #57 Grip) 1
2 JAT751-02 Guard 1
JAT751-02A Gua rd Subassembly (w/#26)
3 JSM6100-03 Air inlet 1
4 JSM6100-04 Throttle lever 1
JSM6100-
04A
5 JSM6100-05 Valve stem 1
6 JSM6100-06 Valve 1
7 SM-30107 O-Ring 3.9x1.9 1
8 JSM6100-08 Spring 1
9 JSM6100-09 O-Ring 14.5x1.5 1
10 JSM6100-10 Spacer 1
11 JSM6100-11 Retaining ring RTW-18 1
12 JAT751-12 Spacer 1
13 BB-608ZZ Ball bearing 608ZZ 1
14 JAT751-14 Rear end plate 1
15 JAT751-15 Rotor 1
16 JAT751-16 Rotor vane 4
17 JAT751-17 Key 4x4x10 1
18 JAT751-18 Cylinder 1
19 JAT751-19 Front end plate 1
20 BB-6000ZZ Ball bearing 6000ZZ 1
21 JAT751-21 Cap 1
22 JAT751-22 Drive pulley 1
23 TS-1541041 Nylon lock hex nut M10 1
24 JAT751-24 Shoe 1
25 JHM610-54 Socket hd cap screw M5x18L 1
26 JAT751-26 Dust shield 1
27 JAT751-27 Silencer 1
28 JSM6100-27 Pan head screw M4x25 1
Throttle lever assembly
(incl. #4,51,52,53)
1
Index Part No. Description Qty
29 JSM6100-57 Lever support
30 TS-2284082 Pan hd screw M4x8L
31 TS-2361041 Spring washer M4 2
32 TS-2331041 Lock nut M4 1
33 JAT751-33 Bushing 1
34 JAT751-34 Finger pad 1
35 TS-1550031 Flat washer M5 1
36 TS-2361051 Spring washer M5 1
37 TS-1502011 Socket hd cap screw M5x8L 1
38 JAT751-38 Spring 1
39 JAT751-39 Arm 1
40 TS-2331061 Nylon lock hex nut M6 1
41 JAT751-41 Idle pulley 1
42 JAT751-42 Idle pulley shaft 1
43 BB-686ZZ Ball bearing 686ZZ 2
44 JAT751-44 Spacer 1
45 JAT741-09 Retaining ring ETWJ-4 1
46 JAT751-46 Bolt 1
47 TS-1502031 Socket hd cap screw M5x12L 1
48 JAT751-48 Spacer 1
49 J A T751-4 9 S an di n g belt 12 0G 1
50 JSM3330-49 O-Ring 26.7x1.78 1
51 JSM6100-48 Spring 1
52 JSM6100-47 Safety lever 1
53 40337 Spring pin 3x18L 1
54 JSM6100-51 Screw 1
55 SM-40130 O-Ring 8.8x1.7 1
56 JSM6100-52 Pin 2x13.8 1
57 JAT750-46 Rubber Grip 1
58 TS-152705 Hex wrench 4mm 1
1
2
JAT751-RPK, Repair Kit, contains #7,9,11,16(4),26
JAT751-RBK, Rebuild Kit, contains #40-45,48
JET 17
#505752, JAT-752, Mini Belt Sander – exploded view
38
43
48
38
37
36
4
0
49
47
39
46
35
45
44
41
42
25
4
32
33
30
31
55
34
20
1
19
56
57
17
16
12
14
18
15
21
13
60
59
22
24
23
32
32
26
2
5
7
8
6
9
10
11
58
27
54
53
28
29
50
51
52
3
18 J AT-750/75 1/752 Mini Belt Sanders
#505752, JAT-752, Mini Belt Sander – parts list
Index Part No. Description Qty
1 JA T7 50-01 Housi n g (incl . #5 8 gr i p) 1
2 JAT750-02 Guard 1
JAT750-02A Guard Subassembly (w/#26)
3 JSM6100-03 Air inlet 1
4 JSM6100-04 Throttle lever 1
JSM6100-04A
5 JSM6100-05 Valve stem 1
6 JSM6100-06 Valve 1
7 SM-30107 O-Ring 3.9x1.9 1
8 JSM6100-08 Spring 1
9 JSM6100-09 O-Ring 14.5x1.5 1
10 JSM6100-10 Spacer 1
11 JSM6100-11 Retaining ring RTW-18 1
12 61012 Spacer 1
13 BB-607ZZ Ball bearing 607ZZ 1
14 61014 Rear end plate 1
15 61015 Rotor 1
16 61016 Rotor vane 4
17 61017 Key 3x3x10 1
18 61018 Cylinder 1
19 61019 Front end plate 1
20 BB-628ZZ Ball bearing 628ZZ 1
21 61021 Cap 1
22 61222 Drive pulley 1
23 TS-1541021 Nylon lock hex nut M6 1
24 JAT752-24 Shoe 1
25 40343 Screw M5x16L 1
26 61026 Dust shield 1
27 JSM6100-28 Exhaust shaft 1
JSM6100-28A
28 JSM6100-60 Muffler 1
29 JSM6100-61 Exhaust sleeve 1
Throttle lever assembly
(incl. #4,55,56,57)
Exhaust shaft assembly
(inc l . #27,28,29,53,54)
1
1
Index Part No. Description Qty
30 JSM6100-27 Pan head screw M4x25
31 JSM6100-57 Lever support 1
32 TS-2284082 Pan head screw M4x8 4
33 TS-2361041 Spring washer M4 2
34 TS-2331041 Lock nut M4 1
35 61035 Screw M3x8 1
36 61 036 S pri ng pin 3x 10 1
37 61037 Pan hd. screw M2x5 1
38 BB-684ZZ Ball bearing 684ZZ 2
39 61239 Id l e pulley shaft 1
40 61040 Spring 1
41 61041 Tension bar 1
42 JAT752-42 Bushing 1
43 JAT752-43 Idle pulley 1
44 61044 Spring 1
45 JAT752-45 Bracket 1
46 61046 Set screw M3x6 1
47 JAT752-47 Extension bar 1
48 JAT752-48 Spacer 1
49 JSM6100-45 Lock pin 3x11.8 1
50 JSM6100-51 Screw 1
51 SM-40130 O-Ring 8.8x1.7 1
52 JSM6100-52 Pin 2x13.8 1
53 JSM6100-59 O-Ring 5.8x1.9 1
54 JSM5130-35 O-Ring 14x1 1
55 JSM6100-48 Spring 1
56 JSM6100-47 Safety lever 1
57 40337 Spring pin 3x18L 1
58 JAT750-46 Rubber Grip 1
59 J A T752-5 9 S an di n g belt 12 0G 1
60 TS-152705 Hex wrench 4mm 1
1
RPK-6100, Repair Kit, contains #7,9,11,16(4),26
RBK-6100, Rebuild Kit, contains #35-39,43-46
JET 19
20 J AT-750/75 1/752 Mini Belt Sanders
427 New Sanford Road
LaVergne, Tennessee 37086
Phone: 800-274-6848
www.jettools.com
JET 21
Loading...
