Pneumatic Angle Grinder
#505464, JAT-464
#505465, JAT-465
#505467, JAT-467
Operation & Parts Manual
M-505464
Edition 1
05/2019
JET
427 New Sanford Road
LaVergne, TN 37086
Ph.: 800-274-6848
www.jettools.com
Copyright © 2019 JET
Safety warnings
General air tool warnings
1. Read and understand this entire manual
before attempting assembly or operation.
2. Read and understand all warnings posted on
the tool and in this manual. Failure to comply
with all of these warnings may cause serious
injury.
3. Replace warning labels if they become
obscured or removed.
4. Do not use this tool for other than its intended
use. If used for other purposes, JET disclaims
any real or implied warranty and holds itself
harmless from any injury that may result from
that use.
5. Always wear approved safety glasses or face
shield while using this tool. (Everyday
eyeglasses only have impact resistant lenses;
they are not safety glasses.)
6. Wear ear protectors (plugs or muffs) if the
noise exceeds safe levels.
7. Wear gloves and protective clothing if
operation produces sparks or flying particles.
Gloves should be tight-fitting, without frayed
fingers or hanging threads. Keep hands and
body away from the working area of tool.
8. Do not operate an air tool continually at full
throttle without a work load on the tool.
9. The air tool must be properly lubricated before
operating.
10. Never start a percussion type air tool (chipper,
breaker, buster, etc.) without securing the
tooling in the retainer and placing the tip
against the work surface.
11. Do not operate air tool without its guards in
place. Do not modify the tool.
12. Do not operate this tool while tired or under
the influence of drugs, alcohol, or any
medication.
13. Adopt a comfortable posture with proper
balance, and maintain secure footing at all
times. Non-slip footwear or anti-skid floor
strips are recommended.
14. Do not wear loose clothing or jewelry. Confine
long hair.
15. Excessive air pressure and too much free
rotation may decrease life of the tool and may
cause a hazardous situation.
16. Check air hoses for wear, and keep them
away from heat and sharp edges. Repair or
replace damaged air hose immediately. Do
not carry tool by the air hose.
17. Air hose may cause tripping hazards; keep
hose away from traffic areas.
18. Do not use this tool near flammable objects,
or in potentially explosive environments. Do
not use near live electrical wires.
19. Do not use power tools in damp or wet
location, or expose them to rain. Keep work
area well lighted.
20. Do not leave a connected tool unattended.
When not in use, disconnect tool from air
source.
21. Shut off air supply and discharge any residual
pressure from tool before removing hose,
making adjustments, changing accessories,
or storing tool.
22. Make sure tool is switched off, and your finger
off the trigger, before connecting to air supply.
23. Remove adjusting keys and wrenches before
turning on tool.
2 JAT-464,-465,-467 Pneumatic Angle Grinder
24. Keep visitors a safe distance from the work
area. Keep children away.
25. Give your work undivided attention. Looking
around, carrying on a conversation and
“horse-play” are careless acts that can result
in serious injury.
26. Do not force a tool or attachment to do a job
for which it was not designed. The right tool
will do the job better and more safely.
27. Repetitive motions and/or exposure to
constant vibration can be harmful to hands
and arms. Take frequent breaks and relax
hands during extended operation. Change
posture to avoid discomfort or fatigue.
28. Compressed air can be harmful if directed
toward sensitive areas of the body, and may
propel small particles caught in the air stream.
Exercise proper caution.
29. Use only recommended accessories;
improper accessories may be hazardous.
30. Maintain tools with care. Keep air tool clean
and oiled for best and safest performance.
31. Do not use combustible gases, carbon
dioxide, oxygen or any bottled gas as an air
source for the tool. These can present risk of
explosion and serious injury.
32. Do not lubricate the tool with combustible
liquids, such as kerosene, diesel or jet fuel.
33. Do not dispose of this tool with normal
household waste. Never dispose of the air tool
into fire.
Specific warnings for Angle Grinders
34. This grinder is designed and intended for use
by properly trained and experienced
personnel only. If you are not familiar with the
proper and safe operation of a pneumatic
angle grinder, do not use until proper training
and knowledge have been obtained.
35. Inspect grinding wheel for cracks, bends,
excessive wear, or any other deformation. Do
not use a defective wheel. If using a wire
brush, inspect for loose wires.
36. Do not get oil or water on the grinding wheel.
37. When operating grinder, place grinding wheel
against work surface immediately after
starting.
38. Use proper size grinding wheel that matches
the tool’s specifications. Do not use
unapproved flanges/bushings to adapt a
grinding wheel to the arbor.
39. The grinding wheel RPM rating must be the
same or higher than RPM rating of grinder.
40. Ensure that work piece is securely fixed by
clamps or other means, and will not move
during operation.
WARNING: This product can expose you
to chemicals including lead which is known to
the State of California to cause cancer and
birth defects or other reproductive harm. For
more information go to http://www.
p65warnings.ca. gov.
WARNING: Some dust, fumes and gases
created by power sanding, sawing, grinding,
drilling, welding and other construction
activities contain chemicals known to the State
of California to cause cancer and birth defects
or other reproductive harm. Some examples of
these chemicals are:
lead from lead based paint
crystalline silica from bricks, cement and
other masonry products
arsenic and chromium from chemically
treated lumber
Your risk of exposure varies, depending on
how often you do this type of work. To reduce
your exposure to these chemicals, work in a
well-ventilated area and work with approved
safety equipment, such as dust masks that are
specifically designed to filter out microscopic
particles. For more information go to
http://www.p65warnings.ca.gov/ and http://
www.p65warnings.ca.gov/wood.
Familiarize yourself with the following safety
notices used in this manual:
This means that if precautions
are not heeded, it may result in serious, or even
fatal, injury.
This means that if precautions
are not heeded, it may result in minor injury
and/or possible tool damage.
JET 3
About this manual
This manual is provided by JET, covering the safe operation and maintenance procedures for a JET Model
JAT-464/-465/-467 Pneumatic Angle Grinder. This manual contains instructions on safety precautions,
general operating procedures, maintenance procedures and parts breakdown. Your tool has been designed
and constructed to provide consistent, long-term operation if used in accordance with the instructions set
forth in this document.
The instructions and warnings in this manual may not encompass all possible workplace environments. The
operator is expected to take appropriate precautions and exercise common sense. As with any tool
operation, safety of operator and bystanders should be first priority.
If there are questions or comments, please contact your local supplier or JET. JET can also be reached at
our web site: www.jettools.com.
Record the serial number and purchase information of your tool on the cover of this manual for quick access.
Retain this manual for future reference. If the tool transfers ownership, the manual should accompany it.
Register your product using the mail-in card provided, or register online:
http://www.jettools.com/us/en/service-and-support/product-registration/
4 JAT-464,-465,-467 Pneumatic Angle Grinder
Tool specifications
Model JAT-464 JAT-465
Stock number 505464 505465
Wheel size
(Dia x Bore x Thk)
Wheel type Type 27 Type 27
Spindle thread 5/8in.–11UNC 7/8in.– 9UNC
Horsepower 1.2 1.2
Free speed 13,000 RPM 12,000 RPM
Air consumption –
free speed
Air consumption –
under load
Air Inlet 3/8 in. NPT 3/8 in. NPT
Air Hose inside diameter 1/2 in. 1/2 in. 1/2 in.
Required air pressure 90 psi (6.2 bar) 90 psi (6.2 bar)
Vibration value 6.1 m/s2 5.78 m/s2
Sound power 1 98.0 dB(A) 98.0 dB(A)
Sound pressure 1 87 dB(A)
Speed settings Variable throttle lever Variable throttle lever
Overall length 8.8 in. (223.5mm) 8.8 in. (223.5mm)
Housing material
Net weight 2.98 lb. (1.35 kg) 3.17 lb. (1.44 kg)
Shipping weight 3.77 lb. (1.7 kg) 3.98 lb. (1.8 kg)
4 x 5/8 x 1/4 in.
(101.6x15.88x6.35mm)
21.3 SCFM / 3CFM at
90psi
34.3 SCFM / 4.8CFM at
90psi
Aluminum with
composite sleeve
5 x 7/8 x 1/4 in.
(127 x 22.23 x 6.35mm)
17.6 SCFM / 2.5CFM at
90psi
30 SCFM / 4.2CFM at
90psi
87 dB(A) 88.4 dB(A)
Aluminum with
composite sleeve
JAT-467
505467
7 x 7/8 x 1/4 in.
(178 x 22.23 x 6.35mm)
Type 27
7/8in.– 9UNC
1.8
7,600 RPM
32 SCFM / 4.5CFM at
90psi
38 SCFM / 5.3CFM at
90psi
3/8 in. NPT
90 psi (6.2 bar)
5.43 m/s
99.4 dB(A)
Variable throttle lever
11 in. (279.4mm)
Aluminum with
composite sleeve
5.5 lb. (2.5 kg)
7.18 lb. (3.26 kg)
2
1
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As
workplace conditions vary, this information is intended to allow the user to make a better estimation of the
hazards and risks involved only.
Specifications were current at time of publication, but because of our policy of continuous improvement, JET
reserves the right to change specifications at any time and without prior notice, without incurring obligations.
JET 5
