Pneumatic Angled Die Grinder
#505405, JAT-405
#505406, JAT-406
JAT-406
JAT-405
Operation & Parts Manual
M-505405
Edition 2
06/2015
JET
427 New Sanford Road
LaVergne, T N 37086
Ph.: 800- 274- 6848
www.jettools.com
Copyright © 2015 JET
Warranty and Service
–
JET warrants every product it sells against manufacturers’ defects. If one of our tools needs service or repair, please contact
Technical Service by calling 1-800-274-6846, 8AM to 5PM CST, Monday through Friday.
Warranty Period
The general warranty lasts for the time period specified in the literature included with your product or on the official JET branded
website.
• JET products carry a limited warranty which varies in duration based upon the product. (See chart below)
• Accessories carry a limited warranty of one year from the date of receipt.
• Consumable items are defined as expendable parts or accessories expected t o become inoperable within a
reasonable amount of use and are covered by a 90 day limited warranty against manufacturer’s defects.
Who is Covered
This warranty covers only the initial purchaser of the product from the date of delivery.
What is Covered
This warranty covers any defects in workmanship or materials subject to the limitations stated below. This warranty does not cover
failures due directly or indirectly to misuse, abuse, negligence or accidents, normal wear-and-tear, improper repair, alterations or
lack of maintenance. JET woodworking machinery is designed to be used with Wood. Use of these machines in the processing of
metal, plastics, or other materials outside recommended guidelines, may void the warranty. The exceptions are acrylics and other
natural items that are made specifically for wood turning.
Warrant y Limitations
Woodworking products with a Five Year Warranty that are used for commercial or industrial purposes default to a Two Year
Warranty. Please contact Technical Service at 1-800-274-6846 for further clarification.
How to Get Technical Support
Please contact Technical Service by calling 1-800-274-6846. Please note that you will be asked to provide proof of initial
purchase when calling. If a product requires further inspection, the Technical Service representat ive will explain and assist with
any additional action needed. JET has Authorized Service Centers located throughout the United States. For the name of an
Authorized Service Center in your area call 1-800-274-6846 or use the Service Center Locat or on the JET website.
More Information
JET is constantly adding new products. For complete, up-to-date product information, check with your local distributor or visit the
JET website.
How State Law Applies
This warranty gives you specific legal rights, subject to applicable state law.
Limitations on Th is Wa rranty
JET LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD OF THE LIMITED WARRANTY FOR EACH PRODUCT. EXCEPT AS
STATED HEREIN, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATION MAY NOT APPLY TO YOU.
JET SHALL IN NO EVENT BE LI A B L E FOR DEA TH, INJURI E S TO PERSONS OR PROPERTY , OR F OR INCIDE NTA L ,
CONTINGENT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR PRODUCTS. SOME STATES
DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
JET sells through distributors only. The specifications listed in JET printed materials and on official JET website are given as
general information and are not binding. JET reserves the right to effect at any time, without prior notice, those alterations to parts,
fittings, and accessory equipment which they may deem necessary for any reason whatsoever. JET
sold in Canada by JPW Industries, Inc.
Product Listing with Warranty Period
90 Days
1 Year – Motors; Machi n e Accessori e s
2 Year – Metalworking Machinery; Electric Hoists, Electric Hoist Accessories; Woodworking Machinery used for industrial
or commercial purposes
5 Year – Woodworking Machinery
Limited Lifetime – JET Parallel clamps; VOLT Series Electric Hoists; Manual Hoists; Manual Hoist
Accessories; Shop Tools; Warehouse & Dock products; Hand Tools; Air Tools
NOTE: JET is a division of JPW Indust ries, Inc. References in this document to JET also apply to JPW Industries, Inc., or any of
its successors in interest to the JET brand.
Parts; Consumable items
®
branded products are not
2 JAT-405,406 Angled Die Grinders
Safety warn ings
General air tool warnings
1. Read and understand this entire manual
bef ore attempti ng assembl y or op erat i on .
2. Read and un derstan d all warn ings post ed on
the tool and in this m anual . Fai lure t o c ompl y
with all of th ese warni ngs may caus e seri ous
injury.
3. Replace warning labels if they become
obscured or remo ved.
4. Do not use this tool for other than its intended
use. If used for other purposes, JET disclaims
any real or implied warranty and holds itself
harmless from any injury that may result from
that use.
5. Al ways wear app roved saf ety gl ass es or fac e
shield while using this tool. (Everyday
eyeglasses only have impact resistant lenses;
they ar e not safet y glas ses.)
6. Wear ear protectors (plugs or muffs) if the
noise exceeds safe levels.
7. Wear gloves and protective clothing if
oper ation pr oduces sparks or fl ying p articles.
Gloves should be tight-fitting, withou t frayed
fing ers or hangi ng threads . Keep h ands and
body aw ay from the work ing area of to ol.
8. Some dust created by power sanding, sawing,
grinding, drilling and other construction
acti viti es c ontai ns c hem ic als know n t o c aus e
cancer, birth defects or other reproductive
harm. Some examples of these chemicals
are:
• Lead from lead based paint.
• Crystalline silica from bricks, cement and
other m as onry prod uc ts .
• Arsenic and chromium from chemically
treated lumber.
Your risk of exposure varies, depending on
how often you do this t yp e of w ork. To reduc e
your e xposure to t hese chemic als, wor k in a
well-ventilated area and work with approved
safety equipment, such as face or dust masks
that are specifically designed to filter out
microscopic particles.
9. Do not operate an air tool continually at full
throttle withou t a w ork l oad on the tool .
10. The air tool must be properly lubricated before
oper atin g.
11. Never start a percussion type air tool (chipper,
breaker, buster, etc.) without securing the
tooling in the retainer and placing the tip
against the work surface.
12. Do not operate air tool without its guards in
place. Do not modify the tool.
13. Do not operate this tool whi le tired or und er
the influence of drugs, alcohol, or any
medication.
14. Adopt a comfortable posture with proper
balance, and maintain secure footing at all
times. Non-slip footwear or anti-skid floor
strips ar e recommend ed.
15. Do not wear loose clothing or jewelry. Confine
long hair.
16. Excessive air pressure and too much free
rotati on may decr eas e lif e of th e tool an d may
caus e a haz ar d ous sit u at i on.
17. Check air hoses for wear, and keep them
away f rom heat and s harp ed ges. R epair or
replace damaged air hose immediately. Do
not carry tool by the air hose.
18. Air hose may cause tripping hazards; keep
hose away from traffic areas.
19. D o not us e this tool near flamm able objects ,
or in potentially explosive environments. Do
not use near live electrical wires.
JET 3
20. Do not use power tools in damp or wet
locat ion, or expose t hem t o rain. Keep w ork
area well lighted.
21. Do not leave a connected tool unattended.
When not in use, disconnect tool from air
source.
22. Shut off air supply and discharge any residual
pressure from tool before removing hose,
making adjustments, changing accessories,
or storing tool.
23. Make sure tool is switched off, and your finger
off the trigger, before connecting to air supply.
24. Remo ve adj ustin g keys and wr ench es bef or e
turnin g on t ool.
25. Keep visitors a safe distance from the work
area. Keep children away.
26. Give your work undivided attention. Looking
around, carrying on a conversation and
“horse-play” are careless acts that can result
in seriou s injury.
30. Use only recommended accessories;
impr op er access ories may be haz ar d ous .
31. Maint ain t ools with care. Keep air t ool clean
and oiled for best and safest performance.
32. Do not use combustible gases, carbon
dioxide, oxygen or any bottled gas as an air
source f or the tool. Th es e can present r isk of
explosion and serious injury.
33. Do not lubricate the tool with combustible
liquids, such as kerosene, diesel or jet fuel.
34. Do not dispose of this tool with normal
household waste. Never dispose of the air tool
into fire.
Specific warnings for Die Grinders
35. This die grinder is designed for deburring,
polishing, gr i ndi ng and s ur f ac e prepar ati on. If
you are not f amiliar with th e prop er and safe
operation of a pneumatic die grin der, do not
use unt il pr oper trai ning and kn owl edg e have
been obtained .
27. D o not forc e a tool or att achm ent to do a job
for which it was not designed. The righ t tool
will do the job better and more safely.
28. Repetitive motions and/or exposure to
constant vibration can be harmful to hands
and arms. Take frequent breaks and relax
hands during extended operation. Change
posture to avoid dis comf ort or f at ig u e.
29. Compressed air can be harmful if directed
toward s ensiti ve areas of th e body, and may
propel small particles caught in the air stream.
Exerc ise proper c auti on.
Familiarize yourself with the following safety notices used in this manual:
Th is means t hat if preca utions are not he eded, it may resu lt in serio us, or ev en
fatal, injury.
This means that if precautions are not heeded, it may result in minor injury and/or
possible tool damage.
36. Sp eed rating of tool att ach m ent m us t equ al or
exceed rated free speed of die grinder.
37. Make sure attachment is securely inserted
into collet and collet nut is tight.
38. Make sure workpiece is secure and will not
shift while operat ing di e grin der. D o not h old
workpi eces with y our han d.
39. U se onl y attach ments d esign ed for th e coll et
size of die grinder. Do not modify an
attachment or use bushings, wheel flanges,
etc., to mount an attachment of incorrect size.
4 JAT-405,406 Angled Die Grinders
About this manual
This manual is provided by JET, covering the safe operation and maintenance procedures for a JET Model
JAT-405 and JAT-406 Pneumatic Angled Die Grinder. This manual contains instructions on safety
prec autions , gener al operatin g proc edures, m ainten ance pr ocedur es and parts breakd own. Your t ool has
been d esig n ed and c onstr uct ed to pr o vid e c onsist ent, lon g-t erm op eration if us ed i n ac c ordanc e w ith t h e
instructions set forth in this document.
The instructions and warnings in this manual may not encompass all possible workplace environments. The
operator is expected to take appropriate precautions and exercise common sense. As with any tool
oper ati on, safet y of op erator and b yst an d ers sh ou ld be fir s t priority.
If th ere are ques ti ons or comments, pl eas e contact you r local su pp lier or J E T . J E T can also be reac h ed at
our web site: www.jettools.com.
Record the serial number and purchase information of your tool on the cover of this manual for quick access.
Retain this manual for future reference. If the tool transfers ownership, the manual should accompany it.
JET 5
Tool speci fications
Model number JAT-405 JAT-406
Stock number 505405 505406
Degree of angle 90 115
Collet size 1/4 in. 1/4 in.
Horsepower 0.3 0.3
Free speed 20,000 RPM 20,000 RPM
Average air consumption 2.5 CFM 2.5 CFM
Air inlet 1/4 in. NPT 1/4 in. NPT
Air hose inside diameter 3/8 in. 3/8 in.
Required air pres s ure 90 psi (62 1 kP a) 90 psi (62 1 kP a)
Vibration val u e 1.24 m/s2 1.24 m/s2
Nois e lev el 1 97 dB(A) 87 dB(A)
Speed setting variable
Grip Inline Inline
Overall Length 6-1/2 in. (165 mm) 7-15/16 in. (201.6 mm)
variable
Housing material Aluminum with rubber grip Aluminum wi th rubber grip
Net weight 1.40 lb. (0.64 kg) 1.45 lb. (0.66 kg)
Shipping weight 1.60 l b. (0.7 3 kg) 1.78 lb. (0.81 k g)
1
The specif ied val ues ar e emiss ion l evels an d ar e not nec ess aril y to be seen as s afe oper atin g levels . As
workpl ac e condit i ons var y, this informat ion is int end ed to al low the us er to mak e a better esti mati on of th e
hazards and ri sks involved only.
Specifications were current at time of publication, but because of our policy of continuous improvement, JET
reserves the right to change specifications at any time and without prior notice, without incurring obligations.
6 JAT-405,406 Angled Die Grinders
Setup an d A ss em bly
Any missing parts or damage should be reported
immediately to your JET
damaged tool. Read this instruction manual
thorou g hl y for oper at i on , m ai ntenance and s afety
instructions.
®
distr ibutor. Do no t use a
IMPORTANT: Connecting a quick-change
coupling directly to the tool is not
recommended, as vibration may cause the
connection to fail. Instead, add a leader hose
and install any quick-change couplings
farther down the line.
5. Select speed with air regulator dial.
Box contents:
1 Die grinder
2 Wrenches
1 Operat i on and p ar ts m anu al
1 Warranty card
Operation
The die grinder must be
properly lubricated before operation. See
“Lubricati on” se ctio n.
6. Grip tool with both hands and push safety
lev er forw a r d t o re le a se throt tl e lever. Ge nt l y
press throttle lever.
7. Release throttle lever to stop die grinder.
Maintenance
Lubrication
The die grinder should be lubricated daily (or
before each use) with air tool oil through the air
inlet. Durin g conti nual op erati on, it s hould b e reoiled every 1 to 2 hours. This can be done with an
in-line oiler, or manually. If done manually,
proc eed as f oll ows :
1. D is c onn ec t air h os e f r om tool.
2. P l ac e 4 or 5 dr ops of air tool oil into air inlet.
NOTE: Air tool oil not provided; it is available
at most major hardware and tool stores. SAE
#10 oil or s ewing mach ine oil may b e us ed
as a substitute. Do not use detergent oil.
Figure 1 (JAT-405 shown)
1. Loosen collet nut using the two wrenches on
the fl ats of th e collet n ut and spi ndle (Fig ure
1). Keep wr ench on spi nd le st ation ar y whil e
turnin g wr ench on coll et nu t.
2. Fully insert 1/4-inch shank of grinding
attachment (not included) into collet, and
retigh t en collet nut s ecur el y wi th wr enc hes.
3. Remove protecti v e cap from air i nl et (Figur e
1). If an in-line oil er is not bei ng used, add 4
or 5 dr ops of air t ool oil ( not i nclud ed) i n to
the air inl et.
4. Blow out air line to remove any dirt or
moisture, then connect air supply hose to
tool. Set air pressure to 90psi.
3. Re-connect air. Run die grinder at low
throttle without load for a few seconds to
distri bu te the oil thr oug hout tool.
4. When finished operating die grinder,
disconnect air hose. Wipe off housing with a
dry cloth. Place 4 or 5 drops of air tool oil into
air inlet; re-connect air and run tool for a few
seconds t o distribut e th e oil. Dis connect air .
The die grinder h as b een pre-gr eased fr om the
manuf actur er, and it is gener ally u nneces sary t o
grease the tool during its normal lif e. However,
should th e tool req uir e fut ur e s ervici ng, a gr eas e
fitting is supplied on the head. Use Lithium
Compl e x M oly 2 greas e or equi valent.
Periodically apply 1 or 2 drops of air tool oil to
throttle lever and safety lever pivots, and work
lever to distribute th e oil.
JET 7
Storage
Rule of Th um b
Avoid storing the die grinder in very humid
locations which promotes rusting of internal
mechan isms. A lways oil t he tool and disc onnect
air hose before storage.
Air system requi rements
1. Use proper air hose size (refer to tool
specifications). The hose should be just long
enough to serve the working area. Excessive
hose len gt h wil l c ause pressur e drop.
2. Make sure air compressor supplies clean,
dry air at correct CFM for the tool.
3. Set air pressure to 90 psi.
Excess air pressure
and/or un clean air will sh orten the tool’ s
life and may create a hazardous situation.
4. Drain water f rom air com press or tan k dail y,
as well as any condens ation from air lin es.
W ater in th e air lin e may enter the tool an d
cause damage.
5. C h ang e f ilt ers on t h e air syst em on a reg ul ar
basis.
6. Air-line pressure may be increased
accor di n gly to compensate f or extra- l ong air
hoses (usually over 25 feet). Inside diameter
of hos e sh oul d b e mini m um 3/8-inc h .
General Air Tool
Information
If it takes more than 8 seconds to tighten or loosen
a bolt or nut with an air impact wrench at
maxim um settin g, the air wrenc h is t oo smal l or
the air compressor CFM is not powerful enough
for the job. Continued use in either capacity will
cause damage to the tool.
Tool Pressure
JET Air Tools oper ate on 70- to-100 ps i (pounds
per square inch) air pressure measured at the tool
when the tool is operating. Set tool to 90 psi
unless indicated otherwise. Pressure in excess of
100 psi will shorten the life of the tool.
Air System Recommendations
Equip the air compressor intake with a
replaceable air filter that can be easily cleaned.
Use safety shut-off valves so air flow can be
stopped quickly in case of a line break.
W hen using multip le hos es, air hoses shou ld be
larger than leader hose. Join multiple hoses
directly, rather than with quick connect fittings
which m ay caus e pressure dr ops and tool power
reduction.
Use anti-whip devices across hose couplings to
prevent hose from whipping in the event of a hose
failur e or c oup li ng dis connec t.
Always us e m oist ure tr aps at th e c ompr ess or f or
the main distr ib ut ion line. Use mois ture traps an d
in-lin e oilers on eac h down line th at is to be used
for air tools. (See Figure 2). Place oiler as close to
air tool as possible f or best lubric ati on.
If the air tool is not performing according to
specif ications , th e foll owing are am ong t he most
common causes. (See also “Troubleshooting”
section.)
• C ontamin ated air suc h as a dirty air system
or water in the system .
• Using wrong size tool for the job.
• P oor main tenanc e pr actic es, suc h as usin g
excessive air pressure or air volume.
• Improper or no lubrication.
8 JAT-405,406 Angled Die Grinders
Lubrication
Use a lig ht oil contai ning rust in hibitors, such as
SAE #10. Many JET air tools have integral oil
reservoirs, which should be kept filled when in-line
oilers ar e not used.
If greasing is required, use a grease that is highly
water resis tant for f ront c ase c ompon ents on air
impact w renches, gr in d ers and sander s .
Recycling
Protect the environment. Your tool contains
materials which can be recovered or recycled.
W hen its us eful life has expired, please leave tool
at a specialized facility.
Figure 2
Recommended arrangement of air piping and air line system
JET 9
Troubl es h oo tin g J AT -4 05/ 40 6 A ngl e d Di e Gri nd er s
Any dis ass embly of the tool should be don e by qualifi ed s ervic e personn el. For probl ems not addr ess ed
below, contact JET technical service at 800-274-6846.
Problem Possible cause Remedy
Tool will not st art . Air val v e cl os ed or obs tr uc t ed. Open val v e; cl ear an y obstruct i ons .
Starts im m ed i ately as soon
as air is connected without
lever b ei ng pressed.
Exc essive or abn orm al
vibration.
Loss of power; erratic
action.
Sever e air l eak ag e.
(Note: M inim a l escape of
air is oft en n or m al f or air
tools.)
Exc essive heat d ev el ops
in tool.
Dirt or gu m d eposits on
components.
Rotor van es or ot h er c om ponents
are wor n.
Thr ottl e l ever m alf u nc ti on. Clean throttl e lev er mechanis m to
Bearin g( s ) w orn. Disass embl e and inspect bearing.
Thr ottl e valve malf unc t i on. Inspect and rep air t hr ot tl e val v e.
Impr op er lubr ication. Lubricate prop er l y accordin g to
Bearin gs w orn. Disassembl e an d ins p ect bearin g.
Low air pressure. Verify compressor has proper CFM
Moisture or obstr uction in air
hose.
Impr op er size of air tr ans m is s i on
lines, h oses, fitti ngs , or
couplings.
Dirt or gu m d eposits on
components.
Rotor van es are worn. R epl ac e vanes (ent ire set).
Air valv e obs truct ed or dam aged. Clean or rep l ac e.
Housi ng loose or damag ed. Tight en or r ep l ac e as n eed ed.
Impr op er lubr ication. Lubricate prop er l y accordin g to
Flush tool wit h gu m s olvent.
If problem persists, disassemble,
clean and lubricate internal parts.
Repl ac e w orn c om p onents.
(Replace vanes as an ent ir e s et. )
ensure free movement. Replace
mechanism if needed.
Greas e or r eplace as need ed .
ins tructions in this manual.
Greas e or r eplace as need ed .
rating for tool.
Che ck compresso r regulato r
setting; set air pressure to 90 psi.
Check for loose connections at air
inlet, o-rings, etc.
Air supply must be clean and dry.
Clean ou t air h os e(s ) and r em ov e
any ki nks or b ends .
Use appr opriat e-si z ed air
lines/hoses.
Verif y pr op er f itt in gs / couplin gs .
Flush tool wit h gu m s olvent.
Check and cl ean air filt er on
compressor.
Clean e xt er n al areas of tool . If
problem persists, disassemble,
clean and lubricate internal parts.
ins tructions in this manual.
10 JAT-405,406 Angled Die Grinders
Replac em e nt par t s
Service parts are listed on the following pages. To order parts or reach our service department, call 1-800274-6 848 Mon day thr ough Fr iday, 8: 00 a.m. to 5:00 p. m. CST. P leas e have the st ock num ber an d serial
number of y our t ool available when you c all, so that we m ay s er v e yo u quickly an d acc u r ately.
JET 11
#505405, JAT-405, Right Angled Die Grinder – exploded view
12 JAT-405,406 Angled Die Grinders
#505405, JAT-405, Right Angled Die Grinder – parts list
Index Part No. Description Qty
1 JAT405-01 Motor housing 1
2 40337 Lever pin 3x18L 1
3 JSM5252-03 Air inlet 1
4 JSM5252-04 Throttle lever 1
JSM5252-04A
5 JSM5252-05 Valve shaft 1
6 JSM5252-06 Deflector 1
7 JSM3330-46 O-Ring 7.5x1.5 3
8 JSM5252-08 Spring 1
9 70109NPN O-Ring 9.8x1.9 1
10 JSM5252-10 Valve screw 1
11 52236 O-Ring 10.5x1 1
12 52212 Rotor spacer 1
13 BB-696ZZ Ball bearing 696ZZ 1
14 52214 Rear end plate 1
15 52215 Rotor 1
16 52216 Rotor vane 4
17 SM-30117 Spring pin 1.5x6 2
18 52218 Cylinder 1
19 52219 Front end plate 1
20 BB-608ZZ Ball bearing 608ZZ 3
21 JSM5252-21 Spring pin 2x15L 1
22 52222 Pinion gear 1
Throttle lever assembly
(incl. #4,21,39,41)
1
Index Pa rt No. Description Qty
23 JSM5252-23 Front coupling
24 51224
25 52225 Collet nut 1
26 JSM5252--26 Front cap 1
27 52227
28 JSM5252-28B Head 1
29 JSM5252-29 Fixed shaft 1
30 52230 Bevel gear 1
31 52231
32 SM-30107 O-Ring 3.9x1.9 1
33 52233 Spindle 1
34 JSM5252-34 Bushing 1
35 JAT406-35 O-Ring 20x1.4 1
36 52232 Key 1
37 56237 Oil ca p 3/16in. 1
38 SB-3/32 Steel ball 3/32i n. 1
39 51540 Safety lever 1
40 JAT406-40 Grip 1
41 JSM5130-41 Spring 1
42 SB-1/8 Steel Ball 1/8in. 1
43 JSM5252-43 Throttle Valve 1
46 JSM5252-46 Washer 1
51 JSM5252-51 Damping material 1
Colle t 1/ 4i n.
Double-end wrench 2
Lo ck ring 1
1
1
JAT405-RPK, Repair Kit, contains 7(3),8,9,11,16(4),35,46
JAT 405-R BK, Rebuild Kit, c ont ains 18, 2 4, 25
JET 13
#505406, JAT-406, 115° Angled Die Grinder – exploded view
14 JAT-405,406 Angled Die Grinders
#505406, JAT-406, 115° Angled Die Grinder – parts list
Index Part No. Description Qty
1 JAT405-01 Motor housing 1
2 40337 Lever pin 3x18L 1
3 JSM5252-03 Air inlet 1
4 JSM5252-04 Throttle lever 1
JSM5252-04A
5 JSM5252-05 Valve shaft 1
6 JSM5252-06 Deflector 1
7 JSM3330-46 O-Ring 7.5x1.5 3
8 JSM5252-08 Spring 1
9 JSM5252-09 O-Ring 9.8x1.9 1
10 JSM5252-10 Valve screw 1
11 52236 O-Ring 10.5x1 1
12 52212 Rotor spacer 1
13 BB-696ZZ Ball bearing 696ZZ 1
14 52214 Rear end plate 1
15 52215 Rotor 1
16 52216 Rotor vane 4
17 SM-30117 Spring pin 1.5x6 2
18 52218 Cylinder 1
19 52219 Front end plate 1
20 BB-608ZZ Ball bearing 608ZZ 3
21 JAT406-21 Crescent ring 5103-31 1
22 JAT406-22 Pinion gear 1
23 JSM5252-23 Fron t coupling 1
Throttle lever assembly
(incl. #4,21,39,41)
1
Index Pa rt No. Description Qty
24 51224
25 52225 Collet nut 1
26 JSM5252-26 Front cap 1
27 52227
28 52428 Head 1
29 JSM5252-29 Fixed shaft 1
30 JAT406-30 Bevel gear 1
31 52231
32 52232 Key 1
33 JAT406-33 Spindle 1
34 JSM5252-34 Bushing 1
35 JAT406-35 O-Ring 20x1.4 1
36 JSM5130-41 Spring 1
37 56237 Oil ca p 3/16in. 1
38 SB-3/32 Steel ball 3/32i n. 1
39 51540 Safety lever 1
40 JAT406-40 Grip 1
41 SB-1/8 Steel ball 1/8in. 1
42 SM-30107 O-Ring 3.9x1.9 1
43 JSM5252-21 Spring pin 2x15L 1
44 JAT406-44 Shim 1
45 JSM5252-43 Throttle valve 1
46 JSM5252-46 Washer 1
51 JSM5252-51 Damping material 1
Colle t 1/ 4i n.
Double-end wrench 2
Lo ck ring 1
1
JAT406-RPK, Repair Kit, contains 7(3),8,9,11,16(4),35,46
JAT 405-R BK, Rebuild Kit, c ont ains 18, 2 4, 25
JET 15
16 JAT-405,406 Angled Die Grinders
427 New Sanford Road
LaVergne, Tennessee 37086
Phone: 800-274-6848
www.jettools.com
Loading...
