JET JAT-126 Operating Instructions and Parts Manual

Pneumatic Impact Wrench
#505126, JAT-126
Operation & Parts Manual
M-505126
05/2019
JET
427 New Sanford Road
LaVergne, TN 37086
Ph.: 800-274-6848
www.jettools.com
Copyright © 2019 JET
IMPORTANT SAFETY INSTRUCTIONS
General air tool warnings
1. Read and understand this entire manual before attempting assembly or operation.
2. Read and understand all warnings posted on the tool and in this manual. Failure to comply with all of these warnings may cause serious injury.
3. Replace warning labels if they become obscured or removed.
4. Do not use this tool for other than its intended use. If used for other purposes, JET disclaims any real or implied warranty and holds itself harmless from any injury that may result from that use.
5. Always wear approved safety glasses or face shield while using this tool. (Everyday eyeglasses only have impact resistant lenses; they are not safety glasses.)
6. Wear ear protectors (plugs or muffs) if the noise exceeds safe levels.
7. Wear gloves and protective clothing if operation produces sparks or flying particles. Gloves should be tight-fitting, without frayed fingers or hanging threads. Keep hands and body away from the working area of tool.
8. Do not operate an air tool continually at full throttle without a work load on the tool.
9. The air tool must be properly lubricated before operating.
10. Never start a percussion type air tool (chipper, breaker, buster, etc.) without securing the tooling in the retainer and placing the tip against the work surface.
11. Do not operate air tool without its guards in place. Do not modify the tool.
12. Do not operate this tool while tired or under the influence of drugs, alcohol, or any medication.
13. Adopt a comfortable posture with proper balance, and maintain secure footing at all times. Non-slip footwear or anti-skid floor strips are recommended.
14. Do not wear loose clothing or jewelry. Confine long hair.
15. Excessive air pressure and too much free rotation may decrease life of the tool and may cause a hazardous situation.
16. Check air hoses for wear, and keep them away from heat and sharp edges. Repair or replace damaged air hose immediately. Do not carry tool by the air hose.
17. Air hose may cause tripping hazards; keep hose away from traffic areas.
18. Do not use this tool near flammable objects, or in potentially explosive environments. Do not use near live electrical wires.
19. Do not use power tools in damp or wet location, or expose them to rain. Keep work area well lighted.
20. Do not leave a connected tool unattended. When not in use, disconnect tool from air source.
21. Shut off air supply and discharge any residual pressure from tool before removing hose, making adjustments, changing accessories, or storing tool.
22. Make sure tool is switched off, and your finger off the trigger, before connecting to air supply.
23. Remove adjusting keys and wrenches before turning on tool.
2 JAT-126 Impact Wrench
24. Keep visitors a safe distance from the work area. Keep children away.
25. Give your work undivided attention. Looking around, carrying on a conversation and “horse-play” are careless acts that can result in serious injury.
26. Do not force a tool or attachment to do a job for which it was not designed. The right tool will do the job better and more safely.
27. Repetitive motions and/or exposure to constant vibration can be harmful to hands and arms. Take frequent breaks and relax hands during extended operation. Change posture to avoid discomfort or fatigue.
28. Compressed air can be harmful if directed toward sensitive areas of the body, and may propel small particles caught in the air stream. Exercise proper caution.
29. Use only recommended accessories; improper accessories may be hazardous.
30. Maintain tools with care. Keep air tool clean and oiled for best and safest performance.
31. Do not use combustible gases, carbon dioxide, oxygen or any bottled gas as an air source for the tool. These can present risk of explosion and serious injury.
32. Do not lubricate the tool with combustible liquids, such as kerosene, diesel or jet fuel.
33. Do not dispose of this tool with normal household waste. Never dispose of the air tool into fire.
Specific warnings for Impact Wrench
34. This impact wrench is designed for removing and installing threaded fasteners. If you are not familiar with the proper and safe operation of a pneumatic impact wrench, do not use until proper training and knowledge have been obtained.
35. Use only impact sockets in good condition. Sockets in poor condition may reduce impact power, and could break, creating a safety hazard.
36. Use only sockets designated for use with impact wrenches. Never use hand tool sockets, as they can shatter.
37. Never hold socket, drive or drive extension with your hand during operation.
38. Make sure workpiece is secure and will not shift while operating impact wrench. Do not hold workpieces with your hand.
39. Make sure fastener can withstand rated torque of impact wrench.
WARNING: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to http://www. p65warnings.ca. gov.
WARNING: Some dust, fumes and gases created by power sanding, sawing, grinding, drilling, welding and other construction activities contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Some examples of these chemicals are:
lead from lead based paint crystalline silica from bricks, cement and
other masonry products
arsenic and chromium from chemically
treated lumber Your risk of exposure varies, depending on how often you do this type of work. To reduce your exposure to these chemicals, work in a well-ventilated area and work with approved safety equipment, such as dust masks that are specifically designed to filter out microscopic particles. For more information go to http://www.p65warnings.ca.gov/ and http:// www.p65warnings.ca.gov/wood.
Familiarize yourself with the following safety notices used in this manual:
This means that if precautions
are not heeded, it may result in serious, or even fatal, injury.
This means that if precautions
are not heeded, it may result in minor injury and/or possible tool damage.
JET 3
About this manual
This manual is provided by JET, covering the safe operation and maintenance procedures for a JET Model JAT-126 Pneumatic Impact Wrench. This manual contains instructions on safety precautions, general operating procedures, maintenance procedures and parts breakdown. Your tool has been designed and constructed to provide consistent, long-term operation if used in accordance with the instructions set forth in this document.
The instructions and warnings in this manual may not encompass all possible workplace environments. The operator is expected to take appropriate precautions and exercise common sense. As with any tool operation, safety of operator and bystanders should be first priority.
If there are questions or comments, please contact your local supplier or JET. JET can also be reached at our web site: www.jettools.com.
Record the serial number and purchase information of your tool on the cover of this manual for quick access. Retain this manual for future reference. If the tool transfers ownership, the manual should accompany it.
Register your product using the mail-in card provided, or register online:
http://www.jettools.com/us/en/service-and-support/warranty/registration/
4 JAT-126 Impact Wrench
Tool specifications
Model
Stock number 505126
Square drive 1/2 in.
Bolt capacity 1 in. (M24)
Anvil retainer type Ring
Impact mechanism Twin hammer
Maximum torque 800 lbf•ft (1084.66 N•m)
Working torque
Free speed 7300 RPM
Blows per minute 1,300
Air consumption at 90psi 38.6 SCFM
Air consumption under load 25.38 SCFM
Air inlet 1/4 in. NPT
Air hose inside diameter 3/8 in.
Required air pressure 90 psi (621 kPa)
Vibration value 7.81 m/s2
Sound power 1 112.2 dB(A)
Sound pressure 1 101.2 dB(A)
Grip Pistol style
Overall Length 6.85 in. (174 mm)
Housing material Composite
Net weight 4.40 lb. (2 kg)
Shipping weight 4.55 lb. (2.06 kg)
JAT-126 Impact Wrench
140~680 lbf•ft (189.8~922 N•m)
1
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As workplace conditions vary, this information is intended to allow the user to make a better estimation of the hazards and risks involved only.
Specifications were current at time of publication, but because of our policy of continuous improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring obligations.
JET 5
Setup and Assembly
Any missing parts or damage should be reported immediately to your JET damaged tool. Read this instruction manual thoroughly for operation, maintenance and safety instructions.
Box contents:
1 Impact wrench 1 Operation and parts manual 1 Product registration card
®
distributor. Do not use a
Operation
properly lubricated before operation. See “Lubrication” section.
1. Remove protective cap from air inlet (Figure
1). If an in-line oiler is not being used, add 4 or 5 drops of air tool oil (not included) into the air inlet.
2. Blow out air line to remove any dirt or
moisture, then connect air supply hose to tool. Set air pressure to 90 psi.
IMPORTANT: Connecting a quick-change coupling directly to the tool is not
The impact wrench must be
Figure 1
recommended, as vibration may cause the connection to fail. Instead, add a leader hose and install any quick-change couplings farther down the line.
3. Push drive socket (not included) onto anvil until it clicks into position.
4. Select rotation direction: “F” for forward, “R” for reverse.
5. Set regulator switch to desired speed setting.
withstand rated torque of impact wrench.
To loosen nut or bolt:
1. Select reverse rotation.
2. Place socket over nut, hold grip firmly, and place other hand over top of housing. Gently squeeze trigger.
Important: If tool cannot loosen nut, DO NOT raise air pressure above 90 psi. If tool’s air regulator is in low setting, raise setting and retry. If tool’s regulator is already at
maximum, do not continue attempts to loosen nut with this impact wrench. Use
other methods or tools to loosen nut.
3. Release trigger to stop impact wrench.
To tighten nut or bolt:
1. Install nut as far as possible by hand.
2. Select forward rotation.
3. Place socket over nut, hold grip firmly, and place other hand over top of housing. Gently squeeze trigger.
Important: If tool stalls while tightening, DO NOT raise air pressure above 90 psi. If tools’ air regulator is in low setting, raise setting and retry. If nut will not tighten on
maximum setting, do not continue attempts to tighten nut with this impact wrench. Use other methods or tools to
tighten nut.
4. Release trigger to stop impact wrench.
NOTE: Do not overtighten. Fasteners with critical torque settings should be fully tightened with a torque wrench.
Make sure nut or bolt can
6 JAT-126 Impact Wrench
Maintenance
Lubrication
The impact wrench should be lubricated daily (or before each use) with air tool oil through the air inlet. During continual operation, it should be re­oiled every 1 to 2 hours. This can be done with an in-line oiler, or manually. If done manually, proceed as follows:
1. Disconnect air hose from tool.
2. Place 4 or 5 drops of air tool oil into air inlet (Figure 1).
NOTE: Air tool oil not provided; it is available at most major hardware and tool stores. SAE #10 oil or sewing machine oil may be used as a substitute. Do not use detergent oil.
3. Re-connect air. Run impact wrench at low throttle without load for a few seconds to distribute the oil throughout tool.
4. When finished operating impact wrench, disconnect air hose. Wipe off housing with a dry cloth. Place 4 or 5 drops of air tool oil into air inlet; re-connect air and run the tool for a few seconds to distribute the oil. Disconnect air.
Storage
Avoid storing the impact wrench in very humid locations which promotes rusting of internal mechanisms. Always oil the tool and disconnect air hose before storage.
Air system requirements
1. Use proper air hose size (refer to tool specifications). The hose should be just long enough to serve the working area. Excessive hose length will cause pressure drop.
2. Make sure air compressor supplies clean, dry air at correct CFM for the impact wrench.
3. Set air pressure to 90 psi.
Excess air pressure
and/or unclean air will shorten the tool’s life and may create a hazardous situation.
4. Drain water from air compressor tank daily, as well as any condensation from air lines. Water in the air line may enter the tool and cause damage.
5. Change filters on the air system on a regular basis.
6. Air-line pressure may be increased accordingly to compensate for extra-long air hoses (usually over 25 feet). Inside diameter of hose should be minimum 3/8-inch.
General Air Tool Information
If the air tool is not performing according to specifications, the following are among the most common causes. (See also “Troubleshooting” section.)
Contaminated air such as a dirty air system
or water in the system.
Using wrong size tool for the job.
Poor maintenance practices, such as using
excessive air pressure or air volume.
Improper or no lubrication.
Rule of Thumb
If it takes more than 8 seconds to tighten or loosen a bolt or nut with an air impact wrench at maximum setting, the air wrench is too small or the air compressor CFM is not powerful enough for the job. Continued use in either capacity will cause damage to the tool.
Tool Pressure
JET Air Tools operate on 70-to-100 psi (pounds per square inch) air pressure measured at the tool when the tool is operating. Set tool to 90 psi unless indicated otherwise. Pressure in excess of 100 psi will shorten the life of the tool.
Air System Recommendations
Equip the air compressor intake with a replaceable air filter that can be easily cleaned.
Use safety shut-off valves so air flow can be stopped quickly in case of a line break.
When using multiple hoses, air hoses should be larger than leader hose. Join multiple hoses directly, rather than with quick connect fittings which may cause pressure drops and tool power reduction.
JET 7
Use anti-whip devices across hose couplings to prevent hose from whipping in the event of a hose failure or coupling disconnect.
Always use moisture traps at the compressor for the main distribution line. Use moisture traps and in-line oilers on each downline that is to be used for air tools. (See Figure 2). Place oiler as close to air tool as possible for best lubrication.
Lubrication
Use a light oil containing rust inhibitors, such as SAE #10. Many JET air tools have integral oil reservoirs, which should be kept filled when in-line oilers are not used.
If greasing is required, use a grease that is highly water resistant for the front case components on air impact wrenches, grinders and sanders.
Recycling
Protect the environment. Your tool contains materials which can be recovered or recycled. When its useful life has expired, please leave tool at a specialized facility.
Recommended arrangement of air piping and air line system
8 JAT-126 Impact Wrench
Figure 2
Troubleshooting JAT-126 Impact Wrench
Any disassembly of the tool should be done by qualified service personnel. For problems not addressed below, contact JET technical service at 800-274-6846.
Problem Possible cause Remedy
Tool will not start. Air valve closed or obstructed. Open valve; clear any obstructions.
Dirt or gum deposits on components.
Rotor vanes or other components are worn.
Trigger inoperable. Clean trigger mechanism to ensure
Bearing(s) worn. Disassemble and inspect bearing.
Excessive or abnormal vibration.
Abnormal sound. Loose fasteners. Check tightness of housing and
Loss of power; erratic action.
Impacts sufficiently, but will not remove fastener.
Will not impact. Damaged impact mechanism. Replace mechanism.
Housing becomes hot during operation.
Bearing(s) worn. Disassemble and inspect bearing.
Low air pressure. Verify compressor has proper CFM
Moisture or obstruction in air hose.
Improper size of air transmission lines, hoses, fittings, or couplings.
Dirt or gum deposits on components.
Rotor vanes are worn. Replace vanes (entire set).
Worn socket. Use good condition sockets.
Worn impact mechanism. Replace components.
Insufficient lubrication. Lubricate with air tool oil.
Worn components. Replace components as needed.
Flush tool with gum solvent. If problem persists, disassemble, clean and lubricate internal parts.
Replace worn components. (Replace vanes as an entire set.)
free movement. Replace mechanism if needed.
Grease or replace as needed.
Grease or replace as needed.
external fasteners.
rating for tool. Check compressor regulator setting; set air pressure to 90 psi. Set regulator dial on tool to maximum setting. Check for loose connections.
Air supply must be clean and dry. Clean out air hose(s) and remove any kinks or bends.
Use appropriate-sized air lines/hoses. Verify proper fittings/couplings.
Flush tool with gum solvent. Check and clean air filter on compressor. Clean external areas of tool. If problem persists, disassemble, clean and lubricate internal parts.
JET 9
Problem Possible cause Remedy
Severe air leakage. (Note: Minimal escape of air is often normal for air tools.)
Air valve obstructed or damaged. Clean or replace.
Housing loose or damaged. Tighten or replace as needed.
10 JAT-126 Impact Wrench
Replacement parts
Service parts are listed on the following pages. To order parts or reach our service department, call 1-800­274-6848 Monday through Friday, 8:00 a.m. to 5:00 p.m. CST. Please have the stock number and serial number of your tool available when you call, so that we may serve you quickly and accurately.
Some parts are shown for reference only, and may not be available individually.
JET 11
#505126, JAT-126, 1/2-inch Impact Wrench – exploded view
12 JAT-126 Impact Wrench
#505126, JAT-126, 1/2-inch Impact Wrench – parts list
# Part No. Description Qty
101 JAT126-101 Hammer Case * 1 102 JAT126-102 Anvil Bushing * 1 103 JAT126-103 Socket Retainer * 1 104 JAT126-104 O-Ring 7x2 mm * 1 105 JAT126-105 Anvil 1/2 in. * 1 106 JAT126-106 Hammer Pin * 2 107 JAT126-107 Hammer * 2 108 JAT126-108 Hammer Frame * 1 201 JAT126-201 Screw M4x57 2 202 JAT125-202 Front End Plate Bushing * 1 203 JAT125-203 O-Ring 8x1 mm * 1 204 JAT125-204 Regulator Stem * 1 205 JAT125-205 Spring * 1 206 JAT125-206 Spring Pin 2.5x20L * 1 207 JAT126-207 Reverse Stem * 1 208 JAT126-208 O-Ring 54x1.5 mm * 1 209 BB-6002ZZ Ball Bearing 6002ZZ * 1 210 JAT126-210 Front End Plate * 1 211 JAT126-211 Cylinder 1 212 JAT126-212 Rotor Vane 6 213 JAT126-213 Rotor 1 214 JAT126-214 Rear End Plate * 1 215 BB-6001ZZ Ball Bearing 6001ZZ * 1 216 JAT126-216 O-Ring 33x2 mm * 1 217 JAT126-217 Screw M4x48 1 301 JAT126-301 Housing 1 302 JAT125-302 Valve Seat * 1 303 JAT125-303 Valve Stem * 1 304 JAT125-304 Spring * 1
# Part No. Description Qty
305 JAT125-305 Muffler 1 306 JAT125-306 Exhaust Deflector 1 307 JAT102-09 Screw M3x8 1 308 JAT125-308 O-Ring 12x3 mm * 2 309 JAT125-309 Air Inlet NPT18 * 1 310 F012088 401 JAT125-401 Trigger Assembly * 1 402 JAT125-402 Regulator Stem * 1 403 JAT125-403 Spring * 1 404 SB-2.5MM Steel Ball 2.5 mm * 1 405 JAT126-405 Reverse Button * 1 406 JAT126-406 Forward Button * 1 407 JAT125-407 O-Ring 7.6x1 mm * 2 408 JAT125-408 Nyloc SHC Screw M4x18 1 409 JAT126-409 Screw M4x84 4 410 JAT126-410 Gasket 1 411 JAT126-411 Gasket 1
JAT126-HCK Hammer Case Kit - #101,102 JAT126-AA Anvil Assembly - #103,104,105 JAT126-HK Hammer Kit - #106(2),107(2),108
JAT126-FEPK
JAT126-REPK
JAT125-AIK
JAT126-TK
Spring Pin 3x30 mm *
Front End Plate Kit - #202,203, 204,205,206,208,209,210 Rear End Plate Kit ­#214,215,216 Air Inlet Kit ­#302,303,304,308(2),309,310 Trigger Kit - #207,401,402,403, 404,405,406,407(2)
1
* These parts are only provided in the larger kit or assembly.
JET 13
Warranty and Service
JET warrants every product it sells against manufacturers’ defects. If one of our tools needs service or repair, please contact Technical Service by calling 1-800-274-6846, 8AM to 5PM CST, Monday through Friday.
Warranty Period The general warranty lasts for the time period specified in the literature included with your product or on the official JET branded website.
JET products carry a limited warranty which varies in duration based upon the product. (See chart below) Accessories carry a limited warranty of one year from the date of receipt. Consumable items are defined as expendable parts or accessories expected to become inoperable within a reasonable
amount of use and are covered by a 90 day limited warranty against manufacturer’s defects.
Who is Covered
This warranty covers only the initial purchaser of the product from the date of delivery.
What is Covered
This warranty covers any defects in workmanship or materials subject to the limitations stated below. This warranty does not cover failures due directly or indirectly to misuse, abuse, negligence or accidents, normal wear-and-tear, improper repair, alterations or lack of maintenance. JET woodworking machinery is designed to be used with Wood. Use of these machines in the processing of metal, plastics, or other materials outside recommended guidelines, may void the warranty. The exceptions are acrylics and other natural items that are made specifically for wood turning.
Warranty Limitations
Woodworking products with a Five Year Warranty that are used for commercial or industrial purposes default to a Two Year Warranty. Please contact Technical Service at 1-800-274-6846 for further clarification.
How to Get Technical Support Please contact Technical Service by calling 1-800-274-6846. Please note that you will be asked to provide proof of initial purchase when calling. If a product requires further inspection, the Technical Service representative will explain and assist with
any additional action needed. JET has Authorized Service Centers located throughout the United States. For the name of an Authorized Service Center in your area call 1-800-274-6846 or use the Service Center Locator on the JET website.
More Information
JET is constantly adding new products. For complete, up-to-date product information, check with your local distributor or visit the JET website.
How State Law Applies
This warranty gives you specific legal rights, subject to applicable state law.
Limitations on This Warranty
JET LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD OF THE LIMITED WARRANTY FOR EACH PRODUCT. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. JET SHALL IN NO EVENT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY, OR FOR INCIDENTAL, CONTINGENT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF OUR PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
JET sells through distributors only. The specifications listed in JET printed materials and on official JET website are given as general information and are not binding. JET reserves the right to effect at any time, without prior notice, those alterations to parts, fittings, and accessory equipment which they may deem necessary for any reason whatsoever. JET sold in Canada by JPW Industries, Inc.
Product Listing with Warranty Period
90 Days – Parts; Consumable items 1 Year – Motors; Machine Accessories; Air Tool Accessories 1 Year Wear and Tear – Air Tools 2 Year – Metalworking Machinery; Electric Hoists, Electric Hoist Accessories; Woodworking Machinery used for industrial or commercial purposes 3 Year – Woodworking Bench Top Machinery 5 Year – Woodworking Machinery Limited Lifetime – JET Parallel clamps; VOLT Series Electric Hoists; Manual Hoists; Manual Hoist Accessories; Shop Tools; Warehouse & Dock products; Hand Tools: Air Tools
NOTE: JET is a division of JPW Industries, Inc. References in this document to JET also apply to JPW Industries, Inc., or any of its successors in interest to the JET brand.
®
branded products are not
14 JAT-126 Impact Wrench
JET 15
16 JAT-126 Impact Wrench
427 New Sanford Road
LaVergne, Tennessee 37086
Phone: 800-274-6848
www.jettools.com
Loading...
