Jenn-Air JES1750FS User Manual

User Guide

Electric Downdraft Range

THANK YOU for purchasing this high-quality product. Register your range at www.jennair.com. In Canada, register your range at www.jennair.ca.

For future reference, please make a note of your product model and serial numbers. These can be found on the label located on the oven frame behind the top right side of the oven door.

Model Number______________________________________________ Serial Number_______________________________________________

Para una versión de estas instrucciones en español, visite www.jennair.com. Deberá tener a mano el número de modelo y de serie, que están ubicados en el marco del horno, detrás del lado derecho superior de la

puerta del horno.

Table of Contents

RANGE SAFETY .............................................................................2

The Anti-Tip Bracket ....................................................................2

KEY USAGE TIPS ...........................................................................4

AquaLift® Self-Cleaning Technology ............................................4

Surface Temperatures ..................................................................4

Preheating ....................................................................................4

Ceramic Glass Cooktop Cleaning ...............................................4

FEATURE GUIDE ............................................................................5

Electronic Oven Controls .............................................................7

COOKTOP .......................................................................................9

Downdraft Ventilation System ....................................................10

Cookware ...................................................................................11

Home Canning ...........................................................................11

OVEN .............................................................................................12

Aluminum Foil .............................................................................12

Positioning Racks and Bakeware ..............................................12

Roll-Out Rack .............................................................................13

Oven Vent ...................................................................................14

Sabbath Mode............................................................................14

Baking and Roasting ..................................................................14

Broiling........................................................................................14

Convection Cooking ..................................................................15

Prooﬁng Bread ...........................................................................15

Favorite .......................................................................................15

Cook Time ..................................................................................16

Oven Light ..................................................................................16

RANGE CARE ...............................................................................17

Clean Cycle ................................................................................17

General Cleaning ........................................................................18

TROUBLESHOOTING ..................................................................20

ACCESSORIES .............................................................................22

WARRANTY ..................................................................................23

W10896663A

Range Safety

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or hurt you and others.

All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”

These words mean:

You can be killed or seriously injured if you don't immediately

DANGER

WARNING

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

The Anti-Tip Bracket

The range will not tip during normal use. However, the range can tip if you apply too much force or weight to the open door without having the anti-tip bracket fastened down properly.

follow instructions.

You

can be killed or seriously injured if you don't

instructions.

WARNING

Tip Over Hazard A child or adult can tip the range and be killed. Verify the anti-tip bracket has been properly installed and engaged per installation instructions. Re-engage anti-tip bracket if range is moved. Do not operate range without anti-tip bracket installed and engaged. Failure to follow these instructions can result in death or serious burns to children and adults.

To verify the anti-tip bracket is installed and engaged:

Anti-Tip Bracket

Range Foot

State of California Proposition 65 Warnings: WARNING: This product contains one or more chemicals known to the State of California to cause cancer. WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other

reproductive harm.

• Slide range forward.

• Look for the anti-tip bracket securely attached to floor or wall.

• Slide range back so rear range foot is under anti-tip bracket.

• See installation instructions for details.

IMPORTANT SAFETY INSTRUCTIONS

WARNING: To reduce the risk of fire, electrical shock,

injury to persons, or damage when using the range, follow basic precautions, including the following:

■ WARNING:

THE RANGE, THE RANGE MUST BE SECURED BY PROPERLY INSTALLED ANTI-TIP DEVICES. TO CHECK IF THE DEVICES ARE INSTALLED PROPERLY, SLIDE RANGE FORWARD, LOOK FOR ANTI-TIP BRACKET SECURELY ATTACHED TO FLOOR OR WALL, AND SLIDE RANGE BACK SO REAR RANGE FOOT IS UNDER ANTI-TIP BRACKET.

■ CAUTION: Do not store items of interest to children in

cabinets above a range or on the backguard of a range – children climbing on the range to reach items could be seriously injured.

■ Proper Installation – Be sure the range is properly installed

and grounded by a qualified technician.

■ Never Use the Range for Warming or Heating the Room.

■ Do Not Leave Children Alone – Children should not be left

alone or unattended in area where the range is in use. They should never be allowed to sit or stand on any part of the range.

Wear Proper Apparel – Loose-fitting or hanging garments

■

should never be worn while using the range. User Servicing – Do not repair or replace any part of the

■

range unless specifically recommended in the manual. All other servicing should be referred to a qualified technician.

■ Storage in or on the Range – Flammable materials should

not be stored in an oven or near surface units.

■ Do Not Use Water on Grease Fires – Smother fire or flame

or use dry chemical or foam-type extinguisher.

■ Use Only Dry Potholders – Moist or damp potholders on

hot surfaces may result in burns from steam. Do not let potholder touch hot heating elements. Do not use a towel or other bulky cloth.

■ DO NOT TOUCH SURFACE UNITS OR AREAS NEAR

UNITS – Surface units may be hot even though they are dark in color. Areas near surface units may become hot enough to cause burns. During and after use, do not touch, or let clothing or other flammable materials contact surface units or areas near units until they have had sufficient time to cool. Among those areas are the cooktop and surfaces facing the cooktop.

■ Use Proper Pan Size – The range is equipped with one or

more surface units of different size. Select utensils having flat bottoms large enough to cover the surface unit heating element. The use of undersized utensils will expose a portion of the heating element to direct contact and may result in ignition of clothing. Proper relationship of utensil to burner will also improve efficiency.

■ Never Leave Surface Units Unattended at High Heat

Settings – Boilover causes smoking and greasy spillovers that may ignite.

■ Make Sure Reflector Pans or Drip Bowls Are in Place –

Absence of these pans or bowls during cooking may subject wiring or components underneath to damage.

TO REDUCE THE RISK OF TIPPING OF

■ Protective Liners – Do not use aluminum foil to line surface

unit drip bowls or oven bottoms, except as suggested in

the manual. Improper installation of these liners may result

in a risk of electric shock, or fire.

Glazed Cooking Utensils – Only certain types of glass,

■

glass/ceramic, ceramic, earthenware, or other glazed

utensils are suitable for range-top service without breaking

due to the sudden change in temperature.

■ Utensil Handles Should Be Turned Inward and Not Extend

Over Adjacent Surface Units – To reduce the risk of burns,

ignition of flammable materials, and spillage due to

unintentional contact with the utensil, the handle of a

utensil should be positioned so that it is turned inward, and

does not extend over adjacent surface units.

■ Do Not Soak Removable Heating Elements – Heating

elements should never be immersed in water.

■ Do Not Cook on Broken Cooktop – If cooktop should

break, cleaning solutions and spillovers may penetrate the

broken cooktop and create a risk of electric shock. Contact

a qualified technician immediately.

■ Clean Cooktop With Caution – If a wet sponge or cloth is

used to wipe spills on a hot cooking area, be careful to

avoid steam burn. Some cleaners can produce noxious

fumes if applied to a hot surface.

Use Care When Opening Door – Let hot air or steam

■

escape before removing or replacing food.

Do Not Heat Unopened Food Containers – Build-up of

■

pressure may cause container to burst and result in injury.

■ Keep Oven Vent Ducts Unobstructed.

■ Placement of Oven Racks – Always place oven racks in

desired location while oven is

cool. If rack must be moved while oven is hot, do not let potholder contact hot heating element in oven.

DO NOT TOUCH HEATING ELEMENTS OR INTERIOR

■

SURFACES OF OVEN – Heating elements may be hot even though they are dark in color. Interior surfaces of an oven become hot enough to cause burns. During and after use, do not touch, or let clothing or other flammable materials contact heating elements or interior surfaces of oven until they have had sufficient time to cool. Other surfaces of the appliance may become hot enough to cause burns – among these surfaces are oven vent openings and surfaces near these openings, oven doors, and windows of oven doors.

For self-cleaning ranges –

■ Do Not Clean Door Gasket – The door gasket is essential

for a good seal. Care should be taken not to rub, damage, or move the gasket.

■ Do Not Use Oven Cleaners – No commercial oven cleaner

or oven liner protective coating of any kind should be used in or around any part of the oven.

■ Clean Only Parts Listed in Manual.

■ Before Self-Cleaning the Oven – Remove broiler pan and

other utensils.

For units with ventilating hood –

■ Clean Ventilating Hoods Frequently – Grease should not

be allowed to accumulate on hood or filter.

■ When flambeing foods under the hood, turn the fan on.

SAVE THESE INSTRUCTIONS

Key Usage Tips

AquaLift® Self-Cleaning Technology

AquaLift® Self-Cleaning Technology is a ﬁrst-of-its-kind cleaning solution designed to minimize the time, temperature, and odors that ordinarily come with traditional self-cleaning methods. With AquaLift® Self-Cleaning Technology, an exclusive coating on the interior of the oven is activated with heat and water to release baked-on soil. To use AquaLift® Self-Cleaning Technology, simply wipe out loose debris, pour water into the oven bottom, and run the AquaLift® Self-Cleaning cycle. When the cycle ﬁnishes in under 1 hour at a lower temperature than in traditional self-cleaning methods, just wipe out the remaining water and loose debris. See the “Clean Cycle” section for more detailed instructions. For additional information, frequently asked questions, and videos on using AquaLift® Self-Cleaning Technology, visit our website at http://whirlpoolcorp.com/aqualift.

Surface Temperatures

When the range is in use, all range surfaces may become hot, such as the knobs and oven door.

Baking Drawer

When the oven is in use, the drawer may become hot. Do not store plastics, cloth, or other items that could melt or burn in the drawer.

Ceramic Glass Cooktop Cleaning

To avoid damaging the cooktop, do not use steel wool, abrasive powder cleansers, chlorine bleach, rust remover, or ammonia.

1. Remove food/residue with the Cooktop Scraper.

■ For best results, use the Cooktop Scraper while the

cooktop is still warm but not hot to the touch. It is recommended to wear an oven mitt while scraping the warm cooktop.

■ Hold the Cooktop Scraper at approximately a 45° angle

against the glass surface and scrape the residue. It will be necessary to apply pressure in order to remove the residue.

Allow the cooktop to cool down completely before proceeding to Step 2.

2. Apply a few dime-sized drops of affresh® Cooktop Cleaner to

the affected areas.

Oven Vent

The oven vent releases hot air and moisture from the oven and should not be blocked or covered. Do not set plastics, paper, or other items that could melt or burn near the oven vent.

Preheating

When beginning a Bake, Convect Bake, or Convect Roast cycle, the oven will begin preheating after Start is pressed. The oven will take approximately 12 to 15 minutes to reach 350°F (177°C) with all of the oven racks provided with your oven inside the oven cavity. Higher temperatures will take longer to preheat. The preheat cycle rapidly increases the oven temperature. The actual oven temperature will go above your set temperature to offset the heat lost when your oven door is opened to insert food. This ensures that when you place your food in the oven, the oven will begin at the proper temperature. Insert your food when the preheat tone sounds. Do not open the door during preheat before the tone sounds.

■ Rub affresh

with the Blue Cooktop Cleaning Pad. Some pressure is needed to remove stubborn stains.

■ Allow the cleaner to dry to a white haze before proceeding

to Step 3.

3. Polish with a clean, dry cloth or a clean, dry paper towel.

■ Repeat steps 1 through 3 as necessary for stubborn or

burned-on stains.

The Complete Cooktop Cleaner Kit is available for order including the following:

■ Cooktop Scraper

■ affresh

■ Blue Cooktop Cleaning Pads

See the “Accessories” section for part numbers and information on ordering.

Cooktop Cleaner onto the cooktop surface

Cooktop Cleaner

Feature Guide

WARNING

This manual covers several models. Your model may have some or all of the items listed. Refer to this manual or the Product Help section of our website at www.jennair.com for more detailed instructions. In Canada, refer to the Product Help Section at www.jennair.ca.

Food Poisoning Hazard

Do not let food sit for more than one hour before or after cooking.

Doing so can result in food poisoning or sickness.

Keypad Feature Instructions

OPTIONS/CLOCK Clock

OPTIONS/CLOCK Settings

LIGHT Oven cavity

light

TIMER SET/OFF Oven timer

START Cooking start

CANCEL Range function BAKE Baking and

roasting

BROIL Broiling

The Clock can use a 12- or 24-hour cycle. See the “Electronic Oven Controls” section.

1. Press OPTIONS/CLOCK until “CLOCK” is displayed.

2. Use the number keypads to set the time of day.

3. Press START to change the time.

4. Press “3” for AM or “6” for PM.

Enables you to personalize the audible tones and oven operation to suit your needs. See the “Electronic Oven Controls” section.

The oven light is controlled by a keypad on the oven control panel. While the oven door is closed, press LIGHT to turn the light on and off. When the oven door is opened, the oven light will automatically come on.

The Timer can be set in hours or minutes up to 9 hours and 59 minutes.

1. Press TIMER SET/OFF.

2. Press the number keypads to set the length of time in hr-min-min. Leading zeros do not

have to be entered. For example, for 2 minutes, enter “2.”

3. Press TIMER SET/OFF to begin the countdown. If enabled, one tone will sound at end of

countdown.

4. Press TIMER SET/OFF again to cancel the Timer and return to the time of day. Do not

press CANCEL because the oven will turn off.

5. If the Timer is running but not in the display, press TIMER SET/OFF to display the

countdown for 5 seconds.

The Start keypad begins any oven function. If Start is not pressed within 2 minutes after pressing a keypad, the function is canceled and the time of day is displayed.

The Cancel keypad stops any function for the oven except the Clock and Timer.

1. Press BAKE.

2. Set the desired temperature between 170°F and 500°F (75°C and 260°C) using the

number keypads. The default temperature is 350°F (180°C).

3. Press START.

4. To change the temperature, repeat steps 2 and 3.

5. Press CANCEL when ﬁnished.

1. Press BROIL.

2. Press the number keypads to set the desired temperature.

3. Press START and allow the oven to preheat for 2 minutes.

4. To change the temperature, repeat steps 2 and 3.

5. Position the cookware in the oven and close the door.

6. Press CANCEL when ﬁnished.

Keypad Feature Instructions

MANUAL CONVECT MODES

AUTO CONVECT MODES

KEEP WARM Hold warm

PROOF Prooﬁng bread

FAVORITE Saved favorite

DELAY START Delayed start

COOK TIME Timed cooking

AQUALIFT SELF CLEAN

DOWNDRAFT FAN HIGH/LOW/AUTO OFF/OFF

START (hold for 3 sec to lock)

Convection cooking

Clean cycle

Downdraft fan

Oven control lockout

1. Press MANUAL CONVECT MODES until the desired convection mode appears in the

display.

2. Press START.

3. Press the number keypads to set the desired temperature.

4. Press START.

5. Insert food when prompted.

6. To change the temperature, repeat steps 3 and 4.

7. Press CANCEL when ﬁnished.

1. Press AUTO CONVECT MODES until the desired convection mode appears in the

display.

2. Press START.

3. Press the number keypads to set the desired temperature.

4. Press START.

5. Press the number keypads to set the desired cook time.

6. Press START.

7. Insert food when prompted.

8. To change the temperature, repeat steps 3 through 6.

9. Press CANCEL when ﬁnished.

Food must be at serving temperature before placing it in the warmed oven.

1. Press KEEP WARM.

2. Set the desired temperature between 145°F and 190°F (63°C and 88°C) using the

number keypads. The default temperature is 170°F (75°C).

3. Press START.

4. Press CANCEL when ﬁnished.

1. Place prepared dough in oven. Press PROOF.

2. Press START.

3. Let the dough rise until nearly doubled in size. Prooﬁng time may vary depending on

dough type and quantity.

4. Press CANCEL when ﬁnished prooﬁng. Refer to the “Prooﬁng Bread” section for more information.

The Favorite keypad stores the oven mode, cook time, and temperature for your favorite recipe. To save or use favorite, see the “Favorite” section.

The Delay Start keypad is used to enter the starting time for an oven function with a delayed start. Delay Start should not be used for foods such as breads and cakes because they may not bake properly.

To set a Timed Cook or a Delayed Timed Cook, see the “Cook Time” section. Timed cooking allows the oven to be set to turn on at a certain time of day, cook for a set

length of time, and/or shut off automatically. To set a Timed Cook or a Delayed Timed Cook, see the “Cook Time” section.

See the “Clean Cycle” section.

Press DOWNDRAFT FAN HIGH or DOWNDRAFT FAN LOW to turn on the Downdraft Fan at the desired speed.

Press DOWNDRAFT FAN OFF to turn off the Downdraft Fan immediately. Press DOWNDRAFT FAN AUTO OFF to automatically turn off the Downdraft Fan after a set

time. To add 15 minutes to the set time, up to 1 hour, press DOWNDRAFT FAN AUTO OFF again.

If the Downdraft Fan is OFF, pressing DOWNDRAFT FAN AUTO OFF will turn the Downdraft Fan on at High speed. If the Downdraft Fan is already ON, pressing DOWNDRAFT FAN AUTO OFF will not change the Downdraft Fan speed.

1. Check that the oven is OFF.

2. Press and hold START (hold for 3 sec to lock) for 3 seconds.

3. A tone will sound, “Control Locked” will scroll, and then “Locked” will be displayed.

4. Repeat to unlock. No keypads will function with the controls locked. The cooktop

functions are not affected by the oven control lockout.

Keypad Feature Instructions

OPTIONS/CLOCK Energy save

1. Press OPTIONS/CLOCK until “ENERGY SAVER” is displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press CANCEL to exit and display the time of day.

If Energy Save is ON, the range will go into Sleep mode after 5 minutes of inactivity. Any keypad press will activate the display. If Energy Save is OFF, the display will be ON at all times.

Electronic Oven Controls

Control Display

The display will ﬂash when powered up or after a power loss. Press CANCEL to clear. When the oven is not in use, the time of day is displayed. If the range is in Energy Save mode, the display will be blank when not in use.

Tones

Tones are audible signals, indicating the following:

One Tone

■ Valid keypad press

■ Oven is preheated (long tone).

■ Function has been entered.

■ Reminder, repeating each minute after the end-of-cycle tones

Three Tones

■ Invalid keypad press

Four Tones

■ End of cycle

Use the Options/Clock keypad to change the tone settings.

Energy Save

The Energy Save mode puts the range into Sleep mode and reduces energy consumption.

To Activate the Energy Save Mode:

1. Press OPTIONS/CLOCK until “ENERGY SAVER” is displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press CANCEL to exit and display the time of day.

5. The setting will be activated after 5 minutes. To Deactivate the Energy Save Mode:

1. Press OPTIONS/CLOCK until “ENERGY SAVER” is displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press CANCEL to exit and display the time of day.

5. The clock will reappear in the display and the range can be

operated as usual.

Clock

The Clock can use a 12- or 24-hour cycle.

1. Press OPTIONS/CLOCK until “CLOCK” is displayed.

2. Use the number keypads to set the time of day.

3. Press START to change the time.

4. Press “3” for AM or “6” for PM.

Fahrenheit and Celsius

The temperature is preset to Fahrenheit but can be changed to Celsius.

1. Press OPTIONS/CLOCK until “TEMP UNIT” is displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press START or CANCEL to exit and display the time of day.

Audible Tones Disable

Turns off all tones, including the end-of-cycle tone and keypress tones. Reminder tones are still active when all tones are disabled.

1. Press OPTIONS/CLOCK until “SOUND” is displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press START or CANCEL to exit and display the time of day.

Sound Volume

Sets the volume of the tone to either high or low.

1. Press OPTIONS/CLOCK until “SOUND VOLUME” is displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press START or CANCEL to exit and display the time of day.

End-of-Cycle Tone

Activates or turns off the tones that sound at the end of a cycle.

1. Press OPTIONS/CLOCK until “END TONE” is displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press START or CANCEL to exit and display the time of day.

Settings

Many features of the oven control can be adjusted to meet your personal needs. These changes are made using the Options/ Clock keypad.

Use the Options/Clock keypad to scroll through the features that can be changed. Each press of the Options/Clock keypad will advance the display to the next setting. After selecting the feature to be changed, the control will prompt you for the required input. Then press START or CANCEL to exit and display the time of day. Details of all of the feature changes are explained in the following sections.

Press CANCEL to exit Settings.

Keypress Tones

Activates or turns off the tones when a keypad is pressed.

1. Press OPTIONS/CLOCK until “KEYPRESS TONE” is

displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press START or CANCEL to exit and display the time of day.

Reminder Tones Disable

Turns off the short repeating tone that sounds every 1 minute after the end-of-cycle tones.

1. Press OPTIONS/CLOCK until “REMINDER TONE” is displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press START or CANCEL to exit and display the time of day.

12/24 Hour Clock

1. Press OPTIONS/CLOCK until “12/24 HOUR” is displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press START or CANCEL to exit and display the time of day.

Demo Mode

IMPORTANT: This feature is intended for use on the sales ﬂoor with 120 V power connection and permits the control features to be demonstrated without the oven turning on. If this feature is activated, the oven will not work.

1. Press OPTIONS/CLOCK until “DEMO MODE” is displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press START or CANCEL to exit and display the time of day.

Sabbath Mode

The Sabbath mode sets the oven to remain on in a Bake setting until turned off.

When the Sabbath mode is set, only the Bake cycle will operate. All other cooking and cleaning cycles are disabled. No tones will sound and the displays will not indicate temperature changes.

When the oven door is opened or closed, the oven light will not turn on or off and the heating elements will not turn on or off immediately.

To Enable Sabbath Mode Capability (One Time Only):

1. Press OPTIONS/CLOCK until “SABBATH” is displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press START or CANCEL to exit and display the time of day.

Languages - Scrolling Display Text

Language options are English, Spanish, and French.

1. Press OPTIONS/CLOCK until “LANGUAGE” is displayed.

2. The current setting will be displayed.

3. Press the “1” or “2” keypad to select the desired language.

4. Press START or CANCEL to exit and display the time of day.

Oven Temperature Offset Control

IMPORTANT: Do not use a thermometer to measure oven temperature. Elements will cycle on and off as needed to provide consistent temperature but may run slightly hot or cool at any point in time due to this cycling. Most thermometers are slow to react to temperature change and will not provide an accurate reading due to this cycling.

The oven provides accurate temperatures; however, it may cook faster or slower than your previous oven, so the temperature can be adjusted to personalize it for your cooking needs. It can be changed to Fahrenheit or Celsius.

To Adjust Oven Temperature:

1. Press OPTIONS/CLOCK until “TEMP CALIB” is displayed.

2. Press START, wait 10 seconds for the display to change, and

then continue with Step 3.

Press START to adjust the oven temperature calibration. Wait 10 seconds for the display to change, and then continue with Step 3.

3. Press the “3” keypad to increase the temperature in 5°F

(3°C) increments or press the “6” keypad to decrease the temperature in 5°F (3°C) increments. The offset range is from

-30°F to +30°F (-18°C to +18°C).

4. Press START or CANCEL to exit and display the time of day.

12-Hour Shutoff

The oven control is set to automatically shut off the oven 12 hours after the oven initiates a cook or clean function. This will not interfere with any timed or delay cook functions.

1. Press OPTIONS/CLOCK until “12Hr AUTO_OFF” is displayed.

2. The current setting will be displayed.

3. Press the “1” keypad to adjust the setting.

4. Press START or CANCEL to exit and display the time of day.

Cooktop

WARNING

Fire Hazard

Turn off all controls when done cooking.

Failure to do so can result in death or fire.

The control knobs can be set to anywhere between Hi and Lo. Push in and turn to setting.

REMEMBER: When range is in use, the entire cooktop area may become hot.

Ceramic Glass

The surface cooking area will glow red when an element is ON. Some parts of the surface cooking area may not glow red when an element is ON. This is normal operation. It will also randomly cycle off and back on again, even while on Hi, to keep the cooktop from extreme temperatures.

It is normal for the surface of light-colored ceramic glass to appear to change color when surface cooking areas are hot. As the glass cools, it will return to its original color.

Clean the cooktop after each use to help avoid scratches, pitting, abrasions and to condition the glass surface. Ceramic glass cooktop cleaner and a cooktop scraper are also recommended for stubborn soils. Do not use abrasive cleaners, cleaning pads, or harsh chemicals for cleaning. The Cooktop Care Kit contains all of the items needed to clean and condition your ceramic glass cooktop. Refer to the “Range Care” section for additional information.

IMPORTANT: To avoid permanent damage to the cooktop surface and to make soils easier to remove, clean the cooktop after each use to remove all soils.

■ Avoid storing jars or cans above the cooktop. Dropping

a heavy or hard object onto the cooktop could crack the cooktop.

■ To avoid damage to the cooktop, do not leave a hot lid on

the cooktop. As the cooktop cools, air can become trapped between the lid and the cooktop and the ceramic glass could break when the lid is removed.

■ For foods containing sugar in any form, clean up all spills and

soils as soon as possible. Allow the cooktop to cool down slightly. Then, while wearing oven mitts, remove the spills using a scraper while the surface is still warm. If sugary spills are allowed to cool down, they can adhere to the cooktop and can cause pitting and permanent marks.

■ To avoid scratches, do not slide cookware or bakeware across

the cooktop. Aluminum or copper bottoms and rough ﬁnishes on cookware or bakeware could leave scratches or marks on the cooktop.

■ Do not cook popcorn in prepackaged aluminum containers on

the cooktop. They could leave aluminum marks that cannot be removed completely.

■ To avoid damage to the cooktop, do not allow objects that

could melt, such as plastic or aluminum foil, to touch any part of the entire cooktop.

■ To avoid damage to the cooktop, do not use the cooktop as a

cutting board.

■ Use cookware about the same size as the surface cooking

area. Cookware should not extend more than ½" (1.3 cm) outside the area.

A. Surface cooking area B. Cookware/canner C. ½" (1.3 cm) maximum overhang

Rapid Boil Element (Right Front Element)

The Rapid Boil cooking element offers additional cooking ﬂexibility. The Rapid Boil cooking element can be used to boil liquids faster. The lowest melt setting can be used to prepare sauces, brown or saute foods, and keep foods at a low temperature. Use cookware appropriate in size for the Rapid Boil cooking element.

■ Use ﬂat-bottomed cookware for best heat conduction and

energy efﬁciency. Cookware with rounded, warped, ribbed, or dented bottoms could cause uneven heating and poor cooking results.

■ Determine ﬂatness by placing the straight edge of a ruler

across the bottom of the cookware. While you rotate the ruler, no space or light should be visible between it and the cookware.

■ Cookware designed with slightly indented bottoms or small

expansion channels can be used.

■ Make sure the bottoms of pots and pans are clean and dry

before using them. Residue and water can leave deposits when heated.

■ To avoid damage to the cooktop, do not cook foods directly

on the cooktop.

Cooktop On Indicator Light

The Cooktop On indicator light is located on the console panel. When any control knob on the console panel is turned on, the Cooktop On indicator light will glow.

Hot Surface Indicator Light

On ceramic glass models, the Hot Surface indicator light is located on the console panel.

The Hot Surface indicator light will glow as long as any surface cooking area is too hot to touch, even after the surface cooking area is turned off.

Dual Zone Cooking Element

The Dual Zone cooking element offers ﬂexibility depending on the size of the cookware. Single size can be used in the same way as a regular element. The dual size combines both the single and outer element and is recommended for larger-size cookware.

A. Rapid boil option B. Lower heat option

Melt Element (Left Rear Element)

The Melt cooking element offers ﬂexibility due to a wide range of settings between Hi and Melt. The Hi heat option can be used to boil small amounts of liquid quickly. To reduce the power setting, turn the knob clockwise. The Melt setting is designed for delicate foods that require low heat, such as when melting chocolate or holding sauces. Use cookware appropriate in size for the Melt cooking element.

A. High heat option B. Melt option

Downdraft Ventilation System

The built-in downdraft ventilation system removes cooking vapors, odors, and smoke from foods prepared on the cooktop.

IMPORTANT: For optimal performance, operate the downdraft ventilation system with the ﬁlter properly installed.

To avoid the buildup of grease, the ﬁlter should be cleaned often. For more information on proper ﬁlter placement and cleaning, see

“Downdraft Ventilation System” in the “General Cleaning” section.

A. Single B. Dual

Cookware

IMPORTANT: Do not leave empty cookware on a hot surface cooking area, element, or surface burner.

Ideal cookware should have a ﬂat bottom, straight sides, and a well-ﬁtting lid, and the material should be of medium-to-heavy thickness.

Rough ﬁnishes may scratch the cooktop. Aluminum and copper may be used as a core or base in cookware. However, when used as a base, they can leave permanent marks on the surfaces.

Cookware material is a factor in how quickly and evenly heat is transferred which affects cooking results. A nonstick ﬁnish has the same characteristics as its base material. For example, aluminum cookware with a nonstick ﬁnish will take on the properties of aluminum.

Cookware with nonstick surfaces should not be used under the broiler.

Check for ﬂatness by placing the straight edge of a ruler across the bottom of the cookware. While you rotate the ruler, no space or light should be visible between it and the cookware.

1 0

1 1

1 2

1 3

1 4

1 5

1 6

1 7

1 8

1 9

2 0

Cookware Characteristics

Copper

Earthenware

Porcelain enamel-on-steel or cast iron

Stainless steel

Use ﬂat-bottomed cookware for best cooking results and energy efﬁciency. The cookware should be about the same size as the cooking area outlined on the cooktop. Cookware should not extend more than ½" (1.3 cm) outside the area.

■ Heats very quickly and evenly.

■ May leave copper residues which may

be diminished if cleaned immediately after cooking.

■ Can leave a permanent stain or bond

to the cooktop if overheated.

■ Follow manufacturer’s instructions.

■ Use on low heat settings.

■ May scratch the cooktop.

■ See stainless steel or cast iron.

■ Porcelain enamel bakeware without the

metal base may bond to the cooktop if overheated.

■ Heats quickly, but unevenly.

■ A core or base of aluminum or copper

on stainless steel provides even heating.

Use the following chart as a guide for cookware material characteristics.

Cookware Characteristics

Aluminum

Cast iron

Ceramic or ceramic glass

■ Heats quickly and evenly.

■ Suitable for all types of cooking

■ Medium or heavy thickness is best for

most cooking tasks.

■ May leave aluminum residues

which may be diminished if cleaned immediately after cooking.

■ Heats slowly and evenly.

■ Good for browning and frying

■ Maintains heat for slow cooking.

■ Rough edges or burrs may scratch

the cooktop.

■ Follow manufacturer’s instructions.

■ Heats slowly, but unevenly.

■ Ideal results on low-to-medium heat

settings

■ May scratch the cooktop.

Home Canning

Canning can be performed on a glass smoothtop cooking surface or traditional coil element cooktop. When canning for long periods, alternate the use of surface cooking areas or elements between batches. This allows time for the most-recently used areas to cool.

■ Center the canner on the largest surface cooking area or

element. On electric cooktops, canners should not extend more than ½" (1.3 cm) beyond the surface cooking area or element.

■ Do not place canner on 2 surface cooking areas or elements

at the same time.

■ On ceramic glass models, use only ﬂat-bottomed canners to

avoid damage to the cooktop and elements.

■ For more information, contact your local agricultural

extension ofﬁce or refer to published home canning guides. Companies that manufacture home canning products can also offer assistance.

Oven

7 6 5

Odors and smoke are normal when the oven is used the ﬁrst few times or when it is heavily soiled.

IMPORTANT: The health of some birds is extremely sensitive to the fumes given off by the oven. Exposure to the fumes may result in death to certain birds. Always move birds to another closed and well-ventilated room.

Aluminum Foil

IMPORTANT: To avoid permanent damage to the oven bottom ﬁnish, do not line the oven bottom with any type of foil or liner.

For best cooking results, do not cover entire oven rack with foil because air must be able to move freely.

Positioning Racks and Bakeware

IMPORTANT: To avoid permanent damage to the porcelain ﬁnish, do not place food or bakeware directly on the oven door or bottom.

Bakeware

To cook food evenly, hot air must be able to circulate. Allow 2" (5 cm) of space around bakeware and oven walls. Make sure that no bakeware piece is directly over another.

Racks

■ Position racks before turning on the oven.

■ Do not position racks with bakeware on them.

■ Make sure racks are level.

To position a rack, pull it out to the stop position, raise the front edge, and then lift out. Use the following illustration and charts as guides.

A. Ends of rack in position 3 B. Food in position 2

IMPORTANT: These rack positions are for ﬂat racks. If a Max Capacity Oven Rack is used, the rack position must be adjusted as shown in the previous ﬁgure.

Multiple Rack Cooking

2-rack (non-convection): Use rack positions 2 and 5 or 3 and 6. 2-rack (convection): Use rack positions 2 and 5 or 3 and 6. 3-rack (convection): Use rack positions 2 and 7 and a Max

Capacity Oven Rack in rack position 5.

Baking Cookies and Layer Cakes on 2 Racks

Baking Layer Cakes

For best results when baking cakes on 2 racks, use the Bake function, a ﬂat rack in rack position 3, and a roll-out rack in rack position 5. Place the cakes on the racks as shown. Keep at least 3" (7.6 cm) of space between the front of the racks and the front cakes.

The oven has 7 positions for a ﬂat rack as shown in the previous illustration and the following table.

Flat Rack Position* Type of Food

7 Broiling/searing meats, hamburgers,

6 Broiled meats, poultry, ﬁsh 3 or 4 Most baked goods, casseroles,

2 Roasted meats 1 Large roasts or poultry

For hamburger patties to have a well-seared exterior and a rare interior, use a ﬂat rack in rack position 7. Side 1 should cook for approximately 2½ to 3½ minutes. Side 2 should cook for approximately 4 to 5 minutes. Expect a moderate degree of smoke when broiling.

*If your model has a Max Capacity Oven Rack, the recessed ends

must be placed in the rack position above the desired position of the food. See the following illustration.

steaks

frozen foods

Baking Cookies

For best results when baking cookies on 2 racks, use the Convection Bake function, a ﬂat rack in rack position 3, and a roll-out rack in rack position 5.

Roll-Out Rack

The roll-out rack allows easy access to position and remove food in the oven. It is not recommended to use the roll-out rack in the top rack, position 7, or the bottom rack, position 1.

Open Position

A. Rack frame B. Sliding rack

Closed and Engaged Position

3. Lower the front of the rack assembly, and then gently slide

rack assembly into oven, bypassing the “V” cutouts. Push the rack assembly into the oven until it stops at the ladder in the back of the oven.

A. “V” cutout B. Rack guides C. Ladder hook D. Ladder

4. Reach through the rack to hold the sliding rack and the front

crossbar. Lift the front of the rack assembly, and then push the rack assembly to the back of the oven. Lower the front of the rack assembly so the ladder hook engages with the ladder on both sides of the oven.

A. Rack frame B. Sliding rack

To Insert Roll-Out Rack

1. Angle the front of the rack assembly up, and then insert

the rack frame into the “V” cutout in the rack guides of the oven cavity.

A. “V” cutout B. Rack guides

2. Keep rack assembly lifted up at an angle, and then push

in to bypass the lower “V” cutout.

A. Sliding rack B. Front crossbar

To Remove Roll-Out Rack

1. Push the sliding rack in completely so that it is in the closed

and engaged position.

2. Reach through the rack to hold the sliding rack and the front

crossbar. Lift the front of the rack assembly to disengage the ladder hook from the ladders at the rear of the oven, and then pull the rack assembly forward.

3. Using 2 hands, gently pull the sliding rack and the rack frame

at the same time to the “V” cutout. Angle the rack so that the front is higher than the back, and then gently pull rack past “V” cutout and then out of the oven.

To avoid damage to the sliding rack, do not place more than 25 lbs (11.4 kg) on the rack.

Do not clean the roll-out rack in a dishwasher. It may remove the rack’s lubricant and affect its ability to slide.

See the “General Cleaning” section for more information.

Oven Vent

A. Oven vent

The oven vent releases hot air and moisture from the oven and should not be blocked or covered. Blocking or covering the vent will cause poor air circulation, affecting cooking and cleaning results. Do not set plastics, paper, or other items that could melt or burn near the oven vent.

Sabbath Mode

The Sabbath mode sets the oven to remain on in a Bake setting until turned off.

When the Sabbath mode is set, only the Bake cycle will operate. All other cooking and cleaning cycles are disabled. No tones will sound and the displays will not indicate temperature changes.

When the oven door is opened or closed, the oven light will not turn on or off and the heating elements will not turn on or off immediately.

To Enable Sabbath Mode Capability (One Time Only):

1. Press OPTIONS/CLOCK until “SABBATH” is displayed. “OFF.

Press (1) for On” will scroll in the display.

2. Press the “1” keypad. “ON. Press (1) for Off” will scroll in the

display. Sabbath mode can be activated for baking.

3. Press START or CANCEL to exit and display the time of day. NOTE: To disable the Sabbath mode, repeat steps 1 through 3

to change the status from “SABBATH ON” to “SABBATH OFF.”

To Activate Sabbath Mode:

1. Press BAKE.

2. Press the number keypad to set a temperature other than

350°F (177°C).

3. Press START. For timed cooking in Sabbath mode, press COOK TIME, and

then the number keypads to set the desired cook time.

4. Press OPTIONS/CLOCK. Three tones will sound. Then press “7.” “SAb” will appear in the display.

To Adjust Temperature (When Sabbath Mode Is Running):

1. Press the number keypad as instructed by the scrolling text

to select the new temperature. NOTE: The temperature adjustment will not appear on the

display. The scrolling text will be shown on the display as it was before the keypad was pressed.

2. Press START.

To Deactivate Sabbath Mode:

Press OPTIONS/CLOCK and then press “7” to return to regular baking, or press CANCEL to turn off the range.

NOTE: No tones will sound while deactivating Sabbath mode.

Baking and Roasting

Preheating

When beginning a Bake, Convect Bake, or Convect Roast cycle, the oven will begin preheating after Start is pressed. The oven will take approximately 12 to 15 minutes to reach 350°F (177°C) with all of the oven racks provided with your oven inside the oven cavity. Higher temperatures will take longer to preheat. The preheat cycle rapidly increases the oven temperature. The actual oven temperature will go above your set temperature to offset the heat lost when your oven door is opened to insert food. This ensures that when you place your food in the oven, the oven will begin at the proper temperature. Insert your food when the Preheat tone sounds. Do not open the door during preheat before the tone sounds.

Oven Temperature

While in use, the oven elements will cycle on and off as needed to maintain a consistent temperature, but they may run slightly hot or cool at any point in time due to this cycling. Opening the oven door while in use will release the hot air and cool the oven which could impact the cooking time and performance. It is recommended to use the oven light to monitor cooking progress.

NOTE: On models with convection, the convection fan may run in the non-convection Bake mode to improve oven performance.

Temperature Management System

The Temperature Management System electronically regulates the oven heat levels during preheat and Bake to maintain a precise temperature range for optimal cooking results. The bake and broil elements or burners cycle on and off in intervals. On convection range models, the fan will run while preheating and may be cycled on and off for short intervals during Bake to provide the best results. This feature is automatically activated when the oven is in use.

Before baking and roasting, position racks according to the “Positioning Racks and Bakeware” section. When roasting, it is not necessary to wait for the oven preheat cycle to end before putting food in unless it is recommended in the recipe.

Broiling

When broiling, preheat the oven for 2 minutes before putting food in unless recommended otherwise in the recipe. Position food on grid in a broiler pan, and then place it in the center of the oven rack.

IMPORTANT: Close the door to ensure proper broiling temperature.

Changing the temperature when broiling allows more precise control when cooking. The lower the broil setting is, the slower the cooking. Thicker cuts and unevenly shaped pieces of meat, ﬁsh, and poultry may cook better at lower broil settings. Use rack 6 or 7 for broiling. Refer to the “Positioning Racks and Bakeware” section for more information.

On lower settings, the broil element will cycle on and off to maintain the proper temperature.

■ For best results, use a broiler pan and grid. It is designed

to drain juices and help avoid spatter and smoke. If you would like to purchase a broiler pan, one may be

ordered. See the “Accessories” section.

Convection Cooking

Proong Bread

In a convection oven, the fan-circulated hot air continually distributes heat more evenly than the natural movement of air in a standard thermal oven. This movement of hot air helps maintain a consistent temperature throughout the oven, cooking foods more evenly, crisping surfaces while sealing in moisture, and yielding crustier breads.

During convection baking or roasting, the bake, broil, and convection elements cycle on and off in intervals while the fan circulates the hot air. During convection broiling, the broil and convection elements cycle on and off.

If the oven door is opened during convection cooking, the fan will turn off immediately. It will come back on when the oven door is closed.

With convection cooking, most foods can be cooked at a lower temperature and/or a shorter cooking time than in a standard thermal oven. When using Manual Convect modes, reduce the time and temperature when setting the oven. Use the following chart as a guide.

Convection Mode Time/Temp. Guidelines

Convection Bake 25°F (15°C) lower temperature,

possible shortened cooking time Convection Roast Cooking time shortened by up to 30% Convection Broil Shortened cooking time

Prooﬁng bread prepares the dough for baking by activating the yeast. Follow the recipe directions as a guide. Proof should be used for fresh dough, thawed dough, and for the ﬁrst and second rise.

To Proof:

Before ﬁrst prooﬁng, place the dough in a lightly greased bowl and cover loosely with wax paper, coated with shortening. Place on rack guide 2 and close the oven door.

NOTE: If the temperature of the oven is greater than 120°F (49°C), “Oven Cooling” will be displayed until the temperature is less than 120°F (49°C).

1. Press PROOF.

2. Press START.

Let the dough rise until nearly doubled in size. Prooﬁng time may vary depending on dough type and quantity.

3. Press CANCEL when ﬁnished prooﬁng. Before second prooﬁng, shape the dough, place it in baking

pan(s), and cover loosely. Follow the same placement and control steps above. Before baking, remove the cover.

NOTE: If the oven temperature is greater than 120°F (49°C), the display will indicate “Oven Cooling” until the temperature is below 120°F (49°C).

Favorite

Favorite stores the oven mode and temperature for your favorite recipe. Favorite can only be stored for the upper oven.

To Save a Recipe:

1. While the oven is being used for Bake, Broil, Convect Bake,

Convect Roast, or Convect Broil, press and hold FAVORITE for 3 seconds.

2. The current oven mode, cook time, and temperature will be

displayed. “SAVED” will be displayed. The recipe has been saved.

NOTE: Only one recipe can be saved at a time. Saving a new recipe will overwrite a previously saved recipe.

When using Auto Convect modes, the oven will automatically adjust the time and temperature for the selected mode.

Convect Modes

Manual Convect Modes:

Convect Bake - Multiple-rack baking or cookies, biscuits, breads, casseroles, tarts, tortes, cakes

Convect Roast - Whole chicken or turkey, vegetables, pork roasts, beef roasts

Convect Broil - Thicker cuts or unevenly shaped pieces of meat, ﬁsh, or poultry

Auto Convect Modes:

Meats - Chicken: whole and pieces; meat loaf; roasts: pork, beef, ham

Baked Goods - Biscuits, quick breads, yeast breads, cakes, cookies, casseroles

Others - Frozen convenience foods: French fries, nuggets, ﬁsh sticks, lasagna, pizza

To Select the Favorite Recipe:

1. Press FAVORITE. The saved oven mode and temperature will

be displayed.

NOTE: Favorite does not store cook times.

2. Press START.

3. Once the recipe is selected, oven will begin preheating to the

set program.

4. To change the temperature, press the number keypads to set

the desired temperature.

5. Press START.

6. To change the cook time, press COOK TIME.

7. Press the number keypads to set the desired cook time.

8. Press START.

9. Press CANCEL when ﬁnished cooking.

+ 33 hidden pages
