JDS Uniphase T-BERD MTS 8000, T-BERD 6000A, T-BERD 5800 Getting Started Manual

21165803 rev 002

Remote Operation Getting Started Guide

This guide describes remote operation and control of a Transport Module, Multi-Service
Application Module (MSAM), or T-BERD/MTS 5800 using SCPI commands.

SCPI command syntax and format requirements are presente d alo ng w ith instr uction s on
how to establish a connection to a module and initiate example applications. A list of
commands and queries that apply to all applications concludes this section as a refere nce
for basic remote control applications.

Controlled modules may be a part of an MTS-8000 or MTS 6000A Test Platform. As these
platforms are physically diff erent, only those phys ical features that apply directly to remo te
operations will be discussed when necessary.

The sections contained in this chapter are as follows:
– “About the T-BERD/MTS 8000, 6000A, and 5800” on p age2

– “Remote control flow” on page 4
– “Command syntax and format requirements” on page 4
– “Getting the module port number” on page 6
– “Getting the remote control port number” on page 7
– “Working with applications” on page 11
– “Using setups, actions, and results” on page 14
– “Rebooting an instrument” on page 19
– “Example remote control procedur e s” on page 19
– “Demo Remote Control Scripts” on page25
– “SCPI command reference” on page 26

Transport Module, DMC, MSAM, and 5800 Remote Operation 1

Remote Operation Getting Started Guide

About the T-BERD/MTS 8000, 6000A, and 5800

About the T-BERD/MTS 8000, 6000A, and 5800

Before beginning a remote session, you should be familiar with the products and modules,
found in the T-BERD

Transport Module, and MSAM Getting Started Guide and T-BERD/MTS 5800 Getting
Started Manual.

The following terms have a specific meaning when referring to the T-BERD/MTS 8000 or
6000A:

– 10/100/1000 Ethernet — Used to represent 10/100/1000 Mbps Ethernet. The

connector panel also uses 10/100/1000M to identify the connector used for 10/100/
1000 Mbps Ethernet testing.

– 1GigE — Used to represent 1 Gigabit Ethernet. The Transport Module connector

panel also uses GigE to identify the optical connector used for 1 Gigabit Ethernet
testing.

– 10GigE — Used to represent 10 Gigabit Ethernet. The Transport Module connector

panel also uses 10GE and 10G to identify the optical connectors used for
10 Gigabit Ethernet LAN and WAN testing.

–Action — Refers to an item that triggers some change to the test interface, such as

inserting an alarm or enabling the laser. In the user interface, these are located in the
Actions toolbar at the bottom of the main results screen.

– Application module — Used to refer to the component that provides test functionality

to the assembled instrument. This manual supports two application modules: the
Transport Module, and the MSAM.

– Assembly — Used to refer to a complete set of components assembled as an instru-

ment and used for testing. This manual supports three assemblies: The Transport
Module assembly, consisting of an T-BERD ⁄ MTS 8000 base unit and T ransport
Module, the MSAM assembly, consisting of a MSAM, Physical Interface Modules
(PIMs), and a T-BERD ⁄ MTS 6000A base unit, and a DMC assembly, consisting of
up to two MSAMs, up to four PIMs, a Dual Module Carrier (DMC), and a
T-BERD ⁄ MTS 8000 base unit.

– Base unit — The unit which connects to the application module and power adapter,

providing the user interface and a variety of connectivity and work flow tools. If
optioned to do so, the base unit also allows you to measure emitted power, received
power, and optical link loss on fiber optic networks.

– Battery Module — The module connected to the back of the T-BERD / MTS 8000

base unit, which supplies power whenever it is not provided using the power adapter.

– Component— Used to refer to an individual hardware component which is connected

to the other components to build a test instrument (assembly). This manual supports
the following components: the Transport Module, the MSAM, and the DMC. The base
units are documented in separate manuals.

–DMC — Dual Module Carrier. The DMC is a two slot chassis which you ca n connect to

the T-BERD / MTS 8000 base unit to test using up to two MSAM application modules
and four Physical Interface Modules (PIMs).

– FC — Used to represent Fibre Channel on the Transport Module connector panel and

the Transport Mod ule and M SAM use r i nterfa c e to iden tify the optica l conn ectors used
for Fibre Channel testing.

⁄

MTS 8000 and T-BERD⁄MTS 6000A Dual Module Carrier,

2 Transport Module, DMC, MSAM, and 5800 Remote Operation

Remote Operation Getting Started Guide

About the T-BERD/MTS 8000, 6000A, and 5800

– JDSU Ethernet test set — A test set marketed by JDSU and designed to transmit an

Acterna Test Packet (ATP) payload. These packets carry a time stamp used to calcu­late a variety of test results. The FST-2802 TestPad, the SmartClass Ethernet tester,
the HST with an Ethernet SIM, the T-BERD/MTS 8000 Transport Module, and the
T-BERD/MTS 6000A MSAM can all be configured to transmit and analyze ATP
payloads, and can be used in end-to-end and loopback configurations during testing.

– MSAM Multiple Services Application Module — Referred to generically as “the

instrument” when inserted in the T-BERD / MTS 6000A base unit or the DMC with a

PIM. The MSAM provides testing functionality for the base unit.
– MTS 8000 and MTS 6000A — See T-BERD/MTS 8000 and T-BERT 6000A.
– OC-n — Used to refer to each of the optical SONET rates supported by the Transport

Module or MSAM (OC-3, OC-12, OC-48, and OC-192), where “n” represents the

user-selected line rate.
– OTN — Optical Transport Network.
– OTU1 — Optical Transport Unit 1. A 2.7G OTN sign al d esigned to ca rr y a SONET OC-

48 or SDH STM-16 client signal. OTU1 is used on the connector panel and the

Transport Module and MSAM user interfaces to identify the connectors and applica-

tions used for 2.7G OTN testing.
– OTU2 — Optical Transport Unit 2. A 10.7G, 11.05G, or 11.1G OTN signal designed to

carry SONET OC-192, SDH STM-64, or 10GigE Ethernet WAN and LAN client signals.

OTU2 is used on the <product name> connector panel and the Transport Module and

MSAM user interfaces to identify the connectors and applications used for 10.7G,

11.05G, or 11.1G OTN te sting.

– PIM — The physical interface module (PIM) inserted into one of up to two ports

provided on the MSAM chassis. PIMs supply the physical connectors (interfaces)

required to connect the MSAM to the circuit under test. A variety of cables, SFPs, and

XFPs are offered as options, and can used to connect the PIMs to the circuit.
–Result — Refers to a measurement made by the test ap plication. In the user interface,

these are displayed in the result windows and in the software LED panel on the main

Results screan.
– Setup — Refers to a setting of a test application that is usually changable by the user.

In the user interface, they are located on the Setup screen and on the main Result

screen in the horizontal toolbars.
– SFP — Small form-factor pluggable module. Used on the connector panel and

throughout this manual to represent pluggable optical modules.
–Slice — Used as a generic term for an applicaiton module or battery module. Typical

use is referring to the Transport Module, as the “BERT slice”. After assembling a T-

BERD/MTS 8000 base unit to a battery module and then to the Transport Module, the

instrument resembles a sandwich; thus, the indivicual components are slices.
– STM-n — Used to refer to each of the optical SDH rates supported by the Transport

Module or MSAM (STM-1, STM-4, STM-16, and STM-64), where “n” represents the

user-selected line rate.
– STS-1 — Used to refer to the electrical equivalent of OC-1 (51.84 Mbps) supported by

the Transport Module or MSAM.
– STM-1e — Used to refer to the electrical equivalent of STM-1 (155.52 Mbps)

supported by the Transport Module or MSAM.

Transport Module, DMC, MSAM, and 5800 Remote Operation 3

Remote Operation Getting Started Guide

Remote control flow

– T-BERD ⁄ MTS 8000 and T-BERD ⁄ MTS 6000A — The family of products, typically

a combination of a base unit, a battery module, and one or more application modules.
The Dual Module Carrier (DMC) can be used on the T-BERD / MTS 8000 platform to
test using two MSAMs.

The products are branded T-BERD in North American and branded MTS in Europe,
and are interchangeably referred to as the T-BERD 8000, MTS 8000, MTS-6000,
MTS5800 and Media Test Set 6000 throughout supporting documentation.

– Transport Module — Referred to generically as “the instrument” when connected to

the T-BERD / MTS 8000 base unit. The T ranspor t Module provides testin g functionality
for the base unit.

– XFP — 10 Gigabit Small Form Factor Pluggable optical transceiver. A variety of

optional XFPs are available for testing 10 Gigabit fibre circuits.

Remote control flow

When running a remote control session, the basic flow is as follows:

1 Obtain the remote control port number
2 Start remote control
3 Interacting with the applications

a query for running applications
b launching an application
c using setup, action, and results
d restarting a test

e configuring a timed test
4 Exiting the application(s)
5 Leaving remote control

Command syntax and format requirements

Before starting the remote session you sould become familiar with the syntax and format
requirements.

Command case-

sensitivity

SCPI command headers are not case sensitive , so both commands below are correct and
return the Signal Present test result.

:SENSE:DATA? CSTatus:PHYSical:SIGNal

:sense:data? CSTatus:PHYSical:SIGNal

Result names are not case sensitive, so both commands below return the Signal Present
test result.

:SENSE:DATA? CSTatus:PHYSical:SIGNal

4 Transport Module, DMC, MSAM, and 5800 Remote Operation

:SENSE:DATA? cstatus:physical:signal

Setup and action values are case-sensitive.

:SENSe:PAYLoad:BERT:PATTern ALL_ONESCorrect
:SENSe:PAYLoad:BERT:PATTern all_onesIncorrect

Remote Operation Getting Started Guide

Command syntax and format requirements

Sockets and

messages

Issuing multiple

commands

Serial command

processing

Short-form v. Long-

form commands

All remote control communications are socket-based TCP/IP. Any message passed via
remote control must be terminated with a newline character ("\n") as shown (or ENTER in
direct entry mode).

:INITiate\n

Without the following \n, a message may be interpreted incorrectly or cause an error condi­tion.

You can issue multiple commands on a single line by separating each of the commands
using a semicolon. The following examples show correct and incorrect presentation of the
multiple commands.

:INITiate; :SYSTem:ERRor:NEXT?\nCorrect
:INITiate :SYSTem:ERRor:NEXT?\nIncorrect

The remote control system processes commands sequentially in the order they are
received. It does not process multiple commands simultaneously. If a command is sent
while another command is still being processed, the second command will not be
processed until the first command has been fully executed.

Commands may be abbreviated using the short form (the capital lette rs in the comma nd).
Each word in the command may be either the long or short-form.

If long-form is used, the entire word must be specified; "partial" long -form is not recognized.
The following examples show the complete long-fo rm ver sio n fo llow ed by var iou s, sh or t-

form versions of the same command. The final example shows an exam ple of "partial" long­form that is not acceptable.

:SENSe:DATA? CSTatus:PHYSical:SIGNal Correct
:SENSe:DATA? CST:PHYS:SIGNCorrect
:SENS:DATA? CSTatus:PHYS:SIGNalCorrect
:SENS:DATA? CST:PHYS:SIGNCorrect
:SENS:DATA? CST:PHYS:SIGNaIncorrect

Transport Module, DMC, MSAM, and 5800 Remote Operation 5

Remote Operation Getting Started Guide

Getting the module port number

Getting the module port number

Starting remote

operation

Obtaining the module

port number

The first step is to start remote operation

1 Open a TCP/IP socket connection to the unit on port 8000.
2 Start remote operation.

*REM

IMPORTANT:

The *REM command must always be the first command sent after opening a
socket (to port 8000, the module port, or the RC port). On the ANT pla tforms
this was not necessary - they allowed you to connect, acce ss ap plic at ion s,
disconnect, then reconnect and continue without having to send *REM
again; on the MTS platforms, it is required.

Before issuing any SCPI commands, a socket connection to the module must be estab­lished.

Module identification and location

In order to establish a connection, the module must be identified and located.
Since multiple layers (slices) of transport modules (MTS-8000) and installation locations

(sides) for Multi-Service Application Modules (MSAM) are possible, the exact location of
the module to which a connection is being made must be verified.

There are two arguments that are required in the following commands and queries that
establish the exact physical location of the module being used in the test. These are indi­cated as <side>
value as follows:

<side>

–PWRS - Power Side - specify this location when connecting to an MSAM connected to

an MTS-6000A

OR

on the right side (viewed from front of base unit) of MTS-8000 dual carrier (same side

as power connector).
– OPPS - Opposite Side - specify this location when connecting to an MSAM connected

to the left side (viewed from front of base unit) of MTS-8000 dual carrier (far side from

power connector).
– BOTH - specify this location when connecting to full-width Transport Module (on MTS-

8000).

and <slice>. These are required arguments and must be filled with a

NOTE

The <side> parameter was added to the ":SYST:FUNC" commands in ver­sion 8.0 of the MTS-8000 BERT software and version 3.0 on the MTS-6000.
For previous versions, this parameter must be omitted.

6 Transport Module, DMC, MSAM, and 5800 Remote Operation

Remote Operation Getting Started Guide

Getting the remote control port number

<slice>

– SLIC1 - specify this location when connecting to an MTS-6000A MSAM

OR
to the transport module connected directly to the MTS-8000.

– SLIC2, SLIC3 - specify this location when connecting to the second or third transport

module (counting from the front) on an MTS-8000.

NOTE

For MTS-6000A, <side> will always be PWRS and <slice> will always be
SLIC1.

Verify the location of the module to which a connection is being made:

Example procedure

MOD:FUNC:LIST?

replacing <side> and <slice> as detailed in “Module identification and location” on

page 6.

If the module is located where queried, the system will respond with “BERT”.

1 Verify whether the module is powered.

MOD:FUNC:SEL? <side>,<slice>,"BERT"
example:
MOD:FUNC:SEL? PWRS,SLIC1,"BERT"
The module will return “OFF” or “ON”.

2 If the module state response was OFF, turn ON the module:

MOD:FUNC:SEL <side>,<slice>,"BERT",ON

3 Query the module’s port number.

MOD:FUNC:PORT? <side>,<slice>,"BERT"
The module will return its port number.If the module is in a ready state, the response to

the port query will be the port number, for example “8002”.
If the port is not in a ready state, the response will be -1 .
This port number will be needed in the next step.

<side>,<slice>

Getting the remote control port number

1 Open a TCP/IP socket to the module port obtained in “Module identification and loca-

tion” on page 6.

2 Enable remote operations on the module:

*REM

3 Verify the BERT module is ready

:SYST:FUNC:READY? <side>,<slice>,"BERT"

Returns 1 if the BERT module is in a ready state (i.e. po were d o n and finishe d b ooting
up), 0 otherwise.

Transport Module, DMC, MSAM, and 5800 Remote Operation 7

Remote Operation Getting Started Guide

Getting the remote control port number

4 Enable the remote control socket and return its port number

:SYST:FUNC:PORT? <side>,<slice>,"BERT"

Returns this module's remote control port number. If the module is not in a ready state,

the response will be -1.

Remote modes

Default Mode

GUI Mode

Remote operations are often conducted when the re is no physical access to th e base unit
where applications can be directly implemented using the Graphical User Interface (GUI).
Alternate situations can exist where remote operations need to be monitored by a techni­cian at the base unit or even supplemented with input from the base unit.

The default remote operational mode disables the Graphical User Interface (GUI) on the
base unit. This mode is activated by the implementation of the following command with no
optional values:

*REM

In this mode, the GUI is disabled and a message is displayed indicating the unit is under
remote control. At any time the GUI is enabled or disabled, all currently running applicaitons
will be shut down.

Alternatively, remote control may be used without deactivating the GUI. This mode can be
used to debug remote control tests and to verify that commands have the expected
behavior; the default mode is recommended for routine automated tasks. To activate GUI
mode, two optional parameters may be a dded to the *REM command on the remote con trol
port: <GUI-mode> and <access-mode>.

<GUI-mode> parameter

The <GUI-mode> parameter has three variables that can be defined:
– HIDDEN - when specified, the GUI is disabled (default if not specified).

– VISIBLE - when specified, the GUI is enabled.
– CURRENT - when specified, whatever is currently set will continue to be applied to the

new application or command.

<access-mode> parameter

The <access-mode> parameter has three variables that can be defined.
– READ_ONLY - when specified, a GUI user may navigate the UI but not change any

settings (default, if not specified).
– FULL - when specified, a GUI user may change settings.
– CURRENT - when specified, whatever is currently set will continue to be applied to the

new application or command.
These modes may be activated by the implementation of the REM command and speci-

fying the alternate parameters as follows:

*REM <GUI-mode> <access-mode>

8 Transport Module, DMC, MSAM, and 5800 Remote Operation

Remote Operation Getting Started Guide

Getting the remote control port number

Remote Mode

Indicators

To inform the local user of the base unit of the GUI mode specified by the remote opera­tions, one of two icons will display on the GUI.

Read-Only

The Read-Only icon will display when the *REM <access-mode> has been set to
READ_ONLY.

Full-Access

The Full-Access icon will display when the *REM <access-mode> has been set to FULL.
Once remote control has been started with the GUI active, an "Access Mode" entry will

become available in the Tools menu, which allows the GUI user to switch between read­only or full-access mode.

Global Commands

*REM

*RST

*IDN?

The following commands are recognized by remote control. The *RST, *IDN? and *OPC?
commands are loosely based on the SCPI standar d, but may not have the same behavior.
Other common commands from the SCPI standard starting with "*" are not supported.

The *REM command is usually the first command issued once connected to the remote
control port. This puts the unit into remote control mode. By default, this will shut down any
running applications, disable the graphical user interface (GUI), and display a message
indicating the unit is under remote control.

*REM may be given additional parameters to keep the GUI active, and possibly prevent
another user from modifying any settings while the GUI-enabled remote control mode is
active.

The *RST command shuts down all running applications and clears any saved application
settings. This is useful for closing multiple applications at one time, or to ensure that a newly
launched application isn't affected by any settings made in a previous test.

The *IDN? command returns identifying information about the test unit in the form of a
comma separated list. The manufacturer , software name, mod ule id, and software ver sion
number are provided.

> *IDN?
JDSU,BERT,A1-4690290,V11.1

Transport Module, DMC, MSAM, and 5800 Remote Operation 9

Remote Operation Getting Started Guide

Getting the remote control port number

*OPC?

*GUI

The operation complete query from the SCPI standar d is recognized, but does not have the
same behavior the standard describes. This due to the fact that in remote control,
commands are processed serially; a command will not be processed until all previous
commands are completed. This means that *OPC? will not be processed until all previous
operations are complete, at which point it will always return 1.

It is recommended that the :SYSTem:ERRor? query be used instead of *OPC?, as it also
provides error checking on the prev iou s com m a nd .

This command terminates remote control mode and restores the GUI interface. All applica­tions that were running under remote control will be shut down, and first application in the
test menu will be launched. Alternatively , the application to launch may be specified as an
optional parameter.

The example below shows this command with a parameter to launch 10/100/1000M
Ethernet Layer 2 Traffic Terminate. Keep in mind the *GUI command may take some time
to process. The 0, "No error" message may not show up for a minute or two.

> *GUI TermEth10ML2Traffic

> :SYSTem:ERRor?

0, "No error"

Switching to

Remote Control

mode

Prepare BERT Application

Using the information discovered in “Getting the remote control port number” on page 7,
establish a socket connection to the BERT application port so the BERT application can be
set for operation.

To prepare the BERT application port for use, it must be reset to its default configuration,
shutting down all running applications.

Start Remote Operation

Set the BERT application for remote operations:

*REM

Exits all running applications and shows a message on the screen indicating the unit is
under remote control.

Reset BERT

Optional. Exit all currently running applications and restore the default configurations:

*RST

Query for Error Status

To verify that the system has been reset, the system must be checked for errors. There will
be no return from this query until the reset sequence has been completed. This may take
a little while but a 90 second time-out on this command should be sufficient.

Check the system for errors:

10 Transport Module, DMC, MSAM, and 5800 Remote Operation

:SYSTem:ERRor?

The return from this command will be 0, "No error"
the *RST command is finished.

Remote Operation Getting Started Guide

Working with applications

. There will be no return until

When the 0, "No error"
completed. The system is now ready to have testing applications started on that module

Working with applications

System Commands

Check for Errors :SYSTem:ERRor?

If a remote control command has an error, no message will be returned unless requested
with ":SYSTem:ERRor?". The response to this command is an error code number and a
brief description in quotes. The description will be one of the messages in the table below,
possibly followed by more information.

response is received, the desired module connection has been

.

Error code Error message Error code Error message

0 No error -141 Invalid character data

-100 Command Error -144 Character data too long

-102 Syntax Error -150 String data error

-103 Invalid separator -151 Invalid string data

-108 Parameter not allowed -200 Execution error

-109 Missing parameter -220 Parameter error

-113 Undefined header -221 Settings conflict

-120 Numeric data error -222 Data out of range

-121 Invalid character in number -224 Illegal parameter value

-138 Suffix not allowed -231 Data questionable

It is recommended that this command is sent automatically after any query command
(ending with a '?'). If a command is errored, checking ":SYSTem:ERRor?" will immediatly
report the mistake, while not checking it will result in the mistake being silently ignored.

Examples:

> *REM
> :INITiate
> :SYSTem:ERRor?

-221, "Settings conflict; no application has been selected"

> :SENSe:MISSpelled:COMMand?

Transport Module, DMC, MSAM, and 5800 Remote Operation 11

Remote Operation Getting Started Guide

Working with applications

> :SYSTem:ERRor?

-113, "Undefined header; could not find

':sense:misspelled:command'"

List Available

Applications

:SYST e m:APPLication:APPLications?

This command returns a comma-separated list of all applications that can be launched in
addition to any applications currently running.

If an existing application is using a particular interface, then all other applications that use
that interface type will be unavailable unless another suitable interface is available. For
example, if a 10/100/1000M electrical Ethernet application is using the only Ethernet po rt,
all other 10/100/1000M Ethernet applications will be unavailable and therefore will not show
up in this query. To determine the full list of applications a unit supports, query this
command when no other applications are running.

Example:

> :SYSTem:APPLication:APPLications?

TermDs1Bert,ThruDs1Bert,SingleMonDs1Bert,...

For units that have multiple ports, this query can also be given additional parameters to
request the applications that are available to a specific port. The first parameter is reserved
for internal use; use the value "none". The second p arameter spe cifies the port to query: 1
or 2.

Example:

> :SYSTem:APPLication:APPLications? none 2

MonEth10ML2Traffic,TermEth10ML2Loopback,...

List Currently

Running Applications

:SYST e m:APPLication:CAPPlications?

This command returns a comma-separated list of the unique identifiers for all currently
running applications. The return values returned from this query may be used to select an
application (using the :SYSTem:APPLication:SELect command).

Example:

> :SYSTem:APPLication:CAPPlications?

TermStm16Au4Vc4E4Bert_121,TermStm64Au4Vc4E4Bert_121

Launch an

Application

:SYST e m:APPLication:LAUNch <application name> [port]

This command will launch the specified application. This operation is different from normal
GUI interaction in that the application will be launched in addition to any existing applica­tions; it will not replace the currently running application. The port number on which to
launch the application (1 or 2) may be specified as an optional parameter if the unit has a
second port. If not specified, the default is the first available port. If no open port s are avail­able, an error message will be stored (accessible with the :SYSTem:ERROR? command)
and no action will be taken.

12 Transport Module, DMC, MSAM, and 5800 Remote Operation

Remote Operation Getting Started Guide

Working with applications

Examples:

Launch 2G Fibre Channel on port 1 (or port 2 if port 1 is unavailable)

> :SYSTem:APPLication:LAUNch TermFc1GL2Traffic

Launch 2G Fibre Channel on port 2

> :SYSTem:APPLication:LAUNch TermFc1GL2Traffic 2

Another key difference from laun ching the test on the GUI is that in remote control, the test
will come up in the "stopped" state, leaving most test results unreadable. The remote
control user should usually send the :INITiate command after initializing the remote
session.

:SYST e m:APPLication:LAUNch?

Adding a question mark (?) to the end of the launch command will query for the application
identifier of the most recently launched application. This identifier may be used to select the
application using the :SYSTem:APPLication:SELect command.

Example:

> :SYSTem:APPLication:LAUNch?
TermFc1GL2Traffic_121

Select an Application :SYSTem:APPLication:SELect <application id>

This command selects a specific running instance of an applica tion, which directs all subse­quent commands to that application. It must be sent after the application is launched and
the unique id for that application instance has been obtained.

The application id will be the application name followed by a 3-digit number. The first two
digits represent the "slice" number and the "side" number where the module is located (see
the documentation on Connecting to Remote Control for more explanation of these), and
will always be the same within a particular remote control connection. The third digit repre­sents the port number: 1 or 2. The example below shows two instances of the same
ethernet application, one running on port 1 and one running on port 2, and the command
to select the one running on port 1.

Example:

> :SYSTem:APPLication:CAPPlications?
TermEth10ML2Traffic_121,TermEth10ML2Traffic_122
> :SYSTem:APPLication:SELect TermEth10ML2Traffic_121
> :SYSTem:ERRor?
0, "No error"

Remote Control

Session

Commands

A remote control session maintains information about a specific connection to an applica­tion. Once an application has been selected, a remote control session must be created and
started before the user can interact with the application.

Transport Module, DMC, MSAM, and 5800 Remote Operation 13

Remote Operation Getting Started Guide

Using setups, actions, and results

:SESSion:CREate

:SESSion:STARt

:SESSion:END

Common Application

Commands

This command creates a remote control session with the selected application.

This command starts a previously created remote control session.

This command terminates the current remote control session. The session will automati­cally be ended when an application is shut down or the remote connection is terminated.

The following commands apply to all test applications.

:INITiate

The :INITiate command starts the test if it is in the "stopped" state.

:ABORt

The :ABORt command stops the test if it is in the "running" state.
To perform a test restart and restart all test measurement results, perform a test stop,

followed by a test start.

Example:

> :ABORt

> :INITiate

> :SYSTem:ERRor?

0, "No error"

:EXIT

Shuts down the currently running application.

Using setups, actions, and results

Setup commands

A unique SCPI command exists for every setup.
The setup value should be space-separa ted from the command, but there should be no

space before the port number and/or question mark.

NOTE

Commands do not return any values unless they are a que ry. Remember to
check each command with the :SYSTem:ERRor? query. If you do not
check each command, and one is incorrect, the error message does not
indicate the incorrect command.

14 Transport Module, DMC, MSAM, and 5800 Remote Operation

Remote Operation Getting Started Guide

Using setups, actions, and results

Setup values
specification

Setup value format

String values

T o ch ange a setup, issue the SCPI command for that setup followed by the new value. The
command in the following example sets (or changes) the receive pattern on port 2 to all
ones:

:SENSe:PAYLoad:BERT:PATTern1 ALL_ONES

For setups that are arrays, you can specify an index or list indices of the array element(s)
that you want. A colon (:) can be used to denote an index range (within the @ specification
of the channel) followed by the status value.

The following example disables (0) time slot 4 (first line) and enables (1) time slots 1, 2, 3
and 7 (second line) in fractional E1:

:SOURce:PDH:E1:CHANnel (@4) 0
:SOURce:PDH:E1:CHANnel (@1:3,7) 1

Setup values do not follow standard SCPI naming conventions and must be stated using
the string values and enumerated value formats illustrated in the following examples. As
with all values, setup values need to be space-separated from the command.

String values are used for setups where the exact string is not a value defined by the SCPI
implementation. String values must be enclosed in double quotes.

Port Definition

Enumerated Values

Correct format

:SOURce:DATA:MAC:IPV6:TX:DESTination:ADDRess "ff00::1234:2345"

Incorrect format

:SOURce:DATA:MAC:IPV6:TX:DESTination:ADDRess ff00::1234:2345

Port definitions are generally not required in setup s u nless a d ual po rt a pplica tion is be ing
tested. If no number is specified, 0 (port 1) is assumed.

To specify port numbers in dual port applications, add a zero-based port number (0 for port
1, 1 for port 2) directly after the command (or before the ? if you are issuing a query).

The setup value should be space-separated from the command, but there should be no
space before the port number and/or question mark.

NOTE

Remember to check each command with the SYST:ERR? query. If you do
not check each command, and one is incorrect, the error message does not
indicate the incorrect command.

Enumerated values are used for setups that have specified settings defined by the SCPI
implementation. Enumerated setup values are case sensitive and should not be enclosed
in quotes.

Transport Module, DMC, MSAM, and 5800 Remote Operation 15

Remote Operation Getting Started Guide

Using setups, actions, and results

Correct format

:SENSe:PAYLoad:BERT:PATTern ALL_ONES

Incorrect format

:SENSe:PAYLoad:BERT:PATTern "ALL_ONES"

:SENSe:PAYLoad:BERT:PATTern all_ones

Investigate the command line specifications, found elsewhere in this document, for a more
complete list of string values and enumerated values that apply to various commands.

Query values

Initiating actions

Initiate command

To query the current value of the setup, issue the SCPI command for that setup followed
by a question mark.

The commands in the following examples both query for the transmit DS1 framing on line
0 (as described in “Port Definition” on page 15):

:SOURce:PDH:DS1:FRAMING?

:SOURce:PDH:DS1:FRAMING0?

A unique SCPI command exists for every action. The examples in this section will show
how actions can be implemented, and status can be queried and toggled using the same
root command with minor variations on its initiation.

NOTE

Remember to check each command with the SYST:ERR? query. If you do
not check each command, and one is incorrect, the error message does not
indicate the incorrect command.

The command in the following example inserts a single bit error o n line 0 (line assumed to
be 0 when not indicated):

:SOURce:PAYLoad:BERT:INSert:TSE

Query state

To discover what is the state of error rate insertion action (on line 0) the:RATE? query is
added:

:SOURce:PAYLoad:BERT:INSert:TSE:RATE?

:SOURce:PAYLoad:BERT:INSert:TSE:RATE0?

Initiate command

To turn error rate insertion ON (on line 0):

:SOURce:PAYLoad:BERT:INSert:TSE:RATE ON

:SOURce:PAYLoad:BERT:INSert:TSE:RATE0 ON

Toggling actions

Many action commands simply toggle the action ON and OFF.

16 Transport Module, DMC, MSAM, and 5800 Remote Operation

Remote Operation Getting Started Guide

Using setups, actions, and results

The following command toggles error rate insertion (rever ses its state) for line 0.

:SOURce:PAYLoad:BERT:INSert:TSE:RATE

Executing the same command a second time without a parameter will turn error rate inse r­tion back to its original state (OFF).

Port Definition

Further resources

Querying results

As with setups, the zero-based port index (0 for port 1 and 1 for port 2) may optionally be
specified at the end of the command (or before the "?" if a query is issued).

If no number is specified, 0 (port 1) is assumed.

Investigate the action initiation specifications, found elsewhere in this document, for a more
complete list of actions commands.

Action commands do not return any value unless they are queries. To obtain the results of
the tests initiated, a query must be issued.

All test results are queried using the following command:

[:SENSe]:DATA <result name>

where

– [:SENSe] is an [optional] entry.

[line] represents the port number. It is not necessary to enter the port num b er

unless a dual port application is running. For dua l p ort ap plication s, "0" corre sponds to
port 1; "1" corresponds to port 2.
Usage: [:SENSe]:DATA[line]? <result name>

– [array indices] specifies indices for results that are arrays. For example,

(@1,3:5) indicates that the query result s are for indices 1, 3, 4 and 5. Note that index
numbering is zero-based.
Usage:[:SENSe]:DATA[line]? [array indices] <result name>

– result name is the name of the result to be queried.
These examples query for the value of the signal presen t result on line 1 (the second port),

illustrating that [:SENSe] is optional:

:SENSe:DATA1? CSTATUS:PHYSICAL:SIGNAL
:DATA1? CSTATUS:PHYSICAL:SIGNAL

The following examples query for the value o f pattern sync present result on line 0 (the first
port), illustrating the optional nature of defining port 0:

:SENSE:DATA? CSTatus:PAYLoad:BERT:PATTern:SYNC
:SENS:DATA0? CST:PAYL:BERT:PATT:SYNC
:DATA? CST:PAYL:BERT:PATT:SYNC
:DATA0? CST:PAYL:BERT:PATT:SYNC

Transport Module, DMC, MSAM, and 5800 Remote Operation 17

Remote Operation Getting Started Guide

Using setups, actions, and results

NOTE

Not-a-Number formats from the SCPI standard are supported. If a result is
not applicable or is out of range, a result query will return an appropriate
value as shown below.

9.91e+37 Not Applicable/Not Ready

(cannot be calculated from current information)

9.90e+37 Over range

-9.90e+37 Under range

Result groups

Group definition

Group result report

Result group

examples

Result commands may be added to user-defined groups, which allow the simultaneous
query and reporting of multiple parameter result values.

The format of a command to add a result parameter to a gr ou p is:

:SENSe:DATA:GROUP [group name] [result parameter]

where
– [group name] specifies the name of the group.
– [result parameter] is the data parameter being tested that is to be reported when

the group results report is queried.

A result can only be in a group once; no change will be made to the group if it is added

again.

Once a group is defined, it can be queried with the following command:

:SENSe:DATA:GROUP? [group name]

This will return the list of result values separated by semicolons (;) in the order in which

they were added to the group.

The following example creates and queries a small group of Ethernet results:

:SENSe:DATA:GROUP summary CSTatus:PHYSical:SIGNal

:SENSe:DATA:GROUP summary CSTatus:PCS:PHY:SYNC:ACTive

:SENSe:DATA:GROUP summary CSTatus:MAC:ETH:FRAMe:DETect

:SENSe:DATA:GROUP? summary

The last command will return something like "1; 0; 9.91e+37", indicating signal is

on, sync is off, and frame detect is not available.

Reset group deletion

Result groups are a report of multiple parameter results from a currently running applica­tion. Result groups are not retained beyond the current session.

All result groups will be deleted when the remote control session is closed with
":SESSion:END".

18 Transport Module, DMC, MSAM, and 5800 Remote Operation

Rebooting an instrument

To reboot the unit, establish a socket connection to port 8000. The *REM command must
be sent first. Then send the following command:

:SYSTem:REBoot

The time to reboot will depend on the platform type.
Query the :SYST:FUNC:READY? <side>,<slice>,"BERT" command on the module port to

determine when the reboot is complete and BER T so f tware i s running again (s ee “Getting

the remote control port number” for information on this command). This will bring the unit

back into GUI mode. Any remote connections will need to be reestablished.

Example remote control procedures

This section includes a few examples of common procedures you may encounter. Lines
that begin with ">" indicate that a command is being sent by the user to the remote control
socket connection. If the command returns a value, the response is shown on the next line.

Remote Operation Getting Started Guide

Rebooting an instrument

Connecting to an

instrument and

obtaining the

remote control

port number

Connecting to a MTS-

6000A

– “Connecting to an instrument and obtaining the remote control port number” on

page 19

– “Starting Remote Control” on page 21
– “Application interaction” on page 22

Remote control is accessed by connecting to the test unit on a specific port number. This
number is determined by connecting to port 8000 and obtaining a port to access the
module, then connecting to that port and querying for its remote control port. Below are a
few examples of this process for specific platforms.

The MTS-6000A only supports the use of a single module (MSAM). Therefore when
connecting to that platform, the paramete rs supplied to the commands below should always
be PWRS,SLIC1,"BERT".

1 Open a TCP/IP socket connection to the unit on port 8000.

> *REM

> MOD:FUNC:SEL? PWRS,SLIC1,"BERT" (Optional query to verify the module

is powered on, returns "OFF" or "ON")

ON

> MOD:FUNC:PORT? PWRS,SLIC1,"BERT" (Query for the module's port

number)

8002

Transport Module, DMC, MSAM, and 5800 Remote Operation 19

Remote Operation Getting Started Guide

Example remote control procedures

2 Open a TCP/IP socket connection to the unit on the port number returned by the

previous step.

> *REM
> :SYST:FUNC:READY? PWRS,SLIC1,"BERT" (Optional query to verify the

BERT application is running and ready to communicate, returns "0" or "1")

1
> :SYST:FUNC:PORT? PWRS,SLIC1,"BERT" (Query for the port number to

remote control)

8003

The port number returned by the final command can be used to establish a remote contr ol
connection, as shown in “Starting Remote Control” on page 21.

Connecting to a MTS-

8000 transport

module

The MTS-8000 supports the use o f multiple transport modules. When connecting to one of
these, the "slice id" must be provided to indicate the desired module. Slice ids are specified
as as SLIC1, SLIC2, etc. with SLIC1 being the closest module to the front display. The
example below connects to the first (or only) slice, SLIC1.

1 1. Open a TCP/IP socket connection to the unit on port 8000. Lines starting with ">"

indicate commands sent by the user.

> *REM
> MOD:FUNC:SEL? BOTH,SLIC1,"BERT" (Optional query to verify the module is

powered on, returns "OFF" or "ON")
ON

> MOD:FUNC:PORT? BOTH,SLIC1,"BERT" (Query for the module's port number)
8002

2 Open a TCP/IP socket connection to the unit on the port number returned by the

previous step.

> *REM
> :SYST:FUNC:READY? BOTH,SLIC1,"BERT" (Optional query to verify the

BERT application is running and ready to communicate, returns "0" or "1")

1
> :SYST:FUNC:PORT? BOTH,SLIC1,"BERT" (Query for the port number to

remote control)

8003

The port number returned by the final command can be used to establish a remote contr ol
connection, as shown in “Starting Remote Control” on page 21.

Connecting to an

MTS-8000 dual MSAM

carrier

The MTS-8000 supports the use of multiple dual MSAM carrier modules, each of which
may have up to two MSAM modules. When connecting to one of these, the "side" and the
"slice id" must be provided to indicate the desired module. The side parameter is either
OPPS - indicating the MSAM is on the side opposite the power connector (the left side
when viewed from the front), or PWRS - on the same side as the po wer connector (the right
side when viewed from the front). Slice ids are specified as as SLIC1, SLIC2, etc. with
SLIC1 being the closest module to the front display. The example below connects to an
MSAM on left side (OPPS) of the first slice (SLIC1).

20 Transport Module, DMC, MSAM, and 5800 Remote Operation

Remote Operation Getting Started Guide

Example remote control procedures

1 Open a TCP/IP socket connection to the unit on port 8000.

> *REM

> MOD:FUNC:SEL? OPPS,SLIC1,"BERT" (Optional query to verify the module is

powered on, returns "OFF" or "ON")

ON

> MOD:FUNC:PORT? OPPS,SLIC1,"BERT" (Query for the module's port number)

8002

2 Open a TCP/IP socket connection to the unit on the port number returned by the

previous step.

> *REM

> :SYST:FUNC:READY? OPPS,SLIC1,"BERT" (Optional query to verify the

BERT application is running and ready to communicate, returns "0" or "1")

1

> :SYST:FUNC:PORT? OPPS,SLIC1,"BERT" (Query for the port number to

remote control)

8003

The port number returned by the final command can be used to establish a remote contr ol
connection, as shown in “Starting Remote Control” on page 21.

Starting Remote

Control

Remote Control with

GUI disabled (default)

Remote Control with

GUI enabled

Once the port number for remote control h as been o btained (see “Connecting to an instru-

ment and obtaining the remote con trol port number” on page 19), remote control mode may

be activated with the *REM command. It is recommended that the ":SYSTem:ERRor?"
command be sent after every non-query command, as this is the easiest way to verify that
each command is processed successfully. Lines starting with ">" indicate commands sent
by the user.

This command will shut down the GUI and display a message indicate the unit is under
remote control. All running applications will be stopped.

> *REM (This may take a few seconds if an application is running...)

> :SYSTem:ERRor? (This command may be sent in the mean time, but will not be

processed until *REM is finished.)

0, "No error" (Once this message is received, the switch to remote control mode

is complete.)

This command does not shut down the GUI, or any running applications.

> *REM VISIBLE (This may take a few seconds.)

> :SYSTem:ERRor? (This command may be sent in the mean time, but will not be

processed until *REM is finished.)

0, "No error" (Once this message is received, the switch to remote control

mode is complete.)

Transport Module, DMC, MSAM, and 5800 Remote Operation 21

Remote Operation Getting Started Guide

Example remote control procedures

Application

interaction

Querying for running

applications

Launching an

application

Once the test unit is in remote control mode, the following commands may be useful to
determine what applications can be launched.

> :SYSTem:APPLication:APPLications?

Get a list of available application names. The return value for this command depends
on what is currently running. To get the list of all applications the unit supports, send
this query when no applications are running.

TermDs1Bert,ThruDs1Bert,SingleMonDs1Bert,...
> :SYSTem:APPLication:CAPPlication?

Get a list of identifiers for applications that are currently running.

TermStm4Au3Vc3Bert_121,TermEth1GL3Traffic_122
> :SYSTem:APPLication:LAUNch?

Get the identifier of the most recently launched application.

TermEth1GL3Traffic_122

Once the test unit is in remote control mode, the following commands may be sent to launch
an application (in this example, 1GigE L3 Traffic Terminate).

> :SYSTem:APPLication:LAUNch TermEth1GL3Traffic

Launch the application (same as "Add test" on the GUI; other running applications will
not be shut down by this command). This may take a few seconds...

> :SYSTem:ERRor?

This command may be sent in the mean time, but will not be processed until the appli­cation launch is finished.

0, "No error"

Once the application is running, this message will be returned.

> :SYSTem:APPLication:LAUNch?

Get the id of the most recently launched application.

TermEth1GL3Traffic_121
> :SYSTem:APPLication:SELect TermEth1GL3Traffic_121

Select that application id.

> :SYSTem:ERRor?
0, "No error"

> :SESSion:CREate

Create a new remote session

> :SESSion:STARt

Start the session

22 Transport Module, DMC, MSAM, and 5800 Remote Operation

Remote Operation Getting Started Guide

Example remote control procedures

> :SYSTem:ERRor?

0, "No error"

> :INITiate

Start the test. (When applications are launched through remote control, they begin in

the "stopped" state).

> :SYSTem:ERRor?

0, "No error"

When using remote control with the GUI enabled and an desired application is already
running, a similar process can be followed to connect to it. Use the ":SYSTem:APPLica­tion:CAPPlication?" query to find its application id, select the app lication, then create and
start a remote session. ":INIT iate" only needs to b e sent if the test is in the "stopped" state.

This example also illustrates use of the :SYST em:ERRor? query . The user sh ould have this
command sent automatically after every non-query command and the 0, "No error"
response should be expected. Doing so will provide vital information in the event of a
command error or connection issue.

Restarting the test

Using setups, actions,

and results (inserting

and checking an

alarm)

T o restart the te st using remote control, send the test stop command followed by a test st art.

> :ABORtTest stop

> :INITiateTest start

The following commands demonstrate the use of applica tion setups, actions and resu lts. In
this example, assume we have launched and initialized the DS1 BERT Terminate applica­tion (TermD s1 Bert). Lines starting with ">" indicate commands sent by the user.

> :SOURce:ALARm:TYPE?

Query the current alarm type setup

"Ds1LofAlarm"

Note: some query commands return values with double quotes (") and some do not.

Making remote control scripts quote-insensitive when checking returned values is

highly recommended.

> :SOURce:ALARm:TYPE Ds1AisAlarm

Set the alarm type setup to AIS.

> :SOURce:PDH:DS1:INSert:AIS ON

Enable the AIS alarm insertion action

> :SOURce:PDH:DS1:INSert:AIS?

Query the current state of the AIS alarm insertion action

ON

Transport Module, DMC, MSAM, and 5800 Remote Operation 23

Remote Operation Getting Started Guide

Example remote control procedures

> :SENSe:DATA? CSTatus:PDH:DS1:AIS

Query the AIS alarm result

1

If the unit is self-looped, it will detect the AIS.

> :SOURce:PDH:DS1:INSert:AIS OFF

Turn the alarm back off

> :SENSe:DATA? CSTatus:PDH:DS1:AIS

Query the AIS alarm result again

0

Configuring a timed

test

Exiting an application

There are three test timing modes: not timed, timed test, and delayed-start timed test. This
example demonstrates how to configure each of those.

> :SENSe:TEST:ENABle OFF

Sets the test type to "Not Timed"

> :SENSe:TEST:ENABle ON

Sets the test type to "Timed Test"

> :SENSe:TEST:DURation 3600

Set the timed test duration in seconds

> :SENSe:TEST:ENABle DELAYED

Sets the test type to "Delayed-start timed test"

> :SENSe:TEST:DURation 3600

Set the timed test duration in seconds

> :SENSe:TEST:DELay:DATE "10/31/2011"

Set the start test date

> :SENSe:TEST:DELay:TIME "23:00:00"

Set the start test time

To shut down an application through remote control, it must first be selected. If the applica­tion is already selected and a session has been created, that session should be ended.

> :SYSTem:APPLication:SELect TermDs1Bert_121
> :EXIT

or

> :SESSion:END
> :EXIT

24 Transport Module, DMC, MSAM, and 5800 Remote Operation

Remote Operation Getting Started Guide

Demo Remote Control Scripts

Leaving remote

control mode

The *GUI command shuts down all applications running under remote contol and restores
the GUI interface. This command may take some time to finish processing. The
":SYSTem:ERRor?" query will still indicate when *GUI is complete, but most other remote
control commands (except *REM, *RST, etc.) will no longer work.

> *GUI

Return to GUI mode, make take a while...

> :SYSTem:ERRor?

This command will return once the GUI is back up.

0, "No error"

Demo Remote Control Scripts

The following Perl scripts are provided on the the USB stick to demonstrate how to establish
and use a remote control session to the various platforms. They ar e all similar , only differing
in the way the script arguments are processed.

RC-Transport.pl - to connect to a Transport Module in a T-BERD/MTS-8000
Usage: perl RC-Transport.pl <unit ip> <slice #>

RC-6000A.pl - to connect to an MSAM module a T-BERD/MTS-6000A
Usage: perl RC-6000A.pl <unit ip>

RC-DMC.pl - to connect to an MSAM module a T-BERD/MTS-8000 dual MSAM carrier
Usage: perl RC-DMC.pl <unit ip> <side> <slice #>

RC-5800.pl - to connect to an MTS-5800
Usage: perl RC-5800.pl <unit ip>

Script parameters:
– <unit ip> - the IP address of the unit

– <side> - optional, specifies which slot of the DMC to communicate with

– OPPS - (default) left side ("opposite side" from the power connector )

– PWRS - right side ("power side", same side as the power connector)
– <slice #> - optional, specifies which module to communicate with

– 1 - (default) the module closest to the front display

– 2, 3, etc - second or third modules, counting from the front

Transport Module, DMC, MSAM, and 5800 Remote Operation 25

Remote Operation Getting Started Guide

SCPI command reference

SCPI command reference

A full list of SCPI commands, along with this manual as HTML, is availabl e on the USB stick
that shipped with your instrument.

Communications Test and Measurement Solutions
One Milestone Center Court
Germantown, Maryland 20876-7100 USA
Toll Free 1-855-ASK-JDSU • Tel [phone] • Fax [phone]

www.jdsu.com

© Copyright 2013 JDS Uniphase Corporation. All rights reserved. JDSU, Enabling Broadband and Optical Innovation, Communications
Test and Measurement Solutions, and the logo are trademarks of JDS Uniphase Corporation. Windows is a registered trademark of
Microsoft Corporation in the United States and other countries. All other trademarks and registered trademarks are the property of their
respective owners. Specifications, terms, and conditions are subject to change without notice.
