JCM Base User Manual

COD. 1248017-GB / 1.1

BASE30-1 / BASE30-2

BASE500-1 / BASE500-2

BASE30 / BASE500

1

COD. 1248017-GB / 1.1

BASE30 / BASE500

BASE500-1B / BASE500-2B

TECHNICAL CHARACTERISTICS

BASE30-1 / BASE30-2 BASE500-1 / BASE500

Frequency 868,35MHz 868,35MHz 868,35MHz

Coding High security rolling code High security rolling code High security rolling code

Memory 30 codes 500 codes 500 codes

Number of relays 1 / 2 relays 1 / 2 relays 1 / 2 relays

Supply 12/24V ac/dc 230V ac 12/24V ac/dc

Power supply range

Relay contacts 1A 1A 1A

Standby/Op.

consumption

Op. temperature -20ºC to +85ºC -20ºC to +85ºC -20ºC to +85ºC

Watertightness IP54 (with glands IP65) IP54 (with glands IP65) IP54 (with glands IP65)

Size 63x55x15mm 63x74x25mm 63x74x25mm

Box dimensions 82x190x40mm 82x190x40mm 82x190x40mm

9-24 / 21-35V dc
8-16 / 15-28V ac

18mA / 80mA 10mA / 15mA 60mA / 90mA

10%

2 BASE500-1B /

BASE500-2B

9-23 / 22-35V dc
8-16 / 16-27V ac

2
