ENGLISH USER MANUAL
OPERATION MANUAL
Thank you for buying this JB Systems® product. To take full advantage of all possibilities and for your own
safety, please read these operating instructions very carefully before you start using this unit.
This unit is radio-interference suppressed. This product meets the requirements of the current European and
national guidelines. Conformity has been established and the relevant statements and documents have been
deposited by the manufacturer.
This device was designed to produce decorative effect lighting and is used in light show systems.
FEATURES
The perfect alternative for the classic mirror ball with pin spots!
This LED GLOBE offers the same type of effect with much more possibilities!
Take control over rotation speed, colors, strobe, etc. or just use the build-in programs.
Simple and fast installation, easy to use
Multiple working modes:
DMX-controlled via 1, 3, 9 or 19 channels.
Standalone: sound activated (internal microphone) or automatic.
Standalone, controlled via the IR remote controller (included)
Great built-in programs for wonderful, ever changing, light shows.
Several units can be connected in master/slave to create wonderful synchronized shows.
3-digit LED display for easy menu navigation.
USB-connector for wireless DMX control by an optional Briteq® WTR-DMX dongle.
IEC power in/out can be used to easily link several units.
BEFORE USE
Before you start using this unit, please check if there’s no transportation damage. Should there be any, do
not use the device and consult your dealer first.
Important: This device left our factory in perfect condition and well packaged. It is absolutely necessary
for the user to strictly follow the safety instructions and warnings in this user manual. Any damage caused
by mishandling is not subject to warranty. The dealer will not accept responsibility for any resulting defects
or problems caused by disregarding this user manual.
Keep this booklet in a safe place for future consultation. If you sell the fixture, be sure to add this user
manual.
Check the contents:
Check if the cardboard box contains the following items:
LED GLOBE
IR Remote controller
Mains cable
Hanging bracket + 4 screws
Operating instructions
JB SYSTEMS® 1/11 LED GLOBE
ENGLISH USER MANUAL
CAUTION: Do not stare at operating lamp.
May be harmful to the eyes.
CAUTION
SAFETY INSTRUCTIONS:
CAUTION: To reduce the risk of electric shock, do not remove the top cover.
No user-serviceable parts inside. Refer servicing to qualified service
personnel only.
The lightning flash with arrowhead symbol within the equilateral triangle is intended to alert the use
or the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within the equilateral triangle is intended to alert the user to the presence of
important operation and maintenance (servicing) instructions in the literature accompanying this
appliance.
This symbol means: indoor use only.
This symbol means: Read instructions.
This symbol determines: the minimum distance from lighted objects. The minimum distance between
light-output and the illuminated surface must be more than 1 meter.
To protect the environment, please try to recycle the packing material as much as possible.
A new light effect sometimes causes some unwanted smoke and/or smell. This is normal and disappears
after some minutes.
To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
To avoid condensation to be formed inside, allow the unit to adapt to the surrounding temperatures when
bringing it into a warm room after transport. Condense sometimes prevents the unit from working at full
performance or may even cause damages.
This unit is for indoor use only.
Don’t place metal objects or spill liquid inside the unit. Electric shock or malfunction may result. If a foreign
object enters the unit, immediately disconnect the mains power.
Locate the fixture in a well ventilated spot, away from any flammable materials and/or liquids. The fixture
must be fixed at least 50cm from surrounding walls.
Don’t cover any ventilation openings as this may result in overheating.
Prevent use in dusty environments and clean the unit regularly.
Keep the unit away from children.
Inexperienced persons should not operate this device.
The save ambient temperature is between 15° & 40°C. Don’t use this unit at higher ambient temperatures.
Make sure the area below the installation place is free from unwanted persons during rigging, de-rigging
and servicing.
Always unplug the unit when it is not used for a longer time or before replacing the bulb or start servicing.
The electrical installation should be carried out by qualified personal only, according to the regulations for
electrical and mechanical safety in your country.
Check that the available voltage is not higher than the one stated on the rear panel of the unit.
The power cord should always be in perfect condition. Switch the unit immediately off when the power cord
is squashed or damaged. It must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Never let the power-cord come into contact with other cables!
This fixture must be earthed to in order comply with safety regulations.
Don’t connect the unit to any dimmer pack.
Always use an appropriate and certified safety cable when installing the unit.
In order to prevent electric shock, do not open the cover. Apart from the lamp and mains fuse there are no
user serviceable parts inside.
Never repair a fuse or bypass the fuse holder. Always replace a damaged fuse with a fuse of the same
type and electrical specifications!
In the event of serious operating problems, stop using the fixture and contact your dealer immediately.
The housing and the lenses must be replaced if they are visibly damaged.
Please use the original packing when the device is to be transported.
Due to safety reasons it is prohibited to make unauthorized modifications to the unit.
JB SYSTEMS® 2/11 LED GLOBE
ENGLISH USER MANUAL
Important: Never look directly into the light source! Don’t use the effect in the presence of persons suffering
from epilepsy.
DESCRIPTION:
1. HANDLE to carry the unit
2. HANGING BRACKET: with a mounting hole in the middle to fix a mounting hook
3. IR RECEIVER: point your IR Remote to this area if you want to control the unit
4. [SOUND] LED: flashes when sound is detected. Use the sensitivity knob (9) to set the desired level
5. [DMX] LED: this LED is on when a dmx signal is detected
6. DISPLAY: shows all the necessary information about settings and working modes.
7. [AUTO] LED: this LED is on when the unit is in automatic mode
8. INTERNAL MICROPHONE: is used to synchronize the sound controlled shows to the beat of the music.
You can set the sensitivity of this microphone by adjusting the sensitivity knob (9)
9. SENSITIVITY KNOB: turn this knob anti-clockwise to decrease the sensitivity or turn it clockwise to
increase the sensitivity of the integrated microphone. Try to make the setting so the sound controlled
programs react to the beat of the music and not to the surrounding noise.
10. [SLAVE] LED: this LED is on when the unit is in slave mode
11. ENTER BUTTON: used to confirm your choice
12. DOWN BUTTON: to go back in the menu and to lower the values shown on the display
13. UP BUTTON: to go up in the menu and to increase the values shown on the display
14. MENU BUTTON: used to browse the different menu options
15. SAFETY EYE: here you can attach the optional safety cable
16. MAINS INPUT WITH FUSEHOLDER + MAINS LINK OUTPUT:
Mains Input: Connect the supplied mains cable here.
Important: Always replace the fuse by a model with exactly the same specifications !
Mains output: use a special IEC male/female power cable (or a JB Systems Combi Cable) to
connect this output with the mains input of the next LED GLOBE unit for easier linking
17. DMX INPUT/OUTPUT: 3pin male/female XLR-connectors used to connect universal DMX-cables. The
input receives instructions from a DMX-controller (in DMX mode) or from the Master unit (in
Master/Slave mode). The output is used to connect the unit with the next unit in the DMX chain.
18. M-DMX INPUT: Please note that this USB-connector is NOT used for updates or to connect the unit to a
PC! Instead this USB-connector makes it very easy to add wireless DMX to the unit! Just add the
(optional) WTR-DMX DONGLE from BRITEQ® and you will get wireless DMX! Moreover you will be able
to connect other DMX-controlled equipment to the DMX-output so you can share the wireless DMX
function with all connected units! No extra settings to be made in the setup menu, just follow the
procedure in the user manual supplied with the WTR-DMX DONGLE from BRITEQ®. The separate
WTR-DMX DONGLE is available from WWW.BRITEQ-LIGHTING.COM (order code: 4645)
JB SYSTEMS® 3/11 LED GLOBE
ENGLISH USER MANUAL
OVERHEAD RIGGING
Important: The installation must be carried out by qualified service personal only. Improper
installation can result in serious injuries and/or damage to property. Overhead rigging requires
extensive experience! Working load limits should be respected, certified installation materials
should be used, the installed device should be inspected regularly for safety.
Make sure the area below the installation place is free from unwanted persons during rigging, de-rigging
and servicing.
Locate the fixture in a well ventilated spot, far away from any flammable materials and/or liquids. The
fixture must be fixed at least 50cm from surrounding walls.
The device should be installed out of reach of people and outside areas where persons may walk by or be
seated.
Before rigging make sure that the installation area can hold a minimum point load of 10times the device’s
weight.
Always use a certified safety cable that can hold 12 times the weight of the device when installing the unit.
This secondary safety attachment should be installed in a way that no part of the installation can drop
more than 20cm if the main attachment fails.
The device should be well fixed; a free-swinging mounting is dangerous and may not be considered!
Don’t cover any ventilation openings as this may result in overheating.
The operator has to make sure that the safety-relating and machine-technical installations are approved by
an expert before using them for the first time. The installations should be inspected every year by a skilled
person to be sure that safety is still optimal.
HOW TO SET UP AND CONTROL THE UNIT
You can operate the unit in several ways:
1) FULL AUTOMATIC STANDALONE MODE:
The effect automatically runs a preprogrammed sequence. Select this mode when only 1 LED GLOBE unit
is used (standalone) or when the unit is placed as the first (master) unit in a chain with several LED
GLOBE units in Master/Slave mode (see below).
There are different types of standalone modes:
Automatic show mode: this is how to select one of the preprogrammed shows
Press the [MENU] button until the display shows [Aut].
Press the [ENTER] button to enter the setup.
Use the [UP] and [DOWN] buttons to select one of the 5 automatic shows (P1-P5)
Press the [ENTER] button to confirm.
Use the [UP] and [DOWN] buttons to select the speed of the program (S.1 to S.100)
Press the [ENTER] button to confirm.
Color mode: this is how to set a fixed color
Press the [MENU] button until the display shows [CoL].
Press the [ENTER] button to enter the setup. The display shows [CoLo].
Press the [ENTER] button to enter the setup.[r] appears on the display
Use the [UP] and [DOWN] buttons to set the intensity of the red color
Press the [ENTER] button. [r***] (r followed by 3 numbers) appears on the display
Use the [UP] and [DOWN] buttons to set the intensity of the red color
Press the [ENTER] button. [G***] (G followed by 3 numbers) appears on the display
Use the [UP] and [DOWN] buttons to set the intensity of the green color
Press the [ENTER] button. [b***] (b followed by 3 numbers) appears on the display
Use the [UP] and [DOWN] buttons to set the intensity of the blue color
Press the [ENTER] button. [W***] (W followed by 3 numbers) appears on the display
Use the [UP] and [DOWN] buttons to set the intensity of the white color
Press the [ENTER] button. [S***] (S followed by numbers) appears on the display
Use the [UP] and [DOWN] buttons to set the intensity strobe speed. 000= no strobe
Press the [ENTER] button. [di-r] appears on the display
JB SYSTEMS® 4/11 LED GLOBE
ENGLISH USER MANUAL
Use the [UP] and [DOWN] buttons to select the direction of the rotation [di –L] = counter clockwise or [di
–r] = clockwise
Press the [ENTER] button to confirm.
Use the [UP] and [DOWN] buttons to select the speed of motor:
o [M 0] = No rotation.
o [M 1] to [M 100] = rotation slow to fast
2) SOUND CONTROLLED STANDALONE MODE:
The LED GLOBE runs a preprogrammed sequence to the rhythm of the music. Select this mode when
only 1 LED GLOBE is used (standalone) or when the LED GLOBE is placed as the first (master) unit in a
chain with several units.
Press the [MENU] button until the display shows [Sou].
Press the [ENTER] button to confirm your choice.
Use the [UP] and [DOWN] buttons to select one of the 3 sound controlled shows (Snd1-Snd3)
Press the [ENTER] button to confirm.
3) MASTER/SLAVE STANDALONE MODE:
When you have several LED GLOBE units and you want them to all work synchronously, you can work in
the so called master/slave mode. To do this, just daisy-chain all the units and make the settings of the
desired automatic or sound controlled program in the first unit of the chain (see description above). This
unit is called the Master unit. Now put all the other units in slave mode. Once this is done, the “slave” units
will follow the orders of the Master unit, so they work in perfect synchronicity.
To set a unit in slave mode:
Press the [MENU] button until the display shows [SLA].
Press the [ENTER] button to enter this mode.
[SLAV] will appear on the display
Press the [ENTER] button to confirm the slave mode.
4) CONTROLLED VIA THE IR REMOTE:
The standalone functions of the LED GLOBE can be controlled via the supplied IR remote controller.
Important: to be able to use the IR remote controller, the IR remote receiver has to be switched on in the
unit.
This is how to do this:
Press the [MENU] button until the display shows [SYS].
Press the [ENTER] button to enter this part of the menu with extra options.
Use the [UP/DOWN] buttons to browse the extra functions in this System menu
When [ir] appears on the screen, press [ENTER]
Use the [UP / DOWN] button to select the desired mode:
o ON = IR remote receiver activated.
o OFF = IR remote receiver deactivated.
When the receiver is switched ON in the unit, you can use the IR remote control
JB SYSTEMS® 5/11 LED GLOBE
ENGLISH USER MANUAL
To switch the effect On or Off
To select the automatic programs P1-P5
To select sound activated programs SOU1-SOU5
Use these buttons to modify the program speed
To pause the program
To toggle between automatic and sound mode
Select the speed for the automatic programs
Static Color mode: press 1 (red), 2 (green), 3 (blue), 6 (white) or 0 (fade)
When in color mode: use the numeric buttons to select the motor rotation
speed
When in color mode: press to invert rotation direction
Functions:
5) CONTROLLED VIA DMX:
The LED GLOBE can be controlled by any standard DMX-controller in 4 different DMX-modes: 1, 3, 9 and
19 channels
Connect the DMX input of the LED GLOBE to the DMX output of the previous unit in the chain or
directly to the DMX-output of your controller.
Press the [MENU] button until the display shows: “DMX”.
Press the [ENTER] button to enter this option
The actual DMX address is shown on the display.
Press the [ENTER] button again
The channel mode is shown on the display
Use the [UP/DOWN] buttons to select the desired DMX-mode. (1CH, 3CH, 9CH or 19CH). See the DMX
charts below
Press the [ENTER] button to confirm your choice.
Now you can use the [UP/DOWN] buttons to set the DMX address. [dxxx]
Press the [ENTER] button to confirm your choice.
Some more information on DMX512:
The DMX-protocol is a widely used high speed signal to control intelligent light
equipment. You need to “daisy chain” your DMX controller and all the connected light
effects with a good quality XLR M/F balanced cable. To prevent strange behavior of
the light effects, due to interferences, you must use a 90Ω to 120Ω terminator at the
end of the chain. Never use Y-splitter cables, this simply won’t work!
Each effect in the chain needs to have its proper starting address so it knows which commands from the
controller it has to decode.
JB SYSTEMS® 6/11 LED GLOBE
ENGLISH USER MANUAL
DMX
Channel
DMXvalue
function
remarks
1
000-005
Blackout
No Rotation
006-036
White
Slow rotation
037-068
Red
069-100
Green
101-132
Blue
118-164
Auto Program P5
165-196
Sound Program S3
No rotation
197-228
Sound Program S3
Slow rotation
229-255
Sound Program S3
Medium rotation
DMX
Channel
DMXvalue
function
remarks
1
000-005
Blackout
Static Color
DMX Channel 2 can not be used
006-033
White
034-061
Red
062-089
Green
090-117
Blue
118-145
Program 1
Preprogrammed Shows
You can use DMX channel 2
for Speed or Sound control
146-173
Program 2
174-201
Program 3
202-229
Program 4
230-255
Program 5
2
000-250
Speed Control
Speed of the selected program via channel 1
251-255
Sound Control
Sound control for the selected program via channel 1
3
000
No rotation
Motor Control
001-127
Clockwise rotation
128
No rotation
129-255
Anticlockwise rotation
DMX
Channel
DMXvalue
function
remarks
RGB Projector control
1
000-255
Dimmer RED
2
000-255
Dimmer GREEN
3
000-255
Dimmer BLUE
4
000-255
Dimmer WHITE
5
000-005
No strobe
STROBE
006-250
Strobe Speed
251-255
Sound Strobe
1 CHANNEL DMX-CONFIGURATION:
3 CHANNEL DMX-CONFIGURATION:
9 CHANNEL DMX-CONFIGURATION:
JB SYSTEMS® 7/11 LED GLOBE
ENGLISH USER MANUAL
6
000
Stop
Motor
001-127
Speed direction 1
128
Stop
129-255
Speed direction 2
7
000-005
Blackout
LED 1
LED 2
LED 3
006-013
Static Colors
Red
Red
Red
014-022
Green
Green
Green
023-031
Blue
Blue
Blue
032-040
White
White
White
041-049
Red
Green
Blue
050-058
Red
Green
White
059-067
Red
Blue
White
068-076
Green
Blue
White
077-085
Red-Green
Red-Blue
Red-White
086-094
Green-Red
Green-Blue
Green-White
095-103
Blue-Red
Blue-Green
Blue-White
104-112
White-Red
White-Green
White-Blue
113-121
Red-Green
Red-Green
Red-Green
122-130
Red-Blue
Red-Blue
Red-Blue
131-139
Red-White
Red-White
Red-White
140-148
Green-Blue
Green-Blue
Green-Blue
149-157
Green-White
Green-White
Green-White
158-166
Blue-White
Blue-White
Blue-White
167-175
Red-Green-Blue
Red-Green-Blue
Red-Green-Blue
176-184
Red-Green-White
Red-Green-White
Red-Green-White
185-193
Green-Blue-White
Green-Blue-White
Green-Blue-White
194-202
Red-Green-Blue
Red-Green-Blue
Red-Green-Blue
203-211
R-G-B-W
R-G-B-W
R-G-B-W
212-220
P 1 / S 1
Automatic & Sound controlled programs
221-229
P 2 / S 2
230-238
P 3 / S 3
239-247
P 4 / S 4
248-255
P 5 / S 5
8
000-250
Program Speed
Speed/sound control for the programs of dmx channel 7
(CH7 from 212 to 255)
004-066
Sound Controlled
9
000
No rotation
Motor Control control for the programs of dmx channel 7
001-127
Clockwise rotation
128
No rotation
129-255
Anticlockwise rotation
JB SYSTEMS® 8/11 LED GLOBE
ENGLISH USER MANUAL
DMX
Channel
DMXvalue
function
remarks
RGB Projector control
1
000-255
Dimmer RED
Led 1
2
000-255
Dimmer GREEN
3
000-255
Dimmer BLUE
4
000-255
Dimmer WHITE
5
000-005
No strobe
Led 1 STROBE
006-250
Strobe Speed
251-255
Sound Strobe
6
000-255
Dimmer RED
Led 2
7
000-255
Dimmer GREEN
8
000-255
Dimmer BLUE
9
000-255
Dimmer WHITE
10
000-005
No strobe
Led 2 STROBE
006-250
Strobe Speed
251-255
Sound Strobe
11
000-255
Dimmer RED
Led 3
12
000-255
Dimmer GREEN
13
000-255
Dimmer BLUE
14
000-255
Dimmer WHITE
15
000-005
No strobe
Led 3 STROBE
006-250
Strobe Speed
251-255
Sound Strobe
16
000
Stop
001-127
Speed direction 1
Motor
128
Stop
129-255
Speed direction 2
17
000-005
Blackout
LED 1
LED 2
LED 3
006-013
Static Colors
Red
Red
Red
014-022
Green
Green
Green
023-031
Blue
Blue
Blue
032-040
White
White
White
041-049
Red
Green
Blue
050-058
Red
Green
White
059-067
Red
Blue
White
068-076
Green
Blue
White
077-085
Red-Green
Red-Blue
Red-White
086-094
Green-Red
Green-Blue
Green-White
095-103
Blue-Red
Blue-Green
Blue-White
104-112
White-Red
White-Green
White-Blue
113-121
Red-Green
Red-Green
Red-Green
122-130
Red-Blue
Red-Blue
Red-Blue
19 CHANNEL DMX-CONFIGURATION:
JB SYSTEMS® 9/11 LED GLOBE
ENGLISH USER MANUAL
131-139
Red-White
Red-White
Red-White
140-148
Green-Blue
Green-Blue
Green-Blue
149-157
Green-White
Green-White
Green-White
158-166
Blue-White
Blue-White
Blue-White
167-175
Red-Green-Blue
Red-Green-Blue
Red-Green-Blue
176-184
Red-Green-White
Red-Green-White
Red-Green-White
185-193
Green-Blue-White
Green-Blue-White
Green-Blue-White
194-202
Red-Green-Blue
Red-Green-Blue
Red-Green-Blue
203-211
R-G-B-W
R-G-B-W
R-G-B-W
212-220
P 1 / S 1
Automatic & Sound controlled programs
221-229
P 2 / S 2
230-238
P 3 / S 3
239-247
P 4 / S 4
248-255
P 5 / S 5
18
000-250
Program Speed
Speed/sound control for the programs of dmx channel 17
(CH17 from 212 to 255)
004-066
Sound Controlled
19
000
No rotation
Motor Control control for the programs of dmx channel 17
001-127
Clockwise rotation
128
No rotation
129-255
Anticlockwise rotation
Extra functions in the menu
Press the [MENU] button until the display shows [SYS].
Press the [ENTER] button if you want to enter this part of the menu with extra options.
Use the [UP/DOWN] buttons to browse the extra functions in this System menu
o [di Sr] = Display inversion
With this option you can invert the information that is shown on the display. This is very
useful is you hang the unit upside-down in a light bridge.
Press the [ENTER] button to enter the option settings
Use the [UP / DOWN] button to select the desired mode:
ON = function activated. The display is ready for units that hang upside-
down.
oFF = function deactivated. The LED display is ready for units that are not
hanging upside-down.
o [diSP] = Display Blackout.
With this option you can decide if the display should be always on or if it can go out after a
while when no new information needs to be shown
Press the [ENTER] button to enter the option settings
Use the [UP / DOWN] button to select the desired mode:
ON = function activated. When no new information needs to be shown on
the display, the display will turn off.
OFF = function deactivated. The LED display will be always lit.
Press the [ENTER] button to confirm your setting
o [ir] = Infra Red Remote controller: with this function you can deactivate the infra-red
remote controller receiver.
Press the [ENTER] button to enter the option settings
Use the [UP / DOWN] button to select the desired mode:
ON = IR remote receiver activated.
OFF = IR remote receiver deactivated.
o [rESt] = Factory Reset. This function can be used to reset all the settings of the unit to the
original factory settings
Just press the [ENTER] button to reset the unit.
JB SYSTEMS® 10/11 LED GLOBE
ENGLISH USER MANUAL
MAINTENANCE
Make sure the area below the installation place is free from unwanted persons during servicing.
Switch off the unit, unplug the mains cable and wait until the unit has been cooled down.
During inspection the following points should be checked:
All screws used for installing the device and any of its parts should be tightly fastened and may not be
corroded.
Housings, fixations and installations spots (ceiling, truss, suspensions) should be totally free from any
deformation.
When an optical lens is visibly damaged due to cracks or deep scratches, it must be replaced.
The mains cables must be in impeccable condition and should be replaced immediately when even a
small problem is detected.
In order to protect the device from overheat the cooling fans (if any) and ventilation openings should be
cleaned monthly.
The interior of the device should be cleaned annually using a vacuum cleaner or air-jet.
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surroundings can cause greater accumulation of dirt on the unit’s optics.
Clean with a soft cloth using normal glass cleaning products.
Always dry the parts carefully.
Clean the external optics at least once every 30 days.
Clean the internal optics at least every 90 days.
Attention: We strongly recommend internal cleaning to be carried out by qualified personnel!
SPECIFICATIONS
Mains Input: AC 100~240V, 50/60Hz
Fuse: 250V 1.6A slow blow (20mm glass)
Total Power consumption: 60W
Sound Control: Internal microphone
DMX connections: 3pin XLR male / female
DMX channels: 1, 3, 9 or 19 channels
LED power: 5 x 8Watt RGBW LEDs
Working temperature: 10°C to 40°C
Dimensions: 397 x 397 x 510mm
Weight: 4.23kg
All the information is subject to change without prior notice
You can download the latest version of this user manual on our website: www.beglec.com
JB SYSTEMS® 11/11 LED GLOBE
Loading...
