ENGLISH USER MANUAL
JB Systems® 1/12 ACCU DECOLITE IP
OPERATION MANUAL
Thank you for buying this JB Systems® product. To take full advantage of all possibilities and for your own
safety, please read these operating instructions very carefully before you start using this unit.
FEATURES
• Battery operated LED-projector, based on 1pce 15Watt RGBW-LED to avoid unwanted color shadows.
• Beam angle = 10°
• The perfect solution for many applications: exhibition booths, parties, special events, ...
• Outdoor use : IP65 rating.
• Inner thread fitting for the use of optional accessories like tubes and balls.
• +/-10hrs use in 3 color fading mode on a fully charged battery!
• Each projector is equipped with a wireless transceiver module (transmitter and receiver) which is 100%
compatible with the W-DMX G4-protocol from “Wireless Solution Sweden”.
• Projector can still be used with empty battery: just connect it to the mains!
• Very smooth RGBW color changes thanks to high freq. dimming electronics
• The battery charger charges the battery while the projector is working on mains power.
• Different working modes:
• Standalone: custom colors selectable or automatic and beat synchronized color changes
• Master/slave mode: wonderful preprogrammed, music synchronized lightshows.
• DMX-controlled : wireless. (5 modes : 4-5-9-10 channels, Ledcon-02 Mk2)
• Controlled by wireless IR remote control
BEFORE USE
• Before you start using this unit, please check if there’s no transportation damage. Should there be any, do
not use the device and consult your dealer first.
• Important: This device left our factory in perfect condition and well packaged. It is absolutely necessary
for the user to strictly follow the safety instructions and warnings in this user manual. Any damage caused
by mishandling is not subject to warranty. The dealer will not accept responsibility for any resulting defects
or problems caused by disregarding this user manual.
• Keep this booklet in a safe place for future consultation. If you sell the fixture, be sure to add this user
manual.
Check the contents:
Check that the packing contains the following items:
• Operating instructions
• ACCU DECOLITE IP
• AC/DC power adapter
• Wireless IR remote control
ENGLISH USER MANUAL
JB Systems® 2/12 ACCU DECOLITE IP
SAFETY INSTRUCTIONS:
• To protect the environment, please try to recycle the packing material as much as possible.
• To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
• To avoid condensation to be formed inside, allow the unit to adapt to the surrounding temperatures when
bringing it into a warm room after transport. Condense sometimes prevents the unit from working at full
performance or may even cause damages.
• This unit is for indoor use only.
• Don’t place metal objects or spill liquid inside the unit. Electric shock or malfunction may result. If a foreign
object enters the unit, immediately disconnect the mains power.
• Locate the fixture in a well ventilated spot, away from any flammable materials and/or liquids. The fixture
must be fixed at least 50cm from surrounding walls.
• Don’t cover any ventilation openings as this may result in overheating.
• Prevent use in dusty environments and clean the unit regularly.
• Keep the unit away from children.
• Inexperienced persons should not operate this device.
• Maximum safe ambient temperature is 40°C. Don’t use this unit at higher ambient temperatures.
• Make sure the area below the installation place is free from unwanted persons during rigging, de-rigging
and servicing.
• Allow the device about 10 minutes to cool down before to start servicing.
• Always unplug the unit when it is not used for a longer time or before to start servicing.
• The electrical installation should be carried out by qualified personal only, according to the regulations for
electrical and mechanical safety in your country.
• Check that the available voltage is not higher than the one stated on the unit.
• The power cord should always be in perfect condition. Switch the unit immediately off when the power cord
is squashed or damaged. It must be replaced by the manufacturer, it’s service agent or similarly qualified
persons in order to avoid a hazard.
• Never let the power-cord come into contact with other cables!
• This fixture must be earthed in order to comply with safety regulations.
• Don’t connect the unit to any dimmer pack.
• Always use an appropriate and certified safety cable when installing the unit.
• In order to prevent electric shock, do not open the cover. There are no user serviceable parts inside.
• Never repair a fuse or bypass the fuse holder. Always replace a damaged fuse with a fuse of the same
type and electrical specifications!
• In the event of serious operating problems, stop using the fixture and contact your dealer immediately.
• The housing and the lenses must be replaced if they are visibly damaged.
• Please use the original packing when the device is to be transported.
CAUTION: To reduce the risk of electric shock, do not remove
the top cover. No user-serviceable parts inside. Refer servicing
to qualified service personnel only.
The lightning flash with arrowhead symbol within the equilateral triangle is intended to alert the
use or the presence of un-insulated “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within the equilateral triangle is intended to alert the user to the presence
of important operation and maintenance (servicing) instructions in the literature accompanying
this appliance.
This symbol means: indoor use only
This symbol means: Read instructions
This symbol determines: the minimum distance from lighted objects. The minimum distance
between light-output and the illuminated surface must be more than 1 meter
The device is not suitable for direct mounting on normally flammable surfaces. (suitable only for
mounting on non-combustible surfaces)
CAUTION: Do not stare at operating lamp.
May be harmful to the eyes.
ENGLISH USER MANUAL
JB Systems® 3/12 ACCU DECOLITE IP
• Due to safety reasons it is prohibited to make unauthorized modifications to the unit.
Important: Never look directly into the light source! Don’t use the effect in the presence of persons suffering
from epilepsy.
OVERHEAD RIGGING
• Important: The installation must be carried out by qualified service personal only. Improper
installation can result in serious injuries and/or damage to property. Overhead rigging requires
extensive experience! Working load limits should be respected, certified installation materials
should be used, the installed device should be inspected regularly for safety.
• Make sure the area below the installation place is free from unwanted persons during rigging, de-rigging
and servicing.
• Locate the fixture in a well ventilated spot, far away from any flammable materials and/or liquids. The
fixture must be fixed at least 50cm from surrounding walls.
• The device should be installed out of reach of people and outside areas where persons may walk by or be
seated.
• Before rigging make sure that the installation area can hold a minimum point load of 10times the device’s
weight.
• Always use a certified safety cable that can hold 12 times the weight of the device when installing the unit.
This secondary safety attachment should be installed in a way that no part of the installation can drop
more than 20cm if the main attachment fails.
• The device should be well fixed; a free-swinging mounting is dangerous and may not
be considered!
• Don’t cover any ventilation openings as this may result in overheating.
• The operator has to make sure that the safety-relating and machine-technical
installations are approved by an expert before using them for the first time. The
installations should be inspected every year by a skilled person to be sure that safety
is still optimal.
ENGLISH USER MANUAL
JB Systems® 4/12 ACCU DECOLITE IP
DESCRIPTION:
1. Knob used to fasten the projector in a desired angle.
2. Indicator/button to turn ON/OFF [Wireless DMX].
3. [■] button : push this button to select the desired topic in the menu.
4. [Power ON/OFF] button : push this button to turn the projector ON or OFF.
5. Lens (10°) in front of LED 15W RGBW.
6. ▲ button : push this button to go up in the menu.
7. [ID] button : used to connect projector wireless to another projector or a transmitter. (see chapter : [HOW
TO SETUP]).
8. [] button : push this button to confirm the selected setting.
9. Display
10. IR sensor.
11. ▼ button : push this button to go down in the menu.
12. Rubber foot.
13. Hanging bracket.
14. Power input connector.
15. Hole in the hanging bracket to fix the projector in truss, using a mounting hook.
16. Indicator for [Wireless DMX]. [Wireless DMX] is ON when this indicator lits.
17. Status LED shows [Wireless DMX]-mode (receiver, transmitter)
18. Battery capacity indicator
19. Valve
ENGLISH USER MANUAL
JB Systems® 5/12 ACCU DECOLITE IP
ELECTRICAL INSTALLATION
Important: The electrical installation should be carried out by qualified personal only,
according to the regulations for electrical and mechanical safety in your country.
Note: In the explanations below we assume that you will operate the projectors with the internal battery
which is already fully charged. If you want to use them with a mains cable, simply connect all projectors to
the mains using the supplied power cable and adaptor.
Electrical installation for 1 standalone unit:
• Switch the projector on using the power switch (4). The unit starts working immediately in the last
selected stand-alone mode.
• Refer to chapter [HOW TO SETUP] to learn how to switch between different working modes.
Electrical installation for two or more units in master/slave:
• Make sure that all units are switched on.
• Setup 1 unit as Master (see [SETUP MENU]) and wireless transmitter (see [SETUP FOR WIRELESS
OPERATION]). Setup the other units as Slave (see [SETUP MENU]) and wireless receiver (see [SETUP
FOR WIRELESS OPERATION])
• Done
Electrical installation for two or more units in DMX-mode:
You can control the ACCU DECOLITE IP projector by wireless DMX. The projector’s wireless DMX protocol
is fully compatible with “Wireless Solution Sweden”.
WIRELESS SOLUTION
• Switch all projectors on.
• Put all projectors in the desired DMX-channel mode (see chapter [HOW TO SETUP]: option [CHnd])
• Set the desired DMX start address on all projectors, take in account the number of DMX channels used
by the selected DMX-channel mode! (see chapter [HOW TO SETUP]: option [Addr] )
• Switch on the wireless mode using switch (2).
• Synchronize all projectors with the wireless DMX transmitter. (for example : JB Systems® “M-DMX
TRANSCEIVER” is 100% compatible)
• Once this is done everything should work.
ENGLISH USER MANUAL
JB Systems® 6/12 ACCU DECOLITE IP
[SETUP MENU]:
MAIN MENU:
• To select any of the menu options, press the [■] button.
• Use ▲ and ▼ button to choose the desired menu option..
• Select the function with the [] button. The display will blink.
• Once the required menu option is selected, press the [] button to select.
• Press the [MENU] button to return to running mode.
[Addr] DMX 512 Address setting
Used to set the start address in a DMX setup.
• Press the [■] button.
• Press the ▲ or ▼ button until [Addr] is shown on the display.
• Press the [] button to select. The display starts blinking.
• Use ▲ and ▼ buttons to change the DMX512 address.
• Once the correct address is shown on the display, press the [] button to confirm.
[CHnd] Channel Mode
The unit has 5 different channel modes, refer to the DMX-chart to see the
differences.
• Press the [■] button.
• Press the ▲ or ▼ button until [CHnd] is shown on the display.
• Press the [] button to select. The display starts blinking.
• Use ▲ and ▼ buttons to select one of the available channel modes.
• Once the mode is selected, press the [] button to confirm.
[SLAU] Slave Mode
The first projector in the chain should be set , all the other projectors have to be in
Slave mode.
• Press the [■] button.
• Press the ▲ or ▼ button until [SLAU] is shown on the display.
• Press the [] button to select. The display starts blinking.
• Then press [] to confirm the slave mode.
[SP--] Speed Mode
• Press the [■] button.
• Press the ▲ or ▼ buttons until [SP--] is shown on the display.
• Press the [] button to select. The display starts blinking.
• Use ▲ and ▼ buttons to select the desired speed.
• Then press [] to confirm the desired speed.
[Pr--] Preset Selection Mode
Used to choose to select one of the preprogrammed colors or fades when used
in standalone or master/slave mode. All projectors will always show an
identical output.
• Press the [■] button.
• Press the ▲ or ▼ buttons until [Pr--] is shown on the display.
• Press the [] button to select. The display starts blinking.
• Use ▲ and ▼ buttons to select one of the preprogrammed colors or shows.
(Pr01…Pr35)
• Once the desired color or show is selected, press the [] button to confirm.
[ASC-] Mode
Used to choose the desired color changing show.
• Press the [■] button.
• Press the ▲ or ▼ buttons until [ASC-] is shown on the display.
• Press the [] button to select.
ENGLISH USER MANUAL
JB Systems® 7/12 ACCU DECOLITE IP
• Use ▲ and ▼ button to select one of the available shows (AC00…AC15)
• Once the desired show is selected, press the [] button to confirm.
[FAdE] Mode
Used to choose a color fading show
• Press the [■] button.
• Press the ▲ or ▼ buttons until [FAdE] is shown on the display.
• Press the [] button to select. The display starts blinking.
• Use ▲ and ▼ button to select a value between [FA00] (fast fading) and [FA15] (slow fading).
• Once the desired mode is selected, press the [] button to confirm.
[FLAS] Strobe Mode
Used to select the strobe speed.
• Press the [■] button.
• Press the ▲ or ▼ buttons until [FLAS] is shown on the display.
• Press the [] button to select. The display starts blinking.
• Use ▲ and ▼ buttons to select the speed (FL00…FL15)
• Once the desired speed is selected, press [] to confirm.
[rL--] Mode
Used to set the minimum value of the Red color
• Press the [■] button.
• Press the ▲ or ▼ buttons until [rL--] is shown on the display.
• Press the [] button to select. The display starts blinking.
• Use ▲ and ▼ buttons to select the speed (r000…r255)
• Once the desired value is selected, press [] to confirm.
[GL--] Mode
Used to set the minimum value of the Green color
• Press the [■] button.
• Press the ▲ or ▼ buttons until [GL--] is shown on the display.
• Press the [] button to select. The display starts blinking.
• Use ▲ and ▼ buttons to select the speed (G000…G255)
• Once the desired value is selected, press [] to confirm.
[bL--] Mode
Used to set the minimum value of the Blue color
• Press the [■] button.
• Press the ▲ or ▼ buttons until [bL--] is shown on the display.
• Press the [] button to select. The display starts blinking.
• Use ▲ and ▼ buttons to select the speed (b000…b255)
• Once the desired value is selected, press [] to confirm.
[UL--] Mode
Used to set the minimum value of the White color
• Press the [■] button.
• Press the ▲ or ▼ buttons until [UL--] is shown on the display.
• Press the [] button to select. The display starts blinking.
• Use ▲ and ▼ buttons to select the speed (U000…U255)
• Once the desired value is selected, press [] to confirm.
[AL--] Mode
Used to set the minimum value of the Amber color (NO FUNCTION)
• Press the [■] button.
• Press the ▲ or ▼ buttons until [AL--] is shown on the display.
• Press the [] button to select. The display starts blinking.
• Use ▲ and ▼ buttons to select the speed (A000…A255)
• Once the desired value is selected, press [] to confirm.
ENGLISH USER MANUAL
JB Systems® 8/12 ACCU DECOLITE IP
[SoUA] Sound Mode
Used to make shows working on sound or not.
• Press the [■] button.
• Press the ▲ or ▼ buttons until the display shows [SoUA].
• Press [] button to select. The display starts blinking.
• Press [], the projector is now working in sound mode.
If you want to go back to normal running mode: press the [■] button.
[Led] Mode
Led of10-30-60-90 : display turns off after 10-30-60 or 90 seconds.
• Press the [■] button.
• Press the ▲ or ▼ buttons until the display shows [LEd].
• Press [] button to select. The display starts blinking and shows [oF10-oF30-oF60 or oF90]
• Select the desired setting by pressing the ▲ or ▼ button.
• Press [] to select the desired mode.
• The display will turn off after .
• The display will turn on again by pressing one of the buttons [■], [▲], [▼], [ID] or []
[node] Function
Used to slow down the dimming speed.
• Press the [■] button.
• Press the ▲ or ▼ buttons until the display shows [node].
• Press the [] button. The display starts blinking and shows [nod0…nod4]
• Use ▲ and ▼ buttons to select [nod0…nod4] where 0 is the fastest and 4 the slowest mode.
• Once the desired mode is selected, press the [] button to confirm.
[UErn] Software Version
Used to show the software version of the unit.
• Press the [■] button.
• Press the ▲ or ▼ buttons until the display shows [UErn].
• Press the [] button. The display starts blinking and shows the version [UE2.0].
• Press the [■] button to leave.
[LoC] Lock/unlock
Used to lock and unlock the display functionality.
• Press the [■] button.
• Press the ▲ or ▼ buttons until the display shows [LoC].
• Press the [] button. The display starts blinking and shows [oFF].
• Press the ▲ or ▼ buttons to change to [on].
• Press the [] button. The display functions are locked now.
• Press the [] button and ▼button simultaneously to unlock the display functions.
• Press the [■] button to leave.
[SETUP FOR WIRELESS OPERATION]
Each unit has a wireless DMX transceiver on board. This means that every unit can be transmitter or
receiver.
To set up the system, you first need to assign each receiver to the universe (transmitter) it should work with.
Each unit has a wireless DMX transceiver on board. This means that every unit can be transmitter or
receiver.
To set up the system, you first need to assign each receiver to the universe (transmitter) it should work with.
VERY IMPORTANT THINGS TO KNOW BEFORE USE
Before you start using these wireless DMX units, you should know about the following some basic
information. It will save you a lot of time and frustration:
• Check information on the [ID] button (24) and status led (16).
o Status LED (17) WHITE : unit is in setup mode or disconnected from any transmitter.
ENGLISH USER MANUAL
JB Systems® 9/12 ACCU DECOLITE IP
o Status LED (17) BLUE : unit is in TRANSMITTER mode and connected to one or more receivers.
o Status LED (17) BLUE (blinking fast) : unit (transmitter) is connecting to receiver(s).
o Status LED (17) BLUE (blinking slow) : no DMX-signal present on transmitter
o Status LED (17) GREEN : unit is connected to a transmitter
o Status LED (17) GREEN (blinking slow) : unit receives no DMX-signal from transmitter.
• A receiver can only connect to a transmitter while it is completely disconnected: status led (17) is WHITE.
SETTING UP IN TRANSMITTER MODE (LED = BLUE)
• Keep the [ID] button (7) pressed while powering up the WIRELESS part of the ACCU DECOLITE IP by
pressing the according button (2). The status LED will become WHITE shortly, than turns BLUE, RED or
GREEN (the last selected mode).
• Choose BLUE by pressing the [ID] button (7) shortly.
• Once BLUE selected, press the [ID] button (7) for 3 seconds to confirm the transmitter mode.
• The status LED will turn white and after a few seconds turns BLUE (blinking if there is no DMX signal
present)
• The unit is now in transmitter mode.
SETTING UP IN RECEIVER MODE (LED = GREEN)
• Keep the [ID] button (7) pressed while powering up the WIRELESS part of the ACCU DECOLITE IP by
pressing the according button (2). The status LED will become WHITE shortly, than turns BLUE, RED or
GREEN (the last selected mode).
• Choose GREEN by pressing the [ID] button (7) shortly.
• Once GREEN selected, press the [ID] button (7) for 3 seconds to confirm the receiver mode.
• The status LED will turn white and after a few seconds turns RED (fast blinking if there is no signal present)
or GREEN (when the receiver is paired with a transmitter).
• The unit is now in receiver mode.
• Release the receiver from any universe (transmitter) by pressing the [ID] button (7) for 5 seconds. The
status led now turns WHITE. The unit is now ready to be paired with a transmitter.
PAIRING TRANSMITTER AND RECEIVER(S)
• First of all : prepare transmitter and receiver(s) as described above.
• Press the [ID] button (7) on the transmitter. The BLUE led starts blinking and the led on the receiver(s)
starts blinking GREEN at the same time.
After a few seconds the leds stop blinking. The transmitter and receiver(s) are now paired.
DISCONNECTING RECEIVERS FROM A DMX UNIVERSE (TRANSMITTER)
To disconnect all the receivers from a DMX universe / transmitter:
• Press the [ID] button (7) from the transmitter for about 5 seconds until the status LED (17) turns RED, the
status LED on the receiver(s) turn WHITE (disconnected).
• After a few moments the status LED (17) on the transmitter turns BLUE again.
• You can also re-connect the receiver(s) again simply by pressing shortly on the [ID] button (7) on the
transmitter. (The status LED (17) on the receiver(s) turns GREEN again.
To disconnect an individual receiver from a DMX universe / transmitter:
• Press the [ID] button (7) of the receiver until the status LED (17) becomes WHITE (RGB lit).
• This receiver is now disconnected from the transmitter (DMX universe).
ENGLISH USER MANUAL
JB Systems® 10/12 ACCU DECOLITE IP
OPERATING INSTRUCTIONS
A. Standalone 1unit:
• Select one of the automatic modes or select a fixed color
• Select the static or sound control mode
• Refer to chapter [HOW TO SETUP] to learn how to make the previous settings.
B. Two or more units in master/slave setup:
• Connect 2 or more units together. Refer to the chapter “electrical installation” to learn how to do this.
• Set the slave mode for each projector: the first one must be set in DMX mode or in a show mode (for
example : [FAdE])
• Connect all units to the mains. The units will start working automatically and show the internal chase
programs.
C. Controlled by IR remote-controller:
Switch on the projector (4). Push button [ON] on the IR remote controller. [Jr00]
will appear on the display. You are now ready to use the IR remote controller.
When you turn the projector off with the IR remote controller, [Jr0F] will be
shown on the display.
Before you can start using the projector with another controller you have to
push one of the buttons under the display ([■]-[▲]-[▼]-[ ]). The projector will
now be disconnected from the IR remote controller.
You can also use the IR remote controller with several projectors in Masterslave mode. Select the desired color, fade on the Master. The slaves will follow
the instructions from the Master projector.
D. Controlled by a wireless DMX-controller:
• Turn on the wireless DMX controller. (for example : JB Systems LEDCON-XL
(order code : 4661) + M-DMX Transceiver (order code : 4646)
• Turn on all the units and put them in the desired channel mode. (4, 5, 9, 10 or [Ledc] : see DMX charts
below). Give each unit a DMX address according to the channel mode. Since each unit has its own
DMX-address, you can control them individually.
DMX CHARTS
Mode 4CH:
DMX
Channel
DMX-value
function
remarks
1
000-255
Color mixing 0% - 100%
2 000-255
White color dimmer
3
000-255
NO FUNCTION
(for compatibility with Accu
Color)
4
000-255
Master Dimmer 0% - 100%
Mode 5CH:
DMX
Channel
DMX-value
function
remarks
1
000-255
Red color dimmer
2
000-255
Green color dimmer
3
000-255
Blue color dimmer
4
000-255
White color dimmer
5
000-256
NO FUNCTION
(for compatibility with Accu
Color)
ENGLISH USER MANUAL
JB Systems® 11/12 ACCU DECOLITE IP
Mode 9CH:
DMX
Channel
DMX-value
function
remarks
1
000-255
Master Dimmer 0% - 100%
2
000-255
Red color dimmer
3
000-255
Green color dimmer
4
000-255
Blue color dimmer
5
000-255
White color dimmer
6
000-255
NO FUNCTION
(for compatibility with Accu
Color)
7
000-014
Open
015-255
Strobe Slow to fast
8
000-031
Open
AUTOMATIC MODES
032-063
Close-open
064-095
Open-close
096-127
Open-close-open (white)
128-159
Color fading
160-191
Open-close-open (colors)
192-223
Color changing
224-255
Sound
9
000-255
Speed automatic modes
0% -100%
SPEED FOR AUTOMATIC MODES
Mode 10CH:
DMX
Channel
DMX-value
function
remarks
1
000-255
Master Dimmer 0% - 100%
2
000-255
Red color dimmer
3
000-255
Green color dimmer
4
000-255
Blue color dimmer
5
000-255
White color dimmer
6
000-255
NO FUNCTION
(for compatibility with Accu
Color)
7
000-014
Open
015-255
Strobe Slow to fast
8
000-031
Open
AUTOMATIC MODES
032-063
Close-open
064-095
Open-close
096-127
Open-close-open (white)
128-159
Color fading
160-191
Open-close-open (colors)
192-223
Color changing
224-255
Sound
9
000-255
Speed automatic modes
0% -100%
SPEED FOR AUTOMATIC MODES
10
000-005
Uses the nodE setting
006-055 Dimmer 0 (fast)
056-105 Dimmer 1
106-155 Dimmer 2
156-205 Dimmer 3
206-255 Dimmer 4 (slow)
Ledcon 02Mk2-Mode: RGB + MASTER DIM/SOUND/STROBE
Channel:
Value:
Function:
Remarks
1
000-255
Red (0-100%)
2
000-255
Green (0-100%)
3
000-255
Blue (0-100%)
4
000-190
Master dimmer
000=0% ~ 190=100% (full open)
ENGLISH USER MANUAL
JB Systems® 12/12 ACCU DECOLITE IP
191-200
Sound control (7 colors)
Audio sensitivity: 191=low ~
200=high
201-247
Strobe
Increasing speed: 201=slow ~
247=fast
248-255
Master dimmer @ 100%
Master dimmer is full open
MAINTENANCE
• Switch off the unit and unplug the mains cable.
During inspection the following points should be checked:
• When an optical lens is visibly damaged due to cracks or deep scratches, it must be replaced.
• The mains cables must be in impeccable condition and should be replaced immediately when even a
small problem is detected.
• In order to protect the device from overheat the cooling fans (if any) and ventilation openings should be
cleaned monthly.
• BATTERY maintenance: We strongly advice to follow the maintenance requirements imposed by the
battery reseller. On top of that you should at least every 6 months:
• Do a visual check of the battery: cleanness, terminal damage, any damage of the housing, …
• Check the if the poles of the battery are still well tightened to the wires.
Attention: We strongly recommend internal cleaning to be carried out by qualified personnel!
RECYCLING OF USED BATTERIES: used Li/ion batteries should be considered and handled as
dangerous waste. Each country has its own regulations for the recycling of used rechargeable
batteries: check the local regulations in your country or ask your battery vendor for more information
on recycling of the used rechargeable batteries!
SPECIFICATIONS
This unit is radio-interference suppressed. This product meets the requirements of the current European and
national guidelines. Conformity has been established and the relevant statements and documents have been
deposited by the manufacturer.
This device was designed to produce decorative effect lighting and is used in light show systems.
Mains Input: 100-240V, 50/60HZ
Power consumption: 15 Watt
Rechargeable battery: 11,1Vdc / 2 x 2600 mAh (lithium)
Charging time: 4 hours
Sound Control: Internal microphone
DMX connections: Wireless
LEDs: 1 LED 4IN1 15W
Beam angle: 10°
Size: 172 x 138 x 62mm
Weight: 1.69 kg
Every information is subject to change without prior notice
You can download the latest version of this user manual on our website: www.jb-systems.eu
Loading...
