Technical Manual
JB L MS28/WH
SPECIFICATIONS
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance: 16 ohms
• Power Capacity: 200W IEC: 800W Peak
• Frequency Range: 40 Hz – 20 kHz (–10dB)
• Sensitivity: 93 dB SPL, 1 Watt @ 1 Meter
• Crossover Frequency: 2.8 kHz
SYSTEM COMPONENTS:
• Cabinet: (Not For Sale)
• Grille: 128-00343-65, 128-00343-00 (Wh)
• Low Frequency 200mm (8 in.) Cone
Transducer: Transducer (508G-3S) (2)
DC Resistance: 5.9 ohm ± 5%
• High Frequency 25mm (1 in.) Titanium
Transducer: Diaphragm (2412H)
DC Resistance: 5.3 ohm ± 10%
SYSTEM COMPONENTS:
(cont’d)
• Crossover Network/ 129-20043-01
Terminal Cup:
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test: 10V Input, 20 Hz to 20 kHz
B. L.F.Aural Sweep Test: 7.0V Input, 20 Hz to 1.2 kHz
C. H.F. Aural Sweep Test: 2.83V Input, 550 Hz to 20 kHz
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions: 676mm x 295mm x 324mm D
(26.0 x 11.6 x 12.75 in. D)
• Weight: 28 lbs. (12.7 kg.)
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
Warranty 59660
Owner’s Manual 10
981-00043-03
Tech Note 980-00036-00
Logo Sticker, Marquis
950-00032-00
Filler (2)
991-00140-00
Microfoam (4)
Packaging
49790P
Carton
990-00145-00
Speaker,
Low Freq
508G-3S (2)
Repl Unit
73284-01X
See Note
Back of Page
Speaker,
High Freq
2412H
(125-10000-00X)
Network
129-20043-01
SCHEMATIC (129-20043-00)
GRN
YEL
GRN/BLK
WHT/BLK
WHT
YEL/BLK
YEL
WHT
GRN
2+
C1
4m 0
SK-3 (2)
N/C
N/C
C2
1m 0
L1
3.4mH
L2
0.3mH
2–
1–
1+
2+
2–
1–
1+
Neutrik
Connector (2)
NL4MPR
R1
9ohm
5W
GRN/BLK
YEL/BLK
WHT/BLK
B1
B2
*
L.F.
508G-3S
H.F.
2412H
BLK RED
BLK RED BLK RED
Logo Hardware Kit
229-00014-00
(supplied)
Mounting
Bracket Kit
133-00012-00
133-00012-01(Wh)
(supplied)
Hardware Kit
229-00015-00
250
250
250
250
110
205
JBL MS28/WH
JBL MS28/WH
COMPONENT EXPLODED VIEW
T-Nut (12)
61860
8-32 x 3/8
T-Nut, M10 (2)
836-44800-00
T-Nut (6)
805-90000-00
M8 x 9.2mm LG
Grille Stick
Right
389-00019-00
Left
389-00020-00
Grille
Support (2)
389-00021-00
Logo Kit,
Marquis
229-00014-00
Screw (2)
818-11710-25
M10 x 25MM
FL PH BLK ZINC
Speaker,
High Freq
2412H
(125-10000-00X)
Screw (8)
803-11010-16
8-32 x 1
FLT, PH, BLK
ZINC, LCS
Treated Cones:
Install Sheet 980-00037-00
WR2 (2 oz)
WR16 (16 oz)
Cabinet
(Not For Sale)
Grille
128-00343-65
128-00343-00 (Wh)
Speaker,
Low Freq
508G-3S (2)
Repl Unit
73284-01X
Network
129-20043-01
Horn
126-00013-00
Gasket (2)
52671
Gasket
359-00110-03
Screw (6)
882-51110-12
6 x 3/4
OV PH
Screw (4)
803-11110-20
8-32 x 1-1/4
PH FLTHD
Screw (12)
882-51110-12
6 x 3/4
OV PH
Screw (6)
817-11610-25
M8 x 25mm
FL PH BLK ZINC
*
*
U-Bracket (supplied)
for installation
133-00012-00
NOTE: BLACK DURAFLEX REPAIR KIT
30052
WHITE DURAFLEX REPAIR KIT
16679
