JBL SYNTHESIS THREE ARRAY, SYN3-ARRAY User Manual
SYSTEM CONTAINS:
SYNTHESIS
®
THREE ARRAY™
SMALL PACKAGE, BIG SOUND
SYNTHESIS THREE ARRAY IS DESIGNED to give your architect or designer maximum leeway in creating your ideal
listening space. The all-important center channel speaker, for example, is available in designs optimized for either
vertical (SAM3VA) or horizontal (SAM3HA) installation. The main left and right SAM3VA speakers may be cabinet/custom-mounted, or configured as freestanding floor units with two S2S subwoofers. Four S4Ai in-wall multipole
ambient surround speakers and electronics that include the SDP-5 processor/controller, SDEC-3000 digital equalizer,
S7150 7-channel amplifier and S800 amplifier complete a package that will fill rooms of up to 10,000 cubic feet with
edge-of-your-seat home entertainment. Alternatively, you can substitute the 1,000-watt powered HTPS-400 for the S2S
subwoofer and fill rooms of up to 7,500 ft.3 (The 110-volt HTPS-400 is replaced by the 14" PS1400 powered subwoofer
in 230-volt markets.)
FROM 1,500 TO 10,000 CUBIC FEET
43– 304 CUBIC METERS
1800 WATTS RMS / 3600 WATTS PEAK
91dB HIGH FREQUENCY
92dB LOW FREQUENCY
1 – SDP-5 THX® Ultra 2® Surround Processor/System Controller
1 – SDEC-3000 Synthesis 8-Channel Digital Equalizer
1 – S7150 7 x 160 Watt THX® Power Amplifier
1 – S800 2 x 200 Watt, 1 x 800 Watt THX® Power Amplifier
2 – SAM3VA Synthesis® Array™ Module Three Vertical Loudspeaker
1 – SAM3HA Synthesis® Array™ Module Three Horizontal Loudspeaker
4 – S4AI Vertical or Horizontal Multipolar Flush-Mount THX® Surround
Loudspeaker
2 – S2S 15-Inch THX Subwoofer
SDP-5
THX® Ultra 2® Surround
Processor/System
Controller
SDEC-3000
Synthesis 8-Channel
Digital Equalizer
S7150
7 x 160 Watt THX® Power
Amplifier
S800
2 x 200 Watt, 1 x 800 Watt
THX® Power Amplifier
SAM3VA
Synthesis® Array™ Module
Three Vertical Loudspeaker
SAM3HA
Synthesis® Array™ Module
Three Horizontal
Loudspeaker
S4AI
Vertical or Horizontal
Multipolar Flush-Mount THX®
Surround Loudspeaker
S2S
15-Inch THX Subwoofer
