JBL Stage1 Technical data
STAGE1 Speakers
Solid cost effective upgrade for factory fitments that delivers great JBL audio performance.
Value engineered JBL performance.
The Stage1 Series speakers brings a JBL concert experience to your car, truck
or SUV and a surprisingly affordable price. Their Polypropylene woofer delivers a
strong performance with great low end extension and clean tight midrange. The
woofer is couple with a Mylar Balanced dome tweeter which fills out their sonic
signature with crisp, high-end frequencies. Legendary JBL sound for less than the
cost of a concert ticket.
Features
JBL Design Language
Competitively Tuned
Rigid Reliability Testing
Value Engineered
STAGE1 Speakers
Solid cost effective upgrade for factory fitments that delivers great JBL audio performance.
Features and Benefits
JBL Design Language
We now have a design language which alludes to other products in JBL’s expansive portfolio,
showcased through the bold horned logo design emblazoned across the tweeter bridge.
Competitively Tuned
For most brands, off-the-shelf speakers and a cursory approval of frequency response curves
are good enough. That’s not the case with JBL. We don’t only listen to our speakers against
the competition – we voice them against each other to ensure each line has the consistent
JBL sound signature that’s known and sought out by those who care about their audio. This
is just part of an extensive development process undertaken by some of the best transducer
engineers in the world to provide the finest listening experience at any price point.
Rigid Reliability Testing
JBL Stage1 speakers have to go through environmental testing that would destroy other
speakers. JBL freezes them, bakes them, shakes them, blasts them with ultraviolet light and
drives them at full power for days at a time.
Value Engineered
With the goal of providing access to great JBL sound at an affordable price, our engineers
valued engineered the Stage1 Series to deliver great sound at an affordable price.
What’s in the Box
Technical Specifications
Stage1 621
6-1/2" (160mm) Two Way Car Speaker
Power Handling: 35Wrms, 175W peak
Sensitivity (@ 2.83V): 90dB
Frequency Response: 55Hz – 20kHz
Nominal Impedance: 4 ohms
Stage1 9631
6" x 9" (152mm x 230mm) Three Way Car
Speaker
Power Handling: 60Wrms, 300W peak
Sensitivity (@ 2.83V): 89dB
Frequency Response: 50Hz – 21kHz
Nominal Impedance: 4 ohms
Stage1 601C
6-1/2" (160mm) Two Way Component System
Car Speaker
Power Handling: 40Wrms, 200W peak
Sensitivity (@ 2.83V): 90dB
Frequency Response: 55Hz – 20kHz
Nominal Impedance: 4 ohms
Stage1 621
2 x Speakers
2 x Grilles
8 x Screws
8 x Speed clips
Stage1 9631
2 x Speakers
2 x Grilles
8 x Screws
8 x Speed clips
2 x JBL logo badge
HARMAN International Industries, Incorporated
8500 Balboa Boulevard, Northridge, CA 91329 USA
www.jbl.com
Stage1 601C
2 x Speakers
8 x Screws
8 x Speed clips
2 x Tweeters
2 x JBL logo badge
© 2019 HARMAN International Industries, Incorporated. All rights reserved. JBL is a trademark of
HARMAN International Industries, Incorporated, registered in the United States and/or other countries.
Features, specifications and appearance are subject to change without notice.
