JBL K2 S5800, K2 S9800SE, K2S9800SE-BG, K2 S4800, 1400 ARRAY User Manual

®

PROJECT K2 S9800SE · S5800 · S4800 PROJECT ARRAY 1500 · 1400 · 1000 · 880 · 800

PROJECT K2

®

PROJECT ARRAY

™

2

INTRODUCING PROJECT

Our K2 was the creation of a loudspeaker

that would bring the unique JBL Profes-

sional listening experience to the home in

an uncompromising form.

And with the innovative Project K2 S9800,

JBL engineers created a reference loud-

speaker system for the 21st century. Now

the all-new K2 S9800 Special Edition scales

even greater heights. Effortlessly delivering

the full bandwidth and dynamics of even

the most demanding sources – without

suppression at any listening level –

Project K2 loudspeakers offer a sense of

realism and sonic accuracy that will trans-

port you to the concert hall.

It’s every music lover’s dream.

And now it’s come true.

FULL BANDWIDTH AND DYNAMICS,
AND EVERY EMOTION
THE MUSIC POSSESSES

In every field of human endeavor, there

is an ultimate objective – one of such

immense difficulty that many believe it

to be beyond the realm of the possible.

In mountaineering, scaling the Himalayan

peak K2 in the Karakoram of Pakistan is

such an objective. At 8610 meters, it is the

second highest mountain on Earth, and is

generally acknowledged to be the most

difficult and dangerous ascent of all.

Still, many are irresistibly drawn to the

challenge.

After successfully scaling our equivalent of

that formidable mountain, we understand a

little more about the complex matrix of

motivations and emotions that drives the

adventurer.

PROJECT K2 S9800SE K2 S5800 S4800

K2

4

1500AL Low-frequency driver

JBL K2 DEVELOPMENT TEAM

CUTTING-EDGE

TECHNOLOGIES

Put simply, Project K2 is what happens when

JBL’s expert team of engineers is given

a free hand, no budgetary constraints and

unlimited access to the world’s finest research

and development facilities.

Taking full advantage of proprietary JBL

technologies and six decades of experience in

professional and consumer audio, Project K2

embodies all the pride and passion for

engineering excellence passed down from

JBL’s founder and namesake, James B. Lansing.

The prize-winning K2 loudspeakers draw

heavily on JBL’s unrivalled experience with

high-sensitivity, high-performance horn sys-

tems and professional subwoofer systems.

The result is an engineering tour de force with

state-of-the-art sound.

Employing newly developed, cutting-edge tech-

nologies, including a next-generation Alnico

woofer and a unique dual-compression-driver

Concert hall

realism and

sonic accuracy

Die-cast-aluminum­motor unit cover
with heatsinks for
cooling

25mm (1") Beryllium
compression driver
super tweeter

75mm (3") Beryllium
compression driver

Rapid-flare phase
plug for minimal
secondary distortion

high-frequency system, Project K2 consists of

three reference speaker systems capable of

delivering the extended musical bandwidth

and exceptional dynamic performance

demanded by today’s advanced digital media.

Grace and ease

at any listening level

Superbly detailed, outstandingly dynamic

and capable of breathtaking power, the

Project K2 Series will reveal crucial sub-

tleties and emotional elements in your

favorite music that you’ve never experi-

enced before.

And it does so with grace and ease, even at

larger-than-life listening levels.

In celebration of the success of the JBL K2

S9800, we raise the bar even higher with the

K2 S9800 Special Edition by employing key

sonic upgrades (aluminum-metalized

polypropylene film capacitors) and an even

more luxurious finish. The critically acclaimed

K2 S5800 uses the advanced components

and technologies expressly designed for the

K2 Series in the service of your listening

pleasure. And by popular demand, the S4800

brings revolutionary K2 sound and styling to

small- to medium-sized rooms for superlative

fidelity and musical realism.

PROJECT K2 S9800SE K2 S5800 S4800

TIMOTHY
PRENTA

Director,
JBL Consumer
Engineering

JBL Consumer
Products

DANIEL
ASHCRAFT

President &
Creative
Director

Ashcraft Design

DOUGLAS
BUTTON

Vice
President,
Research &
Development

JBL Professional

JERRY
MORRO

Senior
Transducer
Engineer

JBL Consumer
Products

GREG
TIMBERS

Chief Systems
Engineer

JBL Consumer
Products

SPEC

K2

PROJECT K2 S9800SE K2 S5800 S4800
