JBL CINEMA SOUND
Hollywood EXCITEMENT,
JBl STylE.
®
INTRODUCING A MAJOR ACHIEVEMENT IN SOUND. AND ART DIRECTION.
JBL® HAS BEEN BRINGING MOVIE SOUNDTRACKS TO LIFE
for more than 60 years, with massive professional loudspeaker systems hidden away behind the screens of the world’s
premier movie houses. But you don’t have to go massive to experience the same level of excitement at home. JBL
Cinema Sound speaker systems are among the smallest and most elegant JBL has ever produced. But they surround
you with crisp, accurate high frequencies, distinct center channel dialogue and deep, floor-rumbling bass – all the stuff
Hollywood dreams are made of.
Available in four speaker-only configurations, as well as three complete home theater packages that include sophisticated source electronics, there’s a JBL Cinema Sound system for any space or budget.
OUTSTANDI NG
VERSATILI TY
DTS® and all the Dolby® sound
processing technologies.
DVD-Video, DVD-Audio, DivX
®
and more CD formats than many
computers can handle. HDMI
™
output and enough digital,
analog, component and S-video
inputs to drive a small multiplex.
JBL Cinema Vision’s CS5 and
CS3 are powerful 5.1 A/V
receiver/DVD players that
are also easy to use.
ALUMINU M
FLOOR S TANDS
JBL Cinema Sound satellites
feature concealed speaker
terminals, and the optional
aluminum floor stands conceal
the wires themselves.
Wall-mount brackets are
included with all satellite and
center channel speakers.
STIFFER CONES
JBL Cinema Sound’s cellulose-fiber cones are
reinforced with a polymer coating for uniform
pistonic motion, eliminating internal resonances
without increasing cone mass. That delivers
tighter, more precise bass.
BETTER IMAGING
Originally developed for Professional LSR studio
monitors, JBL Cinema Sound’s proprietary EOS
waveguides evenly disperse high frequencies,
delivering more precise stereo imaging over
a wider listening area.
GREATER ACC URACY
An extremely thin yet extremely rigid titanium
laminate dome, reinforced with a foil laminate,
ensures accurate, undistorted high-frequency
response, even at realistic (meaning loud)
listening levels.
TIGHTER BASS
The computer-optimized geometry of JBL’s
FreeFlow™ bass reflex port in the powered
subwoofer extends deep bass response while
eliminating unwanted turbulence and noise.
ELEGANCE IS ALSO
AN ENGINEERING TERM.
NYLON S TOCKINGS,
FILM NO IR, THE
DAWN OF AUD IO.
James B. Lansing, who led
the team that first brought
sound to movies, strikes out
on his own, founding JBL.
Among the company’s first
products, a high-frequency
transducer that’s still being
used by audio professionals
today, unchanged after
more than 60 years.
BLUE SU EDE SHO ES,
MCCARTH Y, TH E
ELECTRI C GUITAR.
JBL establishes itself as the
clear leader in studio and
theater sound. Leo Fender
chooses JBL’s D130 transducer to amplify his electric
guitar. The pioneering JBL
Hartsfield speaker introduces true high fidelity to
homes everywhere.
VIETNAM ,
WOODSTO CK,
SPACE.
JBL introduces the
legendary 4320 speaker,
the definitive studio
monitor of its day. After
Woodstock in 1969, JBL
becomes standard equipment at rock concerts
around the world.
MA K I NG E NT E R TA I N M E N T H I S T O RY F O R M O R E T H A N 6 0 Y EA R S .
MIAMI VI CE,
MASTERS OF
THE UNI VERSE, MT V.
The Academy of Motion
Picture Arts and Sciences
chooses JBL components to
introduce 70mm Dolby® stereo in showcase theaters.
JBL introduces titanium
diaphragms and Bi-Radial®
horns in professional studio
monitors, technologies
soon to appear on the home
front.
GEN X, D OTCOMS,
DVD
. JBL corners the
market for THX® theater
installations. JBL near-field
studio monitors take the
lead in 5.1 and 7.1 sound
mixing and mastering. And
JBL introduces Simply
Cinema,® the original “one
box” home theater solution.
FLAT-PANEL TV,
HIGH DE FINITIO N,
JBL CIN EMA SOU ND.
JBL Cinema Sound systems
deliver the same realistic
reproduction of movies and
music that professionals
insist on. Hollywood has
always trusted JBL.
Now it’s your turn.
1940 ’s 1950 ’s 1960 ’s 1970 ’s 1980 ’s 1990 ’s TODAY
POLYESTER, WATER-
GATE, SATURDAY
NIGHT F EVER.
JBL studio monitors
rank Number One by Billboard® magazine. And
JBL introduces the L100,
a consumer version of
the 4320, bringing JBL
Pro technology home for
the first time. The L100
becomes one of the bestselling speakers of the
decade.
STUNNING MULTICHANNEL SOUND.
STUNNINGLY COMPACT.
JBL Cinema Sound systems are available as complete 5.1-channel home theater packages, with advanced
A/V receivers/DVD players, voice-matched satellites, center channel speakers and powered subwoofers. JBL Cinema
Sound speakers and subwoofers are also available in 5.1 and 2.1 packages for use with your own electronics. So
you have a choice of ways to bring the captivating experience of movie house and concert hall performances home,
with powerful, compact systems that fit anywhere -- beautifully.
CINEMA SOUND SYSTEMS
CS46 is a 2.1 system featuring two
2-way satellite loudspeakers with 89mm
midrange drivers and 13mm titanium
laminate dome tweeters, and a 125-watt,
170mm subwoofer.
CS460 is a 5.1 system comprising four 2-way
satellites with 89mm midrange drivers and
13mm titanium-laminate dome tweeters, a dual
89mm, 2-way center channel speaker and a
125-watt, 170mm subwoofer.
CS68 offers great 2.1-channel sound
through two 2-way satellite speakers with
dual 89mm midrange drivers and 13mm
titanium-laminate dome tweeters, along with
a 125-watt, 200mm subwoofer.
CS680 is a 5.1 system with four 2-way
satellites and a 2-way center channel
speaker featuring dual 89mm midrange drivers
and 13mm titanium-laminate dome tweeters,
and a 125-watt, 200mm subwoofer.
CINEMA SOUND POWERED SYSTEMS
CSP430 teams JBL’s CS3 5x35-watt
A/V receiver/DVD player with the CS460
speaker package: four 2-way satellites
featuring 89mm midrange drivers and
13mm titanium-laminate dome tweeters,
a dual 89mm center channel speaker,
plus a muscular 125-watt, 170mm bass
reflex powered sub.
CSP630 matches the CS3 A/V/DVD
source with the powerful CS680 speaker
package, which includes 2-way satellite
and center speakers, all featuring dual
89mm midrange drivers and 13mm titanium
laminate dome tweeters, and a
thunderous 125-watt, 200mm bass
reflex powered sub.
CSP1550 is the ultimate JBL Cinema
Sound system, combining the 5x65-watt
CS5 A/V receiver/DVD player and the
CS1500 speaker package – four floorstandingvideo-shielded satellites and
matching center, each with dual 130mm
midrange drivers and a 19mm titanium
laminate dome tweeter, plus a 150-watt,
250mm powered subwoofer capable of
effortlessly reproducing Hollywood¹s
most exciting special effects.
CS680
CS460 - 5.1 system
CS46 - 2.1 system
SAT CENTER
Frequency Response (– 6dB) 110Hz – 20kHz 100Hz – 20kHz
Recommended 10 – 100 Watts 10 – 100 Watts
Amplifier Power Range
Sensitivity (2.83V @ 1 meter) 86dB 88dB
Nominal Impedance 8 Ohms 8 Ohms
Crossover Frequency 3.0kHz; 12dB/Octave 3.0kHz; 12dB/Octave
High-Frequency Driver 13mm (1/2") Titanium-laminate dome, magnetically shielded
Midrange Driver 89mm (3-1/2"), Dual 89mm (3-1/2"),
magnetically shielded magnetically shielded
Dimensions (H x W x D) 152mm x 162mm x 98mm 133mm x 289mm x 86mm
(6"x 6-3/8" x 3-7/8") (5-1/4" x 11-3/8" x 3-3/8" )
Weight 0.9kg (2.0 lb) 1.5kg (3.2 lb)
SUB
Frequency Response(– 6dB) 38Hz – 160Hz
Amplifier Power 125W RMS/250W Peak*
Driver 170mm (6")
Dimensions (H x W x D) 394mm x 273mm x 305mm
(including feet) (15-1/2" x 10-3/4" x 12")
Weight 11kg (24.5 lb)
CS680 - 5.1 system
CS68 - 2.1 system
SAT CENTER
Frequency Response (– 6dB) 100Hz – 20kHz 100Hz – 20kHz
Recommended 10 – 100 Watts 10 – 100 Watts
Amplifier Power Range
Sensitivity (2.83V @ 1 meter) 88dB 88dB
Nominal Impedance 8 Ohms 8 Ohms
Crossover Frequency 3.0kHz; 12dB/Octave 3.0kHz; 12dB/Octave
High-Frequency Driver 13mm (1/2") Titanium-laminate dome, magnetically shielded
Midrange Driver Dual 89mm (3-1/2"), Dual 89mm (3-1/2"),
magnetically shielded magnetically shielded
Dimensions (H x W x D) 289mm x 131mm x 86mm 133mm x 289mm x 86mm
(11-3/8" x 5-1/8" x 3-3/8") (5-1/4" x 11-3/8" x 3-3/8")
Weight 1.5kg (3.2 lb) 1.5kg (3.2 lb)
SUB
Frequency Response(– 6dB) 35Hz – 160Hz
Amplifier Power 125W RMS/250W Peak*
Driver 200mm (8")
Dimensions (H x W x D) 412mm x 305mm x 346mm
(including feet) (16-1/4" x 12" x 13-5/8")
Weight 13.2kg (29 lb)
*The Peak Dynamic Power is measured by recording the highest center-to-peak voltage measured across the output of a resistive load
equal to minimum impedance of the transducer, using a 50Hz sine wave burst, 3 cycles on, 17 cycles off.
CST55 CSC55
Frequency Response (–6dB) 55Hz to 30kHz 55Hz to 30kHz
Maximum Recommended 150W* 150W*
Amplifier Power
Power Handling 50W/300W 50W/300W
(continuous/peak)
Sensitivity (1 watt/1 meter) 90dB 90dB
Nominal Impedance 8 Ohms 8 Ohms
High-Frequency Driver 19mm (3/4") titanium-laminate dome,
video-shielded
Midrange driver Dual 130mm (5") transducers with PolyPlas™ cones,
neodymium magnets and HeatScape™ motor structure;
video-shielded
Dimensions (H x W x D) 1168mm x 286mm x 286mm 159mm x 667mm x 108mm
(46" x 11-1/4" x 11-1/4") (6-1/4" x 26-1/4" x 4-1/4")
Weight 7.7kg (17 lb) 4.5kg (10 lb)
CSS10
Frequency 27Hz to low-pass-crossover
Response setting at signal source
Amplifier Power 150W RMS
Driver 250mm (10") PolyPlas™ cone
and HeatScape™ motor
structure; video-shielded
Dimensions (H x W x D) 464mm x 337mm x 406mm
(including feet) (18-1/4" x 13-1/4" x 16")
Weight 19.5kg (3 lb)
CS1500 - 5.1 system
CSP430, CSP630 and CSP1550
CSP430 CSP630 CSP1550
Description 5.1 Channel Integrated 5.1 Channel Integrated 5.1 Channel Integrated
Home Theatre System Home Theatre System Home Theatre System
Multi-channel Power 35 x 5 35 x 5 5 x 65
Speaker System CS460 CS680 CSP1500
Surround Formats DTS® 5.1, Dolby® Digital, Dolby® Pro Logic II, Dolby Virtual Speaker
DVD Player Progressive Scan Progressive Scan Progressive Scan
External Audio Connection Tape In/Out Tape In/Out Tape In/Out
Digital Audio Inputs (Coax/Optical) 1/1 1/1 1/1
Video Outputs HDMI
™
, Component, S-Video, Composite, SCART
Video Formats DVD, DVD-R/RW, DVD+R/RW, (S)VCD, DivX
®
Audio Formats DVD-Audio, CD, CD-R/RW, DVD-Audio, CD, CD-R/RW, DVD-Audio, CD, CD-R/RW,
MP3, WMA* MP3, WMA* MP3, WMA*
Still-Image Formats JPEG JPEG JPEG
Test Screen Yes Yes Yes
Fast Play x2, x4, x6, x100 x2, x4, x6, x100 x2, x4, x6, x100
Slow Play x1/2, x1/4, x1/8, x1/16 x1/2, x1/4, x1/8, x1/16 x1/2, x1/4, x1/8, x1/16
Random Play Yes, with CD Yes, with CD Yes, with CD
Repeat Play 1 Track, 1 disc, A/B** 1 Track, 1 disc, A/B** 1 Track, 1 disc, A/B**
Remote System Remote Control System Remote Control System Remote Control
FM Tuner with 30 Presets Yes Yes Yes
Dimensions (H x W x D) 68mm x 440mm x 380mm 68mm x 440mm x 380mm 68mm x 440mm x 380mm
Weight 7.5kg 7.5kg 8.5kg
* Windows Media® Audio (WMA) is a proprietary file format developed by Microsoft.
** A/B Repeat Play is available for DVDs, CDs and VCDs only.
SPECIFICATIONS
CINE MA SOUND POWERED SYSTEMS
CINE MA SOUND SYSTEMS
Loading...
