AUTHENTICS L16
AUTHENTICS L16
Quick Start Guide
Guide de démarrage rapide
WPS
For charging external
devices only*
Pour charger uniquement
*
des appareils externes
Para cargar dispositivos
*
externos solamente
Para carregar apenas
*
dispositivos externos
Nur für das Aufladen
*
externer Geräte
Esclusivamente per il
*
caricamento di
dispositivi esterni
Alleen voor het opladen van
*
externe apparaten
Kun for lading av eksterne
*
enheter
Ainoastaan ulkoisten
*
laitteiden lataamiseen
Только для зарядки
*
внешних устройств
Enbart för laddning av
*
externa enheter
Kun til opladning af
*
eksterne enheder
外部機器のみの充電用
*
외부 장치 충전 전용
*
仅适用于为外部设备充电
*
僅適用於對外部裝置充電
*
iPad
AUX IN
WPS
ON / OFFPOWEROPTICALPHONO INGROUNDING
AUTHENTICS L16
Quick Start Guide
Guide de démarrage rapide
2
3
PRESS
< 1s
AUTHENTICS L16
Quick Start Guide
Guide de démarrage rapide
4
< 2s < 2s < 2s < 2s < 2s
Bluetooth DLNA AUX OPTICAL AIRPLAY
< 2s
PHONO
5
YES NO
JBL L16
PAIR
AUTHENTICS L16
AUX IN
WPS
Quick Start Guide
Guide de démarrage rapide
6
AUX IN
WPS
Wireless router
WPS
7
iOS
1
3
iPad
Allow
> 2s
2
AUTHENTICS L16
Quick Start Guide
Guide de démarrage rapide
8
JBL Music app
JBL Music app
JBL Music app
9
jbl.com/authenticsl16
# Full owners manual
# Mode d'emploi complet
# Manual del propietario completo
# Manual do utilizador completo
# Vollständige Bedienungsanleitung
# Manuale utente completo
# Complete handleiding
# Komplett bruksanvisning
# Täydellinen ohjekirja
# Полное руководство пользователя
# Komplett bruksanvisning
# Komplet betjeningsvejledning
# 正式な所有者用のマニュアル
# 전체사용자설명서
# 完整的用户手册
# 完整的擁有者手冊
AUTHENTICS L16
Quick Start Guide
Guide de démarrage rapide
EN
• Type: Powered three-way stereo speaker with wireless audio
playback and control
• High-frequency transducers: 1 inch tweeter
• Mid-range transducers: 2 inch midrange
• Low-frequency transducers: 5.25 inch woofer
• Frequency response: 35Hz – 35kHz
• Maximum SPL: 108dB @ 1m
• Signal to Noise Ratio (analogue inputs): 92dB
• Signal to Noise Ratio (digital inputs): 95dB
• Amplifier power: 6 x 50W RMS
• Amplifier THD at full power: <1%
• Wireless audio playback formats: AirPlay, DLNA, Bluetooth,
auto-switching
• Connections: 1 x stereo 3.5mm, 2 x USB (type A), 1 x Stereo RCA
phono input, 1 x Digital optical input
• Dimensions (H x W x D): 294mm x 818mm x 369mm
• Weight: 16.3kg
• Power supply: 100-240V~50/60Hz
• Power consumption: 300W maximum, <0.5W eco-standby mode
• Bluetooth transmitter frequency range: 2.402 - 2.480GHz
• Bluetooth transmitter power: Max 4dBm
• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
• Airplay Frequency range: 2412MHz~2472MHz (2.4GHz ISM Band, USA
11 Channels, Europe 13 Channels)
• Airplay Transmitter power: <20dBm (EIRP)
• Airplay Modulation: 802.11b:DSSS (DBPSK, DQPSK, CCK) ;
802.11g:OFDM (BPSK, QPSK, 16QAM, 64QAM);
• Airplay network compatibility: 802.11b/g
