INSTRUCTION MANUAL
CC2002
Cable Collector
for NANO Stations
This manual corresponds to the following reference:
CC2002
Packing List
The following items are included:
Cable collector for NANO Stations ......................................... 1 unit
Allen Key 1,5 mm ........ 1 unit
Ref. 0741610
2
Manual ............................ 1 unit
Ref. 0025685
ROBOT
ROBOT
ROBOT
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
ROBOT
ROBOT
Tool Stand Assembly
Tool Stand Replacement
Loosen the screw (1) and
withdraw the tool stand (2).
www.jbctools.com
321
Insert the new tool stand (3)
and tighten the screw (4).
2
1
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
3
4
NAE
Control Unit
PORT
2
ROBOT
PEDAL
2
3
para manuales - color gris
Specifications
CC2002
Cable Collector for NANO Stations
Ref.: CC2002
- Net Weight: 42 g / 0.09 lb
- Dimensions: 339 x 73 x 35 mm
(L x W x H) 13.35 x 2.87 x 1.38 in
- Package Dimensions / Weight: 235 x 40 x 40 mm / 70 g
(L x W x H) 9.25 x 1.57 x 1.57 in / 0.15 lb
Complies with CE standards.
ESD safe.
Warranty
JBC’s 2 year war ranty covers this e quipment again st all man ufacturing defe cts,
including the replacement of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must be returned, postage paid, to
the dealer where it was purchased.
This pro duct sho uld not be th rown in the garbage.
In accordance with the European directive 2012/19/EU, electronic
equipment at the end of its life m ust be collected and returned to an
authorized recycling facility.
0025685-181122
