JBC Tools C245001, C245161E Tip Guide

Download
C245 Cartridges for T245 Handles
C245 Cartridge range
for T245 Handles
Ref. Description Image
C245-030
C245-032
C245-036
Cartridge Conical
Ø 0,3
Cartridge Conical
Ø 0,4
Cartridge Conical
Ø 0,5 S1
Suggested
components
Package 0201, 0402
QFP, IC, ..
Package 0201, 0402
QFP, IC, ..
Package 0603
QFP, IC, ..
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Ref. Description Image
C245-957
C245-903
C245-803
C245-041
Cartridge Conical
Ø 0,8
Cartridge Conical
Ø 1 S1
Cartridge Conical
Ø 1 L
Cartridge Conical
Ø 1 S2
Suggested
components
Through hole
General use
General use
General use
Tip with an extra tinned
surface
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-930
C245-001
C245-201
C245-937
Cartridge Conical
Ø 0,5 S2
Cartridge Conical
Ø 0,6
Cartridge Conical
Ø 0,6 L
Cartridge Conical
Ø 0,6 HT
Package 0603
QFP, IC, ..
General use
Package 0603
QFP, IC, ..
Package 0603
QFP, IC, ..
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-403
C245-943
C245-933
C245-107
Cartridge Conical
Ø 1 HT
Cartridge Conical
Ø 1,7
Cartridge Conical
Ø 2,2
Cartridge Conical
Ø 3 HT
General use
General use
General use
General use
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
24 25
C245 Cartridges for T245 Handles C245 Cartridges for T245 Handles
Ref. Description Image
C245-034
C245-234
C245-029
Cartr idge Bent
Ø 0,4 S1
Cartr idge Bent
Ø 0,4 S1 L
Cartr idge Bent
Ø 0,4 S2
Suggested
components
Package 0201, 0402
QFP, IC, ..
Package 0201, 0402
QFP, IC, ..
Package 0201, 0402
QFP, IC, ..
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Ref. Description Image
C245-804
C245-259
C245-260
Cartr idge Bent
Ø 1 L
Cartr idge Bent
Ø 1,5
Cartr idge Bent
Ø 2 HT
Suggested
components
General use
General use
General use
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-126
C245-786
C245-929
C245-935
Cartr idge Bent
Ø 0,4 S3
Cartr idge Bent
Ø 0,4 S4
Cartr idge Bent
Ø 0,6
Cartr idge Bent
Ø 0,8
Package 0201, 0402
QFP, IC, ..
Package 0201, 0402
QFP, IC, ..
Package 0603
QFP, IC, ..
Through hole
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-627
C245-628
C245-731
C245-773
Cartr idge Bent
Ø 3
Cartr idge Bent
Ø 4 HT
Cartridge Chisel
0,6 x 0,3
Cartridge Chisel
0,8 x 0,3
General use
General use
Package 0603
Package 0805
Through hole
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-904
Cartr idge Bent
Ø 1
General use
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-673
Cartridge Chisel
0,8 x 0,3 L
Package 0805
Through hole
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
26 27
C245 Cartridges for T245 Handles C245 Cartridges for T245 Handles
Ref. Description Image
C245-742
C245-774
C245-906
Cartridge Chisel
0,8 x 0,6 HT
Cartridge Chisel
1,2 x 0,3
Cartridge Chisel
1,2 x 0,7
Suggested
components
Package 0805
Through hole
General use
General use
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Ref. Description Image
C245-907
C245-807
C245-407
Cartridge Chisel
2,2 x 1
Cartridge Chisel
2,2 x 1 L
Cartridge Chisel
2,2 x 1 HT
Suggested
components
General use
General use
General use
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-806
C245-406
C245-768
C245-944
Cartridge Chisel
1,2 x 0,7 L
Cartridge Chisel
1,2 x 0,7 HT
Cartridge Chisel
1,5 x 0,3
Cartridge Chisel
1,8 x 0,8
General use
General use
General use
General use
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-759
C245-770
C245-741
C245-729
Cartridge Chisel
2,4 x 0,5 HT
Cartridge Chisel
2,4 x 0,3
Cartridge Chisel
2,4 x 0,6 HT
Cartridge Chisel
2,7 x 1
General use
General use
General use
General use
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-844
Cartridge Chisel
1,8 x 0,8 L
General use
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-061
Cartridge Chisel
3 x 1
General use
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
28 29
C245 Cartridges for T245 Handles C245 Cartridges for T245 Handles
Ref. Description Image
C245-261
C245-911
C245-811
Cartridge Chisel
3 x 1 L
Cartridge Chisel
3,2 x 1,2
Cartridge Chisel
3,2 x 1,2 L
Suggested
components
General use
General use
General use
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Ref. Description Image
C245-708
C245-069
C245-966
Cartridge Chisel
4,8 x 1,5 HT S2
Cartridge Chisel
5 x 1,7 HT
Cartridge Chisel
6,6 x 1,8 HT
Suggested
components
General use
General use
General use
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-775
C245-755
C245-756
C245-908
Cartridge Chisel
3,2 x 1,2 S1
Cartridge Chisel
4 x 0,8 HT
Cartridge Chisel
4,8 x 1 HT
Cartridge Chisel
4,8 x 1,5 HT S1
General use
General use
General use
General use
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-962
C245-862
C245-963
C245-863
Cartr idge Bent
1,2 x 0,7
Cartr idge Bent
1,2 x 0,7 L
Cartr idge Bent
1,8 x 0,8
Cartr idge Bent
1,8 x 0,8 L
General use
General use
General use
General use
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-808
Cartridge Chisel
4,8 x 1,5 HT L
General use
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-946
Cartr idge Bent
2,2 x 1,0
General use
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
30 31
C245 Cartridges for T245 Handles C245 Cartridges for T245 Handles
Ref. Description Image
C245-846
C245-732
C245-761
Cartr idge Bent
2,2 x 1 L
Cartr idge Bent
3,2 x 1,5
Cartr idge Bent
3,0 x 1
Suggested
components
General use
General use
General use
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Ref. Description Image
C245-905
C245-405
C245-102
Cartr idge Bevel
Ø 1,5
Cartr idge Bevel
Ø 1,5 HT
Cartr idge Bevel
Ø 2
Suggested
components
Drag soldering
Through hole
Drag soldering
Through hole
Drag soldering
Through hole
Hoof tip with reduced
tinned surface, ideal for
tuch up
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-748
C245-749
C245-747
C245-710
Cartr idge Bent Bevel
Ø 0,6 S1
Cartr idge Bent Bevel
Ø 0,6 S2
Cartr idge Bevel
Ø 0,6
Cartr idge Bevel
Ø 1,2
Package 0603
Through hole
Package 0603
Through hole
Package 0603
Through hole
Drag soldering
Through hole
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-945
C245-845
C245-784
C245-793
Cartr idge Bevel
Ø 2,2
Cartr idge Bevel
Ø 2,2 L
Cartr idge Bevel
Ø 2,8
Cartr idge Bevel
Ø 2,8
Drag soldering
Through hole
Drag soldering
Through hole
Drag soldering
Through hole
Drag soldering
Through hole
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-064
Cartr idge Bevel
Ø 1,3
Drag soldering
Through hole
Hoof tip with reduced
tinned surface, ideal for
tuch up
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-912
Cartr idge Bevel
Ø 3
Drag soldering
Through hole
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
32 33
C245 Cartridges for T245 Handles
C245 Cartridges for T245 Handles
Ref. Description Image
C245-812
C245-056
C245-256
Cartr idge Bevel
Ø 3 L
Cartr idge Bevel
Ø 3,5 HT
Cartr idge Bevel
Ø 3,5 HT L
Suggested
components
Drag soldering
Through hole
Drag soldering
Through hole
Drag soldering
Through hole
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Ref. Description Image
C245-931
C245-938
C245-790
Cartr idge Spoon
Ø 2,7
Cartr idge Spoon
Ø 3,8
Cartridge
Pin/Connector
Ø 0,8
Suggested
components
Drag soldering
Drag soldering
Through hole
Cable sold/desol
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-951
C245-766
C245-301
C245-965
Cartr idge Bevel
Ø 3,8 HT
Cartr idge Bevel
Ø 5
Cartr idge Bevel
Ø 8,8
Cartr idge Spoon
Ø 1,9
Drag soldering
Through hole
Wide are a
Wide are a
Drag soldering
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-785
C245-763
C245-760
C245-762
Cartridge
Pin/Connector
Ø 1,5
Cartridge
Pin/Connector
Ø 2,5
Cartridge
Pin/Connector
Ø 3,5
Cartridge
Pin/Connector
R. 4,5
Through hole
Cable sold/desol
Through hole
Cable sold/desol
Through hole
Cable sold/desol
Cable sold/desol
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-067
Cartr idge Spoon
Ø 2,3
Drag soldering
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-789
Cartridge Knife
3,5 x 0,3
Drag soldering
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
34 35
C245 Cartridges for T245 Handles C245 Cartridges for T245 Handles
Ref. Description Image
C245-939
C245-765
C245-955
Cartridge Knife
6,0 x 0,4
Cartridge Knife
6,0 x 0,4 S1
Cartridge Knife
13,0 x 0,5
Suggested
components
Drag soldering
Drag soldering
Drag Soldering
Conector desoldering
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Ref. Description Image
C245-792
C245-757
C245-016
Cartridge Blade
40
Cartridge Chip
1,2 5
Cartridge Chip
1,9
Suggested
components
Pad cleaning
Conector desoldering
SMD resistors
SMD capacitors
SMD resistors
SMD capacitors
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-914
C245-752
C245-913
C245-949
Cartridge Blade
10 S1
Cartridge Blade
15
Cartridge Blade
21
Cartridge Blade
32
Pad cleaning
Conector desoldering
Pad cleaning
Conector desoldering
Pad cleaning
Conector desoldering
Pad cleaning
Conector desoldering
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-758
C245-017
C245-150
C245-018
Cartridge Chip
2
Cartridge Chip
2,2 S1
Cartridge Chip
2,2 S2
Cartridge Chip
3,4
SMD resistors
SMD capacitors
SMD resistors
SMD capacitors
SMD resistors
SMD capacitors
SMD resistors
SMD capacitors
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-776
Cartridge Blade
37
Pad cleaning
Conector desoldering
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-019
Cartridge Chip
4,5
SMD resistors
SMD capacitors
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
36 37
C245 Cartridges for T245 Handles
C245 Cartridges for T245 Handles
Ref. Description Image
C245-754
C245-654
C245-751
Cartridge Drag
0,75
Cartridge Drag
0,75 L
Cartridge Drag
1,2 5
Suggested
components
Drag soldering
Drag soldering
Drag soldering
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Ref. Description Image
C245-221
C245-303
C245-222
Cartr idge Tunnel
5,4 x 10
Cartr idge Tunnel
6,5 x 6
Cartr idge Tunnel
7,1 x 13
Suggested
components
Dual in Line
IC
Dual in Line
IC
Dual in Line
IC
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-651
C245-667
C245-669
C245-220
Cartridge Drag
1,25 L
Cartridge Drag
1,25 S1 L
Cartridge Drag
1,25 S2 L
Cartr idge Tunnel
5,4 x 6
Drag soldering
Drag soldering
Drag soldering
Dual in Line
IC
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-306
C245-305
C245-304
C245-215
Cartr idge Tunnel
9,6 x 10
Cartr idge Tunnel
9,6 x 12
Cartr idge Tunnel
9,6 x 15
Cartr idge Tunnel
9,6 x 18
Dual in Line
IC
Dual in Line
IC
Dual in Line,
IC
Dual in Line
IC
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-250
Cartr idge Tunnel
5,4 x 8
Dual in Line
IC
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-226
Cartr idge Tunnel
15,2 x 29
Dual in Line
IC
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
38 39
C245 Cartridges for T245 Handles C245 Cartridges for T245 Handles
Ref. Description Image
C245-223
C245-224
C245-228
Cartridge QFP
8,5 x 8,5
Cartridge QFP
12 x 12
Cartridge QFP
12,4 x 15
Suggested
components
QFP
QFP
QFP
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Ref. Description Image
C245-052
C245-054
C245-312
Cartridge Rivet
Ø 4,9
Cartridge Rivet
Ø 6,5
Cartr idge for Plastics
Ø 3,2
Suggested
components
Chrome finisg, de sign for
plastic rivets
Chrome finisg, de sign for
plastic rivets
Plastics
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-315
C245-227
C245-248
C245-247
Cartridge QFP
15 x 15
Cartridge QFP
17,5 x 17,5
Cartr idge Socket
11,9 x 14,5
Cartr idge Socket
17 x 17
QFP
QFP
PLCC sockets
PLCC sockets
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-313
C245-123
C245-124
C245-109
Cartr idge for Plastics
Ø 4,1
Cartr idge for Plastics
4 x 4
Cartr idge for Plastics
4,25 x 2
Cartridge Cutter
4,3 x 0,1
Plastics
Plastics
Plastics
Plastics
Remove underf ill
encapsulants
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-053
Cartridge Rivet
Ø 3,8
Chrome finisg, de sign for
plastic rivets
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-138
Cartridge Cutter
12
Plastic
Rubber
cutter
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
40 41
C245 Cartridges for T245 Handles C245 Cartridges for T245 Handles
Ref. Description Image
C245-121
C245-311
C245-119
Cartridge Cutter
13
Cartr idge for Plastics
20 x 6
Cartridge
Conical Teflon
Ø 1
Suggested
components
Plastic
Rubber
cutter
Plastics
Plastics
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Ref. Description Image
C245-118
C245-730
C245-268
Cartr idge Pin/Wire
0,4
Cartridge Blade
10 S2
Cartr idge Pin/Wire
1,5
Suggested
components
Through hole
Wire tinning
Pad cleaning
Conector desoldering
Through hole
Connectables
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-116
C245-122
C245-764
C245-771
Cartridge
Pin/Connector
R. 1
Cartridge
Pin/Connect.
1,5 x 0,5
Cartr idge Fine Pitch
Ø 0,5
Cartr idge Bent
1 x 0,1
Through hole
Coaxial connector
Cilinder parts
Package 0603
QFP, IC, .. Fine pitch
Cable soldering to
connector Fine pitch
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-136
C245-772
C245-009
C245-010
Cartr idge Micro Stick
Switch
Cartridge Nickel
1,4 x 0,7 S1
Cartridge S-Lead
4,5 x 1,8
Cartridge J-Lead
4,5 x 1,8
Micro Stick
desoldering
HMP soldering
Drag Soldering
Drag soldering
J-lead
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-117
Cartridge Flat
Ø 1,45
Through hole
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
C245-SP01
Solder Pot
Cartridge
15 x 18
Tinnig wires
Desoldering T hrough
Hole Multipin components
Control Units:
CD, DI, DDE, DME
Too ls:
T245 range
42 43
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
