www.jbctools.com
Adjustable Nano Tweezers
Ref. AN105-A
Packing List
The following items should be included:
Adjustable Nano Tweezers ..................................................... 1 u nit
Ref. AN105-A
Features
Control unit
Ref . N AE-1C
NAE-2C
NAE-9C
Manual............................. 1 unit
Ref. 0022399
www.jbctools.com
Adjustable Nano Tweezers
REF. AN105-A
Adjustable Nano Tweezers
Ref. AN105-A
Main switch
Power socket
2
1
2,5
Changing cartridges
Save time and change cartridges safely without switching the station off.
www.jbctools.com
1. Removing
Place the tool in the slot and
pull to remove the cartridge.
2. Inserting * Important
Push the cartridge into the
tool to the mark*.
Aligning cartridges
Use the alignment systems to better suit the component to work.
Tip aligner Vertical cartridge alignment
Mark
For a proper connection insert
the cartridges as far as the mark.
Fit the tip into the aligner and
turn to the desired position.
Turn the screw of the tweezers for a vertical alignment of the
cartridges. One tip lines up with the other.
Compatible cartridges
The AN105 -A works with C105 cartridges. Find the model that suits your needs in www.jbctools.com
Conical
Chisel Bevel KnifeRound
bent
Stainless
steel chisel
High thermal
performance
3
Specifications
- Weight: 50 g (0.1 lb)
- Cable length: 1.2 m (47.4 in)
Complies with CE standards
ESD Safe
Warranty
JBC’s 2 year warranty covers this equipment
against all manufacturing defects, including the
replacement of defective parts and labour.
Warrant y does not cover product wear or misuse.
In order for the warranty to be valid, equipment
must be returned, postage paid, to the dealer
where it was purchased.
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of their life
must be collected and returned to an authorized recycling facilit y.
Manual in other languages available on our website
www.jbctools.comwww.jbctools.com
0022399-1018
