Jaycar Electronics QC8021 User Manual

Wifi Sports Camera

User Manual

1

Quick Guide:

1. Download and install the app “SYMAGIX” from Itunes® or Google Play

2. Press the Wi-Fi button on the side of the camera to initialize the signal, the LED will be red

3. Search for the wireless signal “QC8021” on your smartphone or tablet using

the password “1234567890”.

4. You can now start using the camera once the wireless signal is connected and you have opened the app.

Note: Class 10 Micro SD Cards are required for this camera

2

3

Care & Maintenance

 Limit the cameras exposure to direct sunlight; also do not point its lens into direct sunlight. This may

damage the image sensor of the video camera.

 Take precautions to prevent water or sand particles fro m entering the video camera when it is used on th e

beach or near water, as this may damage the video camera.

 Keep the video camera free of dust and chemi cal materials. Place i t in a co ol, dr y and well ventilated place.

Avoid placing the video camera in high temperature conditions, moist or dust y places to avoid damage of
the video camera.

 If dirt or stains are accumulated on the v ideo camera or on its lens, use soft, clean and dry rag to wipe it

away gently. If the video camera or its lens is covered with sand particles, blow them awa y gently. Do not
use a cloth to wipe. Otherwise, it may scratch the surface of video camera or its lens.

 If you are required to clean the camera lens su rface, firstl y blow away the sand o r dust accumulated on this

surface, and then wipe the camera gently with a clean dry cloth. Do not use solvents to clean the video
camera.

 Do not touch the lens surface with fingers.

 Please back up the data if the memory card inside this digital camera is used f or the first time. After that,

format the memory card..

Camera Diagram:

1. Shutter button 8. Micro B USB port

2. Microphone 9. Mini C HDMI port

3. LCD display 10. Micro SD card slot

4. Lens 11. External microphone port

5. Wi-Fi switch and status indicator (red) 12. Battery cover push switch

6. Power / Mode button 13. LED light

4

7. Infrared signal reception light

LCD Display Diagram:

Turn on the Wi-Fi camera, the LCD will display the following status and settings:

1. Camera mode

2. Video recording mode (default)

3. Wi-Fi icon (display when enabled)

4. Micro SD card icon (display when loaded)

5. Resolution icon:
In camera mode, HI stands for 8 Mega Pixels (interpolated) (3264x2448), and in video recording mode, it stands
for FHD (1920x1080, 30fps);

5

6

In camera mode, LO stands for 5 Mega Pixe ls (2592x1920), and in video recording mode, it stands for 720P
(1280x720, 30fps);
HILO only displays in video recording mode, standing for 720P (1280x720,60fps).

6. Mute mode, displays when enabled, and disabled by default.

7. Counter, displays up to 999.

8. Timer, displays hours and minutes.

9. Battery icon: current battery level of the camera.

Note: The above icons may vary according to the status of the camera.

Operation:

After turning on the camera, you can press the Power/Mode button to switch the following modes in turn:

Video preview mode (1080P default)

Video mode (720P, 60fps)

Video mode (720P, 30fps)

Camera mode (8MP)

Camera mode (5MP)

In video mode, press the Shutter button to start recording, LED will flash，and press it again to stop;

In camera mode, press the Shutter button to take photo.

7

Using your Camera:

When you use the camera for the first time, please:

1. Insert a micro SD or micro SDHC card (not included), as shown in the following picture.

A Class 10 Micro SD Card is required for this camera.

Turn off the camera before inserting or removing the card.

8

2. Using the battery

2.1 Install the battery.

Please install the lithium battery correctly as shown:

Figure 1 Figure 2 Figure 3 Figure 4

Step 1. Push the battery cover switch to the l ock position(

), and remove the battery cover. As shown in

figure 1.

Step 2. Place the lithium battery into the battery slot. Make sure the polarity of the battery is corresponding to the

9

symbols of the camera shell( ). As shown in figure 2 and figure 3.

Step 3. Install the battery cover back in place, and lock the switch to the lock pos ition(

)to fix the battery.

As shown in figure 4.

2.2 Charging the battery:
The camera uses removable rechargeable lithium battery. When the camera is off, connect it to the PC via the

USB cable to charge the battery.

During charging, the status indicator (blue) will be lit up and the indicator will turnoff when charging
completes.
Note: When the camera is on, connecting it to the PC will not charge

.

10

Turn on/off

1. Turn on: press and hold the button for about 3 seconds, LCD will display “ON” and a beeping sou nd

will be made.

2. Turn off: press and hold the

button for about 3 seconds, LCD wil l display “OFF” and a beeping sound

will be made.

11

Note: The camera will turn off automatically if it is idle for 5 minutes.

Use:
Default setting: After turning on the camera, the default setting is as below:

12

Video recording mode
icon

The camera is in video recording mode.

HI

Video resolution FHD: 1080p@30fps

Recording time Stands for 0 hour and 00 minute.

Micro SD card icon

Display when a Micro SD card is inserted, otherwise no
display.

Battery level Battery is full

Mute icon

The camera is in Mute mode, no Beep will be heard when
pressing the buttons. It displays only when Mute mode is
activated.

Wi-Fi icon Display when activated.

Modes. The camera provides different modes. Press the button repeatedly, the following first two

modes will show on the LCD screen , and other modes display on the APP interface.

13

HI stands for FHD (1920x1080,30 fps) video
Lo stands for 720P (1280x720,30 fps) video

Video

HILO stands for 720P (1280x720,60 fps) video
HI stands for 8M (interpolated) (3264 x 2448) resolution


Lo stands for 5M (2592 x 1920) resolution

Continuous shot

The camera supports taking 3 photos continuously (only via
App)

Self-timer In self-timer mode , you can set 0s, 2s or 10s (only via App)

1. Video

To record a video, please check whether the DV is under Video mode. If the icon is not displa yed on the

screen, press the

button repeatedly until it appears.

14

Start recording: Press and release the button, the icon and [:] displayed in LCD will flash. At the
same time the red indicator will flash too, meaning the recording is in process.

Stop recording: Press and release the

button, the icon and [:] displayed in LCD will stop flashing.

s out, the recording will stop automaticall y, and the recorded

ore the camera turns off.

se c amera mode. If the icon

At the same time the red indicator will stop flashing either, meaning the recording is stopped.

When the Micro SD card is full, or the batte ry run

video will be saved bef

2. Photo

To take a photo, plea heck whether the ca mera is under C is not displayed on

the screen, press the

button repeatedly until it appears.

15

Press and release the button, a beep will be heard and the red indicator will flash, meaning a photo is taken.

ent of video will be deleted to release the corresponding

l stop recording and

(If you take photos more than 999 copies, the LCD screen display only 999)

3. Vehicle Mode

When you use it in the car, connect the car charger and switch on the ignition, it will power on and record 1080P

video automatically. It will save a segment for recording every 1 minute, then start to rec ord the nex t segment of

video. When the storage card is full, the earliest segm

space for continuous recording. When the ca r stalls or you pull out the car charger, it wil

save the video, will power off in 10s automatically.

Note: You can not open WIFI and do any button operation when in vehicle mode.

4. Enable/disable Wi-Fi

The Wi-Fi is disabled by default. Press the Wi-Fi button on the side of the camera to enable it. When starting

16

17

h, and when a Wi-Fi network is connected, the indicator

will remain on. The Wi-Fi icon will display on LCD screen.( In order to save power, Wi-Fi will be automatically

disabled if no terminal is connected after 30 seconds)

connecting to a Wi-Fi network, the indicator will flas

Wi-Fi is disabled by default When Wi-Fi is enabled, the

Wi-Fi icon will display on LCD

18

5. Enable/disable Mute mode

d hold

the buzzer and indicator to enter Mute mode. Under Mute mode, the icon

The buzzer is enabled by default. Under the Video or Photo mode, press an the Shutter button to disable

will display on the screen;

press and hold the Shutter button again to exit Mute mode.

Buzzer is enabled by default When Mute mode is enabled,

the Mute icon will display on LCD

6. Connecting to HDTV via HDMI (not included)

6.1 Connect the camera to a HDTV via a Mini HDMI cable (not included)

If cayou need to view the image and audio to an HDT V for playback, insert the end of the HDMI cable to the

mera, and the other end (output) to the HD input of the HDTV, as shown in the following figure:

19

20

rding,

ayback and disconn Wi-Fi first.

2 When the HDTV is connected, it enters Playback mode, the LCD displays as below:

Note: Before connecting or removing the HDMI cable, please stop video reco
pl ect the

6.

1

2

S/N Icon name Description

1 Playback mo3 de

currently. Under Playback mode

2 File number

There are 31 files and you are viewing the 19

th

one. (example)

3 Video icon The file is a video.

21

nIn Playback mode, press the Power butto to switch between photos and videos. When there are several

photos or videos, p the Wi-Fi buttonress

to select the photo or video. When a video file is selected, press

the Shutter button

to play it, and press the Shutter button again to stop playing.

In Playback mode, press and hold the Shutter button

, a prompt of deleting the file or formatting will

appear. Press the Wi-Fi button

to switch between ing or formatting, thdelet en Press the Power

button to select Yes or No, and press the Shutter button to confirm and exit.

22

7.1 Turn on the camera and connect it to the USB port of the PC via the attached USB cable. The camera will

enter U-disk mode and the LCD will display as below after connection:

7. Connecting to PC

Now you can view the photos or videos taken by the camera on the PC.

23

he system file information, including a file named SSID_PW.CFG,

containing the AP ID of the camera and the password for AP login. Users can view these information but

7.2 In U-disk mode (PCU mode), press th

Note: After the camera connects to the PC to enter U-disk mode, you will see two removable disks

displayed in My computer of Windows, one is the Micro SD card, storing all the photos taken and video

recorded by users; the other one stores t

cannot modify, delete or format them.

e Shutter button

to switch to web cam mode (PCC mode), and

the LCD will display as below:

to U-disk mode (PCU mode), press the

Now you can start the web cam mode. To return button again.

24

ver is not required for web cam mode (PCC mode) on ) version or above. Note: A dri Windows XP(SP3

RBemote Contro plication

uttons

ller Ap

IR Port

Power off button

Video button

Photo button

Power off b

Video button

utton

Remote Control Instruction:

You can use the remote controller to record videos, take photos and shut down the camera. When using the

remote controller, aim the IR port to the infrared signal reception light of the camera, and press the video button ,

photo button or power off button.

Infrared signal reception light

25

APP Interface:

1. Video resolution 6. Photo mode

2. White balance 7. Video mode

3. Setup (enter setup menu) 8. Wi-Fi signal icon

4. Enter Playbac 9. battery icon k mode

5. Shutter button

26

27

1. DV battery icon

2. Video resolution

3. White balance

4. Setup (enter setup menu)

5. Enter Playback mode

6. Shutter button

7. Photo mode

8. Video mode

Note:

1. A Micro SD card must be inserted if you need to take a photo, record a video, or download files on the

terminal;

2. The Wi-Fi indicator will remain on when the terminal is connected to the camera.

1. App Installation:

1.1 Search for ”SYMAGIX” in Google Play (for Android OS),or iTunes® (For Apple OS).

1.2 Install the SYMAGIX APP on your smartphone or tablet. When installation completes, the LCD will dis pla y

icon

.

1.3 Insert a Micro SD card (not included) a nd turn on the ca mera, then press the Wi-Fi button to enable it. N ow

you can see the Wi-Fi icon on the LCD screen of the camera.

1.4 Enable Wi-Fi on your smartphone or tablet and search for wireless AP signal “QC8021, then it will connect

the camera , until the system displays “Connected successfully”.

28

Note: Wireless password is “1234567890”.

1.5 Click on the icon

in the App list of the smartphone or tablet to open it. Now you can preview t he

image sent by the camera on the phone or tablet..

Waterproof Case

 Before sealing the waterproof case, keep the camera housing’s rubber seal clean, a single hair or grain of

sand can cause a leak. You can test by closing the case without inserting the camera. Submerse the case
completely in water for about a minute. Re move the case from the water, dry off its exterior with a towel,
and then open the case. If the interior is dry, the case is safe for use under water.

 Remember to put the Mode Switch in your desired recording position before inserting the camera in the

waterproof case. There are no external buttons for the Mode Switch.

 After use in salt water you will need to rinse the outside of the housing with fresh water an d then dry. This

will prevent corrosion of the hinge pin and salt buildup in the seal, which can cause failure.

29

30

 To clean the seal, rinse in fresh water and shake dry (drying with a cloth may cause lint to compromise the

seal). Re-install the seal into the grooves in the backdoor of the housing.

 To ensure waterproof seal with the waterproof case please ensure you use silicon grease to assist with water

proofing and protection. Smear a thin film of Vaseline on the black rubber O-ring.

31

Distributed by:

TechBrands by

Electus Distribution Pty Ltd

320 Victoria Rd

Rydalmere NSW 2116 Australia

Phone: [phone]

Fax: [phone]

www.techbrands.com

Made in China

32
