Javelin J320i User Manual

Download

General

Information

Rev. 1.1

engenyus limited - August 2003

User's manual

J320i

www.engenyus.com

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

General

Information

Rev. 1.1

1. Install card cleaning cartridge

The card cleaning cartridge is packed separately from the printer in a protective plastic bag. Remove carefully and peel off tape from the cleaning roller before installing it.

Refer to printer user’s manual chapter 2 for more information about the cleaning cartridge.

2. Install card feeder cassette & card output hopper

This two items are delivered separately from the printer in protective plastic bags.

Refer to printer user’s manual chapter 2 for more information.

Quick Start!

Before starting to work with your new JAVELINTMcard printer, please refer to this Quick Start guide. For more complete information regarding all aspects of your printer’s operation, please refer to the main chapters of the printer user’s manual.

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

General

Information

Rev. 1.1

4. Loading ribbon

First, turn on the power to the printer and raise the printhead. Ribbon loading involves the placement of the ribbon onto the supply and take-up spindles. As soon as the ribbon is installed and the printhead is locked down, the spindles will automatically rotate to take up any slack and to synchronize the ribbon to the correct panel.

Refer to printer user’s manual chapter 2 for more instructions

5. Loading cards

First shufﬂe a stack of new cards to reduce any electrostatic charge. Always handle cards by their edges.

Refer to printer user’s manual chapter 2 for more instructions.

6. Set card thickness control lever

This item can be operated by the user to set the card thickness and to prevent more than one card feeding into the printer at the same time and causing a jam. Simply move the lever to adjust correct card thickness position.

Refer to printer user’s manual chapter 2 for more information.

7. Starting to print cards

First connect the interface cable and install the Windows driver on your PC.

Refer to printer user’s manual chapter 3 for more instructions.

SUPPLY SPINDLE

TAKE-UP SPINDLE

Step 1 Step 2 Step 3

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

INTRODUCTION

Thank you for choosing the Javelin J320i plastic card printer.

These printers produce cards ideal for personalised identiﬁcation, access control, visitor, membership, promotion and luggage card, badges and tags.

This manual guides you to an efﬁcient start up and operation of your new card printer.

J320i PRINTER MODELS

Here is a quick review of the Javelin card printer series numbering and lettering system to help you.

The Javelin J320i plastic card printer employs dye sublimation and resin thermal transfer technologies. Model numbers include identiﬁers that specify options are shown using the following lettering conventions:

This information can be found on the printer serial number panel and is also shown on the test card.

Part Number

M : Magnetic

Encoding

E : Smart Card

i : Intelligent printer.

Use only

TrueColours

colour

ribbons from Javelin Dealers

Optional

J320i (X) (X) - nnnnnn

}

GENERAL INFORMATION

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

User's manual

Rev. 1.1

ICONS

Throughout this manual, different icons highlight important information, as follows:

Important general information

Mechanical hazard, such as one associated with moving parts, capable of resulting in equipment damage or personal injury.

Electrical hazard, such as an exposed voltage point, capable of causing electrical shock and personal injury.

GENERAL INFORMATION

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

TABLE OF CONTENTS

1 GETTING STARTED ....................................................... 1

1.1

Unpacking your card printer 1

1.2 Indicators and controls 3

1.3 Printer installation 4

2 OPERATION 5

2.1

Printer Features 5

2.2 Loading ribbons 6

2.3 Loading cards 8 A- Card Feeder 8 B- Card Cleaning Cartridge 10 C- Card Thickness Control Lever 11 D- Card Output Hopper 11

2.4 Reject Card Box 12

2.5 Feeding one card at a time 14

2.6 Printing a test card 15

2.7 Printer menu information 16

3 STARTING TO PRINT CARDS 19

- Install Driver on windows 95/98 20

B- Install Driver on windows NT4.0 21 C- Set Printer Driver Options and printing a test card 21

4 CLEANING 23

4.1

Cleaning system 24

4.2 Cleaning the printhead 25

4.3 Card Cleaning Cartridge 26

5 TROUBLESHOOTING 29

5.1

Interpreting LCD Display Messages 29

5.2 Print Quality issues 32

6 TECHNICAL SPECIFICATIONS 35

iii

Rev. 1.1

TABLE OF CONTENTS

1 GETTING STARTED ...................................................... 1

1.1

Unpacking your card printer ......................................................... 1

1.2 Indicators and controls ............................................................... 3

1.3 Printer installation...................................................................... 4

2 OPERATION ...................................................................... 5

2.1

Printer features ......................................................................... 5

2.2 Loading ribbons ......................................................................... 6

2.3 Loading cards............................................................................ 8

A- Card cartridge ....................................................................... 8

B- Card cleaning cartridge ........................................................... 10

C- Card thickness control lever...................................................... 11

D- Card output hopper................................................................. 11

2.4 Feeding one card at a time........................................................... 12

2.5 Printing a test card .................................................................... 13

2.6 Passcode Electronic Lock............................................................. 14

3 STARTING TO PRINT CARDS ................................. 16

- Install driver on Windows 98, 2000/NT or XP ............................ 17

B- Set printer driver options ......................................................... 18

C- TrueSecure Varnish Imaging Printing .......................................... 19

4 CLEANING ......................................................................... 20

4.1

Cleaning system......................................................................... 21

4.2 Cleaning the printhead............................................................... 22

4.3 Card cleaning cartridge ............................................................... 23

5 TROUBLESHOOTING .................................................. 25

5.1

Interpreting LCD display messages ............................................... 25

5.2 Print quality issues ..................................................................... 29

6 TECHNICAL SPECIFICATIONS................................ 32

GENERAL INFORMATION

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

APPENDIX A JAVELIN i SERIES

INTELLIGENT PRINTING SYSTEM .............................. 36

Frequently asked questions...........................................................

APPENDIX B -

MAGNETIC CARD STRIPE ENCODER ...................... 39

Introduction ................................................................................ 39

- Media loading orientation ....................................................................... 4 0

B- Magnetic encoder cleaning .................................................................... 41

APPENDIX C -

SMART CARD CONTACT STATION .......................... 42

Introduction ................................................................................

A- Media loading orientation ...................................................................... 43

B- Smart card contact station interface .................................................... 4 3

APPENDIX D -

ACCESSORIES & SUPPLIES ......................................... 44

Ribbons......................................................................................................... 4 4

Cards ............................................................................................................ 45

Accessories ................................................................................................. 46

APPENDIX E -

WARRANTY INFORMATION .......................................... 47

APPENDIX F -

TECHNICAL SUPPORT...................................................... 49

APPENDIX G - ....................................................................... 50

Declaration of Conformity ........................................................................... 5 0

Trademarks .................................................................................................. 51

GENERAL INFORMATION

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1GETTING STARTED

Your J320i printer ships in a carton and protective anti-static bag. Keep all packing material in case you need to move or re-ship the printer.

While unpacking, inspect the carton to ensure that no damage occured during shipping.

Please ensure that you have a clean and nearly dust free environment for proper operation and storage of the printer.

1 Getting started

1.1 Unpacking your card printer

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1GETTING STARTED

Make sure the following items are included with your J320i printer:

If any items are missing, please contact your dealer.

To reorder, please refer to Appendix D of this manual.

CLEANING KIT

POWER CABLE

USER MANUAL & PRINTER DRIVER CD

QUICK START GUIDE

INTERFACE CABLE

CLEANING CARTRIDGE

CARD OUTPUT HOPPERCARD FEEDER CASSETTE

General

Information

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

Rev. 1.1GETTING STARTED

Your J320i printer has an LCD Display and and 2 Panel Buttons.

LCD DISPLAY :

The 16 character LCD Display is used for :

●

Showing the printer's current status

●

Providing operator and service messages (Chapter 5)

LEDS :

The two LEDs are used for :

●

Green: Power LED

●

Amber: Alert LED (with beeper) This alert LED is on when an error condition exists. The beeper will sound three alert "beeps" and the LCD display will show the associated error message.

PANEL BUTTONS:

The Menu/Next Button (left) is a push button used for:

●

Bringing printer into menu mode when pressed with the printer showing READY

on the LCD Display.

●

Using in menu mode to scroll through menu options.

The Clear/Select Button (right) is a push button used for:

●

Clearing an error status (when LCD display shows an error report and alert

LED is on).

●

Invoking automatic retry of the operation which gave the error.

●

Selecting a menu option when in menu mode.

NOTE: the buttons “beep” when pressed

1.2 Indicators and Controls

Power LED

Menu/Next Button

LCD Display

Clear/Select Button

Alert LED

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1GETTING STARTED

The following will guide you through the installation of your J320i printer.

1.3 Printer Installation

CAUTION : Limit AC power supplied to the J320i Printer to 110 - 230 V AC, 60 - 50 Hz for an associated 680 mA - 310 mA. Limit excess current draw to 16 amps or less, using an associated circuit breaker or other such device. Never operate the printer in a location where operator, computer, or printer can get wet. Personal injury could result. The printer must be connected to an earthed electrical power supply and properly protected against electrical surges and grounding faults.

CAUTION: Intermittent or unpredictable operation may occur from unsecured connectors. If damaged, the power cable must be replaced by an exact equivalent.

Use only parallel cable under 3 metres in length.

1. Place the printer in a location that allows easy

access to all sides. The printer should never be operated while resting on its side or upside down.

2. Place the printer’s power switch in the OFF

(0) position.

3. Insert the power cable to the printer power socket

and attach to grounded electrical socket of the proper voltage and type.

4. Attach interface cable to printer and computer

and then secure.

5. Switch power on.

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1OPERATION

2 Operation

2.1 Printer Features

STANDARD FEATURES

1. Printhead

2. Printhead Unlock lever

3. LCD Display

4. Panel Buttons

5. Card Output Hopper

6. Card Thickness Control

7. Card Feeder Casette

8. Card Cleaning Cartridge

PLEASE NOTE : Any blue items inside the printer can be operated by the user.

OPTIONAL FEATURES

A. Magnetic Encoder Station B. Smart Card Contact Station

The following shows the features found on your J320i printer:

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

1. Remove ribbon from packaging.

2. With printer power ON and in ‘Check Ribbon’

status, open cover and press down on the printhead unlock lever to open the print head carriage. The printhead carriage will pop open.

Continued on next page ......

Rev. 1.1OPERATION

2.2 Loading Ribbons

The J320i printer requires approved ribbons (See Appendix A & D). The resin thermal transfer and dye sublimation ribbons are speciﬁcally designed for your J320i printer. For optimum performance and printer life (printhead), always use approved ribbons.

Only intelligent TrueColoursTMcolour ribbons purchased from Javelin dealer will work in J320i printers

DO NOT TOUCH the printhead or the electronic components on the printhead carriage. Discharges of electrostatic charge from the human body or other surfaces can damage the printhead or other electronic components used in this device.

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1OPERATION

3. Load ribbon onto the supply spindle (under print

head carriage) and empty core (with tape attached) onto the take-up spindle. Make sure the ribbon comes off the top of the supply spindle and feeds to the top of the take-up spindle. Push ribbon all the way in.

4. Push down on the printhead lock lever until an

audible 'click' signals the locked-down position. Please note that the ribbon automatically synchronises whenever the printhead is locked down. Ready status will appear.

Please note that the ribbon automatically synchronises whenever the printhead is locked down.

SUPPLY SPINDLE

TAKE UP SPINDLE

‘CLICK’

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1OPERATION

2.3 Loading Cards

To help you load, print, and collect cards, the J320i has the following item:

A - CARD FEEDER CASSETTE

This item is used for loading cards.

1. Install card feeder cassette by hooking onto

printer as shown and clicking down.

2. Install cards into card feeder cassette* as shown.

3. Close card feeder cassette.

‘CLICK’

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1OPERATION

DO NOT bend cards or touch print surfaces as this can reduce print quality. The surface of the cards must remain clean and dust free. Always store cards in an enclosed container. Ideally, use cards as soon as possible. If cards stick together, carefully shufﬂe them.

* See Chapter 6, Technical Speciﬁcations, for card requirements and capacities.

Rev. 1.1OPERATION

B - CARD CLEANING CARTRIDGE

1. Remove card cleaning cartridge from packaging.

2. Remove the yellow reminder tape from the

location for the cleaning cartridge.

3. Make sure the arrow on top of the assembly

is facing toward the side of the printer. Hook assembly into slot on printer and rotate down. Ensure the assembly locks in place.

4. Close cover

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

This item is used to clean the cards entering the

printer and must be ﬁtted before using the printer.

Rev. 1.1OPERATION

C- CARD THICKNESS CONTROL LEVER

This item is operated by the user to prevent more than one card feeding into the printer at the same time and causing a jam.

D - CARD OUTPUT HOPPER

This item is used for collecting printed cards.

Install card output hopper to printer by hooking over bottom edge of card exit aperture.

Open cover, and adjust lever to the correct position for the card thickness you are using. Repeat for different card thickness. (Factory setting is for 30mil (0.762 mm) card thickness). See diagram below :

Card thickness:

A - 60mil (1.524mm) to 50mil (1.27mm) B - 40mil (1.016mm)

C - 30mil (0.762mm) - DEFAULT

D - 20mil (0.508mm) E* - Less than 20mil (0.508mm) * Start at lowest position and move lever up to match card thickness.

For other card thickness, start lever at lowest position and move up until cards feed.

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

A manual feed slot is available on the rear of the card feeder cassette cover for feeding single cards. Cleaning cards are fed manually through this slot.

The card feeder cassette must be empty for manual card feeding to work properly.

For one-at-a-time printing, feed cards through slot on rear of card feeder cassette.

Do not feed more than one card at a time.

2.4 Feeding one card at a time

OPERATION

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

With ribbon and cards loaded, your J320i printer is ready to print. To check the operation of the printer you should print a test card.

2.5 Printing a Test Card

This is an example of the test card.

OPERATION

1. Turn off printer.

2. While pressing clear button, switch printer

back on.

3. LCD will show test, depress button once self

test is displayed.

4. A test card is printed. This will show the

current printer settings.

5. The printer is now communicating with the

computer and is ready for use

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

General

Information

Rev. 1.1

The Javelin printer’s passcode system disables the printing and encoding of the printer except by authorised users in possession of the valid passcode. This userselected Passcode gives you the choice of what is the best level of security for your application. The printer ships with the passcode disabled. To enjoy the beneﬁts of the passcode security feature, please follow these steps: 1 In READY mode, hold down both the “Next” and “Select” buttons on your LCD

pad for ﬁve seconds. Bleeps twice goes into passcode menu.

2 If Passcode enabled; enter passcode, if disabled access Passcode menu. 3 Select your passcode ﬁrst. You may choose a 1 to 5 digit number and each

digit may be 0 to 5.

4 Use the “Next” key to move the cursor to the number you want for your ﬁrst

digit, then use the “Select” key to set it.

5 Repeat step four for each of the digits of your passcode. Move cursor to “END”

when you have set all the digits. Press “Select”.

6 You will be prompted to verify your passcode. 7 You will also be prompted to select how often you would like your passcode to

lock out printing, encoding and overlay varnish. When you have ﬁnished your selections, your passcode will be enabled with your settings. Once enabled, the printer will prompt you to enter your passcode before printing, encoding, or resetting your passcode. A complete passcode menu ﬂowchart is shown overleaf.

2.6 Passcode Electronic Lock

OPERATION

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Passcode Menu (starting from ‘Passcode Disabled’)

Rev. 1.1

PASSCODE

ENABLE

PASSCODE

Select to toggle ENABLE/DISABLE

Enter new press procedure (see below)

Card based/ overlay based disable

Legend:

Clear/Select button

*means that 1 password digit has been entered

- means that nothing has been entered for the indicated digit

Menu/Next button

PASSCODE

ENTER NEW

PASSCODE......

1 23450 END

CONFIRM

1 23450 END

Choose Passcode with Next & Select. Choose End & Select to complete

CONFIRMED

PASSCODE

POWER UP ON

PASSCODE

MORE OPTIONS

COUNTER OPTION

CARD BASED

READY

COUNTER VALUE

XXXX

OPERATION

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1STARTING TO PRINT CARDS

3 Starting to

print cards

Printing with the J320i printer requires the Windows Printer Driver, your card design/issuing software or printer command level programming through the printer interface.

The J320i card printer can be used with any Windows 98, ME, 2000, XP or NT 4.0 operating system, using the drivers provided with the printer. Updated drivers can be downloaded from the engenyus website www.engenyus.com

This section contains information on the printing of a single sided card in colour (using the 5-Panel colour ribbon YMCKOi) and the Windows Printer Driver.

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

A-TO INSTALL THE J320i PRINTER DRIVER IN

WINDOWS 98, 2000/NT OR XP, USE THE FOLLOWING STEPS:

●

Start your computer .

●

Insert your Javelin Printer Driver CD into computer drive.

●

The CD will automatically launch and enter the Setup Wizard that will guide you

through installation of your printer driver. (Autorun must be eneabled on PC)

●

If the CD does not launch itself, then open the CD in Explorer, go to Drivers

and run setup.exe. This will launch the Setup Wizard.

The Printer Wizard will copy the necessary ﬁles to the PC for you and the J320i printer driver installation will be completed.

IMPORTANT NOTE - ENSURE THAT YOUR PC PRINTER PORT IS SET TO STANDARD MODE AND ALSO ENSURE THAT YOU HAVE DELETED ANY PREVIOUS VERSIONS OF THIS PRINTER DRIVER. IF INSTALLING ON NT/2000 OR XP ENSURE THAT YOU HAVE ADMINISTRATION PRIVILEGES. IF YOU HAVE ANY DOUBTS PLEASE CONTACT YOUR IT DEPARTMENT.

STARTING TO PRINT CARDS

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1STARTING TO PRINT CARDS

B. SET PRINTER DRIVER OPTIONS. WINDOWS NT,

2000, XP

The printer settings can be accessed by selecting the J320i Plastic Card Printer

driver from within Printers. Under Windows NT, 2000, XP the printer

properties are separated into two distinct pages, Document Defaults and Printer Properties. Highlight the printer icon and right click to open the following options.

Document Defaults

The page set-up window allows the number of copies to be set and the option of portrait or landscape. The advanced settings are:

●

Card: colour conversion, and image rotation.

●

Ribbon: type of ribbon and use of the black panel.

●

Printer: printer colour settings.

Properties

Within the device setting's window are the machine options such as:

●

Print full size cards, smart download.

●

Magnetic encoder settings

●

Toolbox, from the toolbox, self-test printing station can be chosen to produce

a test card.

NOW THAT YOU HAVE LOADED MEDIA AND SET UP THE PRINTER DRIVER, THE J320i PRINTER IS READY TO PRINT

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

General

Information

Rev. 1.1STARTING TO PRINT CARDS

C. TRUESECURE VARNISH IMAGING PRINTING

This is a driver enabled option to print a bitmap in your O (overlay varnish) panel of your ribbon resulting in a simulated “watermark” that produces a more “copy-proof” card. To enable this feature: On Windows 98, ME systems, click on the ribbon tab, or NT, 2000, XP systems choose document defaults/printing preferences, advanced, ribbon. Select the front overlay varnish button. From the drop down list, choose bitmap based overlay. Click the browse button to search your system for the bitmap created and click on the open button. The preview shows the ﬁle to be used in the overlay panel. Click on the close button to return to the driver. Click on the OK button to exit the driver.

A UV “Black light” can be used to view this more dramatically; the protected areas will glow in the light. The best contrast is seen in the white areas on the card where the bitmapped varnish is present.

For additional security, you can passcode protect this feature through your LCD panel. See passcode electronic lock section for details.

Printing a bitmap with a hologram overlay varnish is not recommended. It may cause varnish ﬂaking with some bitmaps which will decrease print quality and can damage the printer or shorten the printer life.

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1CLEANING

4 Cleaning

PROTECT YOUR FACTORY WARRANTY !

The recommended maintenance procedures must be performed to maintain your factory warranty. Other than the recommended cleaning procedures described in this manual, allow only engenyus authorised technicians to service the J320i printer. NEVER loosen, tighten, adjust, or bend, etc. a part or cable inside the printer. NEVER use a high pressure air compressor to remove particles in the printer.

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

4.1 Cleaning System

Your J320i printer includes a simple cleaning system using the pre-saturated cleaning cards provided. The regular use of these cards will clean and maintain important parts of your printer: including the printhead, and transport rollers.

CLEAN PRINTER WHEN TO CLEAN

When LCD screen reports message.

HOW TO CLEAN

Leave power on. Open cover and release printhead bracket to remove ribbon

2.Remove any normal cards from the card cartridge.

Insert one pre-saturated cleaning card (provided) through slot on the rear of the card cartridge. Close the printhead bracket. Close the cover.

3.Press the right panel button for a few seconds.

The card will feed into printer and carry out the cleaning process. Repeat the process with a new cleaning card if necessary.

Note: For a printer cleaning prior to the WHEN TO CLEAN signal, press the left panel button until the LCD screen shows "CLEANING MENU". Press the right panel button to select and one more time again to run the cleaning process (Repeat ﬁrst steps 1 & 2 above).

Although the CLEAN PRINTER message is displayed until the cleaning process has been performed, the printer will continue to operate.

CLEANING

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1CLEANING

4.2 Cleaning the printhead

Cleaning the printer using the cleaning system with cards usually sufﬁces. However, cleaning the printheads using swabs can remove more stubborn deposits when print anomalies persist. To avoid deposits, only use foam-tipped swabs.

1.Raise printhead and remove the ribbon.

2.Clean printhead by moving the alcohol moistened

swab tip side-to-side across printhead elements. Only use moderate force. (To re-order swabs see Appendix D).

Never use a sharp object to scrape deposits from the printhead. Permanent damage will result.

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1CLEANING

4.3 Card Cleaning Cartridge

Your J320i printer also has a card cleaning cartridge. This item cleans the cards entering the printer. To ensure print quality, the adhesive cleaning roller requires periodic replacements.

CLEAN PRINTER WHEN TO MAINTAIN

When LCD screen reports message, every 1,000 cards, or when roller is dirty. Run a printer cleaning ﬁrst . (see 4.1 Cleaning System for more instructions.)

HOW TO MAINTAIN

Open cover and locate cleaning cartridge.

2.Gently remove cleaning cartridge by rotating up

and away from printer.

Continued on next page...

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1CLEANING

3.Remove the adhesive cleaning roller from cartridge

and discard.

4.Install new cleaning roller into cartridge*.

To avoid contamination, always hold the cleaning roller assembly by the ends.

5.Carefully peel off wrapper from new

cleaning roller while in cartridge.

6.Replace cartridge into printer. Make sure the arrow

on top of the assembly is facing toward the rear of the printer. Hook assembly into slot on printer and rotate down. Ensure the assembly locks in place.

DO NOT touch the roller surface that contacts the cards.

7. Close cover

* See Appendix D for replacement cleaning rollers.

Although the CLEAN PRINTER message is displayed until maintenance has been performed, the printer will continue to operate.

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

5 Troubleshooting

TROUBLESHOOTING

This section offers solutions to potential problems you may experience with your J320i printer. The table below lists the screen messages that will be displayed on the printer's LCD, both during normal operation and to alert operator of any error conditions. There is also some additional information dealing with quality issues concerning printing onto cards.

5.1 Interpreting LCD Display

messages

SCREEN MESSAGE

CHECK RIBBON

INITIALISING

READY

WAIT

TEMPERATURE

SELF TEST

DOWNLOADING

DATA

PRINTING YELLOW

PRINTING MAGENTA

PRINTING CYAN

MEANING

No ribbon

The printer is performing an internal test before use

Ready for use

printhead cool down mode

Self test card printing

The card data is being transmitted

The yellow panel is being printed

The magenta panel is printing

The cyan panel is printing

ACTION

Install ribbon

Wait for READY message

Wait for test card

Wait for card printing to start

Rev. 1.1

SCREEN MESSAGE

PRINTING BLACK

PRINTING VARNISH

PRINT HOLOGRAM

CLEAN PRINTER

CLEAN MAG HEAD

CLEANING

REMOVE RIBBON

OUT OF RIBBON

MECHANICAL

ERROR

OUT OF CARD

HEAD OPEN

COMMAND ERROR

PARAMETERS

ERROR

MEANING

A monochrome panel is being printed

The overlay is printing

A hologram overlay is printing

The printer is prompting the operator maintenance

The printer is prompting the operator

The printer is performing an internal cleaning routine

The ribbon has not been removed while the cleaning operation is in progress

The printer ribbon has run out

The printer has an error moving the card internally

The card cartridge is empty, or the card has mis-fed

The printhead is not locked into position

The data being sent from the host is not recognised

The features of the card are not recognised

ACTION

Carry out the cleaning procedure as detailed in section 4 of this manual

Carry out the cleaning procedure as detailed in Appendix B of this manual

Remove ribbon

Replace printer ribbon

Remove the jammed card. Ensure that the card is not out of speciﬁcation. Ensure the cleaning cartridge is correctly ﬁtted!

Add more cards or adjust the card feeder to accept the cards

Lock the printhead in its lower position

Check that the data is suitable for printing. Try reprinting a card from known 'good' data

Check the Windows driver options, magnetic data and printer type

TROUBLESHOOTING

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

SCREEN MESSAGE

ENCODING ERROR

READING ERROR

ENCODING ERROR

FLASH ERROR

NO ACCESS

MEANING

Data cannot be written or read from the card's magnetic stripe

Data cannot be read from the card's magnetic stripe

The printer cannot detect a magnetic stripe on the card.

ACTION

Check that the cards are loaded with the magnetic stripe in the correct orientation. Check whether high or low coercivity cards have been speciﬁed. Check that the data conforms to ISO speciﬁcations. See Appendix B of this manual for further information.

Check the card orientation

Contact your dealer for technical support.

Ribbon Errors: Check that the print ribbon has not 'run out'. Lock and then unlock the printhead assembly; this resynchronises the ribbon automatically. When using a colour ribbon, it should advance automatically so that the leading edge of the yellow panel is beneath the printhead. Ensure that the correct ribbon type has been speciﬁed in the Windows driver.

Card Feed & Mechanical Errors: Ensure that the card thickness adjustment has been set-up correctly to allow one card to feed.

Continued on next page...

TROUBLESHOOTING

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

Magnetic Encoding Errors: Check that the cards are inserted correctly in the printer. Ensure that the cards are low or high coercivity as required, and are set-up correctly in the printer driver.

Cleaning Alert: The printer has counted the number of cards printed and has automatically ﬂagged that a cleaning routine needs to be carried out. (See Chapter 4).

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

5.2 Print Quality Issues

TROUBLESHOOTING

This section will help you resolve print quality problems. The print quality is dependent on several factors. The two most important factors that will increase your print quality are cleanliness and card stock. To diagnose and ﬁx print quality problems, follow the troubleshooting procedure below:

●

Small spots appear on the printed card with a non-printed area or a different color.

Possible Cause

A. Contamination on the card surface. B. Dust inside the printer and/or dirty cleaning roller.

Solution

A1.Check that cards are stored in a dust free environment A2.Use a different supply of cards. B1.Perform a cleaning of the printer (see cleaning section). B2.Replace cleaning roller (see cleaning section).

●

There are non-printing horizontal lines (white) on the card surfaces.

Possible Cause

A. Ribbons is not correctly positioned. B. printhead may be dirty. C. printhead elements may have been damaged

(e.g. scratched or burnt).

Solution

A1.Open cover and press down the printhead unlock lever to open

the printhead carriage. The printhead will move up.

A2.Check that the ribbon is properly rolled onto the ribbon cores and

there are no wrinkles in the ribbon.

A3.Push down on the printhead lock lever until an audible “click”

signals the locked-down position. A4.Ribbon will automatically synchronize. A5.Print again.

B1.Perform a cleaning of the printhead (see 4.2 Cleaning the printhead.)

C1. Call service for printhead replacement information.

➔

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1TROUBLESHOOTING

• Printing shows very pale or inconsistent results.

Possible Cause

A. Ribbon may have been stored improperly or is damaged. B. Cards may not meet speciﬁcations. C. Contrast and/or Intensity may be set to values

which are too high.

D. Dust or embedded contamination on elements

of the printhead.

Solution

A1.Change ribbon and print again. B1.Use a different supply of cards. C1. Adjust contrast and/or Intensity values in software D1.Perform a cleaning of the printhead (see 4.2 Cleaning the printhead.)

•

Printing shows blurry printed image.

Possible Cause

A. Ribbon may not be correctly positioned B. Ribbon may not be synchronized on the correct

color panel position. C. Cards may not meet speciﬁcations. D. Dust inside the printer and/or dirty cleaning roller.

Solution

A1. Open cover and press down the printhead unlock lever to open the

printhead carriage. The printhead will move up. A2. Check ribbon is properly rolled on ribbon cores. A3. Push down on the printhead lock lever until an audible

“

click

”

signals the locked-down position. A4. Ribbon will automatically synchronize. A5. Print again.

Continued on next page...

➔

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

• No printing on the card.

Possible Cause

A. Ribbon may not be installed in the printer B. Cards may not meet speciﬁcations. C. Cable on printhead may be disconnected. D. printhead elements may be scratched or burnt.

Solution

A1.Check for ribbon in the printer. B1.Use a different supply of cards. C1. Power off the printer and check the printhead cable connections. D1.Call service for printhead replacement information.

For optimum print quality, always keep cover of the printer closed except during ribbon loading and card thickness control procedures. The card ﬂipper will not operate and an error will be indicated if you try to ﬂip a card with the cover open.

TROUBLESHOOTING

➔

B1. Open cover and press down the printhead unlock lever to open

the printhead carriage. The printhead will move up. B2. Push down on the printhead Lock Lever until an audible

‹‹

click

››

signals the locked-down position. B3. Ribbon will automatically synchronize. B4. Print again. C1. Use a different supply of cards. D1. Perform a cleaning of the printhead

(see 4.2 Cleaning the printhead.) D2. Replace cleaning roller (see 4.3 Cleaning cartridge.)

Printing shows blurry printed image.

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

6 Technical

Speciﬁcations

● High speed printing, over 144 cards/hour edge to

edge in full colour (YMCKOi) throughput

● Small footprint

● Windows Drivers for 98, NT 4.0, ME, 2000, XP.

● Colour dye sublimation or monochrome thermal

transfer printing

● 25 seconds per card (YMCKOi) throughput

● 300 dpi (11.8 dots/mm) print resolution

● Edge to edge printing standard

● Resident: Arial Normal 100, Arial Bold 100

● True Type fonts available via Windows Driver

● Types PVC, Composite

● Card width/length: ISO CR-80 - ISO 7810,

2.125” (54mm) by 3.375” (86mm)

● Option: Magnetic Stripe - ISO 7811

● Option: Smart Card - ISO 7816-2

● Card thickness: 0.25mm to 1.524mm

● Card feeder capacity: up to 240 cards (10mil), up

to 80 cards (30 mil)

● Card output hopper capacity: 300 cards (10mil),

up to 100 cards (30 mil)

General

Colour Printing

Fonts

Cards

TECHNICAL SPECIFICATIONS

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

CARD DIMENSIONS

ISO STANDARD DIMENSIONS FOR PLAIN CARD

ISO STANDARD DIMENSIONS FOR MAGNETIC STRIPE CARD

CHIP POSITION FOR SMART CARD

TECHNICAL SPECIFICATIONS

0.01 in

(2.54mm)

Min.gap

0.395 in (8.25mm)

0.221 in (5.62mm) max gap

0,218 in (5.54mm) max

0˜0.115 in (2.92mm)

0.115 in (2.92mm)

MAGNETIC STRIPE

0.623 in (15.82mm)

2.125

± 0.002 in

(53.98

± 0.050mm

3.375

± 0.010 in

(85.72

± 0.25mm)

0.009

± 0.034 in

(0.23

± 0.84mm

Radius

0.125 in

(3.18mm)

0.218 in (5.54mm) Max.

0.623 in (15.82mm) Min.

0.782 in (19.87mm) Min.

0.403 in (10.25mm) Max.

0.790 in 21.87mm

0.210 in

(3.54mm)

0.631 in

(7.54mm)

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1TECHNICAL SPECIFICATIONS

●

Monochrome: 1000 cards/roll black, red, blue, green, silver, gold, white, scratch-off.

●

Monochrome: 1500 cards/roll (black only)

●

K-resin + Oi: 500 cards/roll

●

K-dye + Oi: 500 cards/roll

●

YMCKOi: 200 or 330 cards/roll

Thermal transfer (Resin) ribbons offer more durability than dye sublimation, with greater resistance to scratches and UV-induced fading.

Dye Sublimation printing requires dye sublimation ribbons, with either black or cyan, magenta, and yellow (plus black resin) panels.

●

Thermal transfer

- 4 microns thick

●

Clear and holographic options:

- Clear

- Genuine/Secure Hologram

- Custom Hologram

●

Centronics Parallel Standard

●

RS-232C Serial (Optional)

●

USB port (Optional)

●

Width: 7.5" (191 mm)

●

Depth: 17.3" (440 mm)

✝

●

Height: 9.1" (232 mm)

●

Weight: 20.9Ibs (9.5 kg)

✝

Measured without card output hopper.

●

110 ~ 230 Volts AC, 60 ~ 50 Hz

●

FCC Class A, CE, UL, and CUL approved

Ribbons*

Overlay Varnish

Interfaces

Mechanical

Electrical

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

Options & Accessories

●

Centronics Cable (2.0 or 3.0 metres)

●

RS-232C serial port

●

USB port

●

Smart Card Contact Station (0.76mm cards only)

●

Magnetic Encoder (0.76mm cards only)

●

Cleaning supplies

●

Service Manual

*For best results use engenyus-approved cards and TrueColours

colour ribbon media. Using non-approved

cards or ribbon media can void your warranty.

Refer to the Accessories section for more information about cards and ribbon media available from engenyus.

TECHNICAL SPECIFICATIONS

●

Operating Temperature: 60 to 86°F (15 to 30°C)

●

Operating Humidity: 20 to 65% non condensing

●

Storage Temperature: -23 to 158°F (-5 to 70°C)

●

Storage Humidity: 20 to 70% non condensing

●

Ventilation: Free air

Environmental

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

Appendix A

JAVELIN™ i Series: Intelligent Printing System

Fequently Asked Questions

1 What is the Javelin i Series?

The i Series is a new line of Javelin plastic card printers that incorporates an innovative, intelligent card printing system.

2 What is the i Series Intelligent Printing System?

The i Series Intelligent Printing System is combination of design features implemented in Javelin card printers, printer drivers, and Javelin printer ribbons that ensure easy, economical, high quality card printing on Javelin-brand card printers.

3What are the beneﬁts of the new i Series Intelligent Printing System?

- Easy to Use: printer automatically detects the ribbon type and conﬁgures the driver, eliminating extra steps and potential errors when setting up or changing print jobs. Ribbon low alert tells the operator when there are 20 card images remaining on the ribbon and a replacement ribbon will be required soon.

- Excellent Print Quality: wider ribbon for edge-to-edge applications; new HC (High Colour) ribbon formulation for fuller, richer colours; advanced image data processing for greater detail, sharpness and control.

APPENDIX A

Rev. 1.1

4What are the printer features of the new i Series

Intelligent Printing System?

- Image Data Processing: Uses a method of data processing in the printer ﬁrmware to optimise how the image is printed. The printer is able to process a wider range of colours resulting in greater image detail, sharper images, and better colour control.

- Ribbon Type Detection: The printer deploys RFID technology to detect the type of ribbon installed and interacts with the driver to ensure optimisation for printing with the type of ribbon detected.

5What are the ribbon features of the new i Series

Intelligent Printing System?

- New HC (High Colour) Ribbon Formulation: Prints in fuller, richer colours for improved colour reproduction with more vibrant colour range.

- New Wider Ribbon: Covers full range of edge to edge printing for better print quality and increased operating and density range to minimise potential for ribbon wrinkle.

- RFID Intelligence: Factory pre-programmed ribbon type and image count information is communicated to the printer and driver at installation.

- Image Counter: Counts and saves "number of images printed" information. This information is used to provide "ribbon low" status to the driver. The number of images printed is continuously updated and saved in the smart chip on the ribbon cartridge or core, so the ribbon "knows" how many card images have been printed. This means ribbons can be removed or exchanged, even if not fully used, and reinstalled for use of the remaining panels.

6What are the software/driver features of the i Series

Intelligent Printing System?

- Automatic Driver Conﬁguration: Printer detects the i Series ribbon type and the driver automatically conﬁgures the driver to select correct ribbon type.

- Javelin Image Proﬁle: A software tool for Windows 98 and 2000 environments that enhances colours, minimises whitewashing, and enhances colour contrasts.

- Ribbon Low Notiﬁcation and Messaging: Alerts user when ribbon is running low (20 card images remaining) and that a replacement ribbon will soon be required.

- Changed Ribbon Type Notiﬁcation: Notiﬁes user and requests conﬁrmation when a newly installed ribbon is different than the previous ribbon used.

APPENDIX A

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

7 How do I know if I have an i Series ribbon?

The i Series designation is part of the ribbon description. i Series TrueColours' ribbons are packaged in blue boxes and are clearly identiﬁed on ribbon packaging and labelling. In addition, all i Series ribbons part numbers are different from non-i Series ribbon part numbers.

8 What is the difference between i Series and non-i Series ribbons?

i Series multi-panel ribbons have RFID technology that enables the printer and driver features of the Intelligent Printing System, High Colour (HC) ribbon formulation, and are wider for improved edge to edge printing. The i Series ribbons are supplied with a replacement cleaning roller included in the box.

9Will i Series ribbons work on non-i series printers?

Yes. An i Series ribbon will work with a non i Series printer, but when installed on a non i Series printer, the ribbon will not be enabled through RFID technology. This means the resulting colour imaging will not be as optimal as it would be if it were used with an i Series printer.

10 Will non-i Series ribbons work on i Series printers?

- No. i Series printers require use of i Series ribbon for full colour printing or printing with multi-panel ribbons.

- Non-i Series monochrome, single panel ribbons function on i Series printers.

11 Where can I buy i series ribbons?

Javelin i Series ribbons are available only from authorised Javelin card printer dealers.

12 Do I Series ribbons require any special care or handling?

No. The storage and handling requirements are the same as non i Series ribbons.

13 Who do I contact if I have any other questions?

Contact your Javelin dealer for any questions related to Javelin card printers.

Non i Series Ribbon i Series Ribbon

A ﬂange on the supply side of the ribbon core easily identiﬁes unpackaged i Series ribbons.

Flange

APPENDIX A

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

Appendix B

Magnetic Card Stripe Encoder

This section contains information on the additional operations of the J320i printers with magnetic card stripe encoder. (See Chapter 2 for location.)

INTRODUCTION

Operation and maintenance requirements for the J320i printer with the optional magnetic card stripe encoder. (See Chapter 2 for location). The magnetic encoder can be set for either high or low coercivity. (HICO or LOCO)

APPENDIX B

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

A. MEDIA LOADING ORIENTATION

The magnetic encoder is a factory installed item with the read/write head positioned below the card path, available with HICO encoding or LOCO encoding .

When loading cards into the card cartridge, please ensure that the magnetic stripe is facing down and closest to the rear.

Also available are printer models with the magnetic read/write head positioned above the card path, with HICO encoding or LOCO encoding .

When loading cards, please ensure that the magnetic stripe is facing up and closest to the rear.

Approved HICO & LOCO PVC cards are available. (See Appendix D).

ONLY USE cards that comply with ISO 7810 & 7811 standards for magnetic stripe cards. The magnetic stripe must be ﬂush to the surface of the card to work properly. Never use taped-on magnetic stripes.

APPENDIX B

STRIPE DOWN

STRIPE

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

B. MAGNETIC ENCODER CLEANING

The process consists of a standard cleaning of the printer. This cleans the most important parts of the printer; including the printhead, transport roller and magnetic stripe encoder (refer to chapter 4 Cleaning for more instructions).

Track #

ISO STANDARD ENCODING

* Bit per inch

✝

Except the '?' character

‡

Including Start, Stop and LRC characters. Also note that these 3 characters are

automatically managed by the magnetic encoder according to the ISO Standard Norms.

NOTE: Refer to the card printer programmer's manual for complete programming information.

Field Separato

Track density

210BPI*

75BPI*

210BPI*

Valid Characters

Alphanumeric

(ASCII 20~95✝)

Numeric

(ASCII 48~62)

Numeric

(ASCII 48~62)

# of characters

‡

107

‡

APPENDIX B

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

Appendix C

Smart Card Contact Station

This section contains information on the additional operations of the J320i printers with smart card contact stations. (See Chapter 2 for location.)

INTRODUCTION

Smart cards can be either ‘memory’ cards or contain memory and a micropressor. Data can be stored such as the holder’s personal details together with advanced features such as security algorithms and biometic data such as ﬁngerprint patterns.

The Javelin J320iE and J320iEM printers have a contact station to connect a serial interface to the smart card contacts. A suitable smart card coupler and associated software would be required external to the printer to communicate with the smart card. engenyus offers a range of integrated couplers (as detailed on page 46) for both contact, contactless (Mifare) and ‘combi’ cards.

The J320i may be equipped with an optional contact station for programming smart cards (ISO 7816). This printer model responds to commands that position the cards at the contact station, where the printer connects to the contacts on the smart cards. All other printer operations remain the same as the standard J320i model.

APPENDIX C

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

A. MEDIA LOADING ORIENTATION

Position the cards with the smart card chip at the top of the card and towards the printer.

B. SMART CARD CONTACT STATION INTERFACE

When a command to the parallel printer interface sends a card to the smart card contact station, the printer connects the smart card contact station to the female DB-9 connector on the rear of the printer.

An attached external smart card programmer can be used to program smart card chips.

Refer to the card printer programmer's manual for complete programming information.

DB - 9

PINS

SMART CARD

CONTACT POINTS

CI (Vcc)

C2 (Reset)

C3 (Clock)

C4 (RFU)

C5 (GND)

DB - 9

PINS

SMART CARD

CONTACT POINTS

C6 (Vpp)

C7 (I/O)9

C8 (RFU)

(GND when chip

is at station)

APPENDIX C

DO NOT position printing over the smart card chip.

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1APPENDIX D

Appendix D

Please contact your Javelin dealer to place an order for accessories and supplies.

RIBBONS

Intelligent Javelin Encoded Ribbons

New rich colour formula - essential for intelligent J320i printers

Accessories & supplies

Intelligent TrueColours Two-panel Ribbons (Inc. Cleaning Rollers)

6 11 34 509 6 11 34 510

Black (dye-sub) + overlay KdOi - for monochrome photo (500 cards) Black (resin) + overlay KrOi - for text and bar codes (500 cards)

Intelligent TrueColours Full Colour Ribbons (Inc. Cleaning Rollers)

6 11 34 501 6 11 34 503

Five panel YMCKOi (200 cards) Five panel YMCKOi (330 cards)

Intelligent TrueColours “Value Pack” Full Colour Ribbons (Inc. Cleaning Rollers)

6 11 34 511 Five panel YMCKOi - 5 rolls per pack (200 cards)

TrueColours Monochrome Ribbons

6 11 32 101 6 11 31 101 6 11 31 108 6 11 31 107 6 11 31 102 6 11 31 103 6 11 31 104 6 11 31 106 6 11 31 111 6 11 31 112

6 11 31 121

Black (1500 cards) Black (1000 cards) Black (Value pack 100 rolls) (1000 cards) Black for ABS cards (1000 cards) Red (PMS 1795C) (1000 cards) Green (PMS 348C) (1000 cards) Blue (PMS 287C) (1000 cards) White (1000 cards) Gold (1000 cards) Silver (1000 cards)

Scratch-off (880 cards)

IMPORTANT NOTICE:

Only TrueColoursTMcolour ribbons can be used in this printer

Note : Y = Yellow, M = Magenta, C = Cyan, B = Black , O = Overlay

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1APPENDIX D

CARDS

The following plain white plastic cards are available for use in the J320i printers:

Many other card types are also available; ask your dealer for more information.

Cards with no magnetic stripe

Cards with low coercivity magnetic stripe

Cards with high coercivity magnetic stripe

Self-adhesive cards to ﬁx onto proximity cards

Description

engenyus

Part Number

9 19 00 009

9 19 00 011

9 19 00 007

9 19 00 003

Varnish Overlay Ribbons

6 11 32 701 6 11 32 702

Clear (350 cards) Genuine Secure (350 cards)

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1APPENDIX D

ACCESSORIES

Accessories available for J320i printers are listed below:

Description

engenyus

Part Number

2 33 11 001

2 33 13 000

2 33 12 000

6 11 00 914

6 11 00 915

6 11 00 916

6 11 00 902

6 11 00 912

6 11 00 913

2 40 20 000

2 42 62 420

2 42 62 421

Mifare (contactless) encoding kit to be ﬁtted to a J320i or

J320iM printer. Includes integrated Mifare encoder, software

tools, RS232C interface and documentation

Smart Card (contact) encoding kit to be ﬁtted to a

J320i or J320iEM printer. Includes integrated smart card

coupler, software tools, RS232 interface and documentation

Combined Smart Card (contact) & Mifare (contactless) card

encoding kit to be ﬁtted to a J320iE or J320iEM printer.

Includes integrated smart card coupler, software tools,

RS232C interface and documentation

Cleaning kit: cleaning cards (50) and swabs (25)

Cleaning cards (100)

Swabs (25)

Replacement printhead kit

Cleaning roller kit (5)

Card cleaning cartridge

USB connector and cable

2.0m Centronics Cable

3.0m Centronics Cable

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

PRINTERS

All JAVELIN ™ printers are warranted against defects in material or workmanship ENGENYUS JAVELIN™ printers (excluding printhead) are warranted against defects in material or workmanship. Proof of purchase or shipment date is required to validate the warranty. The warranty becomes void if the equipment is modiﬁed, improperly installed or used, damaged by accident or neglect, or if any parts are improperly installed or replaced by the user.

PRINTHEADS

The original printhead is covered by an unlimited number of passes warranty. Warranty period begins on purchase date. To qualify for this warranty, the printhead must be returned to ENGENYUS or to an authorised dealer. Customers are not required to purchase ENGENYUS supplies (media and/or ribbons) for warranty qualiﬁcation. However, if it is determined that the use of other manufacturers' supplies has caused any defect in the printhead for which a warranty claim is made, the user is responsible for all charges required to repair the defect. The warranty becomes void if the printhead is physically worn or damaged; also if it is determined that failure to follow the preventive maintenance schedule listed in the User's Manual has caused defects in the thermal printhead for which a warranty claim is made.

SUPPLIES

These are warranted to be free from defect in material and workmanship provided the user has complied with storage guidelines, handling and usage of the supplies within ENGENYUS Javelin printers.

Appendix E

Warranty Information

APPENDIX E

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

SPARE PARTS

All parts, maintenance kits, options kits, and accessories are warranted to be free of defects in material and workmanship. This warranty becomes void if the item is modiﬁed, improperly installed or used, or damaged by accident or neglect.

Notes

Failure to exercise caution to protect the equipment from electrostatic discharge damage, adverse temperature and humidity conditions or physical abuse, including, but not limited to, improper packaging, shipping, service or repairs performed by personnel not authorised by ENGENYUS or an authorised dealer may void the warranty. ENGENYUS or its authorised dealer will, at its option, repair or replace the equipment or any parts which are determined to be defective within this warranty period, and which are returned to ENGENYUS or its authorised dealer. ENGENYUS speciﬁcally disclaims the implied warranties of merchantability and ﬁtness for a particular purpose. For full warranty terms, please contact the Javelin dealer from whom you purchased your printer.

APPENDIX E

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

Appendix F

Technical Support

If for any reason you require product technical support, please contact the distributor where you purchased your equipment. If they cannot help you, or at their direction, engenyus can be reached at :

ENGENYUS LIMITED

7 Byﬂeet Technical Centre

Canada Road West Byﬂeet

Surrey

United Kingdom KT14 7NB

Tel : +44 1932 351531

Fax : +44 1932 351382

Email : technical.support@engenyus.com

HOW TO RETURN YOUR PRINTER

If you have purchased your printer from an engenyus distributor, please ﬁrst contact them on their returns procedures. Alternatively, contact engenyus Technical Support (details above) for intructions before shipping your printer.

Only complete goods in their original packaging with a valid Returned Materials Advice (RMA) number clearly marked on the outside can be accepted for return to engenyus.

APPENDIX F

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

Appendix G

Declorations of Conformity

Model: J320i conforms to the following speciﬁcation: FCC Part 15, Subpart A, Section 15.107(a) and Section

15.109(a) Class A digital device

Supplemental Information:

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference , and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note:

This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

INDUSTRY CANADA NOTICE

This device complies with Industry Canada ICS-003 class A requirements.

European Council Directive

89/336/EEC

modiﬁed by

92/31/EEC and

93/63/EEC

EMC Directive EN 55022-B

RF Emissions

control

EMC Directive

EN 500082-1,

1992

Immunity to

Electromagnetic

Disturbances

Low voltage Directive EN 60950 Product Safety

73/23/EEC modiﬁed

by 93/68/EEC

Compliance to Standards

APPENDIX G

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Rev. 1.1

TRADEMARKS

JAVELIN and ENGENYUS are trademarks of engenyus limited. Windows and MS-DOS are registered trademarks of Microsoft Corp. All other marks are trademarks or registered trademarks of their respective holders.

This document contains information proprietary to engenyus. This document and the information contained within is copyrighted by engenyus and may not be duplicated in full or in part by any person without written approval from engenyus. While every effort has been made to keep the information contained within current and accurate as of the date of publication, no guarantee is given or implied that the document is error-free or that it is accurate with regard to any speciﬁcation. engenyus reserves the right to make changes, for the purpose of product improvement, at any time.

APPENDIX G

Quick Start

Getting

Started

Operation

Starting to

Print Cards

Cleaning

Trouble

Shooting

Technical

Speciﬁcations

General

Information

Javelin J320i User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
