Jaton V.92-LX User Manual
WinCOMM V.92_LX
Internal 56Kbps Fax Data modem with Caller ID
Quick Start Guide
Version 1.0
FEATURES/SPECIFICATIONS
• V.90, V.92, ITU-T, V.34, V.32 bis, V.32, V.22 bis V.22 and Bell
212A, ITU-T, V.23, V.21 a nd Bell 103
• Transmission speed – receiving rate up to 56Kbps (downstream), and
transmit rate up to 33.6 Kbps.
• Data Compression – ITU - T V.44, V.42 bis and MNP5
• Fax specs – ITU-T V.17, V.29, V.27 ter, V.21 channel 2
EIA/TIA 578 FAX Class 1, or T. 31 Fax Class 1.0 commands
• PCI 2.2-compliant
• Full Duplex
• Tone and Pulse dialing
• Auto detect Voice/Data/Fax modes
SYSTEM REQUIREMENTS:
• x86 compatible PC with a PCI bus expansion slot
• CD-ROM drive, Quad speed or faster
• Hard Drive with at least 100MB free space
• Microsoft Windows® XP, Windows® Vista
• Sound card required for Voice and Answer ing functions
CHECK LIST:
• Internal PCI Modem
• RJ11 Phone Cord
• Software & Document CD-ROM
• Quick Start Guide (Printed)
2
Hardware Installation:
1. Make sure the power to your PC is turned OFF.
2. Remove the computer ’ s cover.
3. Select a PCI bus expansion slot for the new adapter. Remove the slot
cover
4. Insert the modem into place carefully. Secure the adapter and
retaining bracket.
5. Replace the computer’s cover.
HARDWARE DESCRIPTION:
3
Software Installation:
This guide is intended to help you get started quickly with driver
installation in Microsoft Windows.
Important Notice: Add second modem or change the modem to an
existing PC system, you may proceed a few steps before install the new
hardware and software (modem’s driver). The followings are some of the
considers:
1. To c hang e a new modem, p lease remov e the exist ing mo dem dr iver,
or disable it from Windows® system before you remove the existing
hardware.
2. To added second modem, make sure the mainboard that has available
IRQ for new devices, and there is no conflict between the others.
3. The driver installation for upgrade system as same as below, if error
occur when you proceed step 1, or 2, please consult with your system
dealer or the existing hardware manufacturer support.
á Windows
Windows® XP is the latest version out from Microsoft and that has built-in
PnP function to detects any new hardware (included this modem) on the
system but make sure your motherboard utility driver is installed correctly.
®
XP/ Vista Installation
4
After your XP’s desktop loads-up completely, the new hardware wizard
will be prompt for your modem. If your windows system has trouble to
detect it, or your desktop problem to starts-up after modem added
physically, please re-start your windows system again, and make sure the
motherboard utility has been setup properly.
Insert the manufacturer’s software CD into your CD-ROM and follow the
steps to install the modem driver.
1. For WinXP, once you have completed the hardware installation,
power on your computer. The Found New Hardware Wizard will
show a prompt to search for driver for new hardware found. Click
Cancel.
2. After inserting the CD, click on Modem Driver.
3. Select your system Operating System.
4. For Vista system, need to click Allow.
5. Click OK to continue with driver installation
FaxTalk Communication SE
Note: FaxTalk may detect that your modem as supporting
speakerphone, and display spe akerphone options within the
program. The modem chipset in the Modem may support
