Jasco RM24950 User Manual

24950

Universal Remote Instruction Manual

INPUT

ON-OFF

SETUP

VOLVOL

123

456

879

ENTER

INFO GUIDE

TV/VCR

PREV. CHSLEEP

MENU EXIT

PIP SWAP MOVE

IntroductionTable of Contents

Introduction ...................................................... 3

Button Functions ............................................... 4

Setup ............................................................... 6

Battery Installation ....................................... 6

Battery Saver ............................................... 7

Code Saver ................................................. 7

Power-On default ........................................ 7

Code Setup ................................................. 7

Code Entry ....................................................... 8

Direct Code Entry ........................................ 8

Code Search ............................................... 8

Code Identification Feature ............................... 9

Programming Combo Device Codes ............... 10

Controlling Combo Devices ............................ 10

Controlling Devices with Power On and Off .... 10

VCR/DVD/DVR Punch-Through Feature ....... 11

Volume/Mute Control Feature ......................... 11

Setting Volume/Mute Control, Punch-Through . 12 Setting any Mode to use its own Volume/Mute 12

Sleep Timer .................................................... 13

Code Learning ................................................ 14

Tips on Learning ........................................ 14

IR Transmitter Finder feature ...................... 16

Learning Commands .......................................16

Clearing Commands ....................................... 18

Clearing Learned commands for a mode ..... 18

Master Clear ............................................. 18

Troubleshooting .............................................. 19

Congratulations on your purchase of this 24950 Universal Remote Control. It is one of the most unique looking, and easy to use remote controls available today. With the 24950 juggling multiple remote controls is a thing of the past! Your 24950 Universal Remote controls up to 5 devices, including the most popular brands of TV, VCR, DVD, SAT, CBL, and audio equipment.

Note: Some functions from your original remote may not be controlled by the 24950 remote. Use the original remote, if available, to control such functions. Sometimes buttons other than described in these instructions may actually perform the function. For example, the CHAN and VOL buttons might be used to navigate through menu choices. We recommend you experiment with the remote to identify if such situations pertain to your equipment.

The 24950 Universal Remote is easy to use, easy to program, and it gives you total control—at the touch of your fingertips!

Button Functions

Button Functions, cont.

INFO GUIDE

10.

11.

12.

Note: The Record button must be pressed TWICE to record from your VCR. For some brands of VCRs, you might need to press the Record button once, then press it again for three seconds. Some buttons on the remote might have functions that are referred to by different names on the device you are controlling. E.G. PREV.CH may be called RECALL, or ENTER may be called DISPLAY. These differences depend on the brand and model of your product. Also, this remote can only operate features that exist on your product. E.G., your product must have PREV.CH ability for the PREV.CH button to operate this feature.

24.

23.

22.

21.

20.

19.

18.

17.

16.

15.

14.

13.

1. ON-OFF: Turns device On or Off.

2. TV, VCR, DVD, SAT/CBL, AUDIO/AUX: Selects

product to be operated.

3. CHANNEL UP/DOWN: Changes the channels. Also controls DVD/CD CHAPTER +/- track selection i.e. DVD/CD Track Skip Up/Down. Note the VCR buttons also control DVD when in DVD Mode

4. VOLUME UP/DOWN: Changes the volume level of the product, normally the TV.

5. INPUT Selects the video inputs of your TV if equipped with that feature.

6. NUMBERS: Enter numbers for direct channel selection. Some products require Enter to be pressed after channel selection.

7. ENTER: Used after direct channel number entry to immediately change to the selected channel.

8. INFO: Displays on-screen channel information, etc.

9. OK: Selects menu items for the device you are

controlling.

10. MENU: brings up the DVD disc Menu screen. Use with the UP, DOWN, LEFT & RIGHT navigation buttons.

11. LEARN: Used to setup learning functions.

12. PIP: TV Picture-in-Picture control.

13. SWAP: Swaps TV PIP screens.

14. MOVE: Moves the position of the PIP screen.

15. EXIT: Exits On-Screen Menus and/or Returns to

previous On-Screen selection.

16. UP, DOWN, LEFT & RIGHT: Navigation buttons.

17. RECORD, PLAY, STOP, REW, FF, PAUSE: VCR

control buttons operate your VCR even when the remote is set to operate the TV. Also operates DVD Scan -/+.

18. GUIDE: Displays satellite or cable on-screen program guide.

19. TV/VCR: Operates the same as the TV/VCR or antenna keys on your original remotes.

20. PREV CH: Returns to the previously selected channel, or DVD repeat toggle.

21. SLEEP: Turns off the TV after a period of 1 to 99 minutes.

22. MUTE: Turns off the TV sound while the picture remains.

23. Red Indicator: Lights when any button is pressed.

24. SETUP: Used for setting up your remote.

Setup

Setup, cont.

Battery Installation

1. On the back of the remote, push down on the tab and lift the cover off.

2. Match the batteries to the + and - marks inside the battery case, then insert 2 AAA alkaline batteries.

3. Press the battery cover back into place.

Battery Saver

Your remote automatically turns off if the buttons are depressed more than 30 seconds. This will save your batteries should your remote get stuck in a place where the buttons remain depressed (e.g., between the sofa cushions).

Code Saver

Codes are stored in permanent memory while you are changing batteries so you will not lose any codes stored in the remote while you are changing batteries.

Power-On Default

The remote powers on in TV mode.

Code Setup

The SETUP button is used to setup the remote. You can either setup the remote using the code for your brand of product, from the code tables (on separate sheet), or you can search through the library of codes until you find a code that works for your product.

Please refer to “Programming with Code Search” on page 8 for more information on using the code search feature to learn how to search through the library of codes for your products.

NOTE: You can store any kind of code under any mode (except TV). I.E. you can store a VCR code under the CBL button, or a DVD code under the VCR button, etc. However, you can only store TV codes under the TV button.
