Jasco RM24930 User Manual

RM24930

Universal Remote
Instruction Manual

Table of Contents

Setup

Introduction ........................................................... 3

Setup .................................................................... 3

Battery Installation ........................................... 3

Battery Saver ................................................... 3

Code Saver ...................................................... 3

Code Setup ...................................................... 3

Button Functions ............................................. 4

Menu Operation ............................................... 6

Direct Code Entry ............................................ 7

Code Search .................................................... 8

Using Your Remote ............................................... 9

Code Identification ........................................... 9

Sleep Function............................................... 10

Controlling Devices with Power On and Off ..... 11

Controlling Combo Devices ............................. 11

VCR/DVD/DVR Punch-Through ...................... 11

Volume/Mute Control and Punch-Through ...... 12

All Volume/Mute Control to any one Mode ..... 12

Setting any Mode for its own Volume/Mute .... 13

Troubleshooting .................................................. 14

Congratulations on your purchase of the RM24930
Universal Remote Control. The RM24930 is one of
the most easy to use remote controls available
today. With the RM24930, juggling multiple remote
controls is a thing of the past! Your RM24930
controls up to four devices, including the most
popular brands of TV, VCR, DVD, CBL, and SAT.
The RM24930 is easy to use, easy to program, and
it gives you total control—at the touch of your
fingertips!

Note: Some functions from your original remote may
not be controlled by this remote. Use the original
remote, if available, to control such functions.
Sometimes buttons other than described in these
instructions may actually perform the function. For
example, the CHAN and VOL buttons might be
used to navigate through menu choices. We
recommend you experiment with the remote to
identify if such situations pertain to your equipment.

Battery Installation

1. On the back of the remote, push down on the
tab and lift the cover off.

2. Match the batteries to the + and - marks inside
the battery case, then insert 2 AAA Alkaline
batteries.

3. Press the battery cover back into place.

Battery Saver

Your remote automatically turns off if the buttons
are depressed more than 30 seconds. This will save
your batteries should your remote get stuck in a
place where the buttons remain depressed (e.g.,
between the sofa cushions).

Code Saver

You will have up to 10 minutes to change the
batteries in your remote without losing codes you
have programmed. However, do not press any
buttons until batteries are installed in the remote. If
buttons are pressed without batteries in the remote,
all codes will be lost.

Code Setup

The SETUP button is used to setup the remote. You
can either setup the remote using the code tables
(on separate sheet), or you can search through the
library of codes until you find a code that works for
your product. Please refer to “ Code Search” on
page 8 for more information on using the code
search feature to learn how to search through the
library of codes for your products.
NOTE: You can store any kind of code under any
mode (except TV). I.E. you can store a VCR code
under the CBL/SAT button, or a Cable code under
the DVD/AUX button, etc. However, you can only
store TV codes under the TV button.

32

Button Functions

Button Functions, cont.

Some buttons on the remote might have functions that
are referred to by different names on the device you are
controlling. E.G. PREV.CH may be called RECALL, or
ENTER may be called DISPLAY. These differences
depend on the brand and model of your product. Also,
this remote can only operate features that exist on your
product. E.G., your product must have PREV.CH ability
for the PREV.CH button to operate this feature.

TV, CBL/SAT, VCR, DVD/
AUX Selects product to

be operated.

PREV.CH Returns to
the previously selected
channel.

INFO Shows the date
and time if your TV or
VCR has that feature.
Works the same way as
a Display button.

MENU Brings up device
Main Menu. Use Chan
and Vol buttons as cursor
buttons and Mute as Okay.
Press TV to Exit.

ENTER

Used to complete
channels selection for
some brands of TV. Also
used to complete the
code entry process.

Red Indicator
Lights when any
button is pressed.

SETUP Used to setup
the remote, and for
code search function.

ON-OFF Turns
product On or Off.

SLEEP enables the remote

to turn off your TV after a

period of 1 to 99 minutes.

MUTE Turns off the

TV sound while the

picture remains.

VOLUME UP/DOWN

Changes the volume

level of the product,

normally the TV.

CHANNEL Up/Down

Changes the channels.

The Channel buttons

also control DVD SKIP

functions.

INPUT Selects the

video inputs of your

TV if equipped with

that feature.

0-9

Enter numbers for direct

channel selection. Some

products require ENTER

to be pressed after

channel selection.

TV/VCR Operates the TV/

VCR function of your VCR.

RECORD, PLAY, STOP,
REW, FF, PAUSE VCR

control buttons operate
your VCR even when the
remote is set to operate
the TV. Also operates DVD
Scan -/+. Note the VCR
buttons also control DVD
when in DVD Mode.

Note: The REC button must be pressed TWICE to
record from your VCR. For some brands of VCRs, you
might need to press the REC button once, then press it
again for three seconds.
