Jasco 45233 User Manual

Home Monitoring

Wireless Color
Camera

User Manual

45233

For indoor/outdoor use. Do not use in wet locations.

www.jascoproducts.com

1-800-654-8483

2

Thank you for purchasing the GE 45233 Wireless
Color Camera. This product is intended for use as
an add-on camera for GE Color or B/W wireless
systems (45234, 45235, 45236.) Please review these
instructions carefully before attempting to operate
the camera.

PRODUCT FEATURES

“WiFi” friendly—won’t interfere with home

•
wireless networks.

Night Vision feature—View objects in low or no

•
light up to 10 ft.

Small, unique design is simple to set up and

•
easy to use.

Unique “axis-swivel” camera mount allows for

•
desktop or wall mount installation.

Adjustable antenna.

•

Wirelessly transmits audio and video up to

•
200 ft. (unobstructed line of sight.)

For Indoor/Outdoor use.

•

PACKAGE CONTENTS

Please check and identify all the parts before
proceeding with the installation.

1. 45233 Wireless Color Camera

2. Wall mounting hardware

3. AC adapter

CHOOSING A CAMERA MOUNTING LOCATION

The 45233 Wireless Color Camera can be positioned
on a desktop, or mounted to a wall. It is suitable for
indoor or outdoor use. When choosing a mounting
location, please be advised:

Do not use in wet locations. If using outside,

•
position camera in a sheltered location.

DO NOT position the camera so that it points

•
directly into the sun or any bright light, as this
may cause damage to the camera.

Avoid viewing areas where half the area is in

•
bright sunlight and the other half is dark, such
as in the shadow of a building. All types of
cameras have diffi culty “seeing” into areas of
such divergent light levels.

In low light conditions, the camera will

•
automatically activate the Infrared (IR) LED’s and
switch the camera to Night Vision mode. Night
Vision viewing distance is up to 10 feet.

If using the included AC adapter to power the

•
camera, it must be positioned no farther than
8’ from an AC outlet. Do not use the supplied

3

4

adapter outside or run the cord through walls.
If you need to extend the AC adapter cable,
15 ft. extensions are available by contacting
Customer Service at 800-654-8483. If using
the optional rechargeable NiMH battery (sold
separately), the operational time is up to 5
hours, depending on usage.

The Camera has an unobstructed wireless

•
transmission range up to 200 ft. from the
receiver. Transmission distance indoors is
reduced due to interior walls, wiring, household
fi xtures and metal plumbing.

NIGHT VISION

The 45233 Wireless Color

Infra-Red
(IR) LEDs

Camera features Night
Vision technology. Objects
and images can be seen in
little or no light up to 10 ft.
The camera uses a special

Sensor

image sensor that
automatically detects
available light levels.
It turns on/off the Infra-Red (IR)
LEDs on the front of the camera. These LEDs provide
artifi cial light that allows the camera to ‘see’ in the
dark. Night Vision will appear as a Black and White
image. When the image sensor detects enough
