USER MANUAL
BTS300S-BLK
Bluetooth Speaker
DuraVibePro
2
Thank you for choosing the Jarv DuraVibe Pro Bluetooth
Speaker!
Please take the time to read this manual carefully, even if
you are already familiar with a similar product.
The Jarv DuraVibe Pro Bluetooth Speaker oers a unique
blend of power, convenience and features.
PACKAGE CONTENTS
1x Jarv DuraVibe Pro Bluetooth Speaker
1x Micro USB Cable
1x 3.5mm Audio Cable
1x Carry strap
1x User Manual
3
SPEAKER CONTROLS AND INDICATOR
Volume - / Previous track
Volume + / Next track
Power Button
Multi-Function Button
Play/Pause/Answer Call
Front Left
Top
DC IN 5
.0V
AU
X
Bottom
• Micro USB
Charging port
•AUX Port
LED Light
Handlebar mounting option¼ inch 20 mounting pattern
(Handlebar mount not
included)
4
GETTING STARTED
To use your Jarv DuraVibe Pro Bluetooth Speaker, please follow
these steps:
1. Charge your Bluetooth speaker fully
2. Pair your Bluetooth Speaker to a Bluetooth-enabled device prior
to use.
CHARGING YOUR BLUETOOTH SPEAKER
Your Jarv DuraVibe Pro Bluetooth Speaker come with a built-in
rechargeable battery and a Micro USB charging cable. Charge
fully before use. The battery indicator will turn red when
charging and turn green once charging is complete. Initial
charging time is approximately 3-4 hours.
PAIRING YOUR BLUETOOTH SPEAKER
In order to use your Jarv DuraVibe Pro Bluetooth Speaker with a
Bluetooth-enabled device, you will rst need to pair the two.
1. Place the Bluetooth Speaker and the Bluetooth enabled device
where they are easily viewable and no more than 3ft. apart.
2. Turn ON your Bluetooth pairing function on your device
3. Turn the speaker on by pressing down the Power button for
about 7 seconds. A Blue LED light will start ashing quickly
indicating that the speaker is now in Pairing Mode.
4. The speaker will appear as “DuraVibe Pro” when scanning for
available Bluetooth devices within range.
5-Once Pairing is successful a chime will be heard through the
speaker
5
RANGE
Be sure to keep the speaker within 30 feet (10 meters) of the
connected media device at all times for optimal performance.
AUX CONNECTOR
The speaker also features an AUX audio in port, simply connect
the speaker with your non-Bluetooth mobile phone/MP3
player/PC/laptop with the 3.5mm jack audio cable. The green
indicator light will be on, then you can play music via wired
connection.
LOW POWER INDICATION
The speaker will have voice prompt to remind you to recharge
your speaker if your battery capacity is low (at about 10%).
BICYCLE MOUNT OPTION
Camera / Speaker / Handlebar mount option - ¼ inch 20
mounting pattern
1- Attach mount (not included) to handlebar with Philips
screwdriver
2- Attach the speaker to the mounting screw on the mount by
turning it clockwise until secure
3- Adjust position of speaker and tighten the adjustment ring
(Optional handlebar mount to
be used with speaker)
6
Press and hold the button for 2
seconds to reject the incoming call.
Short Press the button once to
accept the call, or answer the call
normally via your mobile phone. Short
Press again to end the call and
resume music
CALL MODE
MUSIC MODE
Long press to power on / o. Powering ON/ OFF
Answering a call
Rejecting a call
Redialing a call
Adjusting the
Volume
Play/Pause Music
Ending a call Short Press the button to end the
call or end the call directly from your
mobile phone.
Press and hold the button to
redial the last dialed phone number
on your mobile phone.
Short Press the Volume + to increase
volume or Volume – to decrease volume.
You can also adjust the volume on your
handset or device
Once connected, Press the button
once to play music. Short Press the
button to pause music.
Previous Track
Press and hold the " -" key to select the
next track.
Next Track
Press and hold the "+" key to select the
previous track.
Disconnect Bluetooth
Connection
Press and hold the " -” and “ +” button to
disconnect current Bluetooth connection
LED INDICATOR GUIDE
STATUS
Power On
Charging
Charging complete
Pairing Mode
Aux Mode
INDICATOR
Blue Light
Red Light
Green Light
Blue Light ashes for Pairing
Green light
8
SPECIFICATIONS
Speaker Interfaces
• Audio input connector: 3.5mm
• AUX cable: support aux external audio input
• Charging interface: Micro USB; Input 5V
Electrical Specications
• Bluetooth 4.1
• Bluetooth Range: 33ft.
• Power: 5W*1
• Frequency Range: 160Hz ~ 20Khz
• Dimensions: 3.75X 3.50 X 1.96 inches
• Weight: 10.1 oz.
Parameters of power
• Rated voltage: 3.7V DC
• Battery: Built-in lithium battery, 3.7V/1500mAh
• Charging Voltage/Current: 5V ± 0.25V / 0.5A
• Charging time: Up to 4 hours
• Playing time: Up to 8 hours
9
CARE AND MAINTENANCE
1. Please charge your new speaker for at least 3 hours before
rst use.
2. To prevent damage and risk of electrical shock, do not expose
this device to dust, vibration, rain, water or liquids of any kind.
3. Do not place device in close proximity to open ames or
extreme heat sources.
Always place your device on level, at and stable surfaces.
4. Avoid placing items on top of the speaker.
5. Do not use excessive force when pressing buttons or
handling your speaker.
6. To clean your speaker, use only a dry, soft cloth or minimally
damp cloth without any corrosive solvent or cleaning agent
SAFETY
To prevent res, shock or injury, please do not disassemble or
replace any parts of this device. In the event that your device
may be damaged or in need of repair, please contact a
professional maintenance or qualied service center for
assistance. We are not responsible for any personal injury or
property damage caused by improper use of this product.
Please do not allow the use of this device by small children
without proper adult supervision.
FCC COMPLIANT
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2)
This device must accept any interference received, including
interference that may cause undesired operation.
10
WARRANTY
At Jarv, we are dedicated to making the best quality product. To
back this up, your Jarv DuraVibe Pro Speaker is covered by a
One (1) Year Limited Manufacturer’s Warranty.
Details of the warranty are as follows: for a period of one (1) year
from the date of retail purchase, Jarv warrants that this product
is free of any defects in manufacturing, materials and
workmanship. During the warranty period, we shall, at our sole
discretion, repair or replace any defective parts within a
reasonable period of time and free of charge.
Please visit our website
www.jarvmobile.com
for more
details
Or Email us at:
customerservice@jarvmobile.com
for
any questions or concerns about your product.
