CM/CB-140 MCL
CM/CB-140 PMCL
CM-140MCL-UV
CM-140PMCL-UV
Digital Monochrome / Color
Compact Mini-CL Camera
Document Version: 3.3
CMB-140MCL/PMCL/UV_Ver.3.3_May2011
User's Manual
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
1
Notice
The material contained in this manual consists of information that is proprietary to JAI Ltd.,
Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty
for the use of its product and assumes no responsibility for any errors which may appear or for
damages resulting from the use of the information contained herein. JAI Ltd., Japan reserves the
right to make changes without notice.
Company and product names mentioned in this manual are trademarks or registered trademarks of
their respective owners.
Warranty
For information about the warranty, please contact your factory representative.
Certifications
CE compliance
As defined by the Directive 2004/108/EC of the European Parliament and of the Council, EMC
(Electromagnetic compatibility), JAI Ltd., Japan declares that CM-140MCL,CM-140PMCL,CM140MCL-UV,CM-140PMCL-UV,CB-140MCL,and CB-140PMCL comply with the following provisions
applying to its standards.
EN 61000-6-3 (Generic emission standard part 1)
EN 61000-6-2 (Generic immunity standard part 1)
FCC
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Warning
Changes or modifications to this unit not expressly approved by the party
responsible for FCC compliance could void the user’s authority to operate the
equipment.
CM-140MCL / CM-140PMCL
Supplement
The following statement is related to the regulation on “ Measures for the Administration
of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “.
The table shows contained Hazardous Substances in this camera.
mark shows that the environment-friendly use period of contained Hazardous
Substances is 15 years.
嶷勣廣吭並㍻
嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕
功象嶄鯖繁酎慌才忽佚連恢匍何〆窮徨佚連恢瞳麟半陣崙砿尖一隈〇云恢瞳ゞ 嗤蕎嗤
墾麗嵎賜圷殆兆各式根楚燕 〃泌和
桟隠聞喘豚㍉
窮徨佚連恢瞳嶄根嗤議嗤蕎嗤墾麗嵎賜圷殆壓屎械聞喘議訳周和音氏窟伏翌
亶賜融延、窮徨佚連恢瞳喘薩聞喘乎窮徨佚連恢瞳音氏斤桟廠夛撹冢嶷麟半
賜斤児繁附、夏恢夛撹冢嶷鱒墾議豚㍉。
方忖仝15々葎豚㍉15定。
CB-140MCL / CB-140PMCL
Supplement
The following statement is related to the regulation on “ Measures for the Administration
of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “.
The table shows contained Hazardous Substances in this camera.
mark shows that the environment-friendly use period of contained Hazardous
Substances is 15 years.
嶷勣廣吭並㍻
嗤蕎嗤墾麗嵎賜圷殆兆各式根楚燕
功象嶄鯖繁酎慌才忽佚連恢匍何〆窮徨佚連恢瞳麟半陣崙砿尖一隈〇云恢瞳ゞ 嗤蕎嗤
墾麗嵎賜圷殆兆各式根楚燕 〃泌和
桟隠聞喘豚㍉
窮徨佚連恢瞳嶄根嗤議嗤蕎嗤墾麗嵎賜圷殆壓屎械聞喘議訳周和音氏窟伏翌
亶賜融延、窮徨佚連恢瞳喘薩聞喘乎窮徨佚連恢瞳音氏斤桟廠夛撹冢嶷麟半
賜斤児繁附、夏恢夛撹冢嶷鱒墾議豚㍉。
方忖仝15々葎豚㍉15定。
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
2
- Contents -
1. General ..................................................................................................... 4
2. Camera nomenclature ................................................................................... 4
3. Main Features ............................................................................................. 4
4. Locations and Functions ................................................................................. 5
4.1. CM-140 MCL / CB-140 MCL ......................................................................... 5
4.2. CM-140 PMCL / CB-140 PMCL ...................................................................... 6
5. Pin Assignment ............................................................................................ 7
5.1. 12-pin Multi-connector (DC-IN/Trigger) – MCL-version only .................................. 7
5.2. Digital Output Connector for Mini-CL (Camera Link) .......................................... 8
5.2.1. CM-140 MCL / CB-140 MCL ................................................................. 8
5.2.2. CM-140 PMCL / CB-140 PMCL .............................................................. 8
5.3. Input and output circuits .......................................................................... 9
5.3.1. Iris video output ............................................................................. 9
5.3.2. Trigger input ................................................................................. 9
5.3.3. XEEN output .................................................................................. 9
5.3.4. Camera Link interface ...................................................................... 9
6. Functions and Operations .............................................................................. 10
6.1. Basic functions ..................................................................................... 10
6.1.1. Digital Video Output (Bit Allocation) .................................................... 10
6.1.2. Electronic Shutter .......................................................................... 11
6.1.3. Continuous operation or triggered operation .......................................... 11
6.1.4. Iris video output. ........................................................................... 11
6.1.5. Rear panel indicator. ...................................................................... 11
6.1.6. Auto-detect LVAL-sync / async. accumulation ........................................ 12
6.1.7. Starting pixel - Bayer color mosaic ...................................................... 12
6.1.8. Vertical Binning ............................................................................. 13
6.2. Sensor Layout and timing ......................................................................... 14
6.2.1. CCD Sensor Layout ......................................................................... 14
6.2.2. Horizontal timing ........................................................................... 15
6.2.3. Vertical timing .............................................................................. 15
6.2.4. Partial Scan .................................................................................. 16
6.2.5. Vertical Binning ............................................................................. 17
6.3. Operation Modes ................................................................................... 18
6.3.1. Continuous operation ...................................................................... 18
6.3.2. Pre-select Trigger Mode ................................................................... 19
6.3.3. Pulse Width Trigger Mode ................................................................ 21
6.3.4 Reset Continuous (RCT) trigger mode ....................................................... 23
6.4. Mode and function matrix. ....................................................................... 24
7. Configuring the Camera ................................................................................ 25
7.1. RS-232C control .................................................................................... 25
7.2. Setting functions ................................................................................... 26
7.2.1. Bit allocation. BA=0, BA=1 ............................................................... 26
7.2.2. Partial scan. SC=0 through 4. ............................................................. 26
7.2.3. Vertical binning. VB=0, VB=1 ............................................................ 26
7.2.4. Shutter mode. SM=0 and SM=1 ........................................................... 26
7.2.5. Trigger input select. TI=0, TI=1. ......................................................... 26
7.2.6. Trigger polarity. TP=0, TP=1. ............................................................ 26
7.2.7. Gain level. GA=-84 through +336. ....................................................... 26
7.2.8. Black level. BL=0 through BL=1023. ..................................................... 26
7.3. Save and Load Functions. ......................................................................... 26
7.4. CM/CB-140MCL / CM/CB-140PMCL command list ............................................. 27
8. Camera Control Tool for CM/CB-140 MCL / CM/CB-140 PMCL ................................... 29
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
3
8.1. Camera Control Tool Interface .................................................................. 29
8.1.1. Camera Control Tool Bar .................................................................. 29
8.2. The About Window ................................................................................. 29
8.3. Communication Window .......................................................................... 30
8.4. Camera Control Window .......................................................................... 31
8.5. Using the Camera Control Tool .................................................................. 31
9. External Appearance and Dimensions ................................................................ 33
10. Specifications ............................................................................................ 34
10.1. Spectral response .................................................................................. 34
10.2. Specification table(CMB-140MCL/CMB-140PMCL) ............................................. 36
10.3. Specification table(CM-140MCL-UV/CM-140PMCL-UV) ....................................... 37
11. Appendix ...................................................................................................... 38
11.1. Precautions ........................................................................................... 38
11.2. Typical Sensor Characteristics ..................................................................... 38
11.3. Caution when mounting a lens on the camera ................................................. 38
11.4. Caution when mounting the camera .............................................................. 39
11.5. Exportation ........................................................................................... 39
11.6. References ............................................................................................ 39
Change History .................................................................................................... 41
User's Record ...................................................................................................... 42
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
4
1. General
CM-140 MCL/CM-140 PMCL is a monochrome progressive scan CCD camera and the CB-140 MCL/CB140 PMCL is the equivalent Bayer mosaic progressive scan CCD camera. Both have 1.45 M pixels
resolutions.
While the MCL version is powered by an external 12-volt supply, the PMCL (Power over Mini-CL)
version is powered by a compatible frame grabber.
These cameras are suitable for a wide range of applications within factory automation, an also for
applications outside the factory floor, such as ITS (Intelligent Traffic Solutions), high-end
surveillance and medical.
The CM-140MCL-UV and CM-140PMCL-UV uses the same 1.45 M pixels CCD but having the
sensitivity in UV area.
The latest version of this manual can be downloaded from: www.jai.com
The latest version of Camera Control Tool for CM/CB-140MCL ,CM/CB-140PMCL and UV versions
can be downloaded from: www.jai.com
For camera revision history, please contact your local JAI distributor.
2. Camera nomenclature
The standard camera composition consists of the camera main body and C-mount protection cap.
The camera is available in the following versions:
CM-140 MCL/MCL-UV/PMCL/PMCL-UV
Where C stands for "Compact" family, M stands for "Monochrome", 140 represents the resolution
"1.4 million pixel" , MCL stands for “ Mini-CL” interface , PMCL for “ Power over Mini-CL” and UV
for specific feature, UV sensitive
CB-140 MCL/PMCL
Where C stands for "Compact" family, B stands for "Bayer mosaic color", 140 represents the
resolution "1.4 million pixel" , MCL stands for "Mini-CL" interface and PMCL for “ Power over Mini-
CL”
3. Main Features
Compact series 1/2” progressive scan camera
Monochrome and Bayer mosaic color versions
UV sensitive versions, CM-140MCL-UV and CM-140PMCL-UV
1380 (h) x 1040 (v) active pixels
4.65 μm square pixels
31 frames/second with full resolution in continuous operation
30 frames/second with external trigger and full resolution
Up to 74 frames/second with partial scan
48 frames/second with vertical binning (CM-140 MCL only)
Shutter speed from 32μs to 2 sec. using Pulse Width Control
Programmable exposure from 64μs to 40 ms
Pre-select and Pulse width trigger modes
LVAL-synchronous/-asynchronous operation (auto-detect)
CM-140PMCL and CB-140PMCL comply with PoCL (Power over CL) standard
Auto iris lens video output allows a wider range of light
10 or 8-bit output
Setup by Windows NT/2000/XP via serial communication
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
5
4. Locations and Functions
4.1. CM-140 MCL / CB-140 MCL
Lens mount C-mount (Note *1)
CCD sensor 1/2 inch CCD sensor
26-pin connector Camera Link Interface (Mini-CL) (Note 2)
12-pin connector DC+12V and trigger input
LED Indication for power and trigger input
Mounting holes M3 depth 3.5mm for tripod mount plate
*1) Note: Rear protrusion on C-mount lens must be less than 10.0mm.
*2) Note: When a Camera Link cable is connected to the camera, please do not excessively
tighten screws by using a screw driver. The Camera Link receptacle on the camera
might be damaged.
For security, the strength to tighten screws is less than 0.291 Newton meter (Nm).
Tightening by hand is sufficient in order to achieve this.
Fig. 1. Locations
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
6
4.2. CM-140 PMCL / CB-140 PMCL
Lens mount C-mount (Note *1)
CCD sensor 1/2 inch CCD sensor
26-pin connector Camera Link Interface (Mini-CL) ( Note “2)
12-pin connector DC+12V and trigger input
LED Indication for power and trigger input
Mounting holes M3 depth 3.5mm for tripod mount plate
*1) Note: Rear protrusion on C-mount lens must be less than 10.0mm.
*2) Note: When a Camera Link cable is connected to the camera, please do not excessively
tighten screws by using a screw driver. The Camera Link receptacle on the camera
might be damaged. For security, the strength to tighten screws is less than 0.291
Newton meter (Nm). Tightening by hand is sufficient in order to achieve this.
Fig. 2. Locations (PoCL version)
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
7
5. Pin Assignment
5.1. 12-pin Multi-connector (DC-IN/Trigger) – MCL-version only
Type: HR10A-10R-12PB-01 (Hirose) male.
Use the part number HR10A-10P-12S for the cable side
*1) Factory default is through CameraLink (TI=0).
*2) To change DIP switch SW600 settings remove the top cover. To select 75 ohm termination
both positions are set to ON position. The factory default OFF the position.
Note: 12-pin connector is only present on CM-140MCL and CB-140MCL.
Pin no.
Signal
Remarks 1 GND
2
+12 V DC input
3
GND
4
Iris video
Only for Continuous mode. TR=0
5
GND
6
NC
7
NC
8
GND
9
XEEN out
10
Trigger in
TI=1 (or Camera Link TI=0). *1)
SW600 selects TTL or 75 ohm *2)
11
DC+12V
12
GND
Fig. 3. Hirose 12-pin connector
SW600
1
2
O
N
TTL 75 Ω
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
8
5.2. Digital Output Connector for Mini-CL (Camera Link)
Type: 26-pin SDR connector (3M or Honda type) Mini-CL connector
5.2.1. CM-140 MCL / CB-140 MCL
5.2.2. CM-140 PMCL / CB-140 PMCL
Important Note for PMCL version
CM-140 PMCL and CB-140 PMCL cameras feature “Safe Power” circuit which is stipulated by the
PoCL standard. This circuit is used to verify the presence of camera and PoCL cable before the
frame grabber provides power.
Pin No
I/O
Name
Note
1,13,14,26
GND
DC GND
7(+),20(-)
I/O
RXD
Serial Com.
8(-),21(+)
O
TXD
10(+),23(-)
I
Reserve
9(-),22(+)
I
Trigger
CC1 Ext. Trigger in
6(-),19(+)
O
TxOUT3
Camera Link out
4(-),17(+)
O
TxOUT2
3(-),16(+)
O
TxOUT1
2(-),15(+)
O
TxOUT0
5(-),18(+)
O
TxClk
Clock for CL
Pin No
I/O
Name
Note
1
I
DC +12V
13 I GND
For # 26 pin
14 I GND
For # 1 pin
26
I
DC +12V
7(+),20(-)
I/O
RXD
Serial Com.
8(-),21(+)
O
TXD
10(+),23(-)
I
Reserve
9(-),22(+)
I
Trigger
CC1 Ext. Trigger in
6(-),19(+)
O
TxOUT3
Camera Link out
4(-),17(+)
O
TxOUT2
3(-),16(+)
O
TxOUT1
2(-),15(+)
O
TxOUT0
5(-),18(+)
O
TxClk
Clock for CL
Fig.5. Mini-CL
Fig.4. Mini-CL
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
9
GND
+5V
15k
TTL
1k
GND
100n
1k
68k
100k
1n
75
Trig input
pin #10
SW302.1
GND
+5V
15k
TTL
1k
GND
100n
1k
68k
100k
1n
75
Trig input
pin #10
SW302.1
GND
+5V
15k
TTL
1k
GND
100n
1k
68k
100k
1n
75
Trig input
pin #10
SW302.1
Fig. 7. Trigger input.
5.3. Input and output circuits
In the following schematic diagrams the input and output circuits for video and timing signals are
shown.
5.3.1. Iris video output
This signal can be used for lens iris control
in Continuous mode.
The signal for iris video output is taken from the CCD
output and digitized. It goes through the process circuit
and is converted analogue signal via the integrator. This
signal is influenced by gain settings. The signal is 0.7 Vpp
(without sync) from 75 without termination.
NOTE: This function is not available in the PoCL version
5.3.2. Trigger input
An external trigger input can be applied to pin 10 of 12pin Hirose connector (when the command TI=1 has been
set). The input is AC coupled. To allow long pulses the
input circuit is designed as a flip-flop circuit. The leading
and trailing edges of the trigger pulse activate the circuit.
The trigger polarity can be changed by TP=1.
Trigger input level 4 V 2 V.
Trigger can also be applied through the Camera Link
connector, when the command TI=0 has been sent.
NOTE: In the PoCL version trigger can only be
applied through the Camera Link connector
5.3.3. XEEN output
XEEN is on pin 9 on 12-pin HR connector. The output
circuit is 75 complementary emitter followers. It will
deliver a full 5 volt signal.
Output level 4 V from 75. (No termination).
EEN is also found in Camera Link.
NOTE: In the PoCL version EEN only appears on the
Camera Link connector
Fig. 8. XEEN output
5.3.4. Camera Link interface
The digital video is available via Camera Link, with 8 or 10-bit pixel depth, using the CL Base
configuration. The digital output signals follow the Camera Link standard using Channel Link chip
sets.
The data bits from the digital video, FVAL, LVAL, DVAL and EEN are multiplexed into the twisted
pairs, which are a part of the Camera Link. Trigger signals and the serial camera control are feed
directly through its own pairs.
The 26-pin Mini-CL SDR connector pin assignment follows the Camera Link base configuration.
For a detailed description of the Camera Link standard, please refer to the Camera Link standard
specifications found on www.jai.com
GND
+5V
2
2
10k
2k2
75
TTL
100
Pin #9
XEEN
output
GND
+5V
2
2
10k
2k2
75
TTL
100
Pin #9
XEEN
output
SW600
Fig. 6. Iris video
ＤＡC
１μ１Ｋ
２Ｋ２
０．１μ
＋５Ｖ
IRIS Video Out
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
10
6. Functions and Operations
6.1. Basic functions
The CMCB-140 MCL / CMCB-140 PMCL /CM-140MCL-UV/PMCL-UV cameras are progressive scan
camera with 1.4 Mega pixels monochrome and Bayer mosaic color CCDs. The interface to the host
PC is via digital Mini Camera Link (Mini-CL). Both models output video as 8 or 10 bits. The CB-140
MCL /PMCL outputs raw Bayer video, requiring host based color interpolation.
An analogue iris-video signal can be used for controlling the iris of an auto-iris lens when
operating in continuous mode.
The camera has 2/3, 1/2, 1/4 or 1/8 partial scanning and vertical binning (CM-140 MCL /UV/PMCL/-UV only) for faster frame rates.
There are 2 trigger modes in addition to continuous operation. The Pre-Select and Pulse Width
control are available with a unique automatic LVAL sync or async selection function.
Below the functions are described in detail.
6.1.1. Digital Video Output (Bit Allocation)
The 10-bit digital output is set 890 LSB as 100% video level when CCD output is 200mV.
The white clip level is set at 1023 LSB when CCD output is 230mV.
CCD out
Analogue level
Digital Out( 10 bits )
Black
Setup 3.6%, 25mV
32LSB
200mV
700mV
890LSB
230mV↑
800mV
1023LSB
Fig.9. Digital Output Bit Allocation ( 10 Bits output )
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
11
6.1.2. Electronic Shutter
The CM/CB-140 MCL ,CM/CB-140PMCL and CM-140MCL-UV/PMCL-UV allow selecting shutter speed
in two ways; preset shutter (10 fixed steps) and programmable exposure (in 1051 line period, LVAL,
increments).
Preset Shutter
The following shutter speeds can be selected by command SH=0 through SH=9.
OFF (1/31), 1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000 seconds
Note: UV version is OFF (1/16), 1/30,1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 seconds
Programmable Exposure (PE)
The exposure time can be programmed in 30.58µs (LVAL period) increments. The range is from 2
LVAL to 1051 LVAL.
Minimum exposure time 2L
Maximum exposure time 1052L
30.584µs x 2(L) = 61.168 µs
30.584µs x 1052 (L) ≈ 32.17ms
MCL/PMCL
58.9µs x 2(L) = 117.8 µs
58.9µs x 1052 (L) ≈ 61.92ms
UV version
In V binning mode:
Minimum Exposure time 2L
Maximum exposure time 527L
38.83 µs x 2(L) = 77.66 µs
38.83 µs x 527 (L) ≈ 20.46 ms
MCL/PMCL
74.793 µs x 2(L) = 149.58 µs
74.793 µs x 527 (L) ≈ 39.4 ms
UV version
6.1.3. Continuous operation or triggered operation
The camera can operate in continuous operation applications not requiring asynchronous external
trigger. This mode permits the use of a lens with video controlled iris. The camera will operate at
its maximum frame rate, 31 frames/seconds (16 frames /second for UV) in this mode.
For applications that require an external trigger, the camera can accept an external trigger input
on pin 10 of the 12-pin Hirose connector or via the Camera Link interface. The command "TI" is
used to switch between inputs.
The camera can operate up to 30 frames/second (16 frames /sec. for UV)in triggered operation.
6.1.4. Iris video output.
The iris video output in pin 4 on 12-pin HR is 700 mV for 100% video
out in Camera Link. The iris video signal is taken before the gain
circuit. It is without sync.
The iris video signal can be used for auto iris lens drive in
continuous mode.
NOTE: In the PoCL version this function is not available.
Fig.10. Iris video output.
6.1.5. Rear panel indicator.
The rear panel mounted LED provides
the following information:
Amber:
Power connected - initiating
Steady green:
Camera is operating in Continuous mode
Flashing green:
The camera is receiving external trigger
Fig.11. Rear panel ( Left for MCL, Right for PMCL)
POCL
POWER / TRIG
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
12
6.1.6. Auto-detect LVAL-sync / async. accumulation
This function replaces the manual setting found in older JAI cameras. Whether accumulation is
synchronous or a-synchronous in relationship to LVAL depends on the timing of the trigger input.
When trigger is received while FVAL is high (during readout), the camera works in LVAL
synchronous mode, preventing reset feed trough in the video signal. There is a maximum jitter of
one LVAL period from issuing a trigger and accumulation start.
When trigger is received when FVAL is low, the cameras works in LVAL-asynchronous mode (no
delay) mode.
This applies to both pre-select (PS) trigger mode and pulse width trigger (PW) modes.
6.1.7. Starting pixel - Bayer color mosaic
The CB-140MCL/MPCL is a color camera based on a
CCD sensor with a Bayer color mosaic.
The color image reconstruction is done in the host
PC.
The color sequence in the video signal differs from
full scanning to partial scanning. The right hand
drawing shows the color sequence at the image
start.
The starting line number is shown from LVAL.
The first active pixel starts from LVAL, when DVAL
rises.
Even lines start with GBG.
Odd lines start with RGR
See also chapter 6.3, Partial Scan
Fig. 13. Bayer RGB color sequence
Ext. trigger
FVAL
(1)
(3)
(1) In this period camera executes trigger at next LVAL (prevents feed-through noise)
(2) Avoid trigger at FVAL transition (+/- 1 LVAL period), as the function may randomly switch
between "next LVAL" and "immediate".
(3) In this period camera executes trigger immediately (no delay)
(2)
Fig. 12. Auto-detect LVAL sync /a-sync accumulation
FVAL Timing
LVAL
DVAL
1
92
135
157
63
8
Full
2/3 Partial
1/2 Partial
1/4 Partial
1/8 Partial
1
Line # from FVAL triming
G B
R GGR
G B
R GGR
G B
R GGR
G BRG
R
G B
R GGR
G B
R GGR
Actual V Line #
1
174
261
391
456
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
13
6.1.8. Vertical Binning
This function is only available on the CM-140MCL/-UV/PMCL/-UV camera.
Binning mode (Command VB) is a function where the signal charge from 2 adjacent (vertical)
pixels are added together and read out as one pixel. Binning results in half vertical resolution and
higher frame rate. By adding 2 pixels together, the sensitivity is doubled. The charge accumulated
in 2 adjacent lines is added together in the horizontal CCD register. This is done by providing two
pulses to the vertical CCD register for each line readout. Vertical binning can not be used
together with the Partial scan.
Fig. 14. Vertical Binning
Normal full
2 line Vertical Binning
H
H
Horizontal CCD Register
S/H
Reset
Video
Out
Xsg1
Vertical CCD Register
Pixel
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
14
6.2. Sensor Layout and timing
6.2.1. CCD Sensor Layout
The CCD sensor layout with respect to pixels and lines used in the timing and video full frame read
out is shown below. For Bayer color sequence, refer to chapter 6.1.3.
Fig. 15. CCD sensor layout
1434
1052
2 401392
7
2
1040
OB
OB OB
OB
Effective Video Output
1392 (H) x 1040 (V)
3
Pixel (1,1)
R
G
G B
G
R
DVAL
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
15
6.2.2. Horizontal timing
The LVAL period is shown for continuous mode.
Model
1 LVAL
1 clock
CMCB-140MCL/PMCL
1988 clks = 30.584 µs
15.38 ns
CM-140MCL-UV/PMCL-UV
1988 clks = 58.9 µs
29.63 ns
Fig. 16. Horizontal timing
6.2.3. Vertical timing
The FVAL period for continuous mode full scan is shown.
Model
Frame rate 1052L
CMCB-140MCL/PMCL
31.08 fps
CM-140MCL-UV/PMCL-UV
16.14 fps
Fig. 17. Vertical timing for full scan
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
16
6.2.4. Partial Scan
Partial scan allows higher frame rate by reading out a smaller center portion of the image. This is
particularly useful when inspecting objects that do not fill the whole height of the image.
Full scan Partial scan
Vertical Timing
The below diagram and table provide vertical timing information for the fixed partial scan settings
1/2, 1/4, 1/3 and 2/3
Values for vertical timing in partial scan continuous mode.
AREA
FVAL Low
(L)
A
(L)
B (L)
C
(L)
Total line
(L)
frame rate(L)
Start line
End line
MCL/PMCL
UV
1/2 3 91
520
88L
702L
46.57
24.19
261
780
1/4 3 134
260
131L
528L
61.92
32.16
391
650
1/8 3 156
130
153L
442L
73.97
38.41
456
585
2/3 3 62
694L
59L
818L
39.97
20.76
174
867
Remark! The color sequence for CB-140MCL/MPCL differs in partial scan. Refer to chapter 6.1.7.
Fig. 18. Vertical timing for partial scanning
Vertical Video Timing
Partial Frame Read out
CCD Exposure
LVAL
FVAL
DVAL
DATA
EEN
XEEN
Valid data
3L
A
B
C
Fast-dump period
Fast-dump period
Normal scan period
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
17
Horizontal Timing
The horizontal timing is the same the full scanning.
Model
1 LVAL
1 clock
CMCB-140MCL/PMCL
1988 clks = 30.584 µs
15.38 ns
CM-140MCL-UV/PMCL-UV
1988 clks = 58.9 µs
29.63 ns
Fig. 19. Horizontal timing for partial scanning
6.2.5. Vertical Binning
Vertical binning combines charge from two adjacent lines, reducing the vertical resolution to half
and at the same time increasing frame rate and sensitivity. By activating this function, the frame
rate is increased to 48.87 fps.
This function is available only for CM-140MCL/PMCL.
Important Note
Vertical Binning can not be used together with the Partial Scanning.
Horizontal Timing
Model
1 LVAL
1 clock
CMCB-140MCL/PMCL
2524clks = 38.83 µs
15.38 ns
CM-140MCL-UV/PMCL-UV
2524 clks = 74.79 µs
29.63 ns
Fig.20. Horizontal Timing for Vertical Binning
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
18
Vertical timing
Model
Frame rate 527L
CMCB-140MCL/PMCL
48.87fps
CM-140MCL-UV/PMCL-UV
25.37fps
Fig.21. Vertical Timing for Vertical Binning
6.3. Operation Modes
This camera can operate in 3 primary modes.
1. TR=0 Continuous Mode. Pre-selected exposure.
2. TR=1 Pre-select Mode. Pre-selected exposure.
3. TR=2 Pulse Width Mode. Pulse width controlled exposure.
4. TR=3 Reset Continuous Pre-selected exposure
6.3.1. Continuous operation
For applications not requiring asynchronous external trigger, but should run in continuous
operation, this mode is used.
For timing details, refer to fig. 16 through fig. 21.
To use this mode:
Set function: Trigger mode to “Continuous”. TR=0
Scanning SC=0 through 4
V Binning VB=0 or 1
Shutter mode pre-set or programmable SM=0 or 1
Shutter speed SH=0 to 9
Programmable exp. PE=2 to 1052
Other functions and settings
LVAL
FVAL
DVAL
DATA
EEN
XEEN
CCD Exposure
Valid data
OB
OB
OB
1+2 3+4
3L3L
520L 1L
1037+1038
1039+1040
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
19
6.3.2. Pre-select Trigger Mode
An external trigger pulse initiates the capture, and the exposure time (accumulation time) is
defined by the SH or PE commands.
The resulting video signal will start to be read out after the selected shutter time.
For timing details, refer to fig. 16 through fig. 21 and fig. 22 & 23.
To use this mode:
Set function: Trigger mode to “Edge pre-select”. TR=1
Scanning SC=0 to 4
V Binning VB=0 or 1
Shutter mode to pre-set or programmable SM=0 or 1
Shutter speed SH=0 to 9
Programmable exp. PE=2 to 1052
Other functions and settings
Input: Ext. trigger. Camera Link or 12-pin Hirose TI=0, TI=1
Important notes on using this mode
1. The minimum trigger interval >1 LVAL.
2. Depending on the timing of the leading edge of the trigger pulse in relationship to FVAL,
accumulation will be synchronous or a-synchronous in relationship to LVAL. See chapter
6.1.1 for details.
LVAL_sync timing
Fig. 22. Pre-select trigger mode. LVAL synchronized.
１L(min.)
Trig
LVAL
EEN
XEEN
FVAL
2L
1L(max)
MCL/PMCL:(FULL:63μs, V Binning:89μs)
UV :(FULL:117.8μs, V Binning:149.6μs)
CCD exposure
Exposure time
When the trigger pulse is input while F VAL is high,
the LVAL accumulation mode is LVAL sync.
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
20
LVAL_async timing
Fig.23. Pre-select trigger mode. LVAL asynchronous
Minimum frame rate (common for all models)
Full
1054L
V Binning
529L
2/3 partial
820L
1/2 partial
704L
1/4 partial
530L
1/8 partial
444L
１L(min.)
CCD exposure
EEN
XEEN
FVAL
Trigger input within FVAL LOW period
2L to 3L
Exposure time
Trig
FLVAL a-sync mode etting
MCL/PMCL : 7.83 μs ± 1μs
UV : 15.66 μs ± 1μs
MCL/PMCL : (Full:63μs ～94 μs) (V Binning:89μs ～126μs)
UV : (Full:117.8μs ～176.7 μs) (V Binning:149.6μs ～224.4μs)
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
21
6.3.3. Pulse Width Trigger Mode
In this mode the accumulation time is equal the trigger pulse width. Here it is possible to have
long time exposure. The maximum recommended time is <60 frames.
For timing details, refer to fig. 16 through fig. 21 and fig. 24 & 25.
To use this mode:
Set function: Trigger mode to “Pulse width control”. TR=2
Partial scan SC=0 to 4
Vertical binning VB= 0 or 1
Other functions and settings
Input: Ext. trigger. Camera Link or 12-pin Hirose TI=0, TI=1
Important notes on using this mode
1. The minimum trigger interval > 1 LVAL
2. Depending on the timing of the leading edge of the trigger pulse in relationship to FVAL,
accumulation will be synchronous or a-synchronous in relationship to LVAL. See chapter
6.1.1 for details.
LVAL_sync timing
Fig. 24. Pulse width trigger mode. LVAL synchronized.
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
22
LVAL_async timing
Fig.25. Pulse Width trigger mode. LVAL asynchronous
Minimum frame rate (common for all models)
Full
1055L
V Binning
530L
2/3 partial
821L
1/2 partial
705L
1/4 partial
531L
1/8 partial
445L
1L(Min.)
Trig
2L to 3L
EEN
XEEN
FVAL
1L
MCL/PMCL : 7.83μs ±1μs
UV : 15.66μs±1μs
MCL/PMCL : (FULL:63μs ~ 94μs, V Binning:89μs ~ 126μs)
UV : (FULL:117.8μs ~ 176.7μs, V Binning:149.6μs ~ 224.4μs)
CCD exposure
Exposure time
When the trigger pulse is input while F VAL is low,
the LVAL accumulation mode is LVAL async.
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
23
6.3.4 Reset Continuous (RCT) trigger mode
The RCT mode operates like EPS (edge preselect) mode with smearless function. An
external trigger pulse will immediately stop the video read out, reset and restart the
exposure, then operate as normal mode until the next trigger. After the trigger pulse is
input, a fast dump read out is performed. In the CM-040MCL/ CB-040MCL, this period is
6.77ms which is 215L. The exposure time is determined by the pre-set shutter speed. If no
further trigger pulses are applied, the camera will continue in normal mode and the video
signal is not output. The fast dump read out has the same effect as “smearless read out”.
Smear over highlight areas is reduced for the trigger frame. The reset continuous trigger
mode makes it possible to use triggering in conjunction with a lens with video controlled
iris.
To use this mode:
Set function: Trigger mode RCT
Scanning Full, Partial
Vertical binning ON / OFF (CM-040MCL only)
Shutter mode Preset, Programmable
Shutter speed 1/61(OFF) to 1/10000
Programmable exposure 2L to 596 L
Accumulation LVAL async only
Other functions and settings
Input: External trigger 12-pin Hirose or Camera Link
Important notes on using this mode
Trigger pulse >2 LVAL to <1 FVAL)
Note: When PE is set at 596 or the shutter is set at OFF, EEN is always HIGH.
Fig.26 RCT mode timing
Trig
CCD Exposure
MCL/PMCL:10.71ms
EEN
XEEN
FVAL
DVAL
2L～3L
MCL/PMCL:(Full:63us
～94us Vbinnig:89us～126us)
350L
UV :(Full:117.8us
～176.7us Vbinnig:149.6us～ 224.4us)
UV :20.615ms
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
24
6.4. Mode and function matrix.
The following table shows which functions will work in the different modes for CM/CB-140MCL and
CM/ CB-140PMCL.
Func.
Shutter
Partial
scan
V
Binning
Accumulation
Iris
video
Trigger Mode
Pre-select
Programmable
LVAL sync/async
out
Cont.
TR=0
Yes
Yes
Yes
Yes - Yes
EPS
TR=1
Yes
Yes
Yes
Yes
Auto
-
PWC
TR=2 - -
Yes
Yes
Auto
-
RCT
TR=3
Yes
Yes
Yes
Yes
Async only
Yes
Fig. 27. Mode and function matrix.
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
25
7. Configuring the Camera
7.1. RS-232C control
All configuration of the CM/CB-140MCL and CM / CB-140PMCL cameras are done via the serial
communication in the Camera Link connector. The camera can be set up from a PC running
terminal emulator software, or using JAI's camera control software.
Below is the description of the ASCII based short command protocol.
Communication setting
Protocol.
Transmit setting to camera:
NN=Parameter<CR><LF> (NN is any kind of command. Capital or small letters.)
The camera answers:
COMPLETE<CR><LF>
To have all communication visible on the emulator screen, start with:
EB=1<CR><LF>
The camera answers:
COMPLETE<CR><LF>
Transmit request command to camera:
NN?<CR><LF> (NN is any kind of command.)
The camera answers:
NN=Parameter<CR><LF>
Transmit the following to have the camera actual setting:
ST?<CR><LF>
The camera answers:
A complete list of the current settings
Transmit the following to have a command list:
HP?<CR><LF>
The camera answers:
A list with all commands and possible settings
Invalid parameters send to camera: (99 is an invalid parameter)
SH=99<CR><LF>
The camera answers:
02 Bad Parameters!!<CR><LF>
To see firmware number.
VN?<CR><LF>
To see camera ID. It shows the manufacturing lot number.
ID?<CR><LF>
Baud Rate
9600 bps
Data Length
8 bit
Start Bit
1 bit
Stop Bit
1 bit
Parity
None
Xon/Xoff Control
None
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
26
7.2. Setting functions
7.2.1. Bit allocation. BA=0, BA=1
This command sets the output for either 8-bit or 10-bit.
7.2.2. Partial scan. SC=0 through 4.
The CCD scanning format can be selected between full or partial scanning. With partial scanning
only the vertical central part of the CCD sensor is read out with a higher frame rate. The partial
scan is done by a fast dump read out of the lines in the vertical CCD register down to the top of
the partial image. This central part of the image is read out with normal speed. The lines below
the partial image are read out and dumped with a high speed.
Note: The color sequence for CB-140 MCL/PMCL differs in partial scan modes. Refer to chapter
6.1.2.
7.2.3. Vertical binning. VB=0, VB=1
This function is only for CM-140MCL/PMCL camera.
The CM-140MCL/PMCL has only vertical binning mode. With V binning the pixel charge from 2
adjacent lines are added together in the horizontal CCD register. It is done by double pulses to the
vertical CCD register.
Note: Vertical Binning can not be used together with the Partial scanning.
7.2.4. Shutter mode. SM=0 and SM=1
With SM=0 this function selects the shutter from the 9 fixed steps (SH=0 through SH=9SH).
With SM=1 from programmable in 1051 steps (PE=2 through PE=1052).
7.2.5. Trigger input select. TI=0, TI=1.
This function selects the trigger input to be through Camera Link (TI=0), or as TTL through the 12
pin Hirose connector (TI=1).
7.2.6. Trigger polarity. TP=0, TP=1.
The active trigger polarity is normal low (TP=0). It can be invert it to active high (TP=1).
7.2.7. Gain level. GA=-84 through +336.
GA=0 is 0dB gain, which is normal working point. The range is from -3 dB to +12 dB.
7.2.8. Black level. BL=0 through BL=1023.
Black level (or set-up level) will set the video level for black. Factory setting is 32 LSB for 10bit
or 8 LSB for 8bit.
7.3. Save and Load Functions.
The following commands are for store and load camera settings in the camera EEPROM.
Load settings. LD.
This command will load previous stored settings to the camera. 3 user settings can be stored in
the camera EEPROM. 1 factory setting is also stored in the camera. The settings stored in the last
used user area is used as default settings at power up.
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
27
Save Settings. SA.
This command will store the actual camera settings to 1 of the 3 user area in the camera EEPROM.
EEPROM Area. EA.
If received, the camera will return the last used user area number.
7.4. CM/CB-140MCL / CM/CB-140PMCL command list
Command Name
Format
Parameter
Remarks
A - General settings and utility commands.
1
Echo Back
EB=[Param.]<CR><LF>
EB?<CR><LF>
0=Echo off
1=Echo on
Off at power up
2
Camera Status
Request
ST?<CR><LF>
Actual setting
3
Online Help
Request
HP?<CR><LF>
Command list
4
Firmware Version
VN?<CR><LF>
3 digits
(e.g.) 100 =
Version 1.00
5
Camera ID
Request
ID?<CR><LF>
max 10 characters
6
Model Name
Request
MD?<CR><LF>
max 16 characters
7
User ID
UD=[Param.]<CR><LF>
UD?<CR><LF>
User can save and
load free text.(16
or less characters)
B – Shutter
1
Shutter Mode
SM=[Param.]<CR><LF>
SM?<CR><LF>
0=Preset Shutter
1=Programmable exposure
2
Preset Shutter
SH=[Param.]<CR><LF>
SH?<CR><LF>
0=Off, 1=1/60, 2=1/100,
3=1/250, 4=1/500,
5=1/1000, 6=1/2000,
7=1/4000, 8=1/8000,
9=1/10000
Available when
SM=0.
3
Programmable
Exposure
PE=[Param.]<CR><LF>
PE?<CR><LF>
2 to 1052
Available when
SM=1.
C - Trigger mode
1
Trigger Mode
TR=[Param.]<CR><LF>
TR?<CR><LF>
0=Normal (Continuous)
1=EPS(Edge pre select)
2=PWC(Pulse width control)
3=RCT
2
Trigger Polarity
TP=[Param.]<CR><LF>
TP?<CR><LF>
0=Active Low
1=Active High
3
Trigger Input
TI=[Param.]<CR><LF>
TI? <CR><LF>
0=Camera Link
1=Hirose 12pin
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
28
Command Name
Format
Parameter
Remarks
D -Image Format
1
Bit Allocation
BA=[Param.]<CR><LF>
BA?<CR><LF>
0=10bit
1=8bit
2
Scan Format
SC=[Param.]<CR><LF>
SC? <CR><LF>
0=Full Frame
1=2/3 Partial
2=1/2 Partial
3=1/4 Partial
4=1/8 Partial
3
V-Binning
VB=[Param.]<CR><LF>
VB?<CR><LF>
0=OFF
1=On
Only for CM140MCL
E - Gain, Black and signal settings
1
Gain Level
GA=[Param.]<CR><LF>
GA?<CR><LF>
-84 to 336
2 Black Level
BL=[Param.]<CR><LF>
BL?<CR><LF>
0 to 1023
F - Saving and loading data in EEPROM
1
Load Setttings
(from Camera
EEPROM)
LD=[Param.]<CR><LF>
0=Factory area
1=User 1 area
2=User 2 area
3=User 3 area
Latest used DATA
AREA becomes
default at next
power up.
2
Save Settings
(to Camera
EEPROM)
SA=[Param.]<CR><LF>
1=User 1 area
2=User 2 area
3=User 3 area
Note : parameter 0 is not
allowed
3
EEPROM Current
Area No Request.
EA?<CR><LF>
0=Factory area
1=User 1 area
2=User 2 area
3=User 3 area
The camera return
the latest used
DATA AREA.
NOTE: Do not try to use commands not shown in this list.
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
29
8. Camera Control Tool for CM/CB-140 MCL / CM/CB-140 PMCL
The Camera Control Tool for Windows 2000/XP can be downloaded from www.jai.com.
The control tool contains a camera control program and a developer's kit for integrating the
control tool in your own software. For the integrator and experienced user, the Camera Control
Toll is much more than a program with a window interface. It also provides an easy and efficient
ActiveX interface built for MS Windows 2000/XP. The OCX interface has the ability to connect to
the camera using the serial interface of the PC by reading and writing properties for the camera.
This integration requires simple programming skills within Visual Basic, Visual C++ or similar
languages in a Microsoft Windows environment.
8.1. Camera Control Tool Interface
The Camera Control Tool Software is based on a main Tool Bar and a number of associated Tool
Windows. Each button in the Tool Bar pops up a separate Tool Window when pressed. The layout
of the program can be adjusted by arranging the windows the way it is preferred. The program
will store this information and recreate this layout, when the program is restarted. All Camera
Control Tools have a Communication Window and an About Window. The other window(s) contains
camera control commands.
8.1.1. Camera Control Tool Bar
This is a Camera Control Tool Bar and when the button of each widow, each control GUI can be
initiated.
8.2. The About Window
The about window contains a picture
of the camera and information about
the version of the program, Internet
connection to JAI A/S and access to
the help documents.
The drop-down box labelled "Help File"
will list all files which have the
extension .pdf and that are found in
the program (default) folder.
It is possible to download updated
operation manuals from the jai
website: http://www.jai.com
An updated manual can be saved in the folder address mentioned above and it will automatically
be included in the list of help files.
At the bottom of the windows (all windows but the Communication Window is a colored bar. The
bar is green when the Camera Control Tool is connected to a camera and the camera is turned on.
About Window
Communication Window
Camera Control Window
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
30
The bar is red when the Camera Control Tool is not connected to a camera or when the camera is
turned off.
8.3. Communication Window
The Communication Window is used to
connect the Camera Control Tool with
the JAI camera.
Camera Link communication:
Select “Camera Link “at the pull-down
box for Category. Port Name shows DLL
file names (or frame grabber names) for
all Camera Link frame grabbers that are
installed in the pc. This is done by using
a DLL file called "clserial.dll" to upload
all frame grabber DLLs that are found
in the pc.
Just select the option for the frame
grabber that is installed in the pc.
Auto search
Click the auto button to search for a
camera on communication port 1 to
16. The camera control program automatically sends camera request on every communication
port. The user is prompted to use a communication port if a camera answers the request.
This button is only used for RS-232 communication.
Off/On-line mode
The Camera Control Tool Application can run Offline (without a camera attached) and
all functions are fully functional in offline mode.
Off line mode is indicated in The Communication Window, where a status field with
graphic and text indicates the on/off-line status.
Changing the selected communication port (from the communication window)
changes the online/off-line status. If a camera is found on the selected communication port the
application runs online otherwise offline.
Changing the settings in the application will automatically update the camera settings when the
application is online.
If the application looses connection with the camera it will automatically go to offline mode and it
is indicated in the communication window.
Synchronize program and camera
The Camera Control software has the ability to synchronize either the camera
or the program. Click Synchronize camera to write all settings from the
program to the camera or click the Synchronize program to load all settings
from the camera to the program.
Files
When clicking the Write to File or Read from File button, the user is prompted for a file using
a standard file dialog. New files are created if they do not already exist.
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
31
Files for camera settings have the extension cam. Information about the communication port is
not stored in the files. All settings are automatically sent to the camera when a file has been
loaded (if the camera is online).
Factory and User Settings
Use the Store button to store the current camera settings into the user settings area in
EEPROM. Current camera settings are not saved when the camera is turned off. To save
current camera settings you have to save them on the available user areas.
Use the Load button to restore previously saved camera settings from either the Factory or the
User EEPROM area.
Write All Camera Data to File.
Click the “Write Camera Data” button to save all camera settings into a
text file. The information that can be saved is:
Model Name, Camera ID, User ID, Firmware Version, Current Settings,
Factory Settings and the available User Areas.
The file is formatted as shown in the picture below:
EEPROM Current Area.
Click the „Get Area‟ button to read the power up settings area number.
8.4. Camera Control Window
The Camera Control Window contains
the fundamental camera setting
functions.
It is possible to set the shutter mode,
Trigger mode, image format, scan
format, gain control and black setting.
8.5. Using the Camera Control Tool
Here is some practical information about the Camera Control Tool:
1. The Camera Control Tool bar is always on top of other windows.
2. When you minimize the Camera Control Tool bar all open windows will close.
3. It is possible to work with the Camera Control Tool when the camera is online and when
the camera is offline.
4. The newer JAI cameras always start up with the last used user area (but for some old
models it will start up with the last saved user area.)
5. The Camera Control Tool saves the last used settings (not the user area), which don‟t have
to be the same as for the last saved user area.
6. The setup file ‟CameraName.ini‟ stores all information about camera settings. When the
program is started the last settings for the program are loaded from the
file ‟CameraName.ini‟
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
32
7. When you turn on the camera and the Camera Control Tool, it is possible that the Camera
Control Tool does not show the actual camera settings (see 4. and 5.).
a. To obtain the camera settings click “Synchronize Program”.
b. To send the settings that are saved in the Camera Control Tool (last used settings)
to the camera click “Synchronize Camera”.
c. To see which area the camera has started up in click “Get Area”.
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
33
9. External Appearance and Dimensions
Fig. 28. Outline. ( CM-140MCL/-UV/CB-140MCL )
Note: The outline for CM/CB-140PMCL is the same as CM/CB-140MCL but the rear panel of CM/CB140PMCL does not have 12 pin HIROSE connector.
Fig.29. Rear Panel (CM-140PMCL / CB-140PMCL)
(2.28)
(2.60)
(1.97)
MI NI-C L
Outs i de s i ze t ol erance：± 0.3mm
POWER/ TRIG
50
66
Serial No.
6-M3 depth 3.5
FCC seal
Caution seal
58
44
29
C-Mount
13
26
26
(1.73)
(1.14)
14.5
(0.57)
(0.51)
5
(0.2)
(1.02)
(1.
02)
(depth0.14)
3-M3 depth 3.5
5
(0.2)
Unit:mm ( ) :inch
(depth0.14)
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
34
10. Specifications
10.1. Spectral response
Fig. 30. Spectral response for CM-140MCL/PMCL
Fig.31. Spectral response for CB-140MCL/PMCL
IR Filter
1.0
0.8
0.6
0.4
0.2
0
400 450 500
550
600
650
700
Relative Response
Wave Length [ nm ]
B
G
R
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
35
Fig 32. Spectral response for CM-140MCL-UV/PMCL-UV
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
36
10.2. Specification table(CMB-140MCL/CMB-140PMCL)
Specifications
CM-140 MCL
CB-140 MCL
Scanning system
Progressive scan
Frame rate full frame
31.08 frames/sec. Progressive
(1052 lines/frame)
Pixel clock
65 MHz
Line frequency
32.681kHz
(1988 pixel clock/line)
CCD sensor
1/2”. Monochrome ICX267AL
1/2” Color ICX-267AK
Sensing area
6.4 (h) x 4.8 (v) mm
Cell size
4.65 (h) x 4.65(v) m
Active pixels
1392 (h) x 1040 (v)
Pixels in video output. Full
2/3 partial
1/2 partial
1/4 partial
1/8 partial
1392 (h) x 1040 (v) 31.08 fps. H = 32.696 kHz
1392 (h) x 694 (v) 39.97 fps H= 32.696 kHz
1392 (h) x 520(v) 46.57 fps. H = 32.696 kHz
1392 (h) x 269 (v) 61.92 fps. H = 32.696 kHz
1392 (h) x 130 (v) 73.97 fps. H = 32.696 kHz
Sensitivity on sensor (minimum)
0.3 Lux (Max. gain, Shutter OFF, 50%
video )
1.4 Lux (Max. gain, Shutter OFF,50%
Green, w/IR cut filter)
S/N ratio
More than 50 dB (0dB gain)
Digital Video output.
8 or 10 bit in Camera Link
8 or 10 bit raw Bayer video
in Camera Link
Iris video output. Analogue
0.7 Vpp
Gain
Manual -3 to +12 dB
Gamma
1.0
Synchronization
Int. X-tal.
Trigger input. TTL
Camera Link
4 V 2 V. TTL
Via Camera Link
EEN output
4 V from 75 source
Trigger modes
Pre-Select , Pulse Width and Reset Continuous
Accumulation
LVAL synchronous or asynchronous automatic selection
Preset Shutter speed
9 fixed steps 1/60 to 1/10,000 second
Programmable exposure
2 L to 1052 L (61.168 s to 32.17 ms)
Pulse width control
1 L to 60 frames.
Readout modes
Full, Partial scan.(2/3, 1/2, 1/4, 1/8)
V Binning
Full, Partial scan.(2/3,1/2, 1/4,1/8)
Control interface
Camera Link serial
Functions controlled by RS 232C
Shutter, Trigger, Scanning, Read out, Polarity, Black level, Gain,
Operating temperature
-5C to +45C
Humidity
20 – 90% non-condensing
Storage temp/humidity
-25C to +60C/20% to 90% non-condensing
Vibration
10G (20Hz to 200Hz, XYZ)
Shock
70G
Regulatory
CE (EN61000-6-2 and EN61000-6-3), FCC part 15 class B, RoHS, WEEE
Power
12V DC 10%. <0.25A ( Normal Operation )
Lens mount
C-mount (Flange back 17.526 mm -0.05mm)
Image centre 0.1mm from C-mount centre
Dimensions
44 x 29 x 66 mm (HxWxD)
Weight
115 g
115 g
Note: Above specifications are subject to change without notice
Note: Approximately 30 minutes pre heat requires to meet specifications.
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
37
10.3. Specification table(CM-140MCL-UV/CM-140PMCL-UV)
Specifications
CM-140 MCL-UV/CM-140PMCL-UV
Scanning system
Progressive scan
Frame rate full frame
16.14 frames/sec. Progressive
(1052 lines/frame)
Pixel clock
33.75 MHz
Line frequency
16.978 kHz
(1988 pixel clock/line)
CCD sensor
1/2” Monochrome UV sensitive ICX407BLA
Sensing area
6.4 (h) x 4.8 (v) mm
Cell size
4.65 (h) x 4.65(v) m
Active pixels
1392 (h) x 1040 (v)
Pixels in video output. Full
2/3 partial
1/2 partial
1/4 partial
1/8 partial
1392 (h) x 1040 (v) 16.14 fps. H = 16.978 kHz
1392 (h) x 694 (v) 20.76 fps H= 16.978 kHz
1392(h) x 520(v) 24.16 fps. H = 16.978 kHz
1392 (h) x 269 (v) 32.16 fps. H = 16.978 kHz
1392(h) x 130 (v) 38.41 fps. H = 16.978 kHz
Sensitivity on sensor (minimum)
0.3 Lux (Max. gain, Shutter OFF, 50% video )
S/N ratio
More than 50 dB (0dB gain)
Digital Video output.
8 or 10 bit in Camera Link
Iris video output. Analogue
0.7 Vpp
Gain
Manual -3 to +12 dB
Gamma
1.0
Synchronization
Int. X-tal.
Trigger input. TTL
Camera Link
4 V 2 V. TTL
Via Camera Link
EEN output
4 V from 75 source
Trigger modes
Pre-Select , Pulse Width and Reset continuous
Accumulation
LVAL synchronous or asynchronous automatic selection
Preset Shutter speed
9 fixed steps 1/30 to 1/10,000 second
Programmable exposure
2 L to 1052 L (118 s to 62 ms)
Pulse width control
1 L to 32 frames.
Readout modes
Full, Partial scan.(2/3, 1/2, 1/4, 1/8) V Binning
Control interface
Camera Link serial
Functions controlled by RS 232C
Shutter, Trigger, Scanning, Read out, Polarity, Black level, Gain,
Operating temperature
-5C to +45C
Humidity
20 – 90% non-condensing
Storage temp/humidity
-25C to +60C/20% to 90% non-condensing
Vibration
10G (20Hz to 200Hz, XYZ)
Shock
70G
Regulatory
CE (EN61000-6-2 and EN61000-6-3), FCC part 15 class B, RoHS, WEEE
Power
12V DC 10%. <0.14A ( Normal Operation )
<0.15A (Max. 1/8 partial operation)
Lens mount
C-mount (Flange back 17.526 mm -0.05mm)
Image centre 0.1mm from C-mount centre
Dimensions
44 x 29 x 66 mm (HxWxD)
Weight
120 g
Note: Above specifications are subject to change without notice
Note: Approximately 30 minutes pre heat requires to meet specifications.
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
38
11. Appendix
11.1. Precautions
Personnel not trained in dealing with similar electronic devices should not service this camera.
The camera contains components sensitive to electrostatic discharge. The handling of these
devices should follow the requirements of electrostatic sensitive components.
Do not attempt to disassemble this camera.
Do not expose this camera to rain or moisture.
Do not face this camera towards the sun, extreme bright light or light reflecting objects, including
laser sources.
When this camera is not in use, put the supplied lens cap on the lens mount.
Handle this camera with the maximum care.
Operate this camera only from the type of power source indicated on the camera.
Remove power from the camera during any modification work, such as changes of jumper and
switch settings.
11.2. Typical Sensor Characteristics
The following effects may be observed on the video monitor screen. They do not indicate any
fault of the camera, but do associate with typical sensor characteristics.
V. Aliasing
When the camera captures stripes, straight lines or similar sharp patterns, jagged image on the
monitor may appear.
Blemishes
All cameras are shipped without visible image sensor blemishes.
Over time some pixel defects can occur. This does not have a practical effect on the operation of
the camera. These will show up as white spots (blemishes).
Exposure to cosmic rays can cause blemishes to appear on the image sensor. Please take care to
avoid exposure to cosmic rays during transportation and storage.
It is recommended using sea shipment instead of air flight in order to limit the influence of cosmic
rays to camera.
Pixel defects/blemishes also may emerge due to prolonged operation at elevated ambient
temperature, due to high gain setting or during long time exposure. It is therefore recommended
to operate the camera within its specifications.
Patterned Noise
When the sensor captures a dark object at high temperature or is used for long time integration,
fixed pattern noise may appear in the image.
11.3. Caution when mounting a lens on the camera
When mounting a lens on the camera dusts particles in the air may settle on the surface of the
lens or the image sensor of the camera. It is therefore important to keep the protective caps on
the lens and on the camera until the lens is mounted. Point the lens mount of the camera
downward to prevent dust particles from landing on the optical surfaces of the camera. This work
should be done in a dust free environment. Do not touch any of the optical surfaces of the camera
or the lens.
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
39
11.4. Caution when mounting the camera
When you mount the camera on your system, please make sure to use screws of the
recommended length described in the following drawing. Longer screws may cause
serious damage to the PCB inside the camera.
If you mount the tripod mounting plate, please use the provided screws.
11.5. Exportation
When exporting this product, please follow the export regulation of your own country.
11.6. References
1. This manual for CM/CB-140 MCL / CM/CB-140 PMCL can be downloaded from www.jai.com
2. Datasheet for CM/CB-140 MCL / CM/CB-140PMCL can be downloaded from www.jai.com
3. Camera control software can be downloaded from www.jai.com
Camera chassis
Fixing plate
3.5mm ± 0.2mm
Camera chassis
Tripod mount
3.5mm ± 0.2mm
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
40
Index
—A—
asynchronous .............. 3, 10, 11, 17, 19, 32
—B—
Bayer mosaic color ........................... 3, 9
Binning mode.................................... 12
Bit Allocation................................. 9, 25
Black Level ...................................... 25
Blemishes ........................................ 33
—C—
Camera Control Tool .......... 3, 26, 27, 28, 29
Camera Link ... 4, 5, 6, 7, 8, 9, 10, 18, 20, 22,
23, 24, 27, 32
CCD sensor ........... 4, 5, 8, 11, 13, 23, 32, 34
Continuous operation ............... 3, 9, 10, 17
—D—
Digital Output ................................. 7, 9
—E—
external trigger ..................... 8, 10, 17, 18
External trigger ................................... 3
—G—
Gain ..................................... 23, 25, 32
Gamma ........................................... 32
—H—
Hirose ................... 6, 8, 10, 18, 20, 23, 24
—I—
indicator ......................................... 10
—L—
Lens mount ...................................... 32
LVAL synchronous .......................... 11, 32
—M—
Mini-CL connector ............................... 7
—O—
OCX ................................................ 26
—P—
Partial scanning ............... 9, 11, 15, 16, 23
Pixels in video output .......................... 32
PoCL .................................. 3, 5, 7, 8, 10
Power over Mini-CL .............................. 3
Preset Shutter ......................... 10, 24, 32
programmable exposure ....................... 10
Programmable exposure ............... 3, 24, 32
Progressive scan............................... 3, 9
Pulse Width ................. 3, 9, 17, 20, 21, 32
—R—
rear panel mounted LED ....................... 10
reset feed trough ............................... 11
—S—
Scanning format ................................. 23
Spectral response ............................... 31
Synchronization ................................. 32
—T—
Trigger input ..................... 4, 5, 10, 11, 23
Trigger polarity ..............................8, 23
—V—
Vertical Binning ....................... 12, 16, 17
—X—
XEEN ............................................ 6, 8
CMCB-140MCL/CM-140MCL-UV/CMCB-140PMCL
41
Change History
Month/Year
Revision
Changes
June 2007
1.0
New release
June 2008
2.0
Add PMCL version
Sept 2009
3.0
Change the depth in chassis for screws from 4mm to 3.5mm and
add caution, Add RCT trigger mode, Add UV version
Feb 2010
3.1
Correct effective horizontal pixel number from 1380 to 1392.
Feb 2011
3.2
Correct the unit of clock on chapters, 6.2.2, 6.2.4 and 6.2.5
from μs to ns.
May 2011
3.3
Correct the drawings for the vertical and horizontal timing of
full and partial scan and the horizontal timing of vertical
binning.
CMCB-140 MCL/CM-140MCL-UV/CMCB-140 PMCL
42
User's Record
Camera type: CM-140 MCL / -UV / CB-140 MCL
CM-140 PMCL / -UV / CB-140 PMCL
Revision: ……………..
Serial No. ……………..
Firmware version. ……………..
For camera revision history, please contact your local JAI distributor.
User's Mode Settings.
User's Modifications.
Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners.
JAI A-S cannot be held responsible for any technical or typographical errors and reserves the right to make changes to products
and documentation without prior notification.
Europe, Middle East & Africa
Asia Pacific
Americas
Phone +45 4457 8888
Fax +45 4491 3252
Phone +81 45 440 0154
Fax +81 45 440 0166
Phone (toll-free) +1 800 445 5444
Phone +1 408 383 0300
Visit our web site at www.jai.com
Loading...
