Introduction
Congratulations on the purchase of your Jaeger‑
LeCoultre watch, and thank you for your confidence.
A fruit of this shared philosophy, the AMVOX2 DBS
Transponder model manufactured by Jaeger‑LeCoultre is ex‑
clusively aimed at owners of an Aston Martin DBS. They will
be able to activate and deactivate their car’s door locking
system by pressing on the watch’s sapphire crystal, as well as
use the vertical‑trigger chronograph functions.
Please check out the operating instructions for your
Jaeger‑LeCoultre timekeeper: we hope that you will be very
happy with it.
Jaeger‑LeCoultre & Aston Martin
There is no chance involved, just a meeting of minds. Jaeger‑
LeCoultre, a benchmark icon of fine watchmaking, and Aston Martin,
a legendary br and and symbol par excellence of fine car engineer‑
ing, were made for each other. No other field than car “engineer‑
ing” could so effectively illustrate the sacred union dear to Jaeger‑
LeCoultre: tradition and pioneering. And this compelling need to
gain the approval of fine watchmaking and fine engineering could
only be achieved with another legendary brand: Aston Martin.
On the strength of a shared history and parallel assets, their
coming together was founded on respect for values and a
constant quest for technical and aesthetic perfection. Each
watch and each car are crafted with special care, in accord‑
ance with traditional rules, while using the most modern tech‑
nologies. It is the passion and taste for precision that make
these two such different worlds so similar, and remain at the
cutting edge of technology, while exhibiting the highest level
of integrity. These two brands were destined to come togeth‑
er under the same passion: meeting challenges.
Accuracy
Manual or automatic winding mechanical models
The accuracy of the mechanical movement watch models
is determined by the balance. The latter performs 21,600 or
28,800 vibrations per hour, depending on the model (see tech‑
nical specifications applicable to each model).
Despite all the care with which the Manufacture Jaeger‑Le‑
Coultre master watchmakers have made and assembled your
watch, its accuracy is subject to the influence of gravity, mag‑
netic fields, impacts and ageing of the oils. Watch accuracy is
measured by rate regularity in a variety of positions.
The nature of your constitution or lifestyle may lead to slight
irregularities. If you observe irregular running of your watch,
you are advised to take it to an authorised Jaeger‑LeCoultre
retailer, who will make any necessary adjustments.
Water‑resistance
Jaeger‑LeCoultre AMVOX2 DBS Transponder watches are
water‑resistant to 5 bar/atm. The water‑resistance of your
watch can be identified by the
symbol engraved on
the back. This means that you can use your watch during short
swims or when diving in from the edge, but not from a diving
board. Nor should it be used for undersea diving or for spor ts
where there are significant risks of hard knocks, such as wind‑
surfing and water‑skiing. Please also note that leather straps
are not suited to water sports.
Furthermore, it is essential to have your watch’s water‑resistance
checked by an authorised Jaeger‑LeCoultre retailer at least
once every 2 years, and definitely before any period in which it
will undergo prolonged and/or regular immersion.
AMVOX2 DBS Transponder
1 Minute hand
2 Minute counter
3 Crown
4 Contact zone for locking the doors
of the connected vehicle (CLOSE)
5 Date
6 Seconds indicator (Operating indicator)
7 Contact zone for unlocking the doors
of the connected vehicle (OPEN)
8 Chronograph locking device
9 Hour counter
10 Chronograph seconds
11 Hour hand
C
L
O
S
E
O
P
E
N
1
2
3
4
5
11
6
8
7
9
10
AMVOX2 dBs Transponder ‑ English 1/6
«1000 Hours Control» test
by Jaeger‑LeCoultre
Jaeger‑LeCoultre subjects each of its watches to the rigourous
“1000 Hours Control” test programme. Unique in its kind,
this programme consists of 1000 hours of comprehensive,
stringent checks.
The “1000 Hours Control” seal or marking affixed or engraved
on the back of your watch certifies that it has undergone
this observation programme in our laboratories and has
passed all the tests, relating to rate regularity, temperature
and atmospheric pressure, resistance to impacts and magnetic
fields, as well as water‑resistance. Your watch is therefore
capable of withstanding the trials awaiting it in everyday life
when you wear it on your wrist.
The criteria of the “1000 Hours Control” programme go far
beyond the official timekeeping test standards, which concern
only part of the movement Jaeger‑LeCoultre tests not only the
movement before casing it within the watch, but also the watch
as a whole.
Built‑in transponder for the DBS car
The AMVOX2 DBS Transponder has a built‑in transmitter micro‑
system for activating and deactivating the door‑locking system
of the Aston Martin DBS sports car, which has been expressly
connected to it by an authorised Aston Martin dealership.
Pressing on the watch crystal’s OPEN position (between
8 and 9 o’clock) will activate the door opening system, while
the same action on the CLOSE position between 3 and
4 o’clock will lock the doors of the connected vehicle.
Security
The watch transponder serves a transmission function
only. This means that the code transmitted by the watch
microsystem can only be read by a vehicle with the
appropriate reading protocol, which has been expressly
enabled to use this protocol by an authorised Aston Martin
dealership.
On delivery, AMVOX2 DBS Transponder watches produced
by Jaeger‑LeCoultre come with a secured coding protocol,
but at this stage it cannot work since it is not connected
to any system or any car. The watch’s owner has the choice
and responsibility to visit the nearest Aston Martin dealership
to have the connection between the watch and the car
activated. Only Aston Martin dealerships are authorised to
enable or disenable this pairing.
Should the watch be lost or the owner decide to stop using
the watch’s locking/unlocking function, the transponder may
be immediately locked by the Aston Martin dealership at the
owner’s request, and at their sole responsibility.
No starting function
Under the strict conditions stated above, the AMVOX2
DBS Transponder watch may only activate and deactivate
the door locking system of the connected car. Under no
circumstances does it incorporate a star ting function for the
car’s engine. The Aston Martin ignition key accompanying the
car is needed to start the engine.
Important note
You are reminded that the AMVOX2 DBS Transponder
watch and its locking/unlocking function are placed under
your own responsibility. You are strongly advised to observe
the elementary security rules and visually check that the
doors are properly closed.
Battery
The transponder’s electronic circuit works with a battery
reference CR1616. If you observe a malfunction or failure
of the unlocking and locking functions, please entrust the
watch to a Jaeger‑LeCoultre or Aston Mar tin authorised
representative, according to the terms of the international
guarantee.
Operation
The transponder system comprises a microsystem housed
on the back of the watch and an antenna. The antenna is built
into the internal surface of the watch’s sapphire crystal (via a
method known as metallisation). Its shape graphically blends
in with the ring and hour‑markers between 4 and 8 o’clock,
ending at these points via vehicle locking control contact
blocks: OPEN to unlock and CLOSE to lock.
Unlike the vertical‑trigger chronograph, which is activated by
turning the case/bezel assembly, activating or deactivating the
locking system does not involve moving the watch case. It is
done by pressing the OPEN and CLOSE zones with a finger.
The transponder range is equivalent to a maximum distance
of around 10 metres between the car and the watch.
C
L
O
S
E
O
P
E
N
AMVOX2 dBs Transponder ‑ English 2/6
Technical specifications
‑ Mechanical automatic movement,
Calibre 751E.
‑ 28,800 vibrations/hour.
‑ Power‑reserve: approximately 65 hours.
‑ Water‑resistant to 5 ATM
Movement
Using the time and chronograph
functions
Starting the watch
Crown in position 1
A few clockwise turns of the crown will suffice to start the
watch. It will then automatically wind up when you wear it.
Please note that the crown does not lock when winding, even
when the watch is fully wound.
Setting the hour and minute
Pull the crown out to position 3.
This locks the movement. The seconds hand will also stop.
Move the hands clockwise up to the desired time and push the
crown back into position 1. The watch will then start running again.
Date setting (fast forward)
Pull the crown out to position 2.
Move the date forward by turning the crown counter‑
clockwise. Perform the required number of turns until the
desired date is displayed in the window.
NB: date correction should not be performed between 10.30
p.m. and 3.30 a.m. During this period the automatic datechange mechanism is already in action.
When the operation is completed, push the crown back into
position 1.
Pushpiece‑free vertical‑trigger chronograph
The AMVOX2 DBS Transponder watch has created a
revolution with its vertical‑trigger chronograph, activated by
tilting the case, and patented by Jaeger‑LeCoultre.
The characteristic pushpieces of the chronograph mechanism
have disappeared. In their place, an ingenious mechanism
allows the chronograph to be started, stopped and reset
by merely pressing directly on the watch’s sapphire crystal.
Pressing the crystal tilts the case on its “chassis” mounting
and, by means of the ingenious transmission levers that form
the heart of the mechanism, activates or deactivates the
chronograph functions.
Jaeger‑LeCoultre Calibre 751E.
123
AMVOX2 dBs Transponder ‑ English 3/6
The chronograph is started and stopped by pressing on the
crystal at 12 o’clock, while the counters are reset by pressing
on the crystal in similar fashion, this time at 6 o’clock.
Operation of the chronograph and timing functions
The central direct‑drive seconds hand of the AMVOX2
DBS Transponder displays the chronograph seconds with an
eighth‑of‑a‑second definition. A counter at 3 o’clock times the
minutes up to 30 minutes (after 1 turn, it continues to count
another 30 minutes). Another counter at 9 o’clock times the
hours up to 12 hours (after one turn, it continues to count
another 12 hours).
‑ The chronograph function is started and stopped by press‑
ing on the crystal at 12 o’clock. Thus, by pressing once on
the crystal at 12 o’clock, the chronograph is activated. The
central direct‑drive seconds hand will turn, and the minute
and hour timing counters will run. Pressing on the crystal
again at 12 o’clock stops the chronograph and enables the
elapsed time to be read.
‑ Pressing on the crystal at 6 o’clock resets the counters
and the central direct‑drive seconds hand. When timing is
in progress, pressing it has no effect.
Note: It is possible to add up several timing results by press‑
ing again on the crystal at 12 o’clock (without resetting the
counters). Timing will restart, added on to the previously
measured time.
Locking the chronograph functions
To prevent any inadvertent use of the chronograph functions,
your AMVOX2 DBS Transponder watch is equipped with a
locking device on the left‑hand flank of the case.
In its central position, you can use all the chronograph functions.
To lock all the chronograph functions (start, stop, reset), push
the locking device upward. If you then press on the crystal at 6
o’clock or 12 o’clock, since tilting movements are limited, all the
chronograph functions are locked.
To lock only the chronograph reset function, e.g. to measure
cumulative times without risking an inadvertent reset, push the
device downward. By pressing on the crystal at 12 o’clock, you
can start and stop timing. However, if you try to press on the
crystal at 6 o’clock, since the tilting movement in this position
is limited, the reset function is locked.
Using the transponder (unlocking and
locking the connected DBS car)
Please consult beforehand the terms of use and the explana‑
tions in the chapter “Built‑in transponder for the DBS” in the
introductory section.
To unlock the vehicle doors, press on the OPEN contact
zone, situated between 8 and 9 o’clock on the watch’s sap‑
phire crystal.
To lock the vehicle doors, press on the CLOSE contact zone,
situated between 3 and 4 o’clock on the watch’s sapphire
crystal.
Please note that these actions do not make any audible signal,
or cause any movement of the sapphire crystal or case.
Start/Stop
Reset
No locking
Locking of Start/Stop/Reset functions
Locking of Reset function
AMVOX2 dBs Transponder ‑ English 4/6
This International Guarantee applies to Jaeger-LeCoultre
products sold or presented for guarantee repairs in all
countries except the United States of America and Canada
(for those two countries, see the Limited Warranty).
The manufacturer’s International Guarantee applies only
to Jaeger‑LeCoultre products purchased from authorised
Jaeger‑LeCoultre retailers. In addition, all maintenance and
repair works must be carried out either by an authorised
Jaeger‑LeCoultre retailer or by an official Jaeger‑LeCoultre
Service Centre. If these conditions are not met, the
manufacturer’s guarantee does not apply. For a list of
authorised Jaeger‑LeCoultre retailers worldwide, please
contact Jaeger‑LeCoultre or its Distributors.
Jaeger‑LeCoultre watches
The terms and conditions of the Jaeger‑LeCoultre
International Guarantee
The following terms and conditions of the Jaeger‑LeCoultre
International Guarantee apply to watches sold or presented
for guarantee repairs in all countries except the United States
of America and Canada (for those two countries, see the
Limited Warranty).
Your Jaeger‑LeCoultre watch is guaranteed against all
manufacturing defects for two years from the date of
purchase, subject to the following conditions.
Any part found by our technical services to be defective as a
result of a manufacturing defect will be, at the sole discretion
of Jaeger‑LeCoultre, repaired or replaced free of charge.
The Jaeger‑LeCoultre International Guarantee is valid only if
the guarantee certificate enclosed with this booklet has been
duly completed, dated, stamped and signed by the authorised
Jaeger‑LeCoultre retailer who sold your watch.
This International Guarantee does not cover defects resulting
from accidents, mishandling or incorrect or abusive use (for
example, knocks, dents, crushing, excessive temperatures,
powerful magnetic fields), the use of or effect of using
batteries other than those designated by Jaeger‑LeCoultre,
unauthorised alteration or repair or the consequences of
normal wear and ageing of the watch, the strap or the glass,
the loss of water resistance after two years after the date
of purchase if your watch is water‑resistant, and any defect
resulting from the contact with water if your watch is not
water‑resistant.
Jaeger‑LeCoultre water‑resistant watches may be identified
by the symbol
engraved on the back. Their water
resistance is guaranteed for two years from the date of
purchase, provided that the glass, the bezel, the back, the
middle part and the crown have not been damaged. It
is essential to have the water resistance checked by an
authorised Jaeger‑LeCoultre retailer or an official Jaeger‑
LeCoultre Service Centre at least once a year, and in any
event, prior to any period of intensive use. Please refer to the
operating instructions for fur ther details.
For quartz watches, this guarantee does not cover the battery
life.
As a consumer, you may have legal rights under applicable
national legislation governing the sale of consumer goods;
those rights are not affected by this guarantee.
Customer service at Jaeger‑LeCoultre
The movement of a mechanical watch requires regular
maintenance (servicing, lubrication, etc.) to ensure a long
operating life. Should your watch need servicing or repairs, please
send it, together with its guarantee certificate, to the authorised
Jaeger‑LeCoultre retailer who sold it to you.
Alternatively, you may send it to one of the official
Jaeger‑LeCoultre Service Centres listed at the end of this booklet,
or to any authorised Jaeger‑LeCoultre retailer of which a list is
available on the «www.jaeger‑lecoultre.com» website.
Our official Service Centres employ watchmakers trained at the
Jaeger‑LeCoultre Manufacture and possess the tools and parts
necessary to repair and maintain all Jaeger‑LeCoultre watches
and clocks. In certain cases, especially for operations requiring
special tools and parts, the Service Centres will send your watch
to the Jaeger‑LeCoultre Manufacture in Switzerland to have the
necessary work carried out.
In any case, or if you live in a country which is not indicated in
our lists, please do not hesitate to contact directly Manufacture
Jaeger‑LeCoultre in Switzerland, Rue de la Golisse 8, 1347 Le
Sentier, telephone +41 21 845 02 02, fax +41 21 845 05 50,
which will inform you of the procedure to follow. We also invite
you to visit our website «www.jaeger‑lecoultre.com» for an
updated list of official Jaeger‑LeCoultre Service Centres.
International Guarantee
AMVOX2 dBs Transponder ‑ English 5/6
The following Limited Warranty applies to Jaeger-LeCoultre
products sold or presented for warranty repairs in the
United States of America and Canada only.
The manufacturer’s Limited Warranty applies only to
Jaeger‑LeCoultre products purchased from authorised
Jaeger‑LeCoultre retailers. In addition, all maintenance and
repair works must be carried out either by an authorised
Jaeger‑LeCoultre retailer or by an official Jaeger‑LeCoultre
Service Centre. If these conditions are not met, the
manufacturer’s Limited Warranty does not apply. For a list
of authorised Jaeger‑LeCoultre retailers worldwide, please
contact Jaeger‑LeCoultre or its Distributors.
Jaeger‑LeCoultre watches
The terms and conditions of the Jaeger‑LeCoultre
Limited Warranty
The following terms and conditions of the Jaeger‑LeCoultre
Limited Warranty apply only to watches sold or presented
for warranty repairs in the United States of America and
Canada.
Your Jaeger‑LeCoultre watch is guaranteed against all
manufacturing defects for two years from the date of
purchase, subject to the following conditions.
Any part found by our technical services to be defective as a
result of a manufacturing defect will be, at the sole discretion
of Jaeger‑LeCoultre, repaired or replaced free of charge.
The Jaeger‑LeCoultre Limited Warranty is valid only if the
warranty cer tificate enclosed with this booklet has been duly
completed, dated, stamped and signed by the authorised
Jaeger‑LeCoultre retailer who sold your watch.
This Limited Warranty does not cover defects resulting
from accidents, mishandling or incorrect or abusive use (for
example, knocks, dents, crushing, excessive temperatures,
powerful magnetic fields), the use of or effect of using
batteries other than those designated by Jaeger‑LeCoultre,
unauthorised alteration or repair or the consequences of
normal wear and ageing of the watch, the strap or the glass,
the loss of water resistance after two years after the date
of purchase if your watch is water‑resistant, and any defect
resulting from the contact with water if your watch is not
water‑resistant.
Jaeger‑LeCoultre water‑resistant watches may be identified by
the symbol
engraved on the back. Their resistance is
guaranteed for two years from the date of purchase, provided
that the glass, the bezel, the back, the middle par t and the
crown have not been damaged. It is essential to have the
water resistance checked by an authorised Jaeger‑LeCoultre
retailer or an official Jaeger‑LeCoultre Service Centre at least
once a year, and in any event, prior to any period of intensive
use. (Please refer to the operating instructions for further
details).
For quartz watches, this warranty does not cover the battery
life.
Except insofar as prohibited by applicable law, this Limited
Warranty shall be the exclusive manufacturer’s warranty.
Neither this Limited Warranty nor any other warranties,
whether express or implied, including, but not limited to,
any implied warranty of merchantability or of fitness for any
particular purpose, shall extend beyond the period of two
years from the date of purchase.
The liability of Jaeger-LeCoultre is limited solely and
exclusively to repair or replacement under the terms and
conditions stated herein. Jaeger-LeCoultre shall not be
liable, by virtue of this Limited Warranty or otherwise, for
any loss or damage arising out of the use of or inability
to use this watch nor for any incidental or consequential
damages relating in any way to this watch. Some States,
Provinces and Territories do not allow limitations on how
long an implied warranty lasts or the exclusion or limitation
of incidental or consequential damages, so the above
limitations or exclusions may not apply to you.
This Limited Warranty grants you specific legal rights, in
addition to which you may have other legal rights which
vary from one Country, State, Province or Territory to
another.
Customer service at Jaeger‑LeCoultre
The movement of a mechanical watch requires regular
maintenance (servicing, lubrication, etc.) to ensure a long
operating life. Should your watch need servicing or repairs,
please send it, together with its warranty certificate, to the
authorised Jaeger‑LeCoultre retailer who sold it to you.
Alternatively, you may send it to one of the official Jaeger‑
LeCoultre Service Centres listed at the end of this booklet,
or to any authorised Jaeger‑LeCoultre retailer of which a list is
available on the «www.jaeger‑lecoultre.com» website.
Our official Service Centres employ watchmakers trained at
the Jaeger‑LeCoultre Manufacture and possess the tools and
parts necessar y to repair and maintain all Jaeger‑LeCoultre
watches and clocks.
In certain cases, especially for operations requiring special
tools and parts, the Service Centres will send your watch to
the Jaeger‑LeCoultre Manufacture in Switzerland to have the
necessary work carried out.
In any case, or if you live in a country which is not indicated
in our lists, please do not hesitate to contact directly
Manufacture Jaeger‑LeCoultre in Switzerland, Rue de la
Golisse 8, 1347 Le Sentier, telephone +41 21 845 02 02,
fax +41 21 845 05 50, which will inform you of the
procedure to follow. We also invite you to visit our website
«www.jaeger‑lecoultre.com» for an updated list of official
Jaeger‑LeCoultre Service Centres.
Limited Warranty
AMVOX2 dBs Transponder ‑ English 6/6
Loading...
