Content
Appendix 1: Printing format
Appendix 2: Exporting data to PC in the form of EXCEL
Appendix 3: U.KEY Conector
1. Introduction …………………………………………………………………….….….1
2. Precaution……………………………………………………....................................1
3. Before Using the Product
3-1 Unpacking and Checking………………………………………………….……….…...1
3-2 Installing Components.……………………………………..……………………….…..1
3-3 Leveling the Scale………………………………………..…………………….….........1
4. Product Introduction
4-1 Specifications & General Features ………………………………………….…………2
4-2 Front Panel …………………………………………………………………….…………3
4-2-1 Display …….……………………………………………………… ………….…….....3
4-2-2 Keyboard…………………………………………………………………….……….....4
4-3 Power Supply……………………………………………………….......…….…….…….5
5. Setting Mode
5-1 Function Setting………………………………………….…………………………….…5
5-2 Parameters………………………………………….……………………………….....…6
6. Single and Multi-point Calibration………………………………….…....…….8
7. Operation
7-1 Weighing………………………………………………………………………………..…9
7-2 Tare & Preset Tare……………………………………………………………….….……9
7-3 Checking function
7-3-1 Upper & Lower Weight Limit Checking ………………………………………..……10
7-3-2 Upper & Lower Quantity Limit Checking ….…………………………………...……11
7-4 Basic Counting
7-4-1 Entering a Known Unit Weight and Unit weight Memory………………….………12
7-4-2 Sample Counting and ACAL………………………………………………………….13
7-5 Accumulation, Accumulation Display and Accumulation Clear………………..........13
7-6 Initialization of the Scale to Printer (Optional)……………………………….……..…14
7-7.The Control from PC to Scale (Optional)…………………………………….……..…15
8. Serial Interface
8-1 RS-232 Connector……………………………………………………………………….15
9. Troubleshooting and Error Message……………………………………...…15
1
1. Introduction
Thank you for choosing purchase a JCN counting scale from Jadever. This scale has the
excellent performance and splendid properties under severe quality management. It is
recommended to read this manual in full before using it for good function application.
2. Precautions
◎ Place the scale on a flat and stable surface. See 3-3 Leveling the Scale for details.
◎ Verify that the input voltage and the plug type matches the local AC power supply. See 4-3
Power Supply.
◎ Warm up the scale for 15 minutes before using it for the first time.
◎ Keep the scale away from EMI noise, strong wind and vibration, which might cause
incorrect reading.
◎ Avoid sudden temperature changes (suitable operating temperature is between 0℃~
40℃.)
◎ Disconnect the power supply when cleaning the scale.
◎ Do not immerse the scale in water or other liquids.
◎ Service should be performed by authorized personnel only.
3. Before Using the Product
3-1 Unpacking and Checking
Open the package and check the instrument for transport damage. Immediately inform your
dealer if you have complaints or if parts are missing. The package should contain:
● Scale body ● User manual
● Weighing pans ● Adaptor
3-2 Installing Components
1) Before using the scale, remove the shipping protection screw (rotate counterclockwise),
which located underneath the scale and cork the plug buckle.
Note: the JCN-30K model was shipped without the shipping protection screw.
2) Cover the weighing pans on the scale body properly.
3-3 Leveling the Scale
To compensate for small irregularities or inclinations at the location, the scale can be leveled.
The scale is equipped with a level indicator at the front panel .Adjust the leveling feet until the
air bubble in the indicator is centered as shown.
Note: The scale should be leveled each time once its location is changed.
2
4. Product Introduction
① Leveler
② Keypad
③ Adjusting feet
④ Plastic weighing pan
⑤ Stainless Steel weighing pan
⑥ On/Off switch
⑦ Transport protection screws
⑧ Power socket
4-1 Specifications & General Features
Specifications
General Features
· Resolution up to 1/15000
· Tare, Preset Tare, auto zero tracking
· Single point and linear calibration available
· HI/OK/LO quantity checking function
· Weighing platter easy to disassemble with dust proof PVC cover
· Low battery and charging status indication
· Accumulation of weight and quantity
· RS 232 port and RELAY port optional for external devices
Model
JCN-3K
JCN-6K
JCN-15K
JCN-30K
Capacity(kg)
3 6 15
30
Weighing units
Kg/g/lb
Display
LED backlit displays (6/5/6 Digits)
Pan size
294 x 228 x 13.5mm
Scale dimensions
330 x 289 x 104mm
Power supply
DC 9v/400mA or rechargeable battery（6V/4A）
3
4-2 Front Panel
4-2-1 Display
1) Low battery indication
2) Tare or Preset Tare indication
3) Center of Zero indicati on. The zeroing range is ±2 ﹪of weighing capacity.
4) Charge Lamp
5) HI Lamp (ON) Indicating parameter item is selected when setting buzz
sounds. (See 5. Function Setting, setting buzz sounds)
OK Lamp (ON) -- Indicating parameter item or is selected when setting buzz
sounds.
LOW Lamp (ON)—Indicating parameter item is selected when setting buzz sounds.
6) ―PRESET TARE” Symbol ― ‖ points at “PRESET TARE” when Tare value entered via
numeric keys.
7) ―NET” Net weight--Gross weight minus Tare. Symbol ― ‖ points at “NET” when TARE or
PRESET TARE action is done.
8) ―STABLE” Stable indication, Symbol ― ‖ appears at the top of “STABLE” when scale
is in stable condition.
9) ―ACAI” Symbol ― ‖ points at “ACAI” when the average unit weight is calculated or
recalculated.
10) ―M+” Symbol ― ‖ points at “M+” when scale is in accumulation mode.
11) “UW” Under entering a known unit weight mode, Symbol ― ‖ points at ―UW” when
entered unit weight is lower than 4/5 of scale division. Unit weight is too small for ensuring
accurate quantity calculations.
12) ―SMPL” Under the sample counting mode, Symbol ― ‖ points at “SMPL” when
calculated unit weight is lower than 4/5 of scale division or the quantity of sample is less
than 10 pieces.
13) “UNIT WEIGHT” Unit Weight Window --Displays the average unit weight value, or
number of weighing.
14) “TOTAL COUNT” Total count window –Displays the calculated number of pieces on the
weighing pan, or accumulated piece count value.
15) “WEIGHT” Weight Window--Displays weight of object on weighing pan, or accumulated
weight value.
4
4-2-2 Keyboard
1) 0 ~9 numeric keys Enter specific values for tare; unit weight and other data entries.
2) ● key Decimal point
3) SMPL key Short press to enter the sampling mode. Long press to close ACAI
after sampling. And shift Units when setting capacity.
4) G N/SET key Shift the displays of Gross weight and Net weight after tare. Long press to
enter parameters setting. And turn on or turn off check weighing when entering HI, LO, OK
setting.
5) UWS/ITEM key Find out the unit weight in memory or reset the unit weight again. Input
the indicated unit weight via numeric keys and press it to start counting function.
6) M+/SAVE key Accumulate the records of counting or weighing. Save the changing
parameter. Set the capacity and resolution.
7) M-/HI key Clear the input figures. Set the value of HI. Enable the blinking figure plus
one when inputting the figures.
8) ZERO/ESC key Zero the display (within 2% of max.capacity) or cancel Tare action.
Exit from the setting without saving.
9) /MR key Recall and display the total Accumulation data (weight, total count and
number of weightments ) and the first 10 records in details. Circle the choices in the
setting. Make the blinking spot shift leftwards when inputting the figures.
10) PRINT/LO key Press the key to print when printing manually is selected. Set the LO
value. Enable the blinking figure decrease one when inputting the figures.
11) TARE/
key Input the weight of the object on the weighing pan as a Tare value ; Inputs
the indicated value entered via the numeric keys as a pre-set Tare value ; cancel tare
action. Display rightwards the first 10 records in detail. Make the blinking spot shift
rightwards when inputting the figures.
5
4-3 Power Supply
Power supply
Please verify the local power source before plugging into the power outlet, and use the
individual power socket and original adaptor.
Alternative power supply
1)（9V/400mA）adaptor
2) (6V/4A) internal rechargeable battery
Power Consumption
About 300mW (without backlight)
About 380 mW (with backlight)
Low battery warning
When ― ‖ appears in the upper left corner of the weight window, the battery power requires
recharging. The charge lamp turns green from red when the recharging is completed (which
takes about 8 hours). Disconnect the scale from power supply when it is fully charged. A full
charged battery can operate the scale for approximately 65 hrs with backlight, 80hrs without
backlight.
Note: Battery is to be replaced only by an authorized service dealer .Risk of explosion can
occur if replaced with the wrong type or connected improperly
5. Setting Mode
5-1 Function Setting
1) Press G N/SET key while powering on
Or long press G N/SET key in the weighing mode to enter parameter setting.
2) Press key
/MR or TARE/
to circle the parameters
3) Press key G N/SET to enter the selected parameter.
4) Press key
/MR or TARE/
to circle the items of present parameter.
5) Press key M+/SAVE to save after changing and return to parameters choosing. While
Press key ZERO/ESC to return without saving.
6) Press key ZERO/ESC again to return to weighing mode.
Note: In the parameter setting mode, press the numeric key to choose the parameter
directly.
6
5-2 Parameters
1) SET00 internal code checking
2) SET01 backlight modes shifting
Options are On, OFF, and AUTO
= Backlight
= No backlight
= Auto-on after getting a stable weigh data or any key is pressed. But auto off after N
seconds (N=2s, 5s, 10s, 20s, ever) with no action.
(ever=the backlight lasts forever with more than 9d placed on the pan) when it is stable.
3) SET02 current using units setting (for weighing window and unit weight window)
options are : kg kg，kg g，g g，lb lb
E.g. When Kg, G is selected, means weighing window current using unit is kg and unit
weight window current using unit is g
How to set current using units?
When parameter SET02 UNIT is selected, press SMPL to choose the desired unit,
press M+/SAVE to save the setting , then press /MR or TARE/ to advance to next
parameter setting.
4) SET03 zero range setting: d0, d1, d2, d3, d4, d5.
d0 (one division) , d1 (2 divisions), d2 (3 divisions), d3 (4 divisions), d4 (5 divisions) and
d5 (6 divisions)
5) SET04 whether to save the upper & lower limit of quantity checking: on, off
OFF = previously set quantity checking values are not retained when the unit is turned on.
ON = previously set quantity checking values are retained when the unit is turned on.
6) SET05 stable weight checking setting: on, off
On: it starts checking weight when the weight and quantity are within the checking range
and the stable symbol appears.
Off: it starts checking weight once the weight and quantity are within the checking range
7) SET06 beep setting: Hi，ok ，Lo，out，no.beep
Hi: There will be a warning sound when the material quantity is more than the upper limit,
and the weight of the material is more than 20 divisions
7
Ok: There will be a warning sound when the quantity of the articles is between the upper
and lower limit (including the upper and lower limits).
Lo: There will be a warning sound when the material quantity is less than the lower limit,
and the weight of the material is more than 20 divisions.
Out: There will be a warning sound when the material quantity exceeds the upper or lower
limits, and the weight of the material is more than 20 divisions
no.beep: No sound alarm.
8) SET07 external equipment setting: PC 、JMS、Godex 、BIRCH、ZEBRA、
GP、DMP、CK 、ET 、CX、U.KEY.
PC: computer output
JMS: connect with weighing system
GODEX: Godex printer （paper size 5cm*3cm）
BIRCH: Birch printer（paper size 5cm*3cm）
ZEBRA: Zebra printer（paper size 5cm*3cm）
GP: Adhesive sticker label printer (paper size 5cmx3cm)
DMP: Dot matrix printer(SH-24)
CK: thermal printer (Chinese available)
ET: Large LED display
CX: CX large screen display (version 0.02)
EXCEL：Work with the function of ―Use Serial Keys‖ in Windows in outputting the data to
Excel. Reference user manual: http://www.jadever.com.cn/Download.aspx
U.KEY: U.KEY connector works with PC to send the weighing data to computer
(WinXP/Win7) in form of Excel and so on.
Note: Special setting is needed by distributor if you want to print in Chinese.
9) SET08 baud rate setting: 9600、4800、2400
10) SET09 printing modes setting: key，stable，contin
contin：Printing continually
stable：Printing automatically when get a stable weight (more than 20d)
key：Printing by pressing keys
11) SET10 printing format setting: prt01~prt03
8
Use the numeric key to set the format directly.
12) SET11 filtering setting: 1，2，3，4
Set the filtering level in which the stable indication turns on .The higher the setting, the
slower stabilization time.
13) SET12 Precondition for zeroing or taring setting: stable, auto, always
stable ：Taring or zeroing can be not action without stable indication after pressing the key
TARE or ZERO
always：Taring or zeroing can be action without stable indication after pressing the key
TARE or ZERO
auto： Press key TARE or ZERO, but it works only when get the stable indication.
14) SET13 weight memory parameter: on，off
On: display the last weight when powering on again
Off: do not display the last weight when powering on again
15) SET14 the kinds of checking: Qty.ck，Wt.ck
Qty.ck: start amount checking
Wt.ck: start weighing checking
16) SET15 parameter initialization
press key G N/SET then key M+/SAVE to start initialization. It is finished when
displaying OK.
6. Single and Multi-point Calibration
Note: Before calibration, please set the capacity first. The unit used in calibration is the one
that has been set before. During the calibration procedure, LONG press ZERO/ESC to
return to normal weighing mode without saving.
Here we take 3kg/0.2g as an example
1. Press and hold TARE/ while powering on.
Do not release it till the window displays ―CAL”
2. With no load on the weighing pan,
press TARE/ to start zero point calibration.
3. Wait till the window displays the first calibration value.
Note: The first calibration value is default. If the value
has been changed, the default value is 1/3 of full load.
9
Note: If you need to change the value, do as the following: Press key G N/SET to enter
the value setting. Press key
/MR or TARE/
to move leftwards or rightwards. Press
key M-/HI or PRINT/LO to modify the value (or via numeric keys). Press key
M+/SAVE to save.
4. Put the corresponding weight on the weighing pan,
and then press TARE/ to complete the first point calibration.
Note: After the first point calibration, the window can display the weight value. If no need
for the other point calibration, move to Step 6 to finish the calibration procedure.
5. Add another weight 500g to the current weight. The window
will show the total weights value. Press TARE/ to complete.
Repeat this step to complete the calibrations of on3, on4 and on5.
6. Press ZERO/ESC to save. After the window displays ― ‖,
It will return to normal weighing mode.
Note: the window displays automatically when on5 is finished. It will be saved and
return to the normal weighing.
7. Operation
7-1 Weighing
Put item to be weighed on the scale. The Weight window shows 1.00kg (Gross Weight).
7-2 Tare & Preset Tare
Tare
When weighing a sample that must be held in a container, tare and store the container weight
into memory.
1) Under the weighing mode, put the container on the scale.
Press the key TARE to complete tare action.
The symbol appears and the window displays as shown on the right
2） Put the item into the container.
Then the window displays the net weight.
10
3） Clear the pan. The window displays the taring weight
That is the weight of container.
4) To cancel tare action, clear the pan and press TARE/ or ZERO/ESC.
Preset Tare
Method 1：
1） Press TARE/ for three seconds, it enters to preset tare setting.
Preset-tare value setting: Press key /MR or TARE/
to shift and key M-/HI or
PRINT/LO to modify the value (or via numeric keys).
Press key M+/SAVE to save and return to weighing mode.
2） Put the items into the container and the weight of container will be tared automatically
from the total weight.
3） To cancel tare action, clear the pan and press TARE/
or ZERO/ESC.
Method 2：
1） Enter the tare value by pressing the numeric botton, the screen will show the tare
value,then press TARE/ :
2） Put the items into the container and the weight of container will be tared automatically
from the total weight.
3） To cancel tare action, clear the pan and press TARE/
or ZERO/ESC.
7-3 Checking function
7-3-1 Upper & Lower Weight Limit Checking
Upper weight limit
1) Long press key M-/HI under the weighing mode.
The number leftmost is blinking.
2) Press key /MR or TARE/
to shift and key M-/HI or PRINT/LO to modify the value
(or via numeric keys)
3) Press key G N/SET to start or close weighing checking
4) Press key M+/SAVE to confirm and save. Press key ZERO/ESC to return to weighing
mode without saving.
Lower limit weight
1) Long press key PRINT/LO under the weighing mode.
The number leftmost is blinking.
11
2) Press key /MR or TARE/
to shift and key M-/HI or PRINT/LO
to modify the value (or via numeric keys)
3) Press key G N/SET to start or close weighing checking
4) Press key M+/SAVE to confirm and save. Press key ZERO/ESC to return to weighing
mode without saving.
Put the sample on the weighing pan.
HI indication appears, when the item on the weighing pan is greater than the upper limit
OK indication appears, when the item on the weighing pan is between upper and lower limits.
LO indication appears, when the item on the weighing pan is smaller than lower limit
Note: the item on the weighing pan should be more than or equal to 20e.
When changing the Hi-Lo value, the scale will activate the weighing checking function
automatically. If the Lo value is higher than Hi value, then the Hi value will become the
same value as Lo data.
7-3-2 Upper & Lower Quantity Limit Checking
Upper Quantity Limit
1） Long press key M-/HI under the weighing mode.
The number leftmost is blinking.
2）Press key
/MR or TARE/
to shift and key M-/HI or PRINT/LO
to modify the value (or via numeric keys)
3）Press key G N/SET to start or close weighing checking
4）Press key M+/SAVE to confirm and save. Press key ZERO/ESC to return to weighing
mode without saving.
Lower Quantity Limit
1) Long press key M-/HI under the weighing mode.
The number leftmost is blinking.
2) Press key /MR or TARE/
to shift and key M-/HI or PRINT/LO
to modify the value (or via numeric keys)
3) Press key G N/SET to start or close weighing checking
4) Press key M+/SAVE to confirm and save. Press key ZERO/ESC to return to weighing
mode without saving.
Put the sample on the weighing pan.
HI indication appears, when the item on the weighing pan is greater than the upper limit
12
OK indication appears, when the item on the weighing pan is between upper and lower limits.
LO indication appears, when the item on the weighing pan is smaller than lower limit
Note: the item on the weighing pan should be more than or equal to 20e.
When changing the Hi-Lo value, the scale will activate the weighing checking function
automatically. If the Lo value is higher than Hi value, then the Hi value will become the
same value as Lo data.
7-4 Basic Counting
7-4-1 Entering a Known Unit Weight
1) Under the weighing mode, use the numeric keys together with key ―·‖ to input unit weight
value, and then press UWS.
2）Put the items on the weighing pan , the scale starts counting.
Note: Symbol ― ‖ points at ―UW‖ when entered unit weight is lower than 4/5 of scale division.
Unit weight Memory
1) When there is one unit weight on the screen, and press UWS/ITEM key.
2) Then enter a number for each unit weight. Use
/MR or TARE/
key to shift and
M-/HI or PRINT/LO key to modify the value (or via numeric keys)
3) Press key M+/SAVE to confirm and save. Press key ZERO/ESC to return to weighing
mode without saving.
Note: the maximum unit weight memory could up to 20pcs (00-19).
Unit weight Calling-out
1) Press UWS/ITEM key. The window displays as shown on the right
(Press M-/HI to clear the value in the unit price screen firstly)..
2) Input the number of unit weight. Press key
/MR or TARE/
to shift and key M-/HI or
PRINT/LO to modify the value (or via numeric keys)
3) Press key M+/SAVE to confirm called-out weight and return to the weighing mode. Press
key ZERO/ESC to exit and return to weighing mode.
13
7-4-2 Sample Counting and ACAL
Sample Counting
1) Place samples onto the weighing pan (or into a tared container) and input the quantity
with numeric keys, then press key SMPL.
The unit weight is calculated, with Symbol ― ‖ pointing at ―ACAI‖.
Note:
●The larger the sample size, the more accurate unit weight.
●Symbol ― ‖ points at ―SMPL‖ when calculated unit weight is lower than 4/5 of scale
division or the quantity of sample is less than 10 pieces.
2) Remove the samples and put the load on, the scale begins to count.
3) Press key M-/HI to exit and return to the weighing mode.
ACAI
Automatic Counting Accuracy Improvement (ACAI) results in a more accurate count by
increasing the reference weight without the need to count additional parts. A higher reference
weight is important when there is a risk of inconsistent piece weights or if the reference weight
is close to the minimum. ACAI uses an initial averaging unit weight to count additional pieces
that are placed on the scale. After a few seconds, the scale gives a beep as the new higher
reference weight is used to recalculate the averaging unit weight. The process can be
repeated as long as the additional weight is less than the previous reference weight. Once
this limit is exceeded, ACAI is turned off.
Manual ACAI closing: ACAI acts automatically after sampling when ACAI indication appears.
Long press SMPL key to turn off ACAI when ACAI indication disappears. ACAI re-acts when
sampling again.
→
7-5 Accumulation, Accumulation Display and Accumulation clear
Accumulation
1) Enter the indicated unit weight, press key UWS/ITEM and put first piece of load on the
weighing pan (or into a tared container). (Refer to 7-4-1 and 7-4-2)
2) Press key M+/SAVE, the first accumulation event is displayed momentarily before
14
Symbol ― ‖ pointing at “M+”. The display reverts to normal
weighing mode in a second .Remove the first piece
3) Put the second piece of load on, and then press key M+/SAVE to add the second
accumulation event into memory. Repeat step 2-3 till accumulation actions are finished.
Note: Maximum is 99 pieces. It is able to calculate the second deal when returning to zero
after the first one under the condition of more than (or equal to) 20d with stability. Minus weight
and gross weight can’t be accumulated. After resetting the sample value or unit weight, the
quantity accumulated will be adjusted automatically according to the new setting value.
Accumulation display
1) Press key
/MR to displays the total accumulation data (weight, quantity and number of
weighments)
2) Press key
/MR or TARE/
to check the total events and
the first 10 accumulation events in detail.
3) When connecting PC, printer DMP or CK, press PRINT/LO to output the events
Note：① XX=total accumulation events； XX=the single accumulation
Accumulation clear
To clear the total accumulation data or the first 10 accumulation events, press key
/MR or
TARE/ to shift the events and then press key M-/HI to clear. Symbol ― ‖ disappears
when the total accumulation data is deleted.
7-6 Initialization of the Scale to Printer (Optional)
Step 1
Press G N/SET key while powering on or long press G N/SET key in the
weighing mode to enter parameter setting. Press key
/MR or TARE/
to circle
the parameters and select SET08 。
Step 2
Press G N/SET to enter the external equipment choosing. Press key
/MR or
TARE/
to select the type of printers. Press G N/SET to start initialization.
The window of unit weight displays the type of printer. And the window of total
amount displays UNSU or init？。
15
Step 3
When UNSUP appears, it means the printer can’t be initialized. Press key
ZERO/ESC to return to the printer choosing. It needs to be initialized when init?
appears. Press key M+/SAVE to start initialization or press key ZERO/ESC to
return to the printer choosing without initialization. It displays ok when initialization
is finished and shows the type of printer after one second. Go further to other
parameter setting or press key ZERO/ESC to return to weighing mode.
7-7.The Control from PC to Scale (Optional)
Step 1
Connect the indicator and computer.
Step 2
Open the serial port to modify. Input the letters Z, T, C , R and P in the sending
window and press key Send again. The scale can conduct the responding
function. Z= Zero, T=Tare, R and P=Printer, C=Cancel Tare.
8. Serial Interface
If external interface is needed, please select the proper RS 232 board firstly, and only when
this board is adopted, the functions can be enabled.
Note: RTC is unavailable.
8-1 RS-232 connector
9. Troubleshooting and Error message
Error
Message
Problem
Solution
ERR0
Exceed the zero range
The item on the pan should be within 2% of
full load.
ERR1
Model setting error. Resolution
should be within 300-300000
Adjust or reset the capacity first then adjust
resolution
16
Appendix 1 BIRCH/GODEX/ZEBRA/GP printing format
Prt-01 Prt-02
Prt-03
CK、DMP printing format
Prt-01 Prt-02
ERR2
Initial zero point exceeds 30% of full
load
1.Remove the obstacle article under the pan
2.Replace the load cell or contact the
maintenance department.
ERR3
Exceed the A/D resolution range
1. Replace A/D
2..Replace the load cell or contact the
maintenance department.
ERR4
EEPROM Chksum failure
Re-weld EEPROM or contact the
maintenance department.
ERR5
Overload condition
Remove the overload item
ERR6
Exceeds the display range
-----------------------------------------------
ERR7
Accumulated number of
weighments exceeds the display
range
Delete the exceeding weights
ERR8
Weight limit value is higher than the
full load value
Reset the weight limit value.
ERR9
Exceed tare or pre-tare range
0＜Tare value≤ full load
ERR10
Wrong calibration weights
Place the right test weights and the
calibration value should be below full load.
N.W.: 0.500 kg
U.W.: 0.0500 kg/pcs
Total: 10pcs
0.500 kg
10 pcs
10 pcs
0.500 kg
17
Prt-03(printing in English) Prt-03（CK printing in Chinese）
When the window of unit weight shows , the printing format of accumulation display
is as follows
NOTE:
The printing sample could be of different kinds of formats. When there is specific demand
about the format, conduct as follows
1) As for BRICH/GODEX/ZEBRA/GP printers, the factory designs the format as planned and
email to the user. Add the format into the previous format file via computer. Then it is
successful to add the new format and able to print the new format.
2) As for DMP and CK printers, it needs to change the scale design
Appendix 2：Exporting data to PC in the form of EXCEL
Introduction:
Connect the scale with PC and set the parameter of external device as ―EXCEL‖ on the scale,
then you could export the weighing data to PC in the form of EXCEL. With this function, you
could record/accumulate/average/data statistical analysis the testing data, which we could
call it as scale-computer data management function.
Note: pls enable ―Use Serial Keys‖ function in the computer.
Hardware connection and settings
1. Use transmitting serial wire or USB wire to connect scale and pc.
Note: pls install usb driver first, if you use usb wire.
2. Parameter settings in scale:
N.W.:
0.500 kg
U.W.:
0.0500 kg/pcs
Total:
10 pcs
N.W.:
0.500 kg
U.W.:
0.0500 kg/pcs
Total:
10 pcs
(01) 1.000 kg
20 pcs
(02) 1.000 kg
20 pcs
(03) 1.000 kg
20 pcs
---------------------(03) 3.000 kg
60 pcs
18
"PERI" = "EXCEL" (external device)
"BAUD" = "2400"/"4800"/"9600" (baud rate)
"PRT.M" = "KEY"/"STABLE" (printing model)
"PRT.F" = "PRT.F01" (printing format)
Enable the function of “Use Serial Keys” in the computer
Set Windows XP as a example:
1. Press ―Start‖ ->"Run", and enter ―access.cpl‖ ->‖OK‖.
2. In the dialog box ‖Accessibility Options‖, enter General option, choose ―Use Serial Keys‖
and press ―Settings‖.
In the dialog box ‖Settings for SerialKeys‖ , set the corresponding Serial port and Baud
rate, which should be same as Baud rate in scale.
3. Test if Serial Keys works well.
Open a Text Document, and press the Print buotton on the scale. The Serial Keys works
well, if pc exports the weighing data to Text.
Export weighing data to Excel
1． Open Excel.
2． Press [Print], then Excel will show Date and Weighing data.
19
3. Use ―Format Cells‖ to beautify Excel:
Troubleshooting
1. Enable ―Fast User Switching‖ function will disable ―Use Serial Keys‖ in the computer.
Note: Start->"Control Panel "->"User Account"-> ―Fast User Switching‖ function.
2. The data export requires only ―GND+RX+TX‖ three lines, while some wire include nine
lines (including usb 9-25pin adapter), which may cause abnormal function.
Note: cut other useless line to check if these three lines work well.
Appendix 3：U.KEY Connector
一、Introduction
Connect the scale with PC and set the parameter of external device as ―U.KEY‖ on the
scale, then you could export the weighing data to PC in the form of EXCEL. With this function,
you could record/accumulate/average/data statistical analysis the testing data, which we
could call it as scale-computer data management function.
Most importantly, you don’t need any setup in computer, but only use U.KEY connector to
link computer system directly, such as EXCEL, Express System, ERP system and so on. This
connector is compatible with windows2000/xp/Vista/win7/win8/Linux/Android system, and the
weighing data will show on the position where the mouse cursor in.
With one USB port, you could connect scale to computer easily.
二、Precaution
1.Close the input method program before connecting.
2.Ensure the decimal point digit is same as the parameter setting of scale, if use EXCEL file in
computer.
20
For Example:
Scale shows: Total Weight: 1.000KG 、Unit Weight: 0.001g、Total: 1000PCS
EXCEL Setting: the decimal point digit should be 3 for total weight and unit weight column,
and the decimal point digit should be 0 for total column.
三、Setting
1．Prepare one computer with windows2000/xp/Vista/win7/win8/Linux system or Android pad.
2. Scale setting:
"PERI" = "U.KEY" (External devices)
"BAUD" = "9600" (Baud)
"PRT.M" = "KEY"/"STABLE" (Print Mode)
"RTC" ="ON"/"OFF" (Time)
3. Open the receiving port such as EXCEL or ECR system, and the weighing data will show
on the position where the mouse cursor in
四、Example：
1. EXCEL：
2.ERP System:
Loading...
