fresco
From the Italian phrase “buon fresco”—“really fresh”—comes the fresco® pure air® ll bath, a truly refreshing experience.
pure air® ll bath
Like its namesake, the Fresco® is pure art.
features:
• Exclusive 360º Balanced Airfl ow™ system
• 800 watt variable speed heated air blower
• Thermal Lumbar Comfort (TLC)™
• Timed purge cycle
• Safely use salts and aromatic oils
™
• PrO
Cleansing System
3
fresco
®
pure air
®
ll bath
model number: Y950
exterior dimensions:
71½" long x 42" wide x 27¼" high
interior dimensions:
47" long x 25" wide
operating gallons:
60 gallons
Detail: The Fresco® Pure Air® ll bath’s high-backed
design cradles the neck and shoulders, while a
handrail adds safety.
Ordering Information
Product Code:
Y950 Fresco® Pure Air® II Bath
Right Hand
Fresco® Pure Air® II Bath
Model: Y950
Installation Notes
Refer to installation instructions included with fi xture before beginning installation.
Please confi rm product availability and specifi cations before commencing with any
installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
• Center Drain Location
• Accessories / Hardware:
Trim Kit Rotary: #BN21
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(845) – Oil Rubbed Bronze
42"
2"
Blower
12" x 4"*
12" H x 18" L
Service Access
Technical Specifi cations
Dimensions
71-1/2” L x 42” W x 27-1/4” H
(1816 mm) L x (1067 mm) W x (692 mm) H
Drain/Overfl ow
A: 20-1/8” (511 mm) B: 11-3/4” (299 mm)
Cutout
Template Provided: P/N P188000
Total Weight
921 lb (418kg) / 44 lb/sq. ft. (215 kg/m2)
Operating Gallonage
60 U.S. Gal. (227 Liters)
Product Weight
146 lb (66 kg)
Skirt Mounting
Not Available
Electrical Specifi cations
Requires a dedicated GFCI protected separate circuit.
Blower: 120 VAC, 15 AMP, 60 Hz.
Heater
No water heater is available on this unit. Blower has integral air heater.
1 1-3/4"
36"
71-1/2"
Product Shown: Fresco® Pure Air® II Bath Right Hand Shown Model: Y950
* Measurements inside unit represent cutout in fl oor to allow for drain/overfl ow.
Minimum Service Access dimensions given.
L
H
SIDE VIEW
#FR41 07/07
© Jacuzzi Whirlpool Bath • 14880 Monte Vista Avenue • Chino • CA • 91710 • www.jacuzzi.com
7-1/2"
(19 cm)
2"
(51 mm)
END VIEW
W
A
(Blower)
B
DRAIN/OVERFLOW
