tara™ whirlpool bath and soaking bath with integral skirt
like the fabled Irish tower of kings that shares its name, the tara™ whirlpool bath is itself a singularly regal experience in an everyday world.
Cozy up to the Tara™ whirlpool bath’s
corner configuration and linger as you
massage away the cares of the day.
features:
• 4 Fully adjustable TheraPro™ jets
• 2 Directionally adjustable AccuPro™ lumbar jets
• 1 Directionally adjustable AccuPro™ foot jet
• Exclusive Tru-Level™ base system
• Slip-resistant bottom
• Patented Silent Air™ Induction system
• Integral skirt
• Drain included on whirlpool baths
Detail: The Tara™ whirlpool bath places Jacuzzi‘s
Magic Touch® controls right in reach. Perfectly
positioned AccuPro™ jets massage away cares as
you recline against Tara‘s backrest.
tara™ whirlpool bath
with integral skirt
model number: N820 RH Pump
exterior dimensions:
60" long x 60" wide x 20¾" high
interior dimensions (at bottom):
45" long x 40" wide
# of Jets/type of Jets:
4 TheraPro™ Jets,
2 AccuPro™ Lumbar Jets,
1 AccuPro™ Foot Jet
operating gallons:
74 gallons
tara™ soaking bath
with integral skirt
model number: N821
exterior dimensions:
60" long x 60" wide x 20¾" high
interior dimensions:
45" long x 40" wide
Tara™ Corner Whirlpool Bath w/Integral Skirt
- 2" x 4" Stud
- Junction Box
27-1/4"
35"
44"
60"
60"
46"
27-1/4"
35"
14" x 4"
Motor
1"
H
FRONT VIEW
SIDE VIEW
DRAIN/OVERFLOW
A
B
Model: N820
Tara™ Corner Bath with Integral Skirt
Model: N821
Installation Notes
Ordering Information
Product Code:
N821 Tara™ Corner Bath
w/Integral Skirt
N820 Tara™ Corner Whirlpool Bath
w/Integral Skirt Right Hand
• Center Drain Location
• Accessories / Hardware:
Trip-Lever Drain Kit #X559
Rotary Drain Kit, 26” Cable #8730
4 X HTC Jet Trim Kit: #D095
2 X BMH Jet Trim Kit: #J869
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(849) – Oil Rubbed Bronze
Refer to installation instructions included with fixture before beginning installation.
Please confirm product availability and specifications before commencing with any
installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
Electrical Components and Electrical Specifications do not apply to non-jetted baths.
Technical Specifications
Dimensions
60” L x 60” L x 20-3/4” H
(1524 mm) L x (1524 mm) L x (527 mm) H
Drain/Overflow
A: 16” (406 mm) B: 12-3/8” (314 mm)
Cutout
NA
Total Weight
N820: 999 lb (453 kg) / 40 lb/sq. ft. (195 kg/m2)
N821: 957 lb (434 kg) / 38 lb/sq. ft. (187 kg/m2)
Operating Gallonage
74 U.S. Gal. (280 Liters)
87 U.S. Gal. (329 Liters)
Product Weight
N820: 133 lb (60 kg)
N821: 91 lb (41 kg)
Skirt Mounting
Integral
Electrical Specifications Model N820 only
Requires a dedicated GFCI protected separate circuit.
Motor/Pump: 120 VAC, 15 AMP, 60 Hz.
RapidHeat™: 120 VAC, 15 AMP, 60 Hz.
Heater (Optional) Model N820 only
Requires a dedicated GFCI protected separate circuit.
RapidHeat™: P/N S750000
Product Shown: Tara™ Corner Whirlpool Bath with Integral Skirt Model: N820
* Measurements inside unit represent cutout in floor to allow for drain/overflow.
#FS27 12 /06
© Ja cuzzi Whir lpool Bath • 14801 Quorum Drive • Dallas • Texas • 75254 • www.jacuz zi.co m
