tara™ pure air® II bath
like the fabled Irish tower of kings that shares its name, the tara™ pure air® II bath is itself a singularly regal experience in an everyday world.
Cozy up to the Tara™ whirlpool bath’s
corner configuration and linger as you
massage away the cares of the day.
features:
• Exclusive 360º Balanced Airflow™ system
• 600 watt variable speed heated air blower
• Thermal Lumbar Comfort™ (TLC)
• Timed purge cycle
• Safely use salts and aromatic oils
• PrO3™ Ozone Sanitation System standard
Detail: The Tara™ Pure Air II bath places
Jacuzzi‘s Magic Touch® controls right in reach.
Perfectly positioned AccuPro™ jets massage away
cares as you recline against Tara‘s backrest.
tara™ pure air® II bath
with integral skirt
model number: EB10 RH Pump
exterior dimensions:
60" long x 60" wide x 20¾" high
interior dimensions (at bottom):
45" long x 40" wide
operating gallons:
71 gallons
Ordering Information
- Junction Box
27-1/4"
35"
44"
60"
60"
46"
27-1/4"
35"
14" x 4"
Blower
1"
(25 mm)
20-3/4"
FRONT VIEW
SIDE VIEW
DRAIN/OVERFLOW
A
B
Tara™ Corner Pure Air® II Bath w/Integral Skirt
Model: EB10
Installation Notes
Refer to installation instructions included with fixture before beginning installation.
Please confirm product availability and specifications before commencing with any
installation work.
Product Code:
EB10 Tara™ Corner Pure Air® II Bath
w/Integral Skirt Right Hand
• Center Drain Location
• Accessories / Hardware:
Trip-Lever Drain Kit #X559
Rotary Drain Kit, 26” Cable #8730
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(849) – Oil Rubbed Bronze
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
Technical Specifications
Dimensions
60” L x 60” L x 20-3/4” H
(1524 mm) L x (1524 mm) L x (527 mm) H
Drain/Overflow
A: 16” (406 mm) B: 12-3/8” (314 mm)
Cutout
NA
Total Weight
1176 lb (535 kg) / 47 lb/ft2 (229 kg/m2)
Operating Gallonage
71 U.S. Gal. (269 Liters)
Min. 55 U.S. Gal. (208 liters)
Max. 87 U.S. Gal. (329 liters)
Product Weight
154 lb (70 kg)
Skirt Mounting
Integral
Electrical Specifications
Requires a dedicated GFCI protected separate circuit.
Blower: 120 VAC, 15 AMP, 60 Hz.
Heater
No water heater is available on this unit. Blower has integral air heater.
Product Shown: Tara™ Corner Pure Air® II Bath with Integral Skirt Model: EB10
* Measurements inside unit represent cutout in floor to allow for drain/overflow.
#FS25 12/06
© Jacuzzi Whirlpool Bath • 14801 Quorum Drive • Dallas • Texas • 75254 • www.jacuz zi.co m
