Jacuzzi P4510, P4515 User Manual

DESIGNER/LUXURY BATH SERIES

INSTALLATION / OPERA TION INSTRUCTIONS

Save These Instructions for Future Use.

Complete and mail-in the product registration card provided with your unit.

Write and save the model and serial number of your unit below.

Owner's Record

Date Purchased ____________________________________________________________

Purchased From ____________________________________________________________

Installed By ________________________________________________________________

Serial Number _____________________________________________________________

Model ____________________________________________________________________

Installer: Leave this manual for homeowner.

Homeowner: Read this manual and keep for future reference.

2005 Jacuzzi Whirlpool Bath K339000X 3/06

IMPORTANT SAFETY INSTRUCTIONS

READ AND FOLLOW ALL INSTRUCTIONS

SAVE THESE INSTRUCTIONS

ENGLISH

INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC

SHOCK, OR INJURY TO PERSONS

WARNING — WHEN USING THIS UNIT, BASIC PRECAUTIONS SHOULD AL WAYS BE FOLLOWED, INCLUDING THE FOLLOWING:

DANGER: — TO REDUCE THE RISK OF INJURY, DO NOT PERMIT CHILDREN TO USE THIS UNIT

UNLESS THEY ARE CLOSEL Y SUPERVISED A T ALL TIMES. WARNING — USE THIS UNIT ONL Y FOR ITS INTENDED USE AS DESCRIBED IN THIS MANUAL. DO

NOT USE ATTACHMENTS NOT RECOMMENDED BY THE MANUFACTURER.

WARNING — NEVER DROP OR INSERT ANY OBJECT INTO ANY OPENING . WARNING — DO NOT OPERATE THIS UNIT WITHOUT THE GUARD OVER THE SUCTION FITTING. WARNING — THIS UNIT MUST BE CONNECTED ONLY TO A SUPPLY CIRCUIT THAT IS PROTECTED

BY A GROUND FAULT CIRCUIT INTERRUPTER (GFCI). SUCH A GFCI SHOULD BE PROVIDED BY THE INSTALLER AND SHOULD BE TESTED ON A ROUTINE BASIS. TO TEST THE GFCI, PUSH THE TEST BUTTON. THE GFCI SHOULD INTERRUPT POWER. PUSH THE RESET BUTTON. POWER SHOULD BE RESTORED. IF THE GFCI FAILS TO OPERATE IN THIS MANNER, THE GFCI IS DEFECTIVE. IF THE GFCI INTERRUPTS POWER TO THE BATHTUB WITHOUT THE TEST BUTTON BEING PUSHED, A GROUND CURRENT FLOWING, INDICATING A POSSIBILITY OF AN ELECTRIC SHOCK. DO NOT USE THIS HYDROMASSAGE BATHTUB. DISCONNECT THE HYDROMASSAGE BATHTUB AND HAVE THE PROBLEM CORRECTED BY A QUALIFIED SERVICE REPRESENTATIVE BEFORE USING.

WARNING — (FOR PERMANENTLY CONNECTED UNITS) A GREEN COLORED TERMINAL (OR A WIRE CONNECTOR MARKED “G”, “GR”, “GROUND”, OR “GROUNDING”) IS PROVIDED WITHIN THE TERMINAL COMPARTMENT. TO REDUCE THE RISK OF ELECTRIC SHOCK, CONNECT THE TERMINAL OR CONNECTOR TO THE GROUNDING TERMINAL OF YOUR ELECTRIC SERVICE OR SUPPLY PANEL WITH A CONDUCTOR EQUIVALENT IN SIZE TO THE CIRCUIT CONDUCTORS SUPPLYING THIS EQUIPMENT.

OPERATING

WARNING — PROLONGED IMMERSION IN HOT WATER MAY INDUCE HYPERTHERMIA. HYPER-

THERMIA OCCURS WHEN THE INTERNAL TEMPERA TURE OF THE BODY REACHES A LEVEL SEV ERAL DEGREES ABOVE THE NORMAL BODY TEMPERATURE OF 98.6°F. THE SYMPTOMS OF HYPERTHERMIA INCLUDE AN INCREASE IN THE INTERNAL TEMPERATURE OF THE BODY, DIZZINESS, LETHARGY, DROWSINESS AND FAINTING. THE EFFECTS OF HYPERTHERMIA INCLUDE:

A) FAILURE TO PERCEIVE HEAT B) FAILURE TO RECOGNIZE THE NEED TO EXIT THE SPA OR HOT TUB, C) UNAWARENESS OF IMPENDING HAZARD, D) FETAL DAMAGE IN PREGNANT WOMEN, E) PHYSICAL INABILITY TO EXIT THE SPA OR HOT TUB, AND

F) UNCONSCIOUSNESS RESULTING IN DANGER OF DROWNING. WARNING — THE USE OF ALCOHOL, DRUGS OR MEDICATION CAN GREATLY INCREASE THE RISK OF FATAL HYPERTHERMIA. WARNING — DO NOT TAMPER WITH USER-OPERATED CONTROLS OR SUCH DEVICES.

Jacuzzi Whirlpool Bath K339000X 3/06

INST ALLATION INSTRUCTIONS

WARNING — WHEN USING THIS UNIT, BASIC PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING: DANGER — RISK OF ELECTRIC SHOCK. CONNECT ONLY TO A CIRCUIT PROTECTED BY A GROUND

FAULT CIRCUIT INTERRUPTER (GFCI). CAUTION — TEST THE GROUND FAULT CIRCUIT INTERRUPTER PROTECTING THIS APPLIANCE PERIODICALLY IN ACCORDANCE WITH MANUFACTURER’S INSTRUCTIONS. WARNING — USE THIS UNIT ONLY FOR ITS INTENDED USE AS DESCRIBED IN THIS MANUAL. DO NOT USE ATTACHMENTS NOT RECOMMENDED BY THE MANUFACTURERS.

WARNING — TO AVOID INJURY, EXERCISE CAUTION WHEN ENTERING OR EXITING THE HYDROMASSAGE BATHTUB. WARNING — KEEP BODY AND HAIR A MINIMUM OF 6" (15,2 cm) AWAY FROM SUCTION FITTING AT ALL

TIMES WHEN THE HYDROMASSAGE SYSTEM IS OPERATING. HAIR LONGER THAN SHOULDER LENGTH SHOULD BE SECURED CLOSE TO THE HEAD. WARNING — RISK OF ELECTRICAL SHOCK; DO NOT PERMIT ELECTRICAL APPLIANCES (SUCH AS HAIR DRYER, LAMP, TELEPHONE, RADIO OR TELEVISION) WITHIN 60" (1,5 M) OF THIS HYDROMASSAGE BATHTUB. WARNING — RISK OF ACCIDENTAL INJURY OR DROWNING; DO NOT USE DRUGS OR ALCOHOL BEFORE OR DURING THE USE OF HYDROMASSAGE BATHTUB EQUIPPED WITH A HEATER TO AVOID UNCONSCIOUSNESS AND POSSIBLE DROWNING. WARNING — RISK OF FETAL INJURY; PREGNANT OR POSSIBLY PREGNANT WOMEN SHOULD CONSULT A PHYSICIAN BEFORE USING A HYDROMASSAGE BATHTUB EQUIPPED WITH A HEATER. WARNING — RISK OF HYPERTHERMIA AND POSSIBLE DROWNING; DO NOT USE A HYDROMASSAGE BATHTUB EQUIPPED WITH A HEATER IMMEDIATELY FOLLOWING STRENUOUS EXERCISE. WARNING — RISK OF HYPERTHERMIA AND POSSIBLE DROWNING; WATER TEMPERATURE IN EXCESS OF 104°F (40°C) MAY BE INJURIOUS TO YOUR HEALTH. CHECK AND ADJUST WATER TEMPERATURE BEFORE USE. WARNING — RISK OF HYPERTHERMIA; PEOPLE USING MEDICATIONS AND/OR HAVING AN ADVERSE MEDICAL HISTORY SHOULD CONSULT A PHYSICIAN BEFORE USING A HYDROMASSAGE BATHTUB EQUIPPED WITH A HEATER.

ENGLISH

FOR BUILT-IN AND DROP-IN UNITS, INSTALL TO PERMIT ACCESS FOR SERVICING.

THIS UNIT SHOULD BE ELECTRICALLY GROUNDED AND INSTALLED BY A LICENSED CONTRACTOR, ELECTRICIAN, AND PLUMBER.

BUILDING MATERIALS AND WIRING SHOULD BE ROUTED AWAY FROM THE MOTOR/PUMP OR BLOWER OR OTHER HEAT PRODUCING COMPONENTS OF THIS UNIT.

A PRESSURE WIRE CONNECTOR IS PROVIDED ON THE EXTERIOR OF THE MOTOR/PUMP AND HEATER TO PERMIT CONNECTION OF AN NO. 8 AWG (8.4 MM) SOLID COPPER BONDING CONDUCTOR BETWEEN THIS UNIT AND ALL OTHER ELECTRIC EQUIPMENT AND EXPOSED METAL IN THE VICINITY, AS NEEDED TO COMPLY WITH LOCAL REQUIREMENTS.

PRECAUTIONS

••

• Do not operate the hydromassage system unless the bath is filled with water to at least 1" to 2" (2,5 - 5,08 cm) above the

••

highest jet.

••

• Do not immerse the control panel by overfilling the bath.

••

• Do not use oil-based bath additives in your hydromassage bath.

••

• When cleaning your bath, do not use abrasive substances which will damage the bath's surface.

••

• To prevent discoloration of the acrylic finish, do not fill the bath with water in excess of 140°F (60°C).

••

NOTE: This is a professional grade product. A knowledge of construction techniques, plumbing and electrical installation according to codes are required for proper installation and user satisfaction. W e recommend that a licensed contractor perform the installation of all Jacuzzi Whirlpool Bath products. Our warranty does not cover improper installation related problems.

PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.

USE INSTALLATION INSTRUCTIONS SUPPLIED WITH PRODUCT.

The Company has obtained applicable code (standards) listings generally available on a national basis for products of this type. It is the responsibility of the installer/owner to determine specific local code compliance prior to installation of the product. The Company makes no representation or warranty regarding, and will not be responsible for any code compliance.

Jacuzzi Whirlpool Bath K339000X 3/06

CONTENTS

Safety Instructions _____________________________________________________________________ 2-3 Contents _____________________________________________________________________________ 4 Specifications _________________________________________________________________________ 5-8

ENGLISH

Roughing-in Reference _________________________________________________________________ 9-13 Installations Instructions _________________________________________________________________ 14-19

Framing and Support _________________________________________________________________ 14 Service Access ______________________________________________________________________ 15 ALLUSION Installation ________________________________________________________________ 16-17 Electrical Connections _________________________________________________________________ 18

Plumbing and Water Supply ____________________________________________________________ 19 Clean Up Af ter Installation _______________________________________________________________ 19 Operating Instructions __________________________________________________________________ 20-22 Maintenance Instructions ________________________________________________________________ 23-24 General Troubleshooting Guide ___________________________________________________________ 25 Authorized Service _____________________________________________________________________ 26 Warranty _____________________________________________________________________________ 27-28

NOTE: If you need a referral for a service company near you, or need assistance with operation or maintenance related questions, please call our Service Support Department at 1-800-288-4002. Visit our web site at http:// www.jacuzzi.com/ for products and services. To find service agent listings for:

Electrical or Mechanical Repairs visit http://jacuzzi.com/pdf/ASA.PDF Finish, Surface, or Shell-Related Repairs visit http://jacuzzi.com/pdf/AFC.PDF Repair Parts or Accessories visit http://jacuzzi.com/pdf/MPD.PDF

Jacuzzi Whirlpool Bath K339000X 3/06

SPECIFICATIONS

)

Important: Read complete instructions before beginning installation.

Each whirlpool bath arrives ready for installation, completely equipped with motor/pump assembly , heater , plumbing, and fittings necessary for whirlpool operation. An optional drain/overflow kit is available for installation on the bath.

Remove the bath from the carton. Retain the shipping carton until satisfactory inspection of the product has been made. Do not lift the bath by the plumbing at any time; handle by the shell only.

Immediately upon receipt, inspect the shell before installing. Should inspection reveal any damage or defect in the finish, do not install the bath. Damage or defect to the finish claimed after the bath is installed is excluded from the warranty . Jacuzzi Whirlpool Bath's responsibility for shipping damage ceases upon delivery of the products in good order to the carrier. Refer any claims for damage to the carrier . For definitions of warranty coverage and limit ations, refer to the published warranty information packed with the product.

All bath units are factory tested for proper operation and watertight connections prior to shipping. NOTE: Prior to

installation, the bath must be filled with water and operated to check for leaks that may have resulted from shipping damage or mishandling. Jacuzzi Whirlpool Bath is not responsible for any defect that could have been

discovered, repaired, or avoided by following this inspection and testing procedure.

(102 mm)

(Heater)

(51 mm)

SIDE VIEW

MAX 1"

(Motor)

END VIEW

DRAIN/OVERFLOW

ALLUSION

ENGLISH

(51 mm)

SIDE VIEW

(Heater)

SIDE VIEW

(Heater)

SIDE VIEW

(Heater)

(Motor)

ELARA

MAX. 1/2"

(Motor)

BELLAVISTA

MAX. 1/2"

END VIEW

(51 mm)2"

(Motor)

SABELLA

END VIEW

1/2"

(13 mm

(25 mm)

(51 mm)

(Heater)

(Motor)

MAX. 1/2"

END VIEW SIDE VIEW

CIPREA™, Right Hand

(Heater)

(Motor)

SIDE VIEW

MAX. 1/2"

END VIEW

REÁL™, Right Hand

(Heater)

(51 mm)

SIDE VIEW END VIEW

(Motor)

MAX. 1/2"

TORRETTA 36

(51 mm)

Jacuzzi Whirlpool Bath K339000X 3/06

SPECIFICATIONS

SPECIFICATIONS (Rectangular) LH = Left Hand, RH = Right Hand

ENGLISH

MODEL

ALLUSION™ 6636

ALLUSION™ 7236

RH ALLUSION™

7242

BELLAVISTA™ 5

BELLAVISTA™

5.5

BELLAVISTA™ 6

CIPREA™

ELARA™ 6042

LH & RH

ELARA™ 6636

LH & RH

ELARA™ 7242

LH & RH

REÁL™

SABELLA™

TORRETTA™ 36 72" (1829 mm) L

66" (1676 mm) L 36" ( 914 mm) W 26" ( 660 mm) H

72" (1829 mm) L 36" ( 914 mm) W 26" ( 660 mm) H

72" (1829 mm) L 42" (1067 mm) W 26" ( 660 mm) H

60" (1524 mm) L 42" (1067 mm) W 26" ( 660 mm) H

66" (1676 mm) L 42" (1067 mm) W 26" ( 660 mm) H

72" (1829 mm) L 42" (1067 mm) W 26" ( 660 mm) H

72" (1829 mm) L† 48" (1219 mm) W 20-1/2" ( 521 mm) H

60” (1524 mm) L 42” (1067 mm) W 23-1/2” (597 mm) H

66” (1676 mm) L 36” ( 914 mm) W 23-1/2” (597 mm) H

72" (1829 mm) L 42" (1067 mm) W 23-1/2" ( 597 mm) H

72" (1829 mm) L† 42" (1067 mm) W 23" ( 584 mm) H

72" (1829 mm) L 47" (1194 mm) W 23-3/4" ( 584 mm) H

35-1/8" ( 892 mm) W 22-7/8" ( 581 mm) H1 21" ( 533 mm) H2 23-1/2" ( 597 mm) H3

DRAIN/OVERFLOW

17-3/8" (441 mm) A 11-15/16" (210 mm) B

11-3/4" (298 mm) B

20" (508 mm) A 11-3/4" (298 mm) B

16-1/4" (413 mm) A 13-1/2" (343 mm) B

18.5” (470 mm) A

10.6” (269 mm) B

18.5” (470 mm) A

10.6” (269 mm) B

18.5” (470 mm) A

10.6” (269 mm) B

20" (508 mm) A 14" (356 mm) B

18-3/16" (459 mm) A 15" (381 mm) B

CUTOUT

Template Provided

P/N

BY20000

Template Provided

P/N

BY20000 Template

Provided

P/N

BY20000

Template Provided

P/N

P187000

Provided

P/N

P187000

Provided

P/N

P187000

58" x 40"

(1473 mm x

1016 mm)

Umt Template

Provided

P/N DQ50000

64" x 34"

(1626 mm x

864 mm)

Umt Template

Provided

P/N DQ51000

70" x 40"

(1778 mm x

1016 mm)

Umt Template

Provided

P/N BZ51000

70" x 40"

(1778 mm x

1016 mm)

Template Provided

P/N

P187000

Provided

P/N

P652000

TOTAL WEIGHT/

FLOOR LOADINGDIMENSIONS

843 lb

(383 kg)/

51 lb/ft

(248 kg/m2)

978 lb

(489 kg)/

54 lb/ft

(263 kg/m2)

1127 lb

(470 kg)/

54 lb/ft

(263 kg/m2)

1026 lb

(466 kg)/

59 lb/ft

(288 kg/m2)

1078 lb

(490 kg)/

56 lb/ft

(273 kg/m2)

1130 lb

(514 kg)/

54 lb/ft

(263 kg/m2)

895 lb

(407 kg)/

37 lb/ft

(180 kg/m2)

(512 kg)/

65.4 lb/ft

(319 kg/m2)

(472 kg)/

63 lb/ft

(307 kg/m2)

(611 kg)/

64 lb/ft

(312 kg/m2)

1130 lb

(514 kg)/

54 lb/ft

(263 kg/m2)

1199 lb

(545 kg)/

51 lb/ft

(249 kg/m2)

948 lb

(431 kg)/

54 lb/ft

(263 kg/m2)

OPERATING

GALLONAGE

Min - 55 U.S. gal

(208 liters)

Max - 75 U.S. gal

(284 liters)

Min - 65 U.S. gal

(246 liters)

Max-85 U.S. gal

(322 liters)

Min - 75 U.S. gal

(284 liters)

Max - 99 U.S. gal

(375 liters)

80 U.S. gal (303 liters)

85 U.S. gal (322 liters)

90 U.S. gal (341 liters)

57 U.S. gal (216 liters)

Min - 83 U.S. gal

(314 liters)

Max - 92 U.S. gal

(348 liters)

Min - 75 U.S. gal

(284 liters)

Max - 83 U.S. gal

(314 liters)

Min - 95 U.S. gal

(360 liters)

Max-105 U.S. gal

(398 liters)

90 U.S. gal (341 liters)

98 U.S. gal (371 liters)

70 U.S. gal (265 liters)

PRODUCT

WEIGHT

135 lb

(61 kg)

145 lb

(66 kg)

169 lb

(77 kg)

110 lb

(50 kg)

120 lb

(56 kg)

130 lb

(59 kg)

170 lb

(77 kg)

200 lb

(91 kg)

200 lb

(91 kg)

215 lb

(98 kg)

130 lb

(59 kg)

133 lb

(60 kg)

115 lb

(52 kg)

SKIRT &

MOUNTING

Not Available

Not Available20" (508 mm) A

Not AvailableTemplate

IncludedNA

Not Available1126 lb

Not Available1039 lb

Not Available1345 lb

Not Available

Not AvailableTemplate

† Add 1/4" to this dimension when roughing-in for 3-wall niche. NOTE: The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4 mm).

FOR ALL UNITS: Electrical Service Requirements: All require a dedicated GFCI protected separate circuit. RapidHeatTM: 120 VAC, 15 AMP, 60 Hz. dedicated GFCI protected separate circuit. Motor/Pump: 120 VAC, 20 AMP, 60 Hz. dedicated GFCI protected separate circuit.

HEATER,

INTAKE/DISCHARGE

Factory Installed

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

Jacuzzi Whirlpool Bath K339000X 3/06

OVAL & ROUND BATHS

SPECIFICATIONS

(Heater)

MAX. 2-1/2"

1/2"

(13 mm)

(Motor)

SIDE VIEW

END VIEW

DUETTA™

(51 mm)

CUTOUT

70" Dia.

(1778 mm)

Hole

Template

Provided

P/N

DA09000

Template

Provided

P/N

DA08000 Template

Provided

P/N

DA07000 Template

Provided

P/N

DA06000 Template

Provided

P/N

P187000

TOTAL WEIGHT/

FLOOR LOADINGDIMENSIONS

1293 lb

(588 kg)/

36 lb/ft

(176 kg/m2 )

999 lb

(454 kg)/

57.1 lb/ft

(278 kg/m2 )

1019 lb

(463 kg)/

61.8 lb/ft

(301 kg/m2 )

1106 lb

(503 kg)/

57.5 lb/ft

(280 kg/m2 )

1277 lb

(581 kg)/

60.8 lb/ft

(296 kg/m2 )

1130 lb

(514 kg)/

54 lb/ft

(263 kg/m2 )

GALLONAGE

Max - 83 U.S. gal

Max - 80 U.S. gal

Max - 95 U.S. gal

Max - 106 U.S. gal

OPERATING

100 U.S. gal

Min - 77 U.S. gal

Min - 75 U.S. gal

Min - 90 U.S. gal

Min - 98 U.S. gal

(Heater)

SIDE VIEW

(Motor)

MAX. 1/2"

END VIEW

VENICIA™

SPECIFICATIONS (Oval & Round) LH = Left Hand, RH = Right Hand

MODEL

CORTINA™

DUETTA™ 6042

DUETTA™ 6636

RH DUETTA™

6642

RH DUETTA™

7242

RH VENICIA™

72" (1829 mm) L 72" (1829 mm) W 22-1/4" ( 565 mm) H

60” (1524 mm) L 42” (1067 mm) W 26” ( 660 mm) H

66” (1676 mm) L 36” (914 mm) W 26” ( 660 mm) H

66” (1676 mm) L 42” (1067 mm) W 26” (660 mm) H

72" (1829 mm) L 42" (1067 mm) W 26" ( 660 mm) H

72" (1829 mm) L 42" (1067 mm) W 23" ( 584 mm) H

DRAIN/OVERFLOW

DIMENSIONS

16-3/4" (426 mm) A 19-1/4" (489 mm) B

18.4" (467 mm) A 11" (279 mm) B

20" (508 mm) A 14" (356 mm) B

(379 liters)

(291 liters) (314 liters)

(284 liters) (303 liters)

(341 liters) (360 liters)

(371 liters) (401 liters)

90 U.S. gal (341 liters)

DRAIN/OVERFLOW

(Heater)

(Motor)

CORTINA™

PRODUCT

WEIGHT

210 lb

(95 kg)

110 lb

(50 kg)

180 lb

(82 kg)

117 lb

(53 kg)

130 lb

(59 kg)

130 lb

(59 kg)

SKIRT &

MOUNTING

Not Available

Not Available Factory Installed

Not Available

HEATER,

INTAKE/DISCHARGE

Factory Installed

Discharge

(U394000 HEATER)

Intake

(S749000 Heater)

Intake

(S749000 Heater)

Intake

(S749000 Heater)

Intake

(S749000 Heater)

Factory Installed

Intake

(S749000 Heater)

ENGLISH

NOTE: The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4

mm).

Jacuzzi Whirlpool Bath K339000X 3/06

CORNER BATHS

SPECIFICATIONS

ENGLISH

SIDE VIEW

(Heater)

MAX. 1/2"

(51 mm)

END VIEW

DRAIN/OVERFLOW

BELLAVISTA™ CORNER, Right Hand

SPECIFICATIONS (Corner) LH = Left Hand, RH = Right Hand

SKIRT &

MOUNTING

Not Available

P/N

TOTAL WEIGHT/

FLOOR LOADING

1046 lb

(475 kg)/

42 lb/ft

(205) kg/m

DRAIN/OVERFLOW

MODEL

BELLAVISTA CORNER

NOTE: The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4

FOR ALL UNITS: Electrical Service Requirements: All require a dedicated GFCI protected separate circuit.

mm).

RapidHeatTM: 120 VAC, 15 AMP, 60 Hz. dedicated GFCI protected separate circuit.

DIMENSIONS

60" (1524 mm) L 60" (1524 mm) W 21-3/4" ( 553 mm) H

DIMENSIONS

18-7/8" (479 mm) A 14" (356 mm) B

CUTOUT

Template

Provided P654000

OPERATING

GALLONAGE

80 U.S. gal (303 liters)

PRODUCT

WEIGHT

130 lb

(59 kg)

Motor/Pump: 120 VAC, 20 AMP, 60 Hz. dedicated GFCI protected separate circuit.

HEATER,

INTAKE/DISCHARGE

Factory Installed

Intake

(S749000 Heater)

Jacuzzi Whirlpool Bath K339000X 3/06

ROUGHING-IN REFERENCE

ROUGHING-IN REFERENCE (RECTANGULAR)

Some tubs are supplied with cutout and/or undermount template. Refer to CUTOUT on pages 6-8 for template part numbers.

66"

72"

ENGLISH

36"

42"

Motor

5" x 5"

ALLUSION™ 6636, Right Hand

72"

Motor

5" x 5"

ALLUSION™ 7242, Right Hand

66"

Motor

42"

4" x 4"

Heater

10"

BELLAVISTA™ 5.5, Right Hand

8-1/2"

Heater

8-1/2"

Heater

35-1/2"

33"

36"

12" H x 18" L Service Access

Opt. Service Access

12" H x 18" L

Service Access

11-15/16"

Opt. Service Access

12" H x 18" L

Service Access

11-15/16"

Opt. Service Access

30-1/8"

11-3/4"

36"

5" x 5"

ALLUSION™ 7236, Right Hand

42"

4" x 4"

BELLAVISTA™ 5, Right Hand

42"

4" x 4"

10-1/2"

BELLAVISTA™ 6, Right Hand

60"

Motor

72"

Motor

8-1/2"

Heater

32-1/2"

Motor

Heater

35-13/16"

Heater

36"

Opt. Service Access

12" H x 18" L

Service Access

11-15/16"

Opt. Service Access

12" H x 18" L Service Access

30-1/8"

11-3/4

12" H x 18" L Service Access

30-1/8"

11-3/4"

Opt. Service Access

12" H x 18" L Service Access

34-1/2"

48"

36"

*72"

14" x 4"

Motor

Heater

CIPREA™, Right Hand

* Add 1/4" to this dimension when roughing-in for 3-wall niche. NOTE: 1. Measurements inside each unit represent cutout in floor to allow for drain/overflow.

2. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.

3. Service access dimensions given are minimum size.

4. The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4 mm). 9

Jacuzzi Whirlpool Bath K339000X 3/06

+ 19 hidden pages
