specifications
specifications
FEATURES
· Ceramic Cartridge
· Lever Style Handle
· 1/2" IPS connections
· Min Flow Rate: 2.4 GPM at 20 PSI
CODE COMPLIANCE
· ASME A112.18.1 / CSA B125.1
· IAPMO Certified
WARRANTY
· Limited Lifetime Warranty
INSTALLATION DIMENSIONS
FINISH
NW55826
MODEL
FREESTANDING TUB FILLER
Brushed Nickel
1/2"-14NPSM-2B
217.6mm
[ 8 5/8" ]
1034.5mm
[ 40 3/4" ]
150.0mm
[ 5 7/8" ]
302.5mm
[ 11 7/8" ]
220.0mm
[ 8 5/8" ]
965.0mm
[ 38" ]
Triple Door Aluminum Tri-View Cabinet
PART NUMBER
PD47000
MATERIAL
Aluminum
COLORS AND FINISH
Silver Anodized
CODE COMPLIANCE
BS EN14749
PACKAGING DIMENSIONS W X D X H
891mm (35 1/16”) x 200mm (7 7/8”) x
810mm (31 7/8”)
ISTA 3A Packaging
(International Safe Transit Association)
SURFACE MOUNTED
CABINET DEPTH
133mm [5 1/4”]
762mm
[30”]
B
Recommended Drill size 8mm (5/16”)
FEATURES
- Can be recessed or surface mounted
- Easy to install Hang ‘N’ Lock system
- Double sided mirror doors with bevel on
front glass
- 165˚ Spring Hinge
- Mirror back panel
- 9 Adjustable toughened glass shelves
Shelf depth: 80mm (3 1/8”)
- Mirror glass side panels for surface
mounting
- Optional pin handles for doors
INSTALLATION DIMENSIONS (APPROXIMATE)
SECTION B-B
ROUGH OPENING DEPTH
660mm
[26”]
B
RECESS MOUNTING
95mm [3 3/4”]
Jacuzzi reserves the right to make changes in specifications and materials and to change and discontinue models, both without the notice
or obligation. Dimensions are for reference only.
06/2018
Rev 04
