JACUZZI JS10294 Specifications

TECHNICAL SPECIFICATIONS

Cetra® 532 Pure Air® II Bath

CET6032 ALR 2XX Cetra 532 Pure Air® II Bath Left Hand (EB30)

DIMENSIONS
60” L x 32” W x 21-¼” H
(1524 mm) L x (813 mm) W x (553 mm) H
DRAIN/OVERFL OW
A: 18-½” (470 mm) B: 9” (229 mm)
CUTOUT
58” x 30”
(1473 mm x 768.4 mm)
TOTAL WEIGHT
771 lb (350 kg) / 58 lb/ft2 (283 kg/m2)
OPERATING GALLONAGE
Min. 47 U.S. Gal. (178 Liters)
Max. 62 U.S. Gal. (235 Liters)
PRODUCT WEIGHT
98 lb (44 kg)
SKIRT MOUNTING
Optional U-Frame: P/N F955
ELECTRICAL SPECIFI CATIONS
Requires a dedicated GFCI protected separate circuit.
Blower: 120 VAC, 15 AMP, 60 Hz.
HEATER
No water heater is available on this unit. Blower has integral air
heater.

*60"

31-7/8"

12" x 4"

INSTALLATION NOTES
Refer to installation instructions included with
xture before beginning installation. Please conrm
product availability and specications before
commencing with any installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY
ARE SUBJECT TO CHANGE WITHOUT NOTICE.

FEATURES, UPGRADES & ACCESSORIESKEY DIMENSIONS

• Left hand Drain Location

• Accessories / Hardware:
Trip-Lever Drain Kit: #X559
Rotary Drain Kit, 26” Cable: #8730

• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(845) – Oil Rubbed Bronze

Product Shown: Cetra 532 Pure Air® II Bath Left Hand
Model: EB30
* Measurements inside unit represent cutout in oor to
allow for drain/overow. Minimum Service Access dimen­sions given.

Blower

12" H x 18" L

Service Access

15-7/8"

5-3/4"

2"

9"

60"

2"

21-1/4"

31-7/8"

(Blower)

A

(51 mm)

B

END VIEW

© 2 010 Ja cuz zi Lux ury Ba th • Fo r a ddi tio nal in for mat ion ca ll Cus tom er Ser vic e 8 00- 288 -40 02 • ww w.ja cuz zi. com /te chn ica lsp ecs
Refer to installation instructions included with xture before beginning installation. Please conrm product availability and specications before commencing with any installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE WITHOUT NOTICE.

SIDE VIEW

DRAIN/OVERFLOW
