majora
this is majora®—“large” to the spanish-speaking. also a whirlpool bath of immense quality—a truly grand experience.
®
5 whirlpool bath and soaking bath
The Majora® offers a deep, oval well with
six jets for larger than life restoration,
muscle therapy and invigoration.
features:
• 4 fully adjustable TheraPro™ jets
• 2 directionally adjustable AccuPro™ jets
• Sculpted armrest and backrest
• Integral handrails
• Built-in tile flange and integral skirt with
access panels on skirted models
• Electronic on/off controls
• Drain included on whirlpool baths
majora® 5 whirlpool bath
model number: H538 – RH, H537 – LH
exterior dimensions:
60" long x 42" wide x 19½" high
interior dimensions (at bottom):
36" long x 27" wide
# of Jets/type of Jets:
4 TheraPro™ Jets,
2 AccuPro™ Lumbar Jets
operating gallons:
46 gallons
majora® 5 soaking bath
model number: H539
exterior dimensions:
60" long x 42" wide x 19½" high
interior dimensions (at bottom):
36" long x 27" wide
Ordering Information
42"
60"
21"
8-3/4"
10" x 4"*
2"
Motor
12" H x 18" L
Service Access
Opt. Service Access
4-3/8"
END VIEW
H
W
SIDE VIEW
L
2"
DRAIN/OVERFLOW
A
B
Product Code:
H538 Majora® 5 Whirlpool Bath
Right Hand
H537 Majora® 5 Whirlpool Bath
Left Hand
H539 Majora® 5 Bath
• Right and Left Hand Drain Location
• Accessories / Hardware:
Trip-Lever Drain Kit #X559
Rotary Drain Kit, 26” Cable #8730
HTC Jet Trim Kit: #D095
BMH Jet Trim Kit: #J869
• Trim Kit Finishes Available:
(827) – Chrome
(898) – Brushed Chrome
(815) – Satin Nickel
(829) – Bright Brass
(805) – Platinum
(826) – Brushed Nickel
(849) – Oil Rubbed Bronze
Majora® 5 Whirlpool Bath
Model: H537, H538
Majora® 5 Bath
Model: H539
Installation Notes
Refer to installation instructions included with fixture before beginning installation.
Please confirm product availability and specifications before commencing with any
installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
Electrical Components and Electrical Specifications do not apply to non-jetted baths.
Technical Specifications
Dimensions
60” L x 42” W x 19-1/2” H
(1524 mm) L x (1067 mm) W x (495 mm) H
Drain/Overflow
A: 15” (381 mm) B: 8-3/4” (222 mm)
Cutout
58” x 40”
Total Weight
H537, H538: 728 lb (330 kg) / 42 lb/sq. ft. (203 kg/m2)
H539: 703 lb (319 kg) / 40 lb/sq. ft. (196 kg/m2)
Operating Gallonage
46 U.S. Gal. (172 Liters)
Product Weight
H537, H538: 95 lb (43 kg)
H539: 70 lb (32 kg)
Skirt Mounting
Not Available
Electrical Specifications Models H537, H538 only
Requires a dedicated GFCI protected separate circuit.
Motor/Pump: 120 VAC, 15 AMP, 60 Hz.
RapidHeat™: 120 VAC, 15 AMP, 60 Hz.
Heater (Optional) Models H537, H538 only
Requires a dedicated GFCI protected separate circuit.
Product Shown: Majora® 5 Whirlpool Bath Left Hand Model: H537
* Measurements inside unit represent cutout in floor to allow for drain/overflow.
Minimum Service Access dimensions given.
#FR62 12/0 6
© Jacuzzi Whirlpool Bath • 14801 Quorum Drive • Dallas • Texas • 75254 • www.jacuz zi.co m
RapidHeat™: P/N S750000
