Jaco Ultralite Power Blade Hot-Swap 300, Ultralite Power Blade Hot-Swap 320, Ultralite Power Blade Hot-Swap 310 Series Manual

25-0163 Rev 02

1

Table of Contents

300 SERIES, MODEL & PART NUMBERS .................................................................................... 2

S

YMBOL INFORMATION ...................................................................................................... 3

P

RODUCT LABELING ......................................................................................................... 3

G

ENERAL SPECIFICATION .................................................................................................... 4

P

OWER MONITORING & CONTROL, WI-FI CONNECTION ............................................................. 5

S

AFETY RECOMMENDATIONS AND WARNINGS ........................................................................... 6

P

ROPER OPERATION, CARE & MAINTENANCE ........................................................................... 7

B

ASIC MOBILE CART INTEGRATION & OPERATION ...................................................................... 8

U

NPACKING & ASSEMBLY: ............................................................................................... 8

C

HANGING THE HEIGHT POSITION: .................................................................................... 8

I

NSTALLING YOUR COMPUTER OR LAPTOP: ........................................................................... 8

I

NSTALLING STAND AND LCD MONITOR: ............................................................................. 9

I

NSTALLING SCANNER MOUNTS: ....................................................................................... 10

I

NSTALLING KEYBOARD AND MOUSE ONTO THE CART: ............................................................ 10

O

PTIONAL JACO PATENTED TRAC™ WHEEL STEERING: ......................................................... 10

K

EYBOARD LIGHT: ....................................................................................................... 11

O

PTIONAL LOCKING DRAWER OPERATION: ......................................................................... 11

P

OWER BLADE BATTERY PACK & CART CONTROLLER ................................................................ 12

P

OWER BLADE CHARGER................................................................................................... 14

A

GENCY CERTIFICATION ................................................................................................... 14

T

ROUBLESHOOTING ......................................................................................................... 15
