Jaclo 1232-X Installation Manual

Distributed in North America by:

JACLO INDUSTRIES

129 Dermody Street,

Cranford,

New Jersey,

07016

USA

Phone: [phone]
Fax: [phone]

www.jaclo.com

Manufactured by:

Hornbeam Ivy Ltd

Whitworth Road, Marston Trading Est.

Frome, Somerset, England

BA11 4BY

Tel:[phone]

Fax:[phone]

Email - [e-mail]

www.steamvalveoriginal.com

3 Hole Mixers
1030
1031
1032

SOLID STAINLESS STEEL

Page 1 Specification
Page 2 Components
Page 3 Installation
Page 4 Maintenance

LF1300

Specification

Fig.1 (1030 3 Hole Mixer Articulated Spout)

Fig.2 (1031 3 Hole Mixer Swivel Spout)

Technical Data

Max Recommended Water Pressure 70psi (5bar)
Test Pressure 145psi (10bar)
Max Flow Rate 2.2g/min (8.3l/min)
Max Hot Water Temp 176degsF 80degsC

SOLID STAINLESS STEEL

1
