Jablotron JA80K Users Manual
JA-80K-US “Oasis”
Control panel installation manual
This manual is valid for control panel JA-80K version KE60108 (printed on internal circuit board).
The control panel can be configured by a PC running ComLink software - version 80 or higher.
Contents:
1. CONTROL PANEL ARCHITECTURE ................................................... 3
1.1. O
PTIONAL SYSTEM CONFIGURATIONS
................................................ 4
2. INSTALLATION ..................................................................................... 4
2.1. P
OWER INLET
.................................................................................. 4
3. CONTROL PANEL MEMORY UNIT ...................................................... 4
4. CONTROL PANEL CONNECTORS AND TERMINALS ...................... 4
5. WIRED KEYPAD CONNECTION .......................................................... 5
6. BACK-UP BATTERY ............................................................................. 5
7. POWERING-UP THE CONTROL PANEL FOR THE FIRST TIME....... 6
7.1. W
IRELESS KEYPAD ENROLLMENT
...................................................... 6
8. LANGUAGE SELECTION OF THE KEYPAD....................................... 6
9. RESETTING THE CONTROL PANEL .................................................. 6
10. CLOSING THE CONTROL PANEL COVER .................................... 6
11. ENROLLING WIRELESS DEVICES ................................................. 6
11.1. I
11.2. E
11.3. T
11.4. M
11.5. E
11.6. E
NSTALLING WIRELESS DEVICES
NROLLING WIRELESS DEVICES TO THE CONTROL PANEL
ESTING ENROLLED DEVICES
EASURING SIGNAL STRENGTH
RASING ENROLLED DEVICES
NROLLING THE CONTROL PANEL TO UC AND AC MODULES
......................................................... 6
............................................................ 7
......................................................... 7
............................................................ 7
.................... 6
................ 7
12. CONTROL PANEL PROGRAMMING .............................................. 8
12.1. C
12.2. E
12.3. E
12.4. A
12.5. PGX
12.6. C
12.7. R
12.8. R
12.9. RESET
12.10. E
CONTROL
12.11. M
12.12. C
CONTROL PANEL
12.13. S
12.14. T
12.15. C
12.16. E
12.17. E
12.18. E
12.19. S
12.20. S
12.21. W
12.22. A
12.23. F
12.24. P
12.25. A
12.26. T
TRIGGERED TAMPER SENSORS
12.27. O
12.28. P
12.29. T
12.30. E
12.31. R
12.32. A
12.33. O
12.34. S
12.35. A
12.36. H
12.37. A
12.38. A
12.39. S
12.40. D
12.41. C
12.42. E
12.43. A
12.44. C
12.45. G
12.46. S
12.47. E
ONTROL PANEL PROGRAMMING SEQUENCES
XIT DELAY TIME
NTRANCE DELAY TIME
LARM DURATION TIME
AND
HANGING TELEPHONE NUMBERS IN MAINTENANCE MODE
ADIO INTERFERENCE INDICATION
ADIO COMMUNICATIONS SUPERVISION
NROLLMENT TO A SUB CONTROL PANEL FOR SETTING (ARMING)
............................................................................ 10
................................................................... 10
................................................................... 11
PGY
FUNCTIONS
............................................................ 11
................................................... 11
ENABLED
.......................................................................... 11
11
ASTER CODE RESET
ONTROL PANEL ENROLLMENT TO UC OR AC MODULES OR TO A SUB
................................................................ 12
12
ETTING (ARMING) WITHOUT AN ACCESS CODE
RIGGERED-DETECTOR INDICATION
ONFIRMATION OF INTRUDER ALARMS
XIT DELAY BEEPS
XIT DELAY BEEPS WHILE PARTIALLY SETTING (ARMING
NTRANCE DELAY BEEPS
ETTING (ARMING) CONFIRMATION BY WIRED-SIREN CHIRP
IRENS ALWAYS SOUND DURING AUDIBLE ALARMS
IRELESS SIREN ALARM ENABLED
UTO-BYPASS USER APPROVAL VIA THE KEY
INAL-DOOR DETECTORS
ARTIAL SETTING (ARMING) OR SYSTEM SPLITTING
UTOMATIC SUMMER TIME (DAYLIGHT SAVING TIME
AMPER ALARM IN RESPONSE TO AN INCREASE IN THE NUMBER OF
..................................................................... 12
........................................................... 13
(IW
........................................................... 13
................................................................................ 14
PERATING THE PG OUTPUTS USING 8 AND
ERMANENT ALARM STATUS DISPLAY FOR A SET SYSTEM
AMPER ALARM IF UNSET
NGINEER RESET
ECORDING PG OUTPUT ACTIVATION TO MEMORY
NNUAL CHECK NOTIFICATION
NLY SINGLE ALARM INDICATION
ETTING (ARMING) BY SERVICE CODE
UDIBLE PANIC ALARM
IGHER CONTROL-PANEL RECEIVER-SENSITIVITY
CCESS BY CODE PLUS CARD
UDIBLE 24 HOUR INTRUDER ALARM
ERVICE MODE ONLY WITH SERVICE CODE AND MASTER CODE
EVICE REACTIONS AND SECTION ASSIGNMENT
ODE/CARD REACTIONS AND SECTION ASSIGNMENT
NROLLMENT BY KEYING IN PRODUCTION CODES
UTOMATIC SETTING/UNSETTING SCHEDULE
HANGING THE SERVICE CODE
O TO MAINTENANCE MODE
ETTING THE INTERNAL CLOCK
DITING KEYPAD TEXT
........................................................... 15
...................................................................... 15
.................................................... 15
................................................ 15
............................................................... 15
..................................................... 16
................................................... 17
....................................................... 17
................................................... 17
............................................................... 18
.................................... 8
................. 11
........................................... 11
........................... 12
............................................ 12
........................................ 12
)............... 13
........... 13
....................... 13
AND
EW)......................... 13
............................... 13
...................... 14
)..................... 14
9 ............................. 14
............. 14
....................... 15
......................................... 15
......................... 15
........................................... 16
...... 16
........................... 16
.................... 17
......................... 17
............................... 17
13. OPERATING THE SYSTEM ........................................................... 18
13.1. T
HE SYSTEM KEYPAD
..................................................................... 18
13.1.1. Keypad indicators: ............................................................. 18
13.1.2. LCD display........................................................................ 18
13.1.3. Keypad display sleep-mode .............................................. 18
13.1.4. Keys ................................................................................... 18
13.1.5. Functions beginning with the key ..................................... 19
13.2. P
ROGRAMMING ACCESS CODES AND CARDS
..................................... 19
13.2.1. Programming access codes and cards ............................. 19
13.3. S
13.4. M
ETTING AND UNSETTING (ARMING/DISARMING) THE SYSTEM
AINTENANCE MODE
..................................................................... 20
............ 20
Installation manual: Oasis security system JA-80K - 2 -
13.4.1. Displaying which user/card positions are occupied ...........20
13.4.2. Bypassing devices ..............................................................20
13.4.3. Protecting a car near the system........................................20
14. OPERATING AND PROGRAMMING THE SYSTEM BY PC.........21
15. BASIC GUIDANCE FOR INSTALLERS..........................................21
16. TROUBLE-SHOOTING ....................................................................22
17. CONTROL PANEL TECHNICAL SPECIFICATIONS .....................22
MKE55800
System installation shall only be undertaken by qualified
Communicator
Back-up battery
Digital bus connector
tamper switch
LEDs
Antenna
technicians holding a training certificate issued by an authorized
distributor. The manufacturer cannot be held responsible for any
damage or consequences related to the improper or incorrect
use of this product.
1. Control panel architecture
• The control panel has 50 addresses (01 to 50), meaning that
up to 50 wireless devices can be enrolled i.e. detectors,
keypads, keyfobs, sirens etc.
• When triggered, a detector sends a so-called natural signal
which dictates what the reaction of the control panel should
be. E.g. the natural signal of a door contact or PIR detector
can be an instant or delayed alarm which is selectable by a
DIP switch inside the detector. A keyfob, for instance, sends
signals for set (arm), unset (disarm) and panic.
o The control panel is factory-set to perform natural reactions
according to the signals sent from wireless devices. By
programming the addresses of the devices in the control
panel, it is possible to define how the control panel reacts to
individual wireless devices. E.g. a door detector assigned to
address 15 could trigger a panic reaction, and a keyfob
button using address 24 could cause a fire reaction etc.
• Wireless devices can be assigned to 3 sections: A,B or C.
Assignments to sections either have an effect when partial
setting is used e.g. only A is set, AB is set, or ABC is set
(which, for example, would be suitable for homes where A
could mean afternoon setting, AB night setting and ABC total
setting), or if the system was split into two independent
partitions A and B, with a common section C. In the second
case, each A or B section can be set individually, and C is
automatically set when both A and B have been set by users.
This would be suitable for two independent families in a single
house, or two companies in one building.
• There are two hard-wired inputs with programmable functions
assigned to addresses 01 and 02. If these two inputs are not
used, the two addresses can be used to enroll wireless
devices. Hard-wired inputs are also provided by some
wireless devices, such as keypads, door detectors, and PIR
movement detectors.
• The control panel has two alarm outputs: IW = internal
(indoor) warning and EW = external (outdoor) warning. Both
these signals are also available as wireless signals.
• There are two programmable outputs in the control panel,
PGX and PGY whose functions can be configured. The PG
outputs are not only available as physical control-panel
terminals, but also as radio signals for the control of UC and
AC receiver outputs.
• The system can be operated by user codes or user cards. The
system can recognise up to 50 different users. The system
can also be operated by wireless keyfobs, and if the control
panel is equipped with a suitable communicator it can also be
remotely controlled by mobile phone or the Internet.
• It is possible to program different reactions to access codes or
access cards and if the system is split, it is possible to
program which part of the building is accessible by a particular
code or card. Each of the possible 50 users can have his own
4-digit access code and/or access card. Setting (arming) and
unsetting (disarming) is possible by card or code, and if a
higher security level is needed it is possible to make it
compulsory to confirm the validity of a card by code entry.
• Programming the system is possible by Oasis keypads such
as the wireless JA-80F or the hard-wired JA-80E, and also by
computers running ComLink software. Further options offer
programming by mobile phone or the Internet.
• There is a power supply in the control panel and space for a
12V, 1.3 to 2.6 Ah back-up battery.
• To connect a hard-wired keypad or a computer, the control
panel is equipped with a digital bus provided by terminals and
RJ connectors.
• The control panel can be equipped with an optional
communicator to provide external communications to the
system. The JA-80Y GSM/GPRS communicator or JA80V LAN and phone line communicator both allow data to be
SIM card
Main board
Transformer
Mains terminal
GSM antenna
Installation manual: Oasis security system JA-80K - 3 -
MKE55800
sent to alarm receiving centres (central monitoring stations).
Mains fuse
antenna connector
RESET
Communicator
Wiring plug
Digital bus
1A +U
fuse for
Terminals for
transformer output
module
memory socket
They can notify the user using SMS reports and allow remote
control and programming of the system by mobile phone and
the Internet. Another option is the JA-80X communicator
which reports alarms via a traditional phone line using voice
messages.
Note: The Oasis JA-80 system has three modes: operating
mode, maintenance mode and service mode. Operating
mode is for the day-to-day use of the system by all authorised
users, e.g. setting/unsetting (arming/disarming). Maintenance
mode is for the holder of the master code (system administrator)
to have limited programming of the system, e.g. changing
codes/cards, bypassing and is inaccessible to all other users.
Service mode is only for installers and is used to program and
control all aspects of the system.
1.1. Optional system configurations
In the European Union region, follow the valid standards and
rules, especially series EN-501-xx. The Oasis control panel
complies with grade 2.
The control panel must have one of the following configurations
as a minimum:
• At least two non-backup-battery sirens (JA-80L or SA-105) +
communicator class ATS2 (JA-80Y, JA-80V or JA-80X)
• At least one backup-battery siren (JA-80A or OS-360/365/300)
+ communicator class ATS2 (JA-80Y, JA-80V or JA-80X)
• No siren + communicator class ATS3 (JA-80Y or JA-80V)
Note: the above-recommended configurations are based on the
EU standard EN-50131-1 valid at the time of issuing this
manual.
2. Installation
The control panel can be attached to the wall using 3 screws.
The drilling template is on the last page of this manual.
• Because the control panel communicates via radio, it
should not be installed near any large metal objects
capable of shielding radio communication.
• Route cables (power supplies, telephone leads etc.) inside
the control panel before tightly screwing in the screws.
2.1. Power inlet
The control-panel power cable should only be installed by a
person holding a sufficient electro-technical qualification.
T 200 mA
The control panel power supply is double-insulated (safety
class 2) and does not incorporate a protective earth wire.
• A double-insulated power cable should be used with a
minimum cross-sectional area of 0.75 to 1.5 mm2. The
power cable should be connected to a switched mains
supply fused to 10 Amps.
Installation manual: Oasis security system JA-80K - 4 -
• In the control panel, connect the cable to the power
terminals equipped with a fuse of type T200mA/250V.
• Fix the cable firmly to the cable holder in the control
panel making sure that the wire ends are properly secured
and connected in the terminals.
Radio
connector
V
0
2
C
A
2
1
M
0
0
O
C
C
C
O
-
N
N
W
E
W
I
Y
X
DAB
G
N
G
P
P
G
U
+
3. Control panel memory unit
The control panel memory unit plugs into its own socket. If, for
example, the control panel was damaged, the memory unit could
be unplugged and then plugged into another control panel circuit
board of the same type to transfer and preserve the settings
including enrolled detectors, access codes and cards. The new
control panel thereby becomes an exact copy of the former one
(a clone).
Notes:
•
There are no communicator settings in this memory unit
•
Do not connect or disconnect the memory unit while the control panel
is powered.
•
Although the memory unit is well-protected, in cases of severe
damage to the control panel there is a risk that memory contents
could be corrupted. It is therefore highly recommended to back-up the
settings in a PC using Comlink software.
4. Control panel connectors and terminals
Antenna connector – This is used to connect either to an
internal antenna or to external antennas such as the AN-80 or
AN-81.
Reset link (normally open) – Used to reset the control panel by
shorting the link only while powering up the control panel. This
link can also be used to enter control panel enrollment mode by
briefly shorting the link while the control panel is powered.
Digital bus connector – for connecting a JA-80E keypad or a
PC running Comlink software with a JA-80T interface cable. The
same digital bus connector is present on the bottom right hand
corner of the plastic housing. Additionally, the same connections
are available on the GND, A, B, +U terminals.
MKE55800
Communicator connector – allows the connection of an
IN
+U
GND
GND
control and programming
optional communicator to the main board.
Internal wiring connector – connects the internal wiring in the
control panel housing.
Terminals:
AC 20V the transformer output is connected here.
01, GND, 02 are hard-wired inputs for the control panel.
• The reactions to triggering these inputs are determined by the
settings of addresses 01 and 02. The factory-set natural
reaction for these hard-wired inputs is a delayed alarm in
section C.
• Terminals 01 and 02 use resistors in connected double
balanced loops to sense loop stand-by, activation or
tampering as follows:
o Connected to GND via a 1 kΩΩΩΩ resistor = untriggered input
o Connected to GND via 2 to 6 kΩΩΩΩ = triggered input,
o Connected to GND via less then 700ΩΩΩΩ or more then 6 kΩΩΩΩ
= tamper signal
o Stand-by (untriggered) input zone must have 1 kΩΩΩΩ
o Up to five normally-closed door/window contacts can be
connected in series to enable one hard-wired input to be
used for multiple contacts with each contact having a 1kΩΩΩΩ
resistor in parallel (see the diagram below).
o Multiple normally-closed tamper contacts should be
connected in series without any parallel resistors. The
number of tamper contacts is unlimited and can be
combined with trigger contacts having parallel resistors (see
the diagram below).
o For wiring examples, see the below diagram.
the instruction ∗81 / ∗80 or using keys
). The factory-default
function of PGY is that it will be activated if any section of the
system is set. The status of PG outputs is also transmitted by
radio for AC and UC output modules.
GND – common ground connection
A,B – digital bus data
+U – back-up power supply (10 to 14V), 1A fuse. Max.
continuous load 0.4 A (max. intermittent load 1 A, for 15
minutes, once an hour). If the 1A fuse is blown, the control panel
will indicate power supply fault.
5. Wired keypad connection
modular connection
cable
keypad JA-80E
GND A B U+
B
A
o If you enroll a wireless device to address 01 or 02, the
corresponding input terminal will be disabled.
o If you do not use an input terminal and you do not enroll a
wireless device to its address, then the terminal must be
connected to the GND terminal via a 1 kΩΩΩΩ resistor.
NC – normally closed contact for the external warning relay.
NO - normally open contact for the external warning relay.
EWC – common contact for the external warning relay max.
relay contact rating: 1A/60V. The control panel also transmits
the external warning relay signal via radio for wireless sirens.
IW – internal warning (siren) output. This output is grounded
during an internal alarm. A standard siren can be wired between
terminals +U and IW (max. 0.5A). The IW output status is also
transmitted by radio for the IW siren.
The main difference between internal and external warning is during
the entrance delay period. If any instant detectors are triggered during
the entrance delay period, e.g. a child running straight to the living
room, only an internal warning will be triggered and an external
warning will only follow if the entrance delay has been exceeded.
PGX, PGY – are a pair of terminals providing programmable
outputs. If an output is activated it switches to GND with a
maximum load of 0.1A/12V. The factory-default setting of PGX is
the function ON/OFF which can be operated from the keypad by
Installation manual: Oasis security system JA-80K - 5 -
The control panel can be operated and programmed by JA80F wireless keypads and/or a JA-80E hard-wired keypad. A
hard-wired keypad can be connected to the control panel either
by flat telephone cable (max. length 10 metres) using RJ
connectors, or via twisted-pair cable (max. length 100 metres)
connected to the digital bus terminals (GND, A, B, +U).
We recommend only having a single JA-80E hard-wired
keypad in the system.
6. Back-up battery
It is possible to use a Jablotron-brand 12V back-up battery in
the control panel with capacities of 1.3Ah or 2.6no Ah. The
capacity to use depends on the total power consumption of the
system and the desired back-up period.
Euro-standard EN 50131-1 specifies a 12 hour minimum backup time for grade 2 systems. The standby consumption of all
system devices is shown in table 1.
Table 1- standby consumption of system devices
Device mA Note
Control panel JA-80K 50 No communicator
Keypad JA-80E 30
Keypad JA-80H (N) 60 Including a WJ-80 interface
Communicator JA-80Y 35
Communicator JA-80V 30
Wireless devices are not powered from the control panel.
•
With a
1.3Ah
current consumption does not exceed
150mA
80% of the battery capacity into account as 20% has to be reserved for
battery aging effects.
•
The average
be replaced. The back-up battery is automatically charged and its
condition is monitored by the system. If the system is being run on only
the back-up battery a technical alarm occurs when the battery is
nearly discharged. If the voltage gets too low the battery will be
back-up battery 12 hours of back-up time can be realised if
should not be exceeded to achieve the same. This only takes
back-up battery lifetime is up to 5 years
85mA
. With
2.2Ah
after which it must
MKE55800
batteries
disconnected. After the mains supply has been restored battery
charging starts again and the system will begin to function again.
Ensure that the battery is correctly connected (Polarity: RED =
positive +, BLACK = negative -).
WARNING – the battery is sold charged – to maintain safety, avoid shorting
out the terminals !!!
7. Powering-up the control panel for the first
time
• First check all the wiring, and if a GSM communicator is
installed, insert its SIM card (PIN code disabled).
• Carefully connect the back-up battery,
• Carefully connect up the mains. A green LED will start
flashing on the control panel board.
• If a hard-wired keyboard is connected it will indicate Service
mode. If not, the control panel is not set to the factory default
and should be reset (see section 9.).
7.1. Wireless keypad enrollment
If no hard-wired keypad is connected to the control panel, and
the wireless keypad was not supplied as part of a JK kit, the
wireless keypad must be enrolled to the control panel as follows:
1. Have an opened keypad and its battery ready.
2. Check that the green LED in the control panel is flashing.
3. Short the reset link in the control panel for 1 second (e.g.
using a screwdriver). This will enter enrollment mode on
the control panel.
4. Install batteries into the keypad not far from the control
panel.
5. The keypad generates a beep sound and enrolls to
address. After that it indicates “Enrollment 04: Device”.
6. Press the # key to exit enrollment mode and “Service”
will be indicated on the keypad.
Warning:
• If the keypad does not enroll, then the control panel settings
are not the factory-defaults. In this case perform a reset and
repeat the enrollment procedure.
• If you want to assign the keypad to another address, re-
enter enrollment mode via the “1” key, then use the arrow
keys to select the desired address. Then disconnect the
keypad battery and reconnect it.
Recommendation: it is highly recommended to install the
wireless keypad with a magnetic door sensor wired to its hardwired input terminal. This way the keypad will wake up every
time after opening the door and it will produce entrance delay
beeps and will be ready to read access cards. It will also save
money on a wireless door detector.
8. Language selection of the keypad
If the ∗ key is kept pressed during battery connection, the internal
keypad menu will be displayed allowing the selection of the
language
selection by the ∗ key.
. Using the arrows, choose your language and confirm
In this menu the door bell function can also be enabled or
disabled (if enabled the keypad makes a sound when its IN input
is triggered).
Notes:
• for the JA-80E wired keypad the power can be connected
by connecting its cable or by turning on the control panel
power
• if the wireless keypad has already had its battery
connected, it is necessary to disconnect the battery for a
while before pressing and holding the ∗ key
• the language can be selected for each individual keypad in
the system (i.e. different keypads can display different
languages – for example if foreigners are working in the
company)
Installation manual: Oasis security system JA-80K - 6 -
desired
9. Resetting the control panel
If you need to return the control panel to the factory-default
settings perform the following:
1. Disconnect the back-up battery and the mains (for
example by removing the fuse from its terminals).
2. Connect the RESET link and leave it connected.
3. Connect the back-up battery and the mains
4. Wait till the green LED starts flashing and then
disconnect the RESET link
Warning:
• After a RESET, all wireless devices are erased from the
control panel and all user codes and access cards are
“forgotten”.
• After a RESET, the Master code returns to 1234, and the
service code to 8080.
• If resetting is disabled (see 12.9) it is impossible to reset the
control panel.
10. Closing the control panel cover
After the keypad has started working it is possible to close the
control panel cover. Before this is done, check that the control
panel has an antenna connected.
11. Enrolling wireless devices
The control panel has 50 addresses (01 to 50), allowing the
enrollment of up to 50 wireless devices i.e. detectors, keypads,
keyfobs, sirens, etc. A wireless device can be assigned to an
address by enrollment or by entering its production code (see
12.42).
11.1. Installing wireless devices
Wireless devices can either be installed at their desired
locations first and then enrolled to the control panel or vice
versa. If there any doubts as to the suitability of device locations
for radio communication, temporarily attach the devices (e.g.
using adhesive tape) and test radio communication before
finalizing installation. Follow the manuals of the particular
devices during their installation.
11.2. Enrolling wireless devices to the control panel
1. The control panel should be in Service mode. If it is not,
then enter ∗0 service code (factory default: 8080). The
control panel must be unset (disarmed).
2. Press the “1” key, enrollment mode will be entered and the
first vacant address will be offered. For a new control panel
it will be 03.
3. Using the arrows keys and , you may select the
desired address. If the address is already occupied this is
indicated by the A indicator being lit.
4. The device will enroll to the selected address just after its
battery (power) is connected .
5. Enrollment is confirmed by the A indicator and the next
vacant address is then offered.
6. By connecting batteries to all devices one after the other
they will all be enrolled to the control panel. Press the # key
to exit enrollment mode.
teké
Notes:
• If a wireless device is enrolled to address 01 or 02 this will
disable the corresponding hard-wired input terminal (if a
wireless device is erased from address 01 or 02, the hard-
wired terminal will be re-enabled).
• Keyfobs type RC-8x can be enrolled by pressing and holding
a pair of buttons simultaneously, i.e.:
(enrollment by battery installation will enroll buttons + ).
This means that a 4-button keyfob can be enrolled to the
+ or +
MKE55800
.
control panel twice but to two different addresses with different
features –see 12.40.
• Only a single device can be enrolled to each address.
• When indicator A lights, it means the displayed address is
occupied and therefore no more devices can be enrolled to
this address.
• If a device has already been enrolled to an address, and it is
then re-enrolled to another address, the device’s address
assignment will change from the original address to the new
one.
• If a device cannot be enrolled to the control panel, either it
does not have a good wireless connection to the control panel
possibly due to excessive distance or it could be too close to
the control panel (closer than 2 meters is not permitted),
• To re-enroll a device, first disconnect its battery. Then wait
about 10 seconds or, to save time, press and release its
tamper switch to quickly discharge any remaining energy.
• A sub-control panel can be enrolled to a master control
panel by keying in the sequence 299 on the keypad of the sub
control panel which must be in Service mode. (see 12.10),
• If you intend to use final-door detectors in the system, they
must be enrolled to addresses 01 to 05 or 46 to 50 (see
12.23).
11.3. Testing enrolled devices
1. The control panel must have its antenna connected and be
in Service mode. If not in Service mode, then key in ∗0
service code (factory-default 8080). To enter Service mode
the control panel must be initially unset (disarmed).
2. Trigger the device to be tested (if it is a detector close its
cover first and then wait until it is ready for testing).
3. The keypad will beep and display a description of the signal
received from the device under test (the keypad cover
should be flipped open). We recommend technicians to
carry the wireless keypad around while testing to ease the
process.
Notes:
• Motion detectors JA-80P and JA-85P can be tested for a
maximum of 15 minutes after closing their covers. After this
period the detector will ignore frequent movements (see
detector manuals for details).
• Devices can also be tested in maintenance mode – see 13.4.
11.4. Measuring signal strength
1. The control panel must have its antenna connected and be
in Service Mode. If it is not, then enter ∗0 service code
(factory default: 8080). The control panel must be unset
(disarmed) to enter Service Mode.
2. Key in 298, and the lowest enrolled address will be
displayed.
3. Trigger the device enrolled to the displayed address. The
keypad display will show the received signal strength on a
scale of 1/4 to 4/4. Keep the keypad cover flipped open
while measuring signals.
4. Other addresses for devices can be selected using the
arrow keys to measure their signals too.
5. Exit signal measuring by pressing the # key.
Notes:
• Motion detectors JA-80P and JA-85P can be tested for a
maximum of 15 minutes after closing their covers. After this
period the detector will ignore frequent movements (see
detector manuals for details).
• Measuring the signals from a JA-80L internal siren can be
activated by pressing its button. A JA-80A outdoor siren can
be activated for signal strength measurement by opening its
cover thereby triggering its cover tamper switch.
• Each installed device should have a minimum signal strength
of 2/4. If the signal is too weak, the device should be relocated
or a higher control panel sensitivity can be selected. (see
12.36) Alternatively the control panel can be equipped with an
external antenna (see 10).
• This measurement shows the quality of the signal received
from the device at the control panel.
• The wireless keypad can be carried during installation or
testing by disabling its tamper contact via the jumper near the
tamper contact – do not forget to re-enable the tamper before
finishing the installation – Note: the keypad usually has a
slightly shorter working range than the detectors. Therefore, if
carried to more-distant detectors the triggering of the
detectors might not be shown.
• The most convenient way of measurement is via a computer
running ComLink SW.
11.5. Erasing enrolled devices
1. The control panel must be in Service Mode. If it is not, then
enter ∗0 service code (factory default: 8080). The control
panel must be unset (disarmed) to enter Service Mode.
2. Key in “1” to enter enrollment mode and using the arrow
keys select the desired address of the device you wish to
erase.
3. Press and hold the “2” key until a beep is heard and the A
indicator turns off.
4. After all the desired devices have been erased, press #.
Notes:
• To erase all wireless devices, press and hold the “4” key in
enrollment mode.
• If a wireless keypad is erased, it will stop communicating with
the control panel and must be re-enrolled before being used
again. (see 7.1).
11.6. Enrolling the control panel to UC and AC
modules
If you wish to use UC and AC modules to output PGX and PGY
signals, you must enroll the control panel to these modules as
follows:
1. The control panel must be in Service Mode. If it is not, then
enter ∗0 service code (factory default: 8080).
2. On the UC or AC module, enter the desired enrollment
mode (see the manual of the particular module)
3. Key in 299 on the control panel keypad and check that all
LEDs on the module flash a few times to confirm successful
enrollment.
Notes:
• Because the UC and AC modules have rather short
enrollment-period timeouts, we recommend locating the
module close to the control panel during enrollment.
Alternatively you could carry the wireless keypad close to the
module to perform enrollment.
• The control panel can be enrolled to the desired number of
UC/AC modules to control multiple PG outputs in an
installation.
• Each UC and AC module has 2 relays, X and Y which have to
go through enrollment separately. The X relay reacts to PGX
signals from an enrolled control panel and the Y relay reacts
to PGY signals from an enrolled control panel. The control
panel’s PGX signal can be enrolled to the X relay and the
control panel’s PGY signal can be enrolled to the Y relay.
Therefore, the enrollment procedure has to be done twice if
both relays are to be controlled by the control panel’s PG
signals.
• Only one control panel can be enrolled to a UC or AC receiver
because a control panel repeats its PG signals every 9
Installation manual: Oasis security system JA-80K - 7 -
MKE55800
Loading...
