MODULATOR BIAS CONTROLLER
MBC-IQ-LAB
USER MANUAL
Version 1.0
iXblue S.A.S.
Photonic Solutions Business Unit
3, rue Sophie Germain, TEMIS
25000 Besançon, France
T. : +33 3 81 85 31 80
F. : +33 3 81 85 15 57
www.photonics.ixblue.com
2
Legal Notice ................................................................................................................ 3
Disclaimers ............................................................................................................. 3
About this Manual ....................................................................................................... 3
Purpose ................................................................................................................... 3
Audience ................................................................................................................. 3
Prerequisites ........................................................................................................... 3
Terms and Symbols in this Manual ......................................................................... 3
Electrical Safety ...................................................................................................... 4
Ventilation of the Board ........................................................................................... 4
Contacting Ixblue PSD: ........................................................................................... 4
General Information .................................................................................................... 5
Mach-Zehnder intensity modulators ........................................................................ 5
Product Overview .................................................................................................... 7
Principle .................................................................................................................. 7
Mechanical Dimensions .......................................................................................... 8
DC bias Cable ......................................................................................................... 9
Getting started ............................................................................................................ 9
Standard Accessories ............................................................................................. 9
Installation and first time operation ......................................................................... 9
Operation ...................................................................................................................10
Selecting Auto/Manual mode ................................................................................ 11
Adjusting dithering amplitude ................................................................................ 11
Adjusting the photocurrent gain circuit .................................................................. 11
iXblue S.A.S.
Photonic Solutions Business Unit
3, rue Sophie Germain, TEMIS
25000 Besançon, France
T. : +33 3 81 85 31 80
F. : +33 3 81 85 15 57
www.photonics.ixblue.com
3
Legal Notice
Disclaimers
No warranty: This documentation is provided « as is » without any express or implied
warranty of any kind.
Limitation of Liability: iXblue does not assume any liability arising out of the
application or use of any products, or software described herein. In no event shall Photline
be liable for any damage whatsoever (including, without limitation, consequential or
incidental damages, damages for lot of profits, or otherwise) arising out of the use of the
information provided in this documentation.
The contents of this publication have been carefully checked for accuracy. However,
iXblue makes no warranty as to the completeness, correctness, or accuracy of the
information contained within this documentation. In the interest of continued product
improvement, Photline further reserves the right to make any change in any products
describers herein without notice. This publication is subject to change without notice.
About this Manual
Purpose
The purpose of this instruction manual is to explain how to set up the MBC-DG-
BOARD and to utilize the various features of the product.
Audience
This manual is designed to professionals with the necessary technical background
and prerequisites needed to use fiber optics components, including Mach-Zehnder lithium
niobate modulators, and the related test equipments and accessories.
Prerequisites
Reader is assumed to be familiar with fiber optics technology.
Terms and Symbols in this Manual
The following terms and symbols may appear throughout this manual :
WARNING : Warning statement identify conditions or practices that could result in injury or
loss of life
CAUTION : Caution statement identify conditions or practices that could result in damage to
this product or other property
iXblue S.A.S.
Photonic Solutions Business Unit
3, rue Sophie Germain, TEMIS
25000 Besançon, France
T. : +33 3 81 85 31 80
F. : +33 3 81 85 15 57
www.photonics.ixblue.com
4
Electrical Safety
WARNING
Do not attempt to perform any servicing or maintenance
To avoid personal injury, do not operate this instrument without
the protective cover of the chassis. Do not make any service or
maintenance of any kind to the system.
Refer servicing only to authorized personnel from iXblue.
WARNING
Operate under the proper environmental conditions.
The board is designed for indoor use, only. To avoid the
possibility of injury, do not expose this instrument to rain or
excessive moisture. Do not operate the instrument in the
presence of flammable gases or fumes.
Ventilation of the Board
WARNING
Do not cover the board with any covering or overlay.
Contacting iXblue PSD:
For application oriented questions, for questions related to service, please contact iXblue
PSD Besançon
iXblue S.A.S.
Photonic Solutions Business Unit
3, rue Sophie Germain, TEMIS
25000 Besançon, France
T. : +33 3 81 85 31 80
F. : +33 3 81 85 15 57
www.photonics.ixblue.com
5
General Information
Mach-Zehnder intensity modulators
Lithium niobate (LiNbO3) Mach-Zehnder intensity modulators are external modulators
that have been widely used since the mid-nineties, mostly in long haul optical networks for
their ability to modulate optical signal from 1300 nm and 1550 nm laser diodes with short
transition times and without chirp. Thanks to their broad wavelength performance, they
currently also offer modulation solutions to 1064 nm and other near infrared lasers.
Mach-Zehnder modulators are two-wave interferometric devices and exhibit a sine
transfer function (Figure 1). Although highly stable components, their operating point can
suffer slow drift due to variations of external conditions and that drift may result in variations
of key performances like extinction ratio.
In order to adjust the operating point of Mach-Zehnder modulators independently from
the high frequency modulation signal applied, they can be designed with two sets of
electrodes: one set of electrodes, the RF Electrodes, is used to apply the RF signal (PRBS
data stream, analog signal, short pulses…). The second set of electrodes, the DC Bias
Electrodes, is generally used to adjust with a controlled DC voltage the working point of the
modulator. Figure 2 illustrate the typical electrode architecture of an IQ modulator with its
internal structure. We will now give more details on the IQ modulator.
IQ modulator
An IQ modulator is basically a dual parallel Mach-Zehnder (DPMZ) modulator composed of
four waveguides. The two first waveguides are linked together with input and output Yjunctions forming a first sub-Mach-Zehnder modulator (MZ1). The two last waveguides are
linked together with Y-junctions as well, forming a second sub-Mach-Zehnder modulator
(MZ2). Each output port of the Y-junctions is linked with a larger Y-junction. In conclusion, the
IQ modulator structure is a Mach-Zehnder modulator with one sub-Mach-Zehnder modulator
nested on each of his arms.
Electrodes are placed parallel to the waveguide arms. Two sets of high speed electrodes
allow high speed modulation of the optical signal (one set per signal quadrature). Two sets of
DC electrodes allow setting the nested modulator’s polarization. A last set of DC electrodes
allows adjusting the phase delay between the I & Q signals. In (D) QPSK / SSB / OFDM /
QAM modulation formats, each DC voltage (DC1 and DC2) of the sub-MZ's is adjusted in
order to introduce a phase shift equal to π, while the voltage applied to the phase difference
between the two sub-MZ's is adjusted to introduce a phase shift of π/2.
iXblue S.A.S.
Photonic Solutions Business Unit
3, rue Sophie Germain, TEMIS
25000 Besançon, France
T. : +33 3 81 85 31 80
F. : +33 3 81 85 15 57
www.photonics.ixblue.com
6
Figure 1 : transfer function of a Mach-Zehnder modulator and data output vs data input at
QUAD+ and QUAD- operating point
Figure 2: Simplified scheme of an IQ modulator with 2 separate sets of electrodes (DC and RF
electrodes) for each signal quadrature (I & Q signals)
iXblue S.A.S.
Photonic Solutions Business Unit
3, rue Sophie Germain, TEMIS
25000 Besançon, France
T. : +33 3 81 85 31 80
F. : +33 3 81 85 15 57
www.photonics.ixblue.com
7
Product Overview
The MBC-IQ-Board is dedicated to operate with lithium niobate dual parallel Mach-Zehnder
Modulators. The equipment is an automatic bias voltage controller designed to stabilize the
operating point of the two sub-MZM of a dual parallel MZM. It continuously adjusts the subMZM DC electrode bias voltage (DC1 and DC2 in figure 2 above) based on real time
monitoring of the sub-MZM polarization set points through digital signal processing.
The MBC-IQ-Board algorithm sets the sub-MZM at MIN point and the main MZM at QUAD+
or QUAD- point.
Principle
The principle is here shown for a single MZM:
Figure 3: basic scheme of a modulation set-up including a modulator bias controller and an
external monitoring photodiode
A Mach-Zehnder modulator is illuminated by a laser at the optical input. The data
stream is applied to the RF electrodes. At the output of the MZ modulator, a fiber coupler
with a strong imbalance (10:90 or 1:99) allows to detect a small portion of the transmitted
light with a monitoring photodiode. The signal is amplified and processed in order to control
the stability of the operating point. Any deviation is compensated by a corrected value of the
electrical bias voltage applied by the feedback loop in order to maintain the operating point at
the desired position.
The principle of operation of the MBC is based on the generation of a very low
frequency and low amplitude electrical signal (dither signal), which is summed to the DC bias
voltage. Any deviation from the working point creates harmonics that can be measured and
compared by frequency analysis and by signal processing carried out by a specific algorithm,
developed by iXblue, in order to retrieve the sign and the amplitude of the deviation.
When using an IQ modulator, DC1 and DC2 are polarized in MIN. And DC3 is
polarized in QUAD+ or QUAD-.
iXblue S.A.S.
Photonic Solutions Business Unit
3, rue Sophie Germain, TEMIS
25000 Besançon, France
T. : +33 3 81 85 31 80
F. : +33 3 81 85 15 57
www.photonics.ixblue.com
8
Mechanical Dimensions
221mm x 221mm x 44mm
MBC LAB:
<1> Power button
<2> Control LED
Lock: MBC is locked to the fixed point (still active when laser light is off)
Scan: MBC is performing a scan. If flashing, no signal detected.
<3> Bias Modulator connector (BNC)
1 DC1+
6 DC1-
2 GND
7 GND
3 DC2+
8 DC2-
4 GND
9 DC3-
5 DC3+
<4> Input Optical Connector
<5> Output optical connector (coupler option)
<6> Power supply connector (Jack 3.5mm, 12V 500mA)
<7> USB connector
iXblue S.A.S.
Photonic Solutions Business Unit
3, rue Sophie Germain, TEMIS
25000 Besançon, France
T. : +33 3 81 85 31 80
F. : +33 3 81 85 15 57
www.photonics.ixblue.com
9
DC bias Cable
The cable is built to be used on iXblue modulator. It has the following pinning:
N°
Color
Function
1
White
DC1+
2
Black
GND
3
Red
DC2+
4
Green
DC3+
Getting started
Standard Accessories
User Manual
Interface User Manual
Cord Kit
USB Cord
Installation and first time operation
Proceed as follow to install the MBC-IQ-LAB:
Set MBC LAB on a flat stable surface
Connect the power supply plug-in to the power supply connector <6>
Connect the modulator optical output through a tap coupler for "no coupler option",
directly for "coupler option" to "In"-connector of the MBC-IQ-LAB(<4>).See optical
connection schemes bellow.
Connect the DC cable to "DC-Bias" (<3>) and wires to the bias electrode of the
modulator. Black (Ground), White (DC1+), Red (DC2+) and Green (DC3+).
Switch on the laser to illuminate the modulator at the desired optical power level
Power ON the MBC-IQ-LAB <1>
A procedure of initialization by scanning the Vbias range from –13.5V to +13.5V will
start to adjust automatically the operating point by use of the initial conditions
After stabilization, the RF signal can be applied and the parameters of the MBC can
be modified.
Any change of the dither frequency results in a new search of the operating point by
scanning of the bias voltage from –13.5V to +13.5V.
iXblue S.A.S.
Photonic Solutions Business Unit
3, rue Sophie Germain, TEMIS
25000 Besançon, France
T. : +33 3 81 85 31 80
F. : +33 3 81 85 15 57
www.photonics.ixblue.com
10
Setup with an external coupler (no
coupler option):
Setup with an internal coupler (coupler
option):
The optical signal processing in the MBC is such that the value of the RF amplitude voltage
is limited. The limit is 0.75V and the MBC will not work correctly if the RF signal with larger
amplitude is applied to the modulator.
A 0.75V amplitude is equivalent to a 1.5V peak-to-peak value and the majority of the
applications operate with a lower RF signal: typically 0.5V amplitude (or 2V peak-to-peak).
Thus, in spite of that restriction, the MBC will operate correctly with most of the application.
Modulator bias stability in industrial environment
Due to its detection sensitivity and the low level of signal applied to the modulator.
The MBC IQ LAB may encounter issues in industrial environment (electrical field
strength from 10V/m and beyond). It can be observed in manual mode, if one can
detect fast contrast variations of a few dB, it may be a sign of electromagnetic
perturbation. To mitigate this effect, one needs to remove the plastic sheet of the
furnished cable near the cable end (2), and connect it to a metal plate with a flange.
The modulator package need also to be fixed (1) on the same metal plate. The
shorter the shielding connection is, the better will be the result.
Operation
For more information on the way to set parameters, please refer to the GUI interface
handbook.
iXblue S.A.S.
Photonic Solutions Business Unit
3, rue Sophie Germain, TEMIS
25000 Besançon, France
T. : +33 3 81 85 31 80
F. : +33 3 81 85 15 57
www.photonics.ixblue.com
11
Selecting Auto/Manual mode
One can choose between two operation modes: AUTO or MANUAL.
In AUTO mode, the board searches the bias value corresponding to the selected transfer
level.
In MANUAL mode, one sets the DC bias value, and no dither is applied to DC Bias.
Adjusting dithering amplitude
The MBC allows the user to adjust the dithering amplitude between 10 mV and 1 V. This
feature proves especially useful to optimize the overall performance of the MBC and to adapt
to various conditions such as modulator Vpi or photodiode response. MBC IQ LAB dither
amplitude is set at 100mVpp (2% of modulator Vpi). Increasing dither, in general by 20 to
50mVpp may help for feedback loop stabilization at low optical power (-20dBm on
photodiode for example).
After modifying this parameter, one must do a scan restart.
Adjusting the photocurrent gain circuit
The MBC IQ offers 127 different gain values for the photocurrent circuit so as to adapt to the
largest variety of applications and to offer the widest dynamic range for the input
photocurrent. In certain conditions, high gain may create loop oscillations.
After modifying this parameter, one must do a scan restart.
Loading...
