BENCH
Thank you for purchasing the BENCH!
Before you st
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the bench, we recommend that it is assembled by two adults, on a
carpeted or padded area, in the room that it is intended for. Approximate assembly time: 15 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or instructions until you have checked all the components and
hardware and the furniture is fully assembled.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all pieces out of reach of small children.
art, here is some helpful advice:
Component:
Hardware:
A
B
C
D
1
Bolt x8
Spring Washer x8
Flat Washer x8
Allen Wrench x1
3
Bench Body x1
1
Bench Leg #3 x2
3
2
3
2
Bench Leg #2 x2
2
Page 1 of 2
BENCH
STEP 1:
Please put the Bench Body (1) upside down on a carpeted or padded area by two adults to make fully visible the corners.
Find the 4pcs Bench Legs (2&3) and hardware package placed inside one bag on the bottom of the Bench Body (1).
Position one of Bench Legs #3 (3) at one of number 3 (labeled) of the four wooden corners.
Insert 2 pieces of each Spring Washer (B), Flat Washer (C) into 2 pieces of Bolt (A) as shown.
Then insert assembled 2 pieces of Bolts (A) into the corner to connect the Bench Leg(2).
Use Allen Wrench (D) to tighten all of Bolts (A).
Repeat the same steps for the remaining three Bench legs (2&3).
2
3
3
2
1
3
1
C
A
B
D
Ax8 Bx8
STEP 2:
Carefully turn over the bench.
Cx8
Dx1
Hardware & Tool required
Assembly is completed. The bench is ready to enjoy now!
Page 2 of 2
